Electronic Pedestrian Protection (epp) Module - Electrical Diagnostics Chrysler Town & Country V рестайлинг

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

B1BC7-00-DEPLOYMENT DATA RECORD FULL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

THEORY OF OPERATION

When powered, the Electronic Pedestrian Protection module (EPPM) performs an internal self test. The repair of this fault condition does not involve any external circuitry and centers on verifying the integrity of the module's internal memory.

WHEN MONITORED

The EPPM checks its internal memory for the number of recorded deployment events once at every power up, during the initialization process.

SET CONDITION

This DTC sets when the EPPM detects that three recorded deploy events have been reached. Once set, this DTC is latched indefinitely.

POSSIBLE CAUSES

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

DIAGNOSTIC TEST

1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, read EPPM DTCs. Is the Deployment Data Record Full DTC active? Yes Go To 2 No Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. REPLACE THE ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Repair Replace the Electronic Pedestrian Protection Module (EPPM) in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B212C-16-IGNITION RUN/START INPUT - CIRCUIT VOLTAGE BELOW THRESHOLD

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

With the ignition in the Run or Start position and every 10ms throughout the ignition cycle.

If voltage on the (F943) Fused Ignition Switch Output (Run-Start) circuit drops below 9.0 volts for 15 seconds. The code will go from active to stored, if the (F943) Ignition (Run-Start) circuit voltage is equal or above 10 volts for five seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. VERIFY THAT DTC B212C-16-IGNITION RUN/START INPUT - CIRCUIT VOLTAGE BELOW THRESHOLD OPEN IS ACTIVE IN THE EPPM NOTE: Make sure the battery is fully charged. Turn the ignition on, then off, then on again, wait 15 seconds. With the scan tool, read EPPM DTCs. Does the scan tool display active: B212C-16-IGNITION RUN/START INPUT - CIRCUIT VOLTAGE BELOW THRESHOLD? Yes Go To 2 No Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. INSPECT EPPM (ACTIVE HOOD) 10A RED FEED FUSE FOR AN OPEN Turn the ignition off. Remove the Active Hood Run/Start Feed Fuse from the Junction Block (JB) and inspect the fuse. NOTE: Check connectors - Clean and repair as necessary. Is the Run/Start Relay fuse open? Yes Go To 3 No Go To 6
3. CHECK (F943) FUSED RUN/START RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND WITH EPPM CONNECTED WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the resistance of the (F943) Fused Ignition Switch Output Run/Start Relay circuit between ground and the Run-Start fuse output terminal in the Underhood JB. Is the resistance below 100.0 Ohms? Yes Go To 4 No Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Replace Run-Start Fuse. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECK (F943) FUSED RUN/START RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND WITH EPPM DISCONNECTED Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (F943) Fused Run/Start Relay Output circuit between ground and the output terminal side of the EPPM Active Hood Feed Fuse in the Underhood JB. Is the resistance below 100.0 Ohms? No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Replace the 10A Run/Start EPPM Feed Fuse from the Underhood PDC in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . Yes Go To 5
5. CHECK (F943) FUSED RUN/START RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND WITH THE UNDERHOOD PDC DISCONNECTED Disconnect the Underhood JB harness connector. Measure the resistance of the (F943) Fused Run/Start Relay Output circuit between ground and the Underhood PDC harness connector. Is the resistance 100 ohms or less? Yes Repair the (F943) Fused Run/Start Relay Output circuit for a short to ground. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Replace the EPPM 10A Run/Start Feed fuse in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Replace the Underhood JB in accordance with the Service Information. Replace the EPPM Run/Start feed fuse in the Underhood JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
6. CHECK VOLTAGE AT THE INPUT SIDE OF THE EPPM 10A RUN/START FUSE CONNECTOR IN THE UNDERHOOD PDC Turn the ignition on. Measure the voltage of the Underhood EPPM 10A feed fuse Run/Start Output circuit between the input side of the Fuse connector and ground. Is the voltage above 9.0 volts? Yes Go To 7 No Go To 9
7. CHECK (F943) 10A FUSED RUN-START RELAY OUTPUT CIRCUIT VOLTAGE AT THE EPPM WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Reinstall EPPM feed Fuse (10A-RED) in the Underhood PDC in accordance with the Service Information. WARNING: Turn the ignition on then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (F943) Fused Run/Start Relay Output circuit between the (special tool #8443-25, 56 Way ACM Adapter) and ground. Is the voltage above 9.0 volts? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 8
8. CHECK (F943) RUN/START RELAY OUTPUT CIRCUIT FOR AN OPEN WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Turn the ignition off. Disconnect the Underhood JB harness connector. Measure the resistance of the (F943) Fused Run Start Relay Output circuit between the Underhood JB harness connector and the (special tool #8443-25, 56 Way ACM Adapter). Is the resistance 10 ohms or less? Yes Replace the Underhood JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair the (F943) Fused Run/Start Relay Output circuit for an Open. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
9. CHECK FUSED B+ CIRCUIT(S) AT RUN/START RELAY FOR AN OPEN OR HIGH RESISTANCE Turn the ignition off. Remove the Run/Start Relay from the Underhood JB. Turn the ignition on. Using a 12-volt test light connected to ground, check the Fused B+ circuits in the Run/Start Relay connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 10 No Repair the Fused B+ circuit(s) for an open circuit or high resistance. Perform EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
10. CHECK RUN/START RELAY CONTROL CIRCUIT OPERATION With the scan tool actuate the Run/Start Relay control to ON. Using a 12-volt test light connected to ground, check the Run/Start Relay Control circuit in the Run/Start Relay connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. With the scan tool, actuate the Run/Start Relay control to OFF. Did the test light illuminate as described above when the control was actuated ON? Yes Go To 11 No Go To 12
11. CHECK RUN/START RELAY CONNECTOR TERMINALS IN UNDERHOOD JB Turn the ignition off. Inspect the connectors where the Run/Start Relay connects to the Underhood JB. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the related connectors. Were any problems found? Yes Repair as necessary. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Replace Run/Start Relay in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
12. CHECK RUN/START RELAY CONNECTOR TERMINALS IN UNDERHOOD PDC Turn the ignition off. Inspect the connectors where the Run/Start Relay connects to the Underhood JB. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the related connectors. Perform any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Replace the Underhood JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

