Communication Devices 18 illustrations ~3236 words

Monitor Conditions

  1. When Monitored: With the ignition on.

Set Conditions

  1. Set Condition: The Hands Free Module detects a fault in any of the microphone circuits.

Possible Causes

Possible Causes
(X712) MICROPHONE 1 IN (+) CIRCUIT SHORTED TO GROUND
INSIDE REARVIEW MIRROR
HANDS FREE MODULE

Scheme 146

Scheme 146: Diagnostic Test
Scheme 146: Diagnostic Test

Scheme 147

Scheme 147
Scheme 147
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Inside Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Inside Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X712) MICROPHONE 1 IN (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Hands Free Module harness connector. Measure the resistance between ground and the (X712) Microphone 1 circuit. Is the resistance below 10K ohms? Yes Repair the (X712) Microphone 1 circuit for short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .

Scheme 148

Scheme 148: Circuit Schematic
Scheme 148: Circuit Schematic
  1. When Monitored: With the ignition on.
  1. Set Condition: The Radio detects a fault in any of the microphone circuits.
Possible Causes
(X712) MICROPHONE 1 IN (+) CIRCUIT SHORTED TO GROUND
INSIDE REARVIEW MIRROR
RADIO

Scheme 149

Scheme 149
Scheme 149
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Inside Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Inside Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X712) MICROPHONE 1 IN (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Radio C2 harness connector. Measure the resistance between ground and the (X712) Microphone 1 circuit. Is the resistance below 10K ohms? Yes Repair the (X712) Microphone 1 circuit for short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Replace the Radio in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault in any of the microphone circuits.
Possible Causes
(X712) MICROPHONE 1 IN (+) CIRCUIT OPEN
(X712) MICROPHONE 1 IN (+) CIRCUITS SHORTED TO VOLTAGE
INSIDE REARVIEW MIRROR
HANDS FREE MODULE

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X712) MICROPHONE 1 IN (+) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Hands Free Module harness connector. Turn the ignition on. Measure the voltage of the (X712) Microphone 1 IN (+) circuit. Is voltage present? Yes Repair the (X712) Microphone 1 IN (+) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Go To 4 .
  4. (X712) MICROPHONE 1IN (+) CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (X712) Microphone 1IN (+) circuit between the HFM connector and the inside rearview mirror connector. Is the resistance below 5.0 ohms? Yes Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (X712) Microphone 1 IN (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Radio detects a fault in any of the microphone circuits.
Possible Causes
(X712) MICROPHONE 1 IN (+) CIRCUIT OPEN
(X712) MICROPHONE 1 IN (+) CIRCUITS SHORTED TO VOLTAGE
INSIDE REARVIEW MIRROR
RADIO

Scheme 152

Scheme 152
Scheme 152

Scheme 153

Scheme 153
Scheme 153
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X712) MICROPHONE 1 IN (+) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Radio C2 harness connector. Turn the ignition on. Measure the voltage of the (X712) Microphone 1 IN (+) circuit. Is the voltage above 1.0 volt? Yes Repair the (X712) Microphone 1 IN (+) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Go To 4 .
  4. (X712) MICROPHONE 1 IN (+) CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (X712) Microphone 1 IN (+) circuit between the Radio C2 connector and the inside Rearview Mirror connector. Is the resistance below 5.0 ohms? Yes Replace the Radio in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (X712) Microphone 1 IN (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault in any of the microphone circuits.
Possible Causes
(X722) MICROPHONE 2 IN (+) CIRCUIT SHORTED TO GROUND
INSIDE REARVIEW MIRROR
HANDS FREE MODULE

Scheme 154

Scheme 154
Scheme 154
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Inside Rearview Mirror C2 harness connector. Turn the ignition on. With the scan tool, read the DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Inside Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X722) MICROPHONE 2 IN (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Hands Free Module harness connector. Measure the resistance between ground and the (X722) Microphone 2 circuit. Is the resistance below 10K ohms? Yes Repair the (X722) Microphone 2 circuit for short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Radio detects a fault in any of the microphone circuits.
Possible Causes
(X722) MICROPHONE 2 IN (+) CIRCUIT SHORTED TO GROUND
INSIDE REARVIEW MIRROR
RADIO

Scheme 155

Scheme 155
Scheme 155
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Inside Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Inside Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X722) MICROPHONE 2 IN (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Radio C2 harness connector. Measure the resistance between ground and the (X722) Microphone 2 IN (+) circuit. Is the resistance below 10K ohms? Yes Repair the (X722) Microphone 2 IN (+) circuit for short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Replace the Radio in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault in any of the microphone circuits.
Possible Causes
(X722) MICROPHONE 2 IN (+) CIRCUIT OPEN
(X722) MICROPHONE 2 IN (+) CIRCUITS SHORTED TO VOLTAGE
INSIDE REARVIEW MIRROR
HANDS FREE MODULE

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X722) MICROPHONE IN 2 (+) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Hands Free Module harness connector. Turn the ignition on. Measure the voltage of the (X722) Microphone IN 2 (+) circuit. Is voltage present? Yes Repair the (X722) Microphone IN 2 (+) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Go To 4 .
  4. (X722) MICROPHONE 2 IN (+) CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (X722) Microphone 2 IN (+) circuit between the HFM connector and the inside rearview mirror connector. Is the resistance below 5.0 ohms? Yes Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (X722) Microphone 2 IN (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault in any of the microphone circuits.
Possible Causes
(X722) MICROPHONE 2 IN (+) CIRCUIT OPEN
(X722) MICROPHONE 2 IN (+) CIRCUITS SHORTED TO VOLTAGE
INSIDE REARVIEW MIRROR
RADIO

