Frame & Bumpers: Removal & Installation Dodge Avenger II

Frames, Subframes & Crossmembers 39 illustrations ~2291 words

INSTALLATION

  1. Install closeout panel (1) onto fascia (3) push pins (2) and screws (4).
  2. Install fasteners (5).

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Remove air inlet push pin (4) and air-box fastener (2).
  2. Remove grille push pins (2) and fascia fasteners (1) from grille.
  3. Lift vehicle and on both the left and right remove two splash shield fasteners (1) and eight push pins.
  4. Remove splash shields from vehicle.
  5. Remove closeout panel. See «REMOVAL»(ref-305765-S42292768982008120200000) .
  6. Slide fascia forward disengaging from push pins.
  7. If equipped, disconnect fog lamp connectors.
  8. Disconnect the side marker lamp electrical connectors.
  9. Remove fascia from vehicle.
  1. Raise vehicle.
  2. Raise fascia up to vehicle and connect fog lamp connectors if equipped.
  3. Connect the side marker lamp electrical connectors.
  4. Slide fascia into push pins ensuring proper seat.
  5. Install closeout panel fasteners and push pins. See «INSTALLATION»(ref-305765-S03562489872008120200000) .
  6. Install right and left splash shield fasteners and push pins.
  7. Lower vehicle.
  8. Place grille onto fascia.
  9. Install grille push pins (2) and fascia fasteners (1). Refer to «INSTALLATION»(ref-305774-S02171654772008120200000) .
  10. Install air box inlet push pin (4) and fastener (2).

Scheme 7

Scheme 7: AVENGER
Scheme 7: AVENGER

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Open decklid.
  2. Remove upper fascia push pins (1).
  3. Raise vehicle.
  4. Remove lower fascia push pins (1).
  5. Remove left and right splash shield push pins and fasteners.
  6. Remove fascia fastener (2).
  7. Slide fascia rearward from push pins (1).
  8. Disconnect wire connector (1) and (2).

Scheme 11

Scheme 11: SEBRING SEDAN
Scheme 11: SEBRING SEDAN

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Release decklid latch and open decklid.
  2. Remove three push-in fasteners (1) attaching center of fascia to rear closure panel.
  3. Remove two wheelhouse fasteners and pull back splash shields exposing fascia to fender hidden fastener (1).
  4. Remove lower fascia fasteners (2).
  5. Slide fascia rearward to disengage hooks holding fascia to bottom of quarter panel.
  6. Remove fascia from vehicle.
  1. Place bumper reinforcement up to vehicle and install fasteners. Tighten to 27 N.m (239 inch lbs.).
  2. Install coolant line push pins to bumper.
  3. Install ambient temperature sensor. Refer to «INSTALLATION»(ref-305799-S33890114542008120200000) .
  4. Install horns and connect electrical connectors. Refer to «INSTALLATION»(ref-305797-S30092610972008120200000) .
  5. Install hood latch fasteners (1).
  6. Install braces and fasteners (2).
  7. Install fascia. See «INSTALLATION»(ref-305765-S04967263522008120200000) .

Scheme 14

Scheme 14: REMOVAL
Scheme 14: REMOVAL
  1. Remove rear fascia. See «REMOVAL»(ref-305765-S25491934272008120200000) .
  2. Support bumper reinforcement (2) on a suitable lifting device.
  3. Mark position of nuts (1) on frame rail to aid in installation.
  4. Remove license plate connector push pin from rear bumper reinforcement.
  5. Remove nuts (1) attaching rear bumper reinforcement (2) to frame rail.
  6. Remove bumper reinforcement (2) from vehicle.
  1. Position rear bumper reinforcement (2) on vehicle.
  2. Install nuts (1) attaching bumper reinforcement to frame rail. Use marks made previously to properly position bumper reinforcement.
  3. Tighten nuts (1) to 28 N.m (250 in. lbs.).
  4. Install license plate connector push pin on bumper.
  5. Install rear fascia. See «INSTALLATION»(ref-305765-S14258120242008120200000) .
  1. Position the front crossbrace/reinforcement bracket (2) over the crossmember rear mounting bushings and body, then install the mounting screws (1). Do not tighten screws at this time.
  2. Install the two rear mounting bolts (2) securing the front crossmember (1) to the body. Tighten the crossmember mounting bolts to 135 N.m (100 ft. lbs.).
  3. Tighten the crossbrace/reinforcement bracket mounting screws (1) to 50 N.m (37 ft. lbs.).
  4. Lower the vehicle.