Scheme 12

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

With the ignition in the Run or Start position and every 10 ms throughout the ignition cycle.

If voltage on the (F943) Fused Ignition Switch Output (Run-Start) circuit is above 18 volts for 15 seconds. The code will go from active to stored, if the (F943) Ignition (Run-Start) circuit voltage is below 17 volts for 5 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. VERIFY THAT DTC B212C-17-IGNITION RUN/START INPUT - CIRCUIT VOLTAGE ABOVE THRESHOLD IS ACTIVE IN THE EPPM NOTE: Make sure the battery is fully charged. Turn the ignition on, then off, then on again, wait 15 seconds. With the scan tool, read (EPPM) DTCs. Does the scan tool display active: B212C-17-IGNITION RUN/START INPUT - CIRCUIT VOLTAGE ABOVE THRESHOLD? Yes Go To 2 No Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. INSPECT EPPM (ACTIVE HOOD) 10A RED FEED FUSE FOR AN OPEN Turn the ignition off. Remove the Active Hood Run/Start Feed Fuse from the JB and inspect the fuse. NOTE: Check connectors - Clean and repair as necessary. Is the Run/Start Relay fuse open? Yes Go To 3 No Go To 6
3. CHECK (F945) FUSED RUN/START RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND WITH EPPM CONNECTED WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the resistance of the (F945) Fused Ignition Switch Output Run/Start Relay circuit between ground and the Run-Start fuse output terminal in the JB. Is the resistance below 100.0 Ohms? Yes Go To 4 No Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Replace Run-Start Fuse. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECK (F945) FUSED RUN/START RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND WITH EPPM DISCONNECTED Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (F943) Fused Run/Start Relay Output circuit between ground and the output terminal side of the EPPM Active Hood Feed 10A Fuse in the JB. Is the resistance below 100.0 Ohms? No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Replace the 10A Run/Start EPPM Feed Fuse from the JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . Yes Go To 5
5. CHECK (F945) FUSED RUN/START RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND WITH THE JB DISCONNECTED Disconnect the JB harness connector. Measure the resistance of the (F943) Fused Run/Start Relay Output circuit between ground and the JB harness connector. Is the resistance 100 Ohms or less? Yes Repair the (F945) Fused Run/Start Relay Output circuit for a short to ground. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Replace the EPPM 10A Run/Start Feed fuse in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Replace the JB in accordance with the Service Information. Replace the EPPM Run/Start feed fuse in the JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
6. CHECK VOLTAGE AT THE INPUT SIDE OF THE EPPM 10A RUN/START FUSE CONNECTOR IN THE JB Turn the ignition on. Measure the voltage of the Underhood EPPM 10A feed fuse Run/Start Output circuit between the input side of the Fuse connector and ground. Is the voltage above 6.5 volts? Yes Go To 7 No Go To 9
7. CHECK (F945) 10A FUSED RUN-START RELAY OUTPUT CIRCUIT VOLTAGE AT THE EPPM WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Reinstall EPPM feed Fuse (10A-RED) in the JB in accordance with the Service Information. If the vehicle is equipped with the standard key ignition, follow this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If the vehicle is equipped with the keyless ignition, follow this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (F943) Fused Run/Start Relay Output circuit between the (special tool #8443-25, 56 Way ACM Adapter) and ground. Is the voltage above 6.5 volts? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 8
8. CHECK (F945) RUN/START RELAY OUTPUT CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the JB harness connector. Measure the resistance of the (F943) Fused Run Start Relay Output circuit between the JB harness connector and the (special tool #8443-25, 56 Way ACM Adapter). Is the resistance 10 Ohms or less? Yes Replace the JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair the (F943) Fused Run/Start Relay Output circuit for an Open. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
9. CHECK FUSED B+ CIRCUIT(S) AT RUN/START RELAY FOR AN OPEN OR HIGH RESISTANCE Turn the ignition off. Remove the Run/Start Relay from the JB. Turn the ignition on. Using a 12-volt test light connected to ground, check the Fused B+ circuits in the Run/Start Relay connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 10 No Repair the Fused B+ circuit(s) for an open circuit or high resistance. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
10. CHECK RUN/START RELAY CONTROL CIRCUIT OPERATION With the scan tool actuate the Run/Start Relay control to ON. Using a 12-volt test light connected to ground, check the Run/Start Relay Control circuit in the Run/Start Relay connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. With the scan tool, actuate the Run/Start Relay control to OFF. Did the test light illuminate as described above when the control was actuated ON? Yes Go To 11 No Go To 12
11. CHECK RUN/START RELAY CONNECTOR TERMINALS IN JB Turn the ignition off. Inspect the connectors where the Run/Start Relay connects to the JB. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the related connectors. Were any problems found? Yes Repair as necessary. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Replace the Run/Start Relay in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
12. CHECK RUN/START RELAY CONNECTOR TERMINALS IN JB Turn the ignition off. Inspect the connectors where the Run/Start Relay connects to the JB. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the related connectors. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Replace the JB in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B222A-VEHICLE LINE MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When powered, the Electronic Pedestrian Protection Module (EPPM) performs an internal self test. The repair of this fault centers on verifying the EPPM and Totally Integrated Power Module (TIPM) configuration. Configuration covering the model year, vehicle line, country code, body style, and LHD/RHD, and checking for differences between what is programmed in the EPPM and what is actually on the vehicle.

