DESCRIPTION

Note. All engines use a fixed ignition timing system. Basic ignition timing is not adjustable. All spark advance is determined by the Powertrain Control Module (PCM).

The ignition system used on these engines is referred to as coil on plug. The system's four main components are the coils, crankshaft position sensor, spark plugs and camshaft position sensors. The coil on plug ignition system utilizes an ignition coil for every cylinder. The ignition coils are mounted directly over the each spark plug.

OPERATION

The crankshaft position sensor and camshaft position sensor are hall effect devices. The camshaft position sensor and crankshaft position sensor generate square wave pulses that are inputs to the PCM. The PCM determines engine position from these sensors. The PCM calculates injector sequence and ignition timing from crankshaft AND camshaft position.

Scheme 1

The firing order is 1-2-3-4-5-6.

IGNITION COIL RESISTANCE

SPARK PLUG

TORQUE

Scheme 2

1. Disconnect and isolate the negative battery cable.
2. Remove the electrical connector (1).
3. Remove the mounting bolt (3) and the ignition capacitor (2).

INSTALLATION

1. Install the ignition coil capacitor (2) and bolt (3). Tighten the bolt to 10 N.m (89 in. lbs.).
2. Connect the electrical connector (1).
3. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).

Scheme 3

Scheme 4

1. Disconnect and isolate the negative battery cable.
2. If removing the ignition coils from cylinders 1 and 3 on the RH side of the engine, first remove the resonator. Refer to «RESONATOR, AIR CLEANER, REMOVAL»(ref-574535-S22698249362013082700000) .
3. If removing the ignition coils from cylinders 2, 4 or 6 on the LH side of the engine, first remove the upper intake manifold (2) and insulator. Refer to «MANIFOLD, INTAKE, REMOVAL»(ref-574534-S20988518732013082700000) for 2.8L Diesel or «MANIFOLD, INTAKE, REMOVAL»(ref-574535-S14110949772013082700000) for 3.6L Engine. NOTE: The LH ignition coils are shown in illustration, the RH ignition coils are similar.
4. Unlock and disconnect the electrical connector (1) from the ignition coil.
5. Remove the ignition coil mounting bolt (3).
6. Pull the ignition coil (2) from cylinder head cover opening with a slight twisting action.

Scheme 5

Scheme 6

Scheme 7

1. Using compressed air, blow out any dirt or contaminants from around the top of spark plug.
2. Check the condition of the ignition coil rubber boot (1). Inspect the opening of the boot (2) for any debris, tears or rips. Carefully remove any debris with a lint free cloth. CAUTION: Do not apply a silicone based grease such as Mopar® Dielectric Grease to the ignition coil rubber boot. The silicone based grease will absorb into the boot causing it to stick and tear.
3. Place a small, 360° bead of Fluostar 2LF lubricant (1) along the inside opening of the coil boot approximately 1 to 2 mm from the chamfer edge but not on the chamfered surface. NOTE: The LH ignition coils are shown in illustration, the RH ignition coils are similar.
4. Position the ignition coil (2) into the cylinder head cover opening. Using a twisting action, push the ignition coil onto the spark plug.
5. Install the ignition coil mounting bolt (3) and tighten to 8 N.m (71 in.lbs).
6. Connect and lock the electrical connector (1) to the ignition coil (2).
7. If removed, install the insulator, upper intake manifold (1) and air inlet hose. Refer to «MANIFOLD, INTAKE, INSTALLATION»(ref-574534-S05717099032013082700000) for 2.8L diesel or «MANIFOLD, INTAKE, INSTALLATION»(ref-574535-S20465120892013082700000) for 3.6L engine.
8. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).

Scheme 8

Glow plugs are used to help start a cold or cool engine. The glow plugs will heat up and glow to heat the combustion chamber of each cylinder. Each cylinder has its own glow plug which attached to cylinder head below fuel rail.

Scheme 9

The Powertrain Control Module (PCM) monitors various engine sensors. When the ignition key is turned to the ON position, the PCM sends a signal to the glow plug module (relay) to turn on, and cycle, the glow plugs for a pre-determined amount of time, plus illuminate the glow plug light in the instrument panel. Once activated, the element inside of the core of the glow plug begins to glow. If there is a fault with the glow plug system, the PCM will store a fault code.

DIAGNOSIS AND TESTING - GLOW PLUGS

Note. To ensure a good contact of the measurement connections the contacts have to be free of oil, dirt or corrosion.

