SPECIFICATIONS
| WARNING | Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS. |
| Application | Description |
|---|
| R-134a System | 23.5-24.7 ozs. |
| Refrigerant Oil In A/C System | Synthetic PAG 9.0 ozs. |
A/C SYSTEM CHARGING CAPACITY
TORQUE SPECIFICATIONS
| Application | INCH lbs. (N.m) |
|---|
| Air Filter Cover Nut | 35 (4) |
| Ambient Air Temperature Retaining Bracket Nut | 53 (6) |
| Blower Motor Resistor Screws | 35 (4) |
| Control Assembly Retaining Screws | 35 (4) |
| Expansion Valve Bolts | 89 (10) |
| Heater/Air Distributor Assembly Case Screws | 89 (10) |
| Liquid Evaporator Pipe Retaining Nuts | 89 (10) |
| Suction Hose Retaining Nuts | 89 (10) |
Scheme 1
Scheme 1: WIRING DIAGRAMS
Scheme 2
Scheme 3