Scheme 15

Scheme 15: REMOVAL
Scheme 15: REMOVAL
  1. Raise and support the vehicle. Refer to «STANDARD PROCEDURE»(ref-305753-S01950477782008120200000) .
  2. Remove the mounting screws (1) securing the rear crossbrace/reinforcement brackets (2).
  3. Remove the brackets.
  1. Position the rear crossbrace/reinforcement brackets (1) through the rear crossmember.
  2. Install the mounting screws (2) and tighten to 50 N.m (37 ft. lbs.).
  3. Lower the vehicle.

Scheme 16

Scheme 16: REMOVAL
Scheme 16: REMOVAL

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Raise and support the vehicle. Refer to «STANDARD PROCEDURE»(ref-305753-S01950477782008120200000) .
  2. If equipped, remove the two front crossmember bolts (1).
  3. Remove the four crossmember bolts (1) in the rear of the fore/aft crossmember.
  4. Remove the engine roll mount (2) through bolt (1) and remove the fore/aft crossmember.
  1. Install the fore/aft crossmember and install the engine anti-roll mount (3) through bolt (1). Tighten to 50 N.m (37 ft. lbs.).
  2. Install front bolts (1) and tighten to 55 N.m (40.5 ft. lbs.).
  3. Install the rear bolts (1) and tighten to 55 N.m (41 ft. lbs.).
  4. If equipped, install the belly pan.