Scheme 158

Scheme 158
Scheme 158

Scheme 159

Scheme 159
Scheme 159
  1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. Attempt to make a phone call with the system. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Rearview Mirror harness connector. Turn the ignition on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X722) MICROPHONE 2 IN (+) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Radio C2 harness connector. Turn the ignition on. Measure the voltage of the (X722) Microphone 2 IN (+) circuit. Is the voltage above 1.0 volt? Yes Repair the (X722) Microphone 2 IN (+) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Go To 4 .
  4. (X722) MICROPHONE 2 IN (+) CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (X722) Microphone 2 IN (+) circuit between the Radio C2 connector and the inside rearview mirror connector. Is the resistance below 5.0 ohms? Yes Replace the Radio in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (X722) Microphone 2 IN (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: Rearview Mirror microphone fault.
Possible Causes
INSIDE REARVIEW MIRROR
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects an open in the (X712) microphone circuit.
Possible Causes
(X712) MICROPHONE 1 IN (+) CIRCUIT OPEN
INSIDE REARVIEW MIRROR
HANDS FREE MODULE

Scheme 160

Scheme 160: Diagnostic Test
Scheme 160: Diagnostic Test
  1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Turn the ignition off, wait 30 seconds then turn the ignition on. With the scan tool, read DTCs. Is the DTC active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chaffed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Rearview Mirror harness connector. Connect a jumper wire from the (X712) Microphone 1IN (+) circuit to ground. Turn the ignition on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X712) MICROPHONE 1IN (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Radio C2 harness connector. Disconnect the Inside Rearview Mirror harness connector. Measure the resistance of the (X712) Microphone 1IN (+) circuit between the Radio C2 connector and the inside rearview mirror connector. Is the resistance below 5.0 ohms? Yes Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (X712) Microphone 1 IN (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects an open in the (X722) microphone circuit.
Possible Causes
(X722) MICROPHONE 2 IN (+) CIRCUIT OPEN
INSIDE REARVIEW MIRROR
HANDS FREE MODULE

Scheme 161

Scheme 161: Diagnostic Test
Scheme 161: Diagnostic Test
  1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Turn the ignition off, wait 30 seconds then turn the ignition on. With the scan tool, read DTCs. Is the DTC active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chaffed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  2. INSIDE REARVIEW MIRROR Turn the ignition off. Disconnect the Rearview Mirror harness connector. Connect a jumper wire from the (X722) Microphone 2 IN (+) circuit to ground. Turn the ignition on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Rearview Mirror in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  3. (X722) MICROPHONE 2 IN (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Radio C2 harness connector. Disconnect the Inside Rearview Mirror harness connector. Measure the resistance of the (X722) Microphone 2 IN (+) circuit between the Radio C2 connector and the inside rearview mirror connector. Is the resistance below 5.0 ohms? Yes Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (X722) Microphone 2 IN (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module will receive and monitor the VIN message from the PCM and record the VIN if different from the last VIN.
Possible Causes
INCORRECT VIN PROGRAMMED IN PCM
HANDS FREE MODULE
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault during an internal diagnostic check.
Possible Causes
HANDS FREE MODULE
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module will receive and monitor the vehicle line message from the PCM and record the vehicle line if different from the last vehicle line.
Possible Causes
INCORRECT PCM
HANDS FREE MODULE
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault during an internal diagnostic check.
Possible Causes
HANDS FREE MODULE
  1. When Monitored: With the ignition on.
  1. Set Condition: The Hands Free Module detects a fault during an internal diagnostic check.
Possible Causes
HANDS FREE MODULE
  1. When Monitored: Continuously
  1. Set Condition: Whenever the CAN B Bus (+) or CAN B Bus (-) circuit is open, shorted to voltage or shorted to ground.
Possible Causes
CAN B BUS DTC's IN TOTALLY INTEGRATED POWER MODULE
(D55) CAN B BUS (+) CIRCUIT OPEN
(D54) CAN B BUS (-) CIRCUIT OPEN
HANDS FREE MODULE

Scheme 162

Scheme 162: Diagnostic Test
Scheme 162: Diagnostic Test

Scheme 163

Scheme 163
Scheme 163
  1. CHECK FOR ACTIVE DTCS With the scan tool, read the active DTC's. Cycle the ignition switch from off to on. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  2. CHECK TOTALLY INTEGRATED POWER MODULE DTC's With the scan tool, read Totally Integrated Power Module active DTC's Does the scan tool display any CAN B BUS DTC's - ACTIVE? Yes Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Go To 3 .
  3. (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the negative battery cable. Disconnect the Hands Free Module connector. Disconnect the Totally Integrated Power Module C6 connector. Measure the resistance of the (D55) CAN B Bus (+) circuit between the Totally Integrated Power Module C6 connector and the Hands Free Module connector. Is the resistance below 2.0 ohms? Yes Go To 4 . No Repair the (D55) CAN B Bus (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  4. (D54) CAN B BUS (-) CIRCUIT OPEN Measure the resistance of the (D54) CAN B Bus (-) circuit between the Totally Integrated Power Module C6 connector and the Hands Free Module connector. Is the resistance below 2.0 ohms? Yes Replace the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Repair the (D54) CAN B Bus (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