1. Measure the electrical resistance of each glow plug while it is still installed in the cylinder head. Resistance should be between 0.2 E 5? between the electrical connector point on the glow plug and the cylinder head. The ground contact on the DVOM must be as close as possible to the point where the glow plug contacts the cylinder head to avoid erratic resistance measurements.
2. If the resistance is out of tolerance, remove the glow plug from the cylinder head and check the resistance again.
3. Dismantled state: measure between connection side (connector/thread) and housing.
4. Engine mounted state: measure between connection side (connector/thread) and engine mass.
5. Resistance value: Resistance > 5 ?: open circuit failure. Resistance < 200 m?: short circuit failure. 200 m? < Resistance < 5 ?: glow plug OK.
6. Use the actuator test function of the scan tool to test the glow plug module and glow plug lamp. The glow plug module's on-board diagnostic tests will automatically check the electrical condition of the entire glow plug system.
7. After the scan tool glow plug actuator test function is complete, if MIL is OFF and no glow plug DTCs are present, testing is complete and the engine can be started.
8. If MIL is still ON, check the harness connectors of glow plugs, repair any loose or damaged connections, and run the glow plug actuator test again.
9. If MIL is still ON, check the electrical connectors of glow plugs and power up the glow plugs again.

Scheme 10

Scheme 11

1. Disconnect the negative battery cable.
2. Remove the engine cover (1).
3. Remove the fuel rail. Refer to «RAIL, FUEL, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/fuel-system/#fuel-system) for gasoline engines or «RAIL, FUEL, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/fuel-system/#fuel-system) for diesel engines.
4. Disconnect glow plug wiring harness (2) at all four glow plugs (1). CAUTION: After plug removal, do not bend, knock, or drop the glow plugs while handling (any mechanical impact may damage the glow plug).
5. Use a socket to loosen all the glow plug(s) (1). After loosening, attach a flexible tool such as a rubber hose to remove glow plug from cylinder head.

1. Attach a flexible tool such as a rubber hose to install glow plug into cylinder head. Tighten each plug to 14 N.m (124 in. lbs.).
2. Connect glow plug wiring harness (2) to all four glow plugs (1).
3. Install fuel rail. Refer to «RAIL, FUEL, INSTALLATION»(/chrysler/town-country/v-2010-2016/remont/fuel-system/#fuel-system) for gasoline engines or «RAIL, FUEL, INSTALLATION»(/chrysler/town-country/v-2010-2016/remont/fuel-system/#fuel-system) for diesel engines.
4. Install the engine cover (1).
5. Connect the negative battery cable.

Scheme 12

The 3.6 liter engine uses a Dual Over Head Camshaft (DOHC) configuration. The camshafts are a nodular cast iron design and have two pressed on magnetic timing wheels (1) that are magnetically encoded.

The Camshaft Position Sensors (CMP) are mounted between the timing wheels (1).

3.6L

The Camshaft Position (CMP) sensors are located at the rear of the cylinder head covers and are bolted to the cylinder head.

Scheme 13

Scheme 14

1. Disconnect and isolate the negative battery cable.
2. Remove the air cleaner body. Refer to «BODY, AIR CLEANER, REMOVAL»(ref-574535-S01902323402013082700000) for 3.6L engine or «BODY, AIR CLEANER, REMOVAL»(ref-574534-S08646539432013082700000) for 2.8L diesel.
3. If removing the LH CMP sensor, first remove the upper intake manifold (2). Refer to «MANIFOLD, INTAKE, REMOVAL»(ref-574534-S20988518732013082700000) for 2.8L diesel or «MANIFOLD, INTAKE, REMOVAL»(ref-574535-S14110949772013082700000) for 3.6L engine. NOTE: The RH CMP sensor is shown in illustration, the LH CMP sensor is similar. If removing both RH and LH CMP sensors, mark the sensors so they can be installed in their original locations.
4. Disconnect the electrical connector (1) from the CMP sensor.
5. Loosen the sensor mounting bolt (2).
6. Pull the sensor and mounting bolt from the cylinder head cover.
7. The O-ring seal (1) can be reused if not damaged.

Scheme 15

1. Disconnect and isolate the negative battery cable.
2. Disconnect the Camshaft Position (CMP) sensor wire harness connector (1).
3. Clean the area at base of CMP sensor.
4. Remove bolt (3) and the CMP sensor (2).

