Automatic Heating & A/c: Diagnosis Daewoo Nubira II

Automatic HVAC System 20 illustrations ~253 words

GENERAL DIAGNOSTICS

The V5 variable displacement compressor combines with thermal expansion valve to form a largely self regulating system. In high pressure refrigerant line, there is a pressure sensor rather than a traditional high or low pressure cut-off switch or pressure cycling switch. The compressor clutch is controlled by Powertrain Control Module (PCM)/Engine Control Module (ECM), which monitors data from various engine systems. The PCM/ECM will disengage compressor clutch if following conditions are detected

  1. The air conditioning is OFF.
  2. The throttle is in wide-open position.
  3. High engine coolant temperature.
  4. High engine RPM.
  5. Low refrigerant pressure.
  6. High refrigerant pressure.

The compressor clutch will remain disengaged until normal operation is established.

SELF-DIAGNOSTIC CIRCUIT CHECK

The Daewoo Fully Automatic Temperature Controller (FATC) contains a self-diagnostic function to aid in finding any problem with system. To enter diagnostic mode, perform following procedures

  1. Turn ignition switch ON.
  2. Set temperature control to 79°F (26°C).
  3. Within 3 seconds, push AUTO and OFF switches simultaneously, more than 3 times.
  4. Count number of times temperature indicator screen blinks.
  5. If there are no error codes set, screen will not blink. When controller indicates an error code, proceed to table for that code.
  6. Push OFF switch to return controller to its normal functions.

Scheme 4

Scheme 4: ATC DOES NOT OPERATE WHEN IGNITION IS ON

Scheme 5

Scheme 5: BLOWER MOTOR DOES NOT RUN AT ALL

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8: COMPRESSOR MAGNETIC CLUTCH DOES NOT ENGAGE

Scheme 9

Scheme 9: CONTROLLER DOES NOT ILLUMINATE WHEN LIGHT SWITCH IS ON

Scheme 10

Scheme 10: MODE CONTROLS DO NOT WORK

Scheme 11

Scheme 11: NO COOL AIR FROM BLOWER

Scheme 12

Scheme 12

Scheme 13

Scheme 13: NO HOT AIR FROM BLOWER

Scheme 14

Scheme 14

SYSTEM TESTS (DTC TESTS)

DTCDescription
DTC 1IN-CAR SENSOR ERROR
DTC 2AMBIENT AIR TEMPERATURE SENSOR ERROR
DTC 3COOLANT TEMPERATURE SENSOR ERROR
DTC 4AIR MIX DOOR ERROR
DTC 5SUN SENSOR ERROR
DTC 6POWER TRANSISTOR ERROR
DTC 7MAX-HI RELAY ERROR

DTC INDEX

Scheme 15

Scheme 15: DTC 1: IN-CAR SENSOR ERROR

Scheme 16

Scheme 16: DTC 2: AMBIENT AIR TEMPERATURE SENSOR ERROR

Scheme 17

Scheme 17: DTC 3: COOLANT TEMPERATURE SENSOR ERROR

Scheme 18

Scheme 18: DTC 4: AIR MIX DOOR ERROR

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21: DTC 5: SUN SENSOR ERROR

Scheme 22

Scheme 22: DTC 6: POWER TRANSISTOR ERROR

Scheme 23

Scheme 23: DTC 7: MAX-HI RELAY ERROR