The EPPM checks its feature configuration for a stored Vehicle Line and Country Code continuously 12 seconds after initialization. The monitoring rate is done at startup during the first 16 seconds of the key cycle.

This DTC sets when the ORC detects a mismatch between the Vehicle Configuration and the EPPM configuration with in the early initialization. Once the code sets in this ignition cycle it stays active for this ignition cycle.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. Wait 12 seconds, then with the scan tool, read all active EPPM DTCs. Is the DTC active or stored? EPPM - ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Go To 2 EPPM - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. CHECK TIPM COUNTRY CODE AND VEHICLE LINE Using the scan tool, check for the correct Country Code, Vehicle Line, and Body Style. Does the Vehicle Configuration in the TIPM match the Vehicle Configuration in the EPPM? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Configure the TIPM in accordance with the service information. NOTE: The EPPM Reset Function must be performed after the repair to force the module to retest for this DTC. Access the Miscellaneous Function or Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation.

B22A6-00-ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) INTERNAL 1

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When powered, the Electronic Pedestrian Protection Module (EPPM) performs an internal self test. The repair of this fault condition does not involve any external circuitry and centers on verifying the integrity of the module's internal circuitry and software validity.

The EPPM checks the status and validity of the internal operating hardware and software at power up during the initialization process, and continuously through the ignition cycle.

This DTC sets when a fault is detected internal to EPPM hardware and/or software. Once set, this DTC is latched for the entire power cycle. If the same failure is detected in two consecutive power cycles, this DTC is latched active indefinitely.

Always Perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. REPLACE ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) Turn the ignition on. With the scan tool, erase and read EPPM DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. When this code is set, view repair. Repair Replace the Electronic Pedestrian Protection Module (EPPM) in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B22A7-00-ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) INTERNAL 2

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When powered, the Electronic Pedestrian Protection Module (EPPM) performs an internal self test. The repair of this fault condition does not involve any external circuitry and centers on verifying the integrity of the module's internal circuitry and software validity.

The EPPM checks the status and validity of the internal operating hardware and software at power up during the initialization process, and continuously through the ignition cycle.

This DTC sets when a fault is detected internal to ORC hardware and/or software. Once set, this DTC is latched for the entire power cycle. If the same failure is detected in two consecutive power cycles, this DTC is latched active indefinitely.

Always Perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. REPLACE ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) Turn the ignition on. With the scan tool, erase and read EPPM DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. When this code is set, view repair. Repair Replace the Electronic Pedestrian Protection Module (EPPM) in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B22A8-00-ELECTRONIC PEDESTRIAN PROTECTION MODULE FIRING STORED ENERGY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When powered, The Electronic Pedestrian Protection Module (EPPM) performs a self test of the capacitors used to initiate the squib deployment circuits in the event of collision detection. The repair of this fault condition does not involve any external circuitry and centers on verifying the integrity of these capacitors.

The EPPM checks the status and capacitance of the stored energy reserve at power up during the initialization process, and continuously through the ignition cycle.

This DTC will set if the EPPM detects a malfunction with the capacitors or internal circuitry used to initiate the squib deployment circuits. Once set, this DTC is latched for the entire ignition cycle. If two consecutive internal faults related to the roll over sensor are detected in one ignition cycle, the DTC is set as active indefinitely.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. REPLACE ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) Turn the ignition on. With the scan tool, erase and read EPPM DTCs. WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. When this code is set, view repair. Repair Replace the Electronic Pedestrian Protection Module (EPPM) in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

All Electronic Pedestrian Protection Module (EPPM) modules destined for service part usage are shipped in a state that inhibits the deployment of all supplemental restraint squib circuits (EPPM unlocked) for safe, initial installation. Once the EPPM initialization procedure is performed (EPPM locked). The EPPM enters a full state of readiness and can no longer transition to the unlocked status.