Scheme 16

Scheme 17

Scheme 18

1. Clean out the camshaft position (CMP) sensor mounting bolt hole (2) in cylinder head.
2. The CMP sensor seal (1) can be reused if not damaged.
3. If required, install a new CMP sensor seal (2) in the cylinder head cover: Lubricate the CMP sensor seal inner and outer diameters with clean engine oil. Place the CMP sensor seal (2) on the Cam Sensor/Spark Plug Tube Seal Installer (special tool #10256, Installer, Cam Installer, Cam Sensor/ Spark Plug Tube Seal) (1). Push the seal into the cylinder head cover until the base of the seal is seated. Remove the tool. NOTE: A properly installed CMP sensor seal (1) will have a 1.5 - 2.0 mm (0.06 - 0.08 in.) gap (2) between the cylinder head cover and the seal upper flange.
4. The sensor mounting bolt O-ring (1) can be reused if not damaged.
5. Apply a small amount of engine oil to the sensor mounting bolt O-ring (1). NOTE: The RH CMP sensor is shown in illustration, the LH CMP sensor is similar. If both RH and LH CMP sensors where removed, install them into their original locations.
6. Install the CMP sensor to the cylinder head. Tighten the mounting bolt (2) to 9 N.m (80 in. lbs.).
7. Connect the electrical connector (1) to the sensor.
8. Following installation of the LH CMP sensor, install the upper intake manifold (1). Refer to «MANIFOLD, INTAKE, INSTALLATION»(ref-574534-S05717099032013082700000) for 2.8L diesel or «MANIFOLD, INTAKE, INSTALLATION»(ref-574535-S20465120892013082700000) for 3.6L engine.
9. Install the air cleaner body. Refer to «BODY, AIR CLEANER, INSTALLATION»(ref-574534-S36681231342013082700000) 2.8L diesel or «BODY, AIR CLEANER, INSTALLATION»(ref-574535-S37239491452013082700000) for 3.6L engine.
10. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).

Note. The Cam/Crank Variation Relearn procedure must be performed using the scan tool anytime there has been a repair/replacement made to a powertrain system, for example: flywheel, valvetrain, camshaft and/or crankshaft sensors or components.

2.8L DIESEL

1. Install Camshaft Position (CMP) sensor (2). Tighten bolt (3) to 11 N.m (97 in. lbs.).
2. Connect the CMP sensor wire harness connector (1).
3. Connect the negative battery cable.

Scheme 19

Note. The forward sensor (1) is known to the powertrain control module (PCM) as knock sensor 1. The rear sensor (3) is known to the PCM as knock sensor 2.

1. Perform the fuel pressure release procedure. Refer to appropriate FUEL SYSTEM PRESSURE RELEASE PROCEDURE in appropriate FUEL SYSTEM article.
2. Disconnect and isolate the negative battery cable.
3. Drain the cooling system. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/accessory-drive-belts/#engine-cooling-system) .
4. Remove the air cleaner housing assembly, upper and lower intake manifolds and the oil filter housing. Refer to «HOUSING, OIL FILTER, REMOVAL»(ref-574534-S36320217562013082700000) for 2.8L diesel or «HOUSING, OIL FILTER, REMOVAL»(ref-574535-S27049779112013082700000) for 3.6L engine.
5. Remove the electrical connector (4). NOTE: There may be a foam strip on the bolt threads. This foam is used only to retain the bolts to the sensors for plant assembly. It is not used as a sealant. Do not apply any adhesive, sealant or thread locking compound to these bolts.
6. Remove the mounting bolt (2) and knock sensor 1 (1) or knock sensor 2 (3).

Note. The forward sensor (1) is known to the powertrain control module (PCM) as knock sensor 1. The rear sensor (3) is known to the PCM as knock sensor 2.