Scheme 19

Scheme 19: REMOVAL
Scheme 19: REMOVAL

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Raise and support the vehicle. Refer to «STANDARD PROCEDURE»(ref-305753-S01950477782008120200000) .
  2. On each side of the vehicle, remove the wheel mounting nuts (3), then the front tire and wheel assembly (1).
  3. On each side of the vehicle, remove the nut (1) attaching the lower ball joint to the lower control arm (2).
  4. On each side of the vehicle, release the lower ball joint (3) from the lower control arm (1) using Remover (2), Special Tool 9360. Do not lift the knuckle out of the lower control arm at this time.
  5. If equipped, remove the engine belly pan.
  6. Remove the fore/aft crossmember. See «REMOVAL»(ref-305765-S37779719632008120200000) .
  7. Remove the rear engine mount. Refer to «REMOVAL»(ref-305761-S33201936982008120200000) for 2.4L. Refer to «REMOVAL»(ref-305762-S01626837682008120200000) for 2.7L. Refer to «REMOVAL»(ref-305763-S26764996532008120200000) for 3.5L.
  8. Remove the screws (1) securing the power steering hose routing clamps (2) to the rear of the crossmember.
  9. Remove the screws and push-pins securing the heat shield (1) over the right side of the steering gear (2).
  10. Remove the two bolts (1) securing the steering gear (2) to the crossmember.
  11. Support the steering gear using a bungee cord or other to keep the steering gear from lowering when the crossmember is lowered.
  12. Remove the screws (1) securing the stabilizer bushing retainers (3) to the crossmember. NOTE: Before lowering the front suspension crossmember, the location of the crossmember must be marked on the body of the vehicle. Do this so the crossmember can be relocated, upon reinstallation, against the body of vehicle in the same location as before removal. If the front suspension crossmember is not reinstalled in exactly the same location as before removal, the preset front wheel alignment settings (caster and camber) may be lost.
  13. Using a crayon or marker (2) that will not break the paint surface, mark the location of the front crossmember (1) on the body near each mounting bolt. Do not use any type of sharp instrument that will damage the underbody of the vehicle.
  14. Support the crossmember (9) with a transmission jack. Secure the crossmember to the jack.
  15. Remove the four mounting bolts (6) securing the front crossmember (9) to the body.
  16. Remove the mounting screws (8) securing the front crossmember reinforcement brackets (7) (one each side of vehicle) to the body (1). Remove the brackets.
  17. Slowly lower the crossmember and control arms to a comfortable working height using the jack.
  18. To remove each lower control arm: Remove the front bolt (1) attaching the lower control arm (3) to the front suspension crossmember. Remove the nut on the rear bolt (2) attaching the lower control arm (3) to the front suspension crossmember. Remove the bolt. Remove the lower control arm (3) from the crossmember.
  1. Support the crossmember with a transmission jack. Secure the crossmember to the jack.
  2. To install each lower control arm on the crossmember: Place the lower control arm (3) into the front suspension crossmember. Insert the rear bolt (2) up through the crossmember and lower control arm (3). Install the nut on the top-end of the bolt, but do not tighten it at this time. Install, but do not fully tighten, the front bolt (1) attaching the lower control arm (3) to the crossmember. With no weight or obstruction on the lower control arm, tighten the lower control arm front mounting bolt (2) to 145 N.m (107 ft. lbs.). With no weight or obstruction on the lower control arm, tighten the lower control arm rear mounting bolt nut to 145 N.m (107 ft. lbs.).
  3. Slowly raise the crossmember (9) into mounted position using the transmission jack matching the crossmember to the marked locations on the body made during removal. As the crossmember is raised, guide the lower ball joints into the mounting holes in the lower control arms. Also, make sure the stabilizer bar is properly positioned on the crossmember.
  4. Position the front crossmember reinforcement brackets (7) (one each side of vehicle) over the crossmember rear mounting bushings and install the mounting screws (8), but do not tighten at this time.
  5. Install the four mounting bolts (6) securing the front crossmember (1) to the body. Tighten the crossmember mounting bolts to 135 N.m (100 ft. lbs.).
  6. Tighten the crossmember reinforcement bracket mounting screws (8) to 50 N.m (37 ft. lbs.).
  7. Remove the transmission jack.
  8. Position both stabilizer bar bushing retainers and install the screws (1) securing the stabilizer bushing retainers (3) to the crossmember. Tighten all four stabilizer bar cushion retainer screws to 60 N.m (44 ft. lbs.).
  9. Remove the bungee cord or other supporting the steering gear (2).
  10. Install the two bolts (1) securing the steering gear (2) to the crossmember. Tighten the steering gear mounting bolts to 100 N.m (74 ft. lbs.).
  11. Position the heat shield (1) over the steering gear (2). Install the mounting screws and push-pins. Tighten the screws to 6 N.m (53 in. lbs.).
  12. Position the power steering hose routing clamps (2) on the crossmember. Install and tighten the screws to 8 N.m (71 in. lbs.).
  13. Install the rear engine mount. Refer to «INSTALLATION»(ref-305761-S03273611882008120200000) for 2.4L. Refer to «INSTALLATION»(ref-305762-S21188741172008120200000) for 2.7L. Refer to «INSTALLATION»(ref-305763-S40741523352008120200000) for 3.5L.
  14. Install the fore/aft crossmember. See «INSTALLATION»(ref-305765-S13787528542008120200000) .
  15. If equipped, install the engine belly pan. NOTE: If a new or cleaned lower control arm is being installed, it is important to have a film of general purpose grease around the ball joint mounting hole on the lower control arm to avoid any future corrosion issues. Make sure the grease does not get inside the ball joint mounting hole or on the ball joint stud during installation.
  16. On each side of the vehicle, install a NEW ball joint stud nut (1). Tighten the nut to 95 N.m (70 ft. lbs.).
  17. On each side of the vehicle, install the tire and wheel assembly (1). Refer to «INSTALLATION»(ref-305760-S08390685702008120200000) . Install and tighten the wheel mounting nuts (3) to 135 N.m (100 ft. lbs.).
  18. Lower the vehicle.
  19. Perform wheel alignment as necessary. Refer to «STANDARD PROCEDURE»(ref-305758-S10766304732008120200000) .