The EPPM will detect the Deployment Disable Status (EPPM LOCKED, EPPM UNLOCKED or EPPM IS RESPONDING WITH INCORRECT DATA) as soon as the ignition is turned on and the power is supplied to the new EPPM.

This DTC will be set as active for all service replacement EPPM modules prior to the initialization procedure (EPPM locked). This DTC is Active within four to six seconds for the EPPM unlocked state at start up. The DTC will change from Active to non Active state immediately upon the EPPM state changing to locked. The EPPM module will not show this DTC as Stored. It will just not show the DTC in a Stored state. Supply voltage range is 9 - 16 volts.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. CHECK FOR ADDITIONAL ACTIVE EPPM DTCS NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read the active EPPM DTC. Is B2769-00-EPPM UNLOCKED - ALL DEPLOYMENT DISABLED the only active DTC? Yes Go To 2 No Select the appropriate diagnostic procedure. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) .
2. INITIALIZE EPPM With the scan tool, select Initialize EPPM. The Scan Tool will display the current Deployment Disable Status (CURRENT STATUS) Select the CURRENT STATUS displayed on the Scan Tool. CURRENT STATUS LOCKED The EPPM is in a full state of readiness. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . CURRENT STATUS UNLOCKED Go To 3 CURRENT STATUS EPPM is Responding with incorrect Data With the scan tool, select MISC. FUNCTION or DIAGNOSTICS PROCEDURES and then EPPM RESET. After the EPPM RESET is complete: Restart this test at step 1. Go To 1
3. CHANGE EPPM STATUS Follow the instruction on the screen to change the status to LOCKED. The Scan Tool will display the result of the initialization. Does the Scan Tool display: EPPM LOCK Successful? Yes CURRENT STATUS is EPPM LOCK Successful Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 4
4. INCOMPLETE OR FAILED EPPM INITIALIZATION Does the Scan Tool display: EPPM Initialization Failed? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. CURRENT STATUS is EPPM Initialization Failed Replace the EPPM in accordance with service information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No CURRENT STATUS is Current and original VIN have not been learned by EPPM. With the scan tool, select MISC. FUNCTION or DIAGNOSTICS PROCEDURES and then EPPM RESET. After the RESET is complete: Restart this test at step 1. Go To 1

B2736-49-LEFT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR - INTERNAL FAILURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The pedestrian impact sensors perform their own self test using power supplied by the Electronic Pedestrian Protection Module (EPPM) then communicate this status back to the EPPM with periodic updates. The repair of this fault condition involves verifying the integrity of the wiring between the EPPM and the impact sensors.

The impact sensor performs a self test for internal circuitry at power up during the initialization process, and continuously through the ignition cycle every 0.25 - 10 ms.

This DTC sets when the ORC receives notification of a self test failure within the impact sensor within 1 second for continuous test and 100 ms for startup test. Once set, this DTC is latched for the entire ignition cycle.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. CHECK FOR OTHER SENSOR INTERNAL DTCS NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, clear the faults. With the scan tool, read EPPM DTCs. Are there any other Sensor Internal DTCs present? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also, inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Repair as necessary. Disconnect then reconnect the sensor into the wire harness. Make sure connectors are fully connected and locking tab is secure. If the vehicle is equipped with the standard key ignition, follow this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If the vehicle is equipped with the keyless ignition, follow this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Cycle power on then off, wait one minute, and read active codes. The EPPM Reset Function must be performed to force the module to retest for this DTC. Perform the EPPM module reset. Access the Miscellaneous Function or Diagnostics Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. If the DTC is Stored, Repair as necessary and perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If DTC is still Active, go to step 2 . No Go To 2
2. CHECK OPERATION OF THE LEFT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Left Pedestrian Protection Satellite Acceleration Sensor in accordance with the Service Information. Refer to «SENSOR, IMPACT, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Reconnect the vehicle body harness to the impact sensor. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase the stored codes in all EPPM system modules. NOTE: The EPPM Reset Function must be performed after the repair to force the module to retest for this DTC. Perform the EPPM module reset. Access the Miscellaneous Function or Diagnostics Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Did the active B2736-49-LEFT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR - INTERNAL FAILURE DTC return? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair is complete. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B2736-78-LEFT PEDESTRIAN PROTECTION SATELLITE SENSOR ALIGNMENT OR ADJUSTMENT INCORRECT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

If there is only one pedestrian protection satellite sensor seeing high g's repeatedly. This would mean a single sensor alignment, sensor not torqued fitting is loose, or some other component may be vibrating or rattling against the sensor. For the description and location of the sensors, refer to SENSOR, IMPACT, DESCRIPTION . For operation of the sensors, refer to SENSOR, IMPACT, OPERATION .

At startup and then continuously.