1. Thoroughly clean the knock sensor mounting holes. NOTE: Over or under tightening the sensor mounting bolts will affect knock sensor performance, possibly causing improper spark control. Always use the specified torque when installing the knock sensors. The torque specification for the knock sensor bolt is less than the typical 8 mm bolt. NOTE: There may be a foam strip on the bolt threads. This foam is used only to retain the bolts to the sensors for plant assembly. It is not used as a sealant. Do not apply any adhesive, sealant or thread locking compound to these bolts.
2. Install knock sensor 1 (1) or knock sensor 2 (3) with mounting bolt (2). Tighten the mounting bolt to 22 N.m (16 ft. lbs.).
3. Connect the electrical connector (4).
4. Install the oil filter housing, upper and lower intake manifolds and air cleaner housing assembly. Refer to «HOUSING, OIL FILTER, INSTALLATION»(ref-574534-S38270417292013082700000) for 2.8L diesel or «HOUSING, OIL FILTER, INSTALLATION»(ref-574535-S08985576842013082700000) for 3.6L engine.
5. If removed, install the oil filter and fill the engine crankcase with the proper oil to the correct level. Refer to «STANDARD PROCEDURE»(ref-574534-S05441081952013082700000) for 2.8L diesel or «STANDARD PROCEDURE»(ref-574535-S31460334432013082700000) for 3.6L engine. .
6. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).
7. Fill the cooling system. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/accessory-drive-belts/#engine-cooling-system) .
8. Operate the engine until it reaches normal operating temperature. Check cooling system for correct fluid level. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/accessory-drive-belts/#engine-cooling-system) .

Scheme 20

The 3.6L engine is equipped with Variable Valve Timing (VVT). This system adjusts the timing of all four camshafts independently using solenoids and oil control valves to direct oil pressure into the camshaft phaser assemblies. The camshaft phaser assembly advances and/or retards camshaft timing to improve engine performance, mid-range torque, idle quality, fuel economy and reduce emissions. The four VVT solenoids are located on the front of the cylinder head covers. The pintle should move freely within the solenoid body. Do not attempt to disassemble the solenoids, they are not serviceable. The solenoids are identical but should be installed in the same location as removed.

Scheme 21

Camshaft phaser position is adjusted using regulated oil pressure through an Oil Control Valve (OCV) (3). To begin Phaser movement, the Powertrain Control Module (PCM) applies a pulse-width modulated voltage signal to the VVT solenoid (1) to extend or retract the solenoid pintle (4). The pintle pushes against an internal spool valve (2) within the OCV moving the valve forwards and backwards to direct oil flow. The position of the spool inside the OCV determines which ports and chambers inside the phaser are being fed, either to advance the timing of the phaser sprocket relative to the camshaft, retard it, or hold a desired position. Refer to ASSEMBLY, VARIABLE VALVE TIMING, PHASER / OIL CONTROL VALVE, OPERATION .

The Camshaft Position (CMP) sensor monitors the position of the camshaft with respect to the crankshaft and provides feedback to the PCM.

Scheme 22

Scheme 23

1. Disconnect and isolate the negative battery cable. NOTE: Mark the variable valve timing solenoid connectors (1) with a paint pen or equivalent so that they may be reinstalled in their original locations.
2. Mark the intake variable valve timing solenoid (4) and the exhaust variable valve timing solenoid (2) with a paint pen or equivalent so that they may be reinstalled in their original locations.
3. Disconnect the electrical connector (1) from the variable valve timing solenoid.
4. Remove the variable valve timing solenoid mounting bolts (3).
5. Pull the variable valve timing solenoid from the cylinder head cover.
6. The seal (1) can be reused if not damaged.

Scheme 24

Scheme 25

1. Disconnect and isolate the negative battery cable.
2. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, FRONT, STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/ac-compressor/#heating-air-conditioning-service-information) .
3. Remove the resonator. Refer to «RESONATOR, AIR CLEANER, REMOVAL»(ref-574535-S22698249362013082700000) .
4. Remove the upper A/C liquid and suction line assembly (1). Refer to «LINE, A/C SUCTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/ac-compressor/#heating-air-conditioning-service-information) . NOTE: Mark the variable valve timing solenoid connectors (1) with a paint pen or equivalent so that they may be reinstalled in their original locations.
5. Mark the intake variable valve timing solenoid (2) and the exhaust variable valve timing solenoid (4) with a paint pen or equivalent so that they may be reinstalled in their original locations.
6. Disconnect the electrical connector (1) from the variable valve timing solenoid.
7. Remove the variable valve timing solenoid mounting bolts (3).
8. Pull the variable valve timing solenoid from the cylinder head cover.
9. The seal (1) can be reused if not damaged.