Scheme 29

Scheme 29: REMOVAL
Scheme 29: REMOVAL

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Remove spare tire from the vehicle.
  2. Remove the upper suspension bracket nuts.
  3. Raise vehicle on jack stands or centered on a frame contact type hoist.
  4. Remove rear wheels/tires.
  5. If equipped, remove the rear drive module from the vehicle. Refer to «REMOVAL»(ref-305764-S04583195012008120200000) .
  6. Make a reference mark on the toe link cam (3), remove the toe link cam bolt and nut (1) attaching the toe link (2) to the rear suspension crossmember.
  7. Loosen the Nut (3) at the knuckle and remove the bolt (4) attaching the upper control arm to the rear suspension crossmember.
  8. Remove the lower control arm. Refer to «REMOVAL»(ref-305758-S23380443272008120200000) .
  9. Support the knuckle and all of the attaching parts using strong cord or wire.
  10. Remove the wheel speed sensor bracket bolt.
  11. Disconnect the ground strap from the muffler.
  12. Remove the extension pipe, muffler and tail pipe from the vehicle. Refer to «REMOVAL»(ref-305850-S13941083082008120200000) .
  13. Remove the stabilizer bar bolts from the rear suspension crossmember. Refer to «REMOVAL»(ref-305758-S27389303332008120200000) .
  14. Remove the lower nut (3) from the rear suspension bracket from the body and rear suspension crossmember.
  15. Position a transmission jack under the center of the rear suspension crossmember to support and lower it during removal. Remove the four bolts attaching the rear suspension crossmember to rear frame rails.
  16. Lower the rear suspension crossmember.

Note. Graphics and steps shown are of the right side of the vehicle. Complete the same steps for the left side of the vehicle.

Scheme 39

Scheme 39
Scheme 39
  1. Position the rear suspension crossmember to the center of a trans jack, secure the crossmember to the jack with straps.
  2. Raise the rear suspension crossmember into position and install the bolts and studs attaching the rear suspension crossmember to rear frame rails. Tighten bolts and studs to 95 N.m (70 ft. lbs.).
  3. Install the rear suspension bracket and tighten the nut to 50 N.m (37 ft. lbs.).
  4. Install the stabilizer bar and bolts to the rear suspension crossmember and tighten to 24.5 N.m (18 ft. lbs.).
  5. Install the wheel speed sensor bracket and tighten the bolt to 18 N.m (13 ft. lbs.).
  6. Remove the strong cord or wire used to support the knuckle and install the lower control arm. Refer to «INSTALLATION»(ref-305758-S35244210162008120200000) .
  7. Install the upper control arm to the rear suspension crossmember and tighten all bolts to 108.5 N.m (80 ft. lbs.). NOTE: Position the toe link cam (3) to the reference mark made during the removal to ease with setting the rear toe adjustment.
  8. Install the toe link cam bolt and nut (1) attaching the toe link (2) to the rear suspension crossmember tighten to 34 N.m (25 ft. lbs.).
  9. If equipped, install the rear drive module from the vehicle. Refer to «INSTALLATION»(ref-305764-S12721761832008120200000) .
  10. Install the exhaust system to the vehicle. Refer to «INSTALLATION»(ref-305850-S38426477592008120200000) .
  11. Install tire and wheel assembly and tighten wheel mounting nuts (3) to 135 N.m (100 ft. lbs.). Refer to «INSTALLATION»(ref-305760-S08390685702008120200000) .
  12. Install the upper suspension bracket nuts and tighten to 23 N.m (17 ft. lbs.).
  13. Install spare tire to the vehicle.
  14. Check and reset the rear wheel alignment to meet the preferred specifications. Refer to «STANDARD PROCEDURE»(ref-305758-S10766304732008120200000) .

Scheme 40

Scheme 40: SHIELD-FUEL TANK - LEFT
Scheme 40: SHIELD-FUEL TANK - LEFT
  1. Raise vehicle on jack stands or centered on a frame contact type hoist. Refer to «STANDARD PROCEDURE»(ref-305753-S01950477782008120200000) .
  2. Remove the nuts (1), pushpin (3) and the left shield (2) from the vehicle.

Scheme 41

Scheme 41: SHIELD-FUEL TANK - RIGHT
Scheme 41: SHIELD-FUEL TANK - RIGHT
  1. Raise vehicle on jack stands or centered on a frame contact type hoist. Refer to «STANDARD PROCEDURE»(ref-305753-S01950477782008120200000) .
  2. Remove the nuts (2), push pins (3) and the right shield (1) from the vehicle.