This code will set when a deployment threshold has been exceeded by one of the three pedestrian protection satellite sensors in the same ignition cycle. Confirmation to deploy from a second pedestrian protection satellite sensor is not received. The current threshold for setting this DTC is 100 occurrences within an ignition cycle. This code can set independently for each sensor. This code will be set for the entire ignition cycle. The Airbag Warning Lamp (AWL) will set for this code.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. VERIFY THE DTC IS ACTIVE NOTE: This DTC must be active for the results of this test to be valid. Perform any Technical Service Bulletins (TSBs) that may apply. Ignition on, engine not running. Using the scan tool, read and record DTCs. Using the scan tool, erase DTCs. A EPPM module reset needs to be done to retest for the active code. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Road test the vehicle. Using the scan tool, read DTCs. Is the DTC active at this time? Yes Go To 2 No Inspect the front end of the vehicle covering fascia, grille, and looking under vehicle for possible damage. Pay extra attention to the pedestrian protection sensor areas for possible damage. Perform the EPPM SYSTEM INTERMITTENT CONDITION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. INSPECT THE PEDESTRIAN PROTECTION SATELLITE SENSOR ALIGNMENT, FOR INCORRECT INSTALLATION OR DAMAGE NOTE: If available, check the vehicle repair history for collision damage. Such as a low speed impact with no system deployment and now there is damage. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Turn the ignition off. Inspect the front end of the vehicle covering fascia, grille, and looking under vehicle for possible damage. Pay extra attention to the pedestrian protection sensor areas for possible damage. Inspect the torque of the suspect sensor for a possible loose connection. Were any problems found? Yes Repair as necessary. Clear DTCs. Test drive vehicle to recreate road vibration to confirm repair. Reset the EPPM. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Perform this operation if the DTC is stored, repair as necessary and perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If the DTC is still active, replace the EPPM. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B2737-49-RIGHT-PEDESTRIAN-PROTECTION-SATELLITE-ACCELERATION-SENSOR-INTERNAL-FAILURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The right pedestrian impact sensor performs its own self test using power supplied by the Electronic Pedestrian Protection Module (EPPM) then communicate this status back to the EPPM with periodic updates. The repair of this fault condition involves verifying the integrity of the wiring between the EPPM and the sensors.

The impact sensor performs a self test for internal circuitry at power up during the initialization process, and continuously through the ignition cycle every 0.25 - 10 ms.

This DTC sets when the EPPM receives notification of a self test failure within the impact sensor within 1 second for continuous test and 100 ms for startup test. Once set, this DTC is latched for the entire ignition cycle.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. CHECK FOR OTHER SENSOR INTERNAL DTCS NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, clear the faults. With the scan tool, read EPPM DTCs. Are there any other Sensor Internal DTCs present? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also, inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Repair as necessary. Disconnect then reconnect the sensor into the wire harness. Make sure connectors are fully connected and locking tab is secure. If the vehicle is equipped with the standard key ignition, follow this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If the vehicle is equipped with the keyless ignition, follow this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Cycle power on then off, wait one minute, and read active codes. The EPPM Reset Function must be performed to force the module to retest for this DTC. Perform the EPPM module reset. Access the Miscellaneous Function or Diagnostics Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. If the DTC is Stored, repair as necessary and perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If DTC is still Active, go to step 2 . No Go To 2
2. CHECK OPERATION OF THE RIGHT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Right Pedestrian Protection Satellite Acceleration Sensor in accordance with the Service Information. Refer to «SENSOR, IMPACT, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Reconnect the vehicle body harness to the impact sensor. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase the stored codes in all EPPM system modules. NOTE: The EPPM Reset Function must be performed after the repair to force the module to retest for this DTC. Perform EPPM module reset. Access the Miscellaneous Function or Diagnostics Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Did the active B2737-49-RIGHT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR - INTERNAL FAILURE DTC return? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair is complete. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/airbag/#occupant-restraint-controller-orc-restraint-system-intermittent-test-pre-diagnostic-procedure-verification-test) .

B2737-78-RIGHT PEDESTRIAN PROTECTION SATELLITE SENSOR ALIGNMENT OR ADJUSTMENT INCORRECT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

If there is only one pedestrian protection satellite sensor seeing high g's repeatedly. This would mean a single sensor alignment, sensor not torqued fitting is loose, or some other component may be vibrating or rattling against the sensor. For the description and location of the sensors, refer to SENSOR, IMPACT, DESCRIPTION . For operation of the sensors, refer to SENSOR, IMPACT, OPERATION .

At startup and then continuously.

