Electronic Control Modules - Service Information: Removal & Installation Dodge Avenger II

REMOVAL

1. Disconnect and isolate the battery negative cable.
2. Remove the door trim panel. Refer to «REMOVAL»(ref-305774-S06626824782008120200000) .
3. Disconnect the electrical connectors.
4. Remove the mounting fasteners and remove the module.

INSTALLATION

Note. The C2 connector of the driver door module must be connected prior to the C1 connector. If this is not done, the scan tool will report multiple passenger door modules. In order to correct this situation, remove fuse #36 for approximately 30 seconds and reinstall the fuse.

1. Install the module and mounting fasteners.
2. Connect the electrical connectors.
3. Install the door trim panel. Refer to «INSTALLATION»(ref-305774-S40736175972008120200000) .
4. Connect the battery negative cable.

Scheme 130

The ECM (3) is located in the left side of engine compartment attached to the left inner fender below the air filter housing.

ADDITIONAL PCM / TCM REPLACEMENT PROCEDURES

Note. Find the PCM/TCM Type for the vehicle, read and write down the steps, and then go to the step by step instructions for additional information on how to perform these procedures. See STEP-BY-STEP INSTRUCTIONS .

If an EDC16-U31 PCM was replaced, perform the following additional steps and/or routines

1. PCM Replaced - if WCM equipped
2. Check PCM VIN - if NOT WCM equipped
3. Program Variant Code

If an EDC16-C2 PCM was replaced, perform the following additional steps and/or routines

1. PCM Replaced - if WCM equipped
2. Check PCM VIN - if NOT WCM / SKREEM equipped
3. IMA Rapid Calibration Test - Only on 06 PT & up
4. Injector Quantity Adjustment - Only on 06 PT & up

1. PCM Replaced - if WCM equipped
2. Check PCM VIN - if NOT WCM equipped
3. Diesel Particulate Filter (Used) Learning
4. NOx Catalyst (New) Initialization
5. Injector Quantity Adjustment
6. IMA Rapid Calibration Test
7. Fuel Mean Value Adaptation Initialization
8. Exhaust Throttle Plate Adaptive Learn Position

1. PCM Replaced - if WCM equipped
2. Check PCM VIN - if NOT WCM equipped
3. Injector Quantity Adjustment
4. Program Variant Code
5. ECU Replacement With Value Transfer - if the ECU to be replaced is still responsive
6. ECU Replacement Without Value Transfer - if the ECU to be replaced is NOT responsive
7. Fuel Mean Value Adaptation Initialization
8. IMA Rapid Calibration Test
9. Set Oil Dilution Mass Value

1. PCM Replaced - if WCM equipped
2. Check PCM VIN - if NOT WCM equipped

1. PCM Replaced - if WCM equipped
2. Check PCM VIN - if NOT WCM equipped
3. Enable / Disable Vehicle Features - need to enable features
4. Injector Quantity Adjustment
5. Reset Regenerative Filter Timers
6. Mobile DeSoot - NO Minimum Required Soot Load

1. Quicklearn

1. Initialize EGS

1. Quicklearn

1. Quicklearn

1. Quicklearn

Find the PCM/TCM Type for the vehicle, read and write down the steps, and then go to the step by step instructions for additional information on how to perform these procedures. See STEP-BY-STEP INSTRUCTIONS .

If a NGC3 or NGC4 PCM was replaced, perform the following additional steps and/or routines

1. PCM Replaced - if WCM equipped
2. Learn ETC - if ETC equipped
3. Check PCM Odometer
4. Check PCM VIN - if NOT WCM equipped
5. Quicklearn - if EATX equipped

1. If the vehicle is equipped with a CVT, ensure that the TCM has the latest software calibration available (if the vehicle is not equipped with a CVT, skip to Step 3 .
2. PCM Replaced - if WCM equipped
3. Learn ETC
4. Check PCM Odometer
5. Check PCM VIN - if NOT WCM equipped
6. TCM Quicklearn - if EATX equipped

1. Initialize CVT

1. Initialize EGS