LEFT

1. Install the variable valve timing solenoid seals (1). The seals can be reused if not damaged.
2. Refer to the markings made at disassembly and install the intake variable valve timing solenoid (4) and the exhaust variable valve timing solenoid (2) in their original locations.
3. Install the variable valve timing solenoid mounting bolts (3) and tighten to 4 N.m (35 in. lbs.).
4. Connect the electrical connector (1) to the variable valve timing solenoid.
5. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).

Note. The Cam/Crank Variation Relearn procedure must be performed using the scan tool anytime there has been a repair/replacement made to a powertrain system, for example: flywheel, valvetrain, camshaft and/or crankshaft sensors or components.

RIGHT

1. Install the variable valve timing solenoid seals (1). The seals can be reused if not damaged.
2. Refer to the markings made at disassembly and install the intake variable valve timing solenoid (2) and the exhaust variable valve timing solenoid (4) in their original locations.
3. Install the variable valve timing solenoid mounting bolts (3) and tighten to 4 N.m (35 in. lbs.).
4. Connect the electrical connector (1) to the variable valve timing solenoid.
5. Install the upper A/C liquid and suction line assembly (1). Refer to «LINE, A/C SUCTION, INSTALLATION»(/chrysler/town-country/v-2010-2016/remont/ac-compressor/#heating-air-conditioning-service-information) .
6. Install the resonator. Refer to «RESONATOR, AIR CLEANER, INSTALLATION»(ref-574535-S33024868012013082700000) .
7. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).

Note. The Cam/Crank Variation Relearn procedure must be performed using the scan tool anytime there has been a repair/replacement made to a powertrain system, for example: flywheel, valvetrain, camshaft and/or crankshaft sensors or components.

REMOVAL

Note. The LH ignition coils are shown in illustration, the RH ignition coils are similar.

Scheme 26

1. Remove the ignition coil (2). Refer to «COIL, IGNITION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/ignition-system/#ignition-system-service-information) .
2. Prior to removing the spark plug, spray compressed air into the cylinder head opening. This will help prevent foreign material from entering the combustion chamber. CAUTION: The spark plug tubes (1) are a thin wall design. Avoid damaging the spark plug tubes. Damage to the spark plug tube can result in oil leaks.
3. Remove the spark plug from the cylinder head using a quality thin wall socket with a rubber or foam insert.
4. Inspect the spark plug condition.

Scheme 27

1. Check and adjust the spark plug gap with a gap gauging tool (1) Refer to «SPECIFICATIONS»(/chrysler/town-country/v-2010-2016/remont/ignition-system/#ignition-system-service-information) . CAUTION: Special care should be taken when installing spark plugs into the cylinder head spark plug wells. Be sure the plugs do not drop into the plug wells as electrodes can be damaged. CAUTION: The spark plug tubes (1) are a thin wall design. Avoid damaging the spark plug tubes. Damage to the spark plug tube can result in oil leaks.
2. Start the spark plug into the cylinder head by hand to avoid cross threading. CAUTION: Spark plug torque is critical and must not exceed the specified value. Overtightening stretches the spark plug shell reducing its heat transfer capability resulting in possible catastrophic engine failure.
3. Tighten the spark plugs to 17.5 N.m (13 ft. lbs.). NOTE: The LH ignition coils are shown in illustration, the RH ignition coils are similar.
4. Install the ignition coil (2) Refer to «COIL, IGNITION, INSTALLATION»(/chrysler/town-country/v-2010-2016/remont/ignition-system/#ignition-system-service-information) .

This vehicle is equipped with a Wireless Ignition Node (WIN). The WIN, along with the FOB with Integrated Key (FOBIK) are the primary components of the keyless ignition system. The only visible component of the WIN is the ignition switch located on the face of the instrument panel just to the inboard side of the steering column. The remainder of the WIN including its mounting provisions and electrical connections are concealed within the instrument panel.

In addition to replacing a conventional keyed ignition switch, the WIN is an integrated electronic receiver that serves as the base station in the vehicle. It communicates with other electronic modules in the vehicle over the Controller Area Network (CAN) data bus.

The WIN interfaces with the Remote Keyless Entry (RKE) FOBIK and the Tire Pressure Monitor (TPM) sensors (if equipped) using Radio Frequency (RF) communication, with the Sentry Key Immobilizer System (SKIS) transponder within the FOBIK using Low Frequency (LF) RF communication.

The WIN cannot be adjusted or repaired, but is flash update capable. If ineffective or damaged the entire WIN must be replaced. Refer to RECEIVER, WIRELESS IGNITION NODE, REMOVAL .