This code will set when a deployment threshold has been exceeded by one of the three pedestrian protection satellite sensors in the same ignition cycle. Confirmation to deploy from a second pedestrian protection satellite sensor is not received. The current threshold for setting this DTC is 100 occurrences within an ignition cycle. This code can set independently for each sensor. This code will be set for the entire ignition cycle. The Airbag Warning Lamp (AWL) will set for this code.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. VERIFY THE DTC IS ACTIVE NOTE: This DTC must be active for the results of this test to be valid. Perform any Technical Service Bulletins (TSBs) that may apply. Ignition on, engine not running. Using the scan tool, read and record DTCs. Using the scan tool, erase DTCs. A EPPM module reset needs to be done to retest for the active code. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Road test the vehicle. Using the scan tool, read DTCs. Is the DTC active at this time? Yes Go To 2 No Inspect the front end of the vehicle covering fascia, grille, and looking under vehicle for possible damage. Pay extra attention to the pedestrian protection sensor areas for possible damage. Perform the EPPM SYSTEM INTERMITTENT CONDITION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. INSPECT THE PEDESTRIAN PROTECTION SATELLITE SENSOR ALIGNMENT, FOR INCORRECT INSTALLATION OR DAMAGE NOTE: If available, check the vehicle repair history for collision damage. Such as a low speed impact with no system deployment and now there is damage. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Turn the ignition off. Inspect the front end of the vehicle covering fascia, grille, and looking under vehicle for possible damage. Pay extra attention to the pedestrian protection sensor areas for possible damage. Inspect the torque of the suspect sensor for a possible loose connection. Were any problems found? Yes Repair as necessary. Clear DTCs. Test drive vehicle to recreate road vibration to confirm repair. Reset the EPPM. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Perform this operation if the DTC is stored, repair as necessary and perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If the DTC is still active, replace the EPPM. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B2738-49-CENTER PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR - INTERNAL FAILURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The pedestrian impact sensors perform their own self test using power supplied by the Electronic Pedestrian Protection Module (EPPM) then communicate this status back to the EPPM with periodic updates. The repair of this fault condition involves verifying the integrity of the wiring between the EPPM and the impact sensors.

The impact sensor performs a self test for internal circuitry at power up during the initialization process, and continuously through the ignition cycle every 0.25 - 10 ms.

This DTC sets when the ORC receives notification of a self test failure within the impact sensor within 1 second for continuous test and 100 ms for startup test. Once set, this DTC is latched for the entire ignition cycle.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. CHECK FOR OTHER SENSOR INTERNAL DTCS NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, clear the faults. With the scan tool, read EPPM DTCs. Are there any other Sensor Internal DTCs present? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also, inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Repair as necessary. Disconnect then reconnect the sensor into the wire harness. Make sure connectors are fully connected and locking tab is secure. If the vehicle is equipped with the standard key ignition, follow this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If the vehicle is equipped with the keyless ignition, follow this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Cycle power on then off, wait one minute, and read active codes. The EPPM Reset Function must be performed to force the module to retest for this DTC. Perform the EPPM module reset. Access the Miscellaneous Function or Diagnostics Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. If the DTC is Stored, repair as necessary and perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If DTC is still Active, go to step 2 . No Go To 2
2. CHECK OPERATION OF THE CENTER PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Center Pedestrian Protection Satellite Acceleration Sensor in accordance with the Service Information. Refer to «SENSOR, IMPACT, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Reconnect the vehicle body harness to the impact sensor. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase the stored codes in all EPPM system modules. NOTE: The EPPM Reset Function must be performed after the repair to force the module to retest for this DTC. Perform the EPPM module reset. Access the Miscellaneous Function or Diagnostics Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Did the active B2738-49-CENTER PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR - INTERNAL FAILURE DTC return? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair is complete. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B2738-78-CENTER PEDESTRIAN PROTECTION SATELLITE SENSOR ALIGNMENT OR ADJUSTMENT INCORRECT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

If there is only one pedestrian protection satellite sensor seeing high g's repeatedly. This would mean a single sensor alignment, sensor not torqued fitting is loose, or some other component may be vibrating or rattling against the sensor. For the description and location of the sensors, refer to SENSOR, IMPACT, DESCRIPTION . For operation of the sensors, refer to SENSOR, IMPACT, OPERATION .

At startup and then continuously.

This code will set when a deployment threshold has been exceeded by one of the three pedestrian protection satellite sensors in the same ignition cycle. Confirmation to deploy from a second pedestrian protection satellite sensor is not received. The current threshold for setting this DTC is 100 occurrences within an ignition cycle. This code can set independently for each sensor. This code will be set for the entire ignition cycle. The Airbag Warning Lamp (AWL) will set for this code.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. VERIFY THE DTC IS ACTIVE NOTE: This DTC must be active for the results of this test to be valid. Perform any Technical Service Bulletins (TSBs) that may apply. Ignition on, engine not running. Using the scan tool, read and record DTCs. Using the scan tool, erase DTCs. A EPPM module reset needs to be done to retest for the active code. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Road test the vehicle. Using the scan tool, read DTCs. Is the DTC active at this time? Yes Go To 2 No Inspect the front end of the vehicle covering fascia, grille, and looking under vehicle for possible damage. Pay extra attention to the pedestrian protection sensor areas for possible damage. Perform the EPPM SYSTEM INTERMITTENT CONDITION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. INSPECT THE PEDESTRIAN PROTECTION SATELLITE SENSOR ALIGNMENT, FOR INCORRECT INSTALLATION OR DAMAGE NOTE: If available, check the vehicle repair history for collision damage. Such as a low speed impact with no system deployment and now there is damage. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Turn the ignition off. Inspect the front end of the vehicle covering fascia, grille, and looking under vehicle for possible damage. Pay extra attention to the pedestrian protection sensor areas for possible damage. Inspect the torque of the suspect sensor for a possible loose connection. Were any problems found? Yes Repair as necessary. Clear DTCs. Test drive vehicle to recreate road vibration to confirm repair. Reset the EPPM. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Perform this operation if the DTC is stored, repair as necessary and perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If the DTC is still active, replace the EPPM. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B276A-00-EPPM SQUIB CONFIGURATION MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring.

The EPPM checks for the presence of a device once at every power up during the module initialization process.

This DTC sets when the EPPM detects a squib diagnosed as present when it should not be. Once set, this DTC will go from active to stored upon the squib being diagnosed as not present.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read EPPM DTCs. Is the DTC active or stored? EPPM - ACTIVE DTC Go To 2 EPPM - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. CHECK EPPM AND VEHICLE CONFIGURATION With the scan tool, check the EPPM and Vehicle Configuration. With the scan tool, check for resistance present on one unused Squib component and not the other. Is there resistance present on any one unused squib component and not the other? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair the unused Squib circuit in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No NOTE: Make sure the part number of the replacement module is the correct part number for the vehicle. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

B276B-11-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO GROUND

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the Supplemental Restraints System (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200ms thereafter while the ignition is in on

The EPPM will set this DTC if it detects short to ground on the EPPM Squib 1 circuits for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the short to ground for more than 2.6 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 1 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276B-11-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO GROUND - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R176) EPPM SQUIB 1 LINE 1 CIRCUIT AND THE (R177) EPPM SQUIB 1 LINE 2 CIRCUIT FOR A SHORT TO GROUND WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the SRS Load Tool (special tool #8443-25, 56 Way ACM Adapter) to the EPPM module harness connectors. Measure the resistance of the (R176) Electronic Pedestrian Protection Hood Hinge Actuator Squib 1 Line 1 circuit between (special tool #8443-25, 56 Way ACM Adapter) cavity 17 of the 24way side and ground. Measure the resistance of the (R177) Electronic Pedestrian Protection Hood Hinge Actuator Squib 1 Line 2 circuit between (special tool #8443-25, 56 Way ACM Adapter) cavity 18 of the 24way side and ground. Is the resistance below 10k Ohms on either circuit? Yes Repair the EPPM Squib 1 circuits with resistance below 10k Ohms for a short to ground. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276B-12-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects a short to voltage on the EPPM Squib 1 circuits. The DTC sets when the EPPM squib circuits have become shorted to voltage for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the short to voltage for more than 2.6 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 1 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276B-12-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO BATTERY - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R176) EPPM SQUIB 1 LINE 1 CIRCUIT AND THE (R177) EPPM SQUIB 1 LINE 2 CIRCUIT FOR A SHORT TO BATTERY WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM module harness connectors. Measure the voltage of the (R176) Electronic Pedestrian Protection Hood Hinge Actuator Squib 1 Line 1 circuit between (special tool #8443-25, 56 Way ACM Adapter) cavity 17 of the 24way side and ground. Measure the voltage of the (R177) Electronic Pedestrian Protection Hood Hinge Actuator Squib 1 Line 2 circuit between (special tool #8443-25, 56 Way ACM Adapter) cavity 18 of the 24way side and ground. Is there voltage present on either circuit? Yes Repair the EPPM Squib 1 circuits with voltage for a short to battery. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276B-13-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

With the ignition on. The EPPM sends out a 40 mA diagnostic current on each squib voltage supply circuit at power up and every 200 ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects an open or high resistance on the EPPM Squib 1 circuits. The DTC will set when the EPPM squib 1 circuits become open for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the open for more than 2.6 seconds. The Airbag Warning Lamp (AWL) will be on while faulted condition is active. The AWL will turn off as soon as the condition is removed and the fault causing the lamp to be "on" dematures.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 1 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276B-13-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - OPEN - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R176) EPPM SQUIB 1 LINE 1 CIRCUIT FOR AN OPEN WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (R176) EPPM Squib 1 Line 1 circuit between the Electronic Pedestrian Protection Hood Hinge Actuator connector cavity 1 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 17 of the 24-way side. Is the resistance below 5.4 - 6.5 Ohms? Yes Go To 4 No Repair the (R176) EPPM Squib 1 Line 1 circuit for an open. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECK THE (R177) EPPM SQUIB 1 LINE 2 CIRCUIT FOR AN OPEN Measure the resistance of the (R177) EPPM Squib 1 Line 2 circuit between the Electronic Pedestrian Protection Hood Hinge Actuator cavity 2 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 18 of the 24-way side. Is the resistance below 5.4 - 6.5 Ohms? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair the (R177) EPPM Squib 1 Line 2 circuit for an open. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
5. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276B-2B-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - WIRES SHORTED TOGETHER

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the Supplemental Restraints System (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects low resistance between the EPPM Squib 1 circuits. The DTC will set when the EPPM squib 1 circuits become shorted together for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the shorted together for more than 2.6 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 1 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276B-2B-LEFT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - WIRES SHORTED TOGETHER - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R176) EPPM SQUIB 1 LINE 1 CIRCUIT FOR A SHORT TO THE (R177) EPPM SQUIB 1 LINE 2 CIRCUIT WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM connectors. Measure the resistance between the (R176) EPPM Squib 1line 1 circuit cavity 17 of the 24way side and the (R177) EPPM Squib 1 line 2 circuit cavity 18 of the 24way side at the (special tool #8443-25, 56 Way ACM Adapter). Is the resistance below 1.24 - 1.71 Ohms? Yes Repair the (R176) EPPM Squib 1line 1 circuit for a short to the (R177) EPPM Squib 1 line 2 circuit. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276C-11-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO GROUND

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the Supplemental Restraints System (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the SRS Load Tool (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects short to ground on the EPPM Squib 2 circuits for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the short to ground for more than 2.6 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 2 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276C-11-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO GROUND - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R178) EPPM SQUIB 2 LINE 1 CIRCUIT AND THE (R179) EPPM SQUIB 2 LINE 2 CIRCUIT FOR A SHORT TO GROUND WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the SRS Load Tool (special tool #8443-25, 56 Way ACM Adapter) to the EPPM module harness connectors. Measure the resistance of the (R178) Electronic Pedestrian Protection Hood Hinge Actuator Squib 2 Line 1 circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 17 of the 24-way side and ground. Measure the resistance of the (R179) Electronic Pedestrian Protection Hood Hinge Actuator Squib 2 Line 2 circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 18 of the 24-way side and ground. Is the resistance below 10k Ohms on either circuit? Yes Repair the EPPM Squib 2 circuits with resistance below 10k Ohms for a short to ground. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276C-12-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200 ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects a short to voltage on the EPPM Squib 2 circuits. The DTC sets when the EPPM squib 2 circuits have become shorted to voltage for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the short to voltage for more than 2.6 seconds. The Airbag Warning Lamp (AWL) will be on while faulted condition is active. The AWL will turn off as soon as the condition is removed and the fault causing the lamp to be "on" dematures.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 2 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276C-12-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - SHORT TO BATTERY - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R178) EPPM SQUIB 2 LINE 1 CIRCUIT AND THE (R179) EPPM SQUIB 2 LINE 2 CIRCUIT FOR A SHORT TO BATTERY WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM module harness connectors. Measure the voltage of the (R178) Electronic Pedestrian Protection Hood Hinge Actuator Squib 2 Line 1 circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 20 of the 24way side and ground. Measure the voltage of the (R179) Electronic Pedestrian Protection Hood Hinge Actuator Squib 2 Line 2 circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 19 of the 24way side and ground. Is there voltage present on either circuit? Yes Repair the EPPM Squib 2 circuits with voltage for a short to battery. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276C-13-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects an open or high resistance on the EPPM Squib 2 circuits. The DTC will set when the EPPM squib 2 circuits become open for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the open for more than 2.6 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 2 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276C-13-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - OPEN - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R179) SQUIB 2 LINE 1 CIRCUIT FOR AN OPEN Disconnect the (special tool #8443A, SRS Load Tool) and (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connector. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (R179) EPPM Squib 2 Line 1 circuit between the Electronic Pedestrian Protection Hood Hinge Actuator connector cavity 2 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 19 of the 24way side. Is the resistance below 5.4 - 6.5 Ohms? Yes Go To 4 No Repair the (R179) EPPM Squib 2 Line 1 circuit for an open. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECK THE (R178) EPPM SQUIB 2 LINE 2 CIRCUIT FOR AN OPEN Measure the resistance of the (R178) EPPM Squib 2 Line 2 circuit between the Electronic Pedestrian Protection Hood Hinge Actuator cavity 1 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 20 of the 24way side. Is the resistance below 5.4 - 6.5 Ohms? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair the (R178) EPPM Squib 2 Line 2 circuit for an open. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/airbag/#occupant-restraint-controller-orc-restraint-system-intermittent-test-pre-diagnostic-procedure-verification-test) .
5. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

B276C-2B-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - WIRES SHORTED TOGETHER

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For description of the Electronic Pedestrian Protection Module (EPPM), refer to ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, DESCRIPTION . For operation of the EPPM, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION . When powered, the EPPM sends a test current to the Electronic Pedestrian Protection actuator squibs to verify the integrity of the squib and the wiring. Use of the Supplemental Restraints System (special tool #8443A, SRS Load Tool) in the tests below substitutes a suspect EPPM actuator squib with a known good component. The use of the (special tool #8443-25, 56 Way ACM Adapter) provides a test point, as well as a method for opening the shorting bar connections within the harness connector. The EPPM is powered by a Ignition Run/Start (F943) control output circuit through the 32 pin connector side of the 56 way EPPM module connector. The 32 pin connector side of the 56 way EPPM module connector provides ground.

The EPPM sends out a 40mA diagnostic current on each squib voltage supply circuit at power up and every 200ms thereafter while the ignition is in on.

The EPPM will set this DTC if it detects low resistance between the EPPM Squib 2 circuits. The DTC will set when the EPPM squib 2 circuits become shorted together for more than 2.6 seconds. The DTC will go from active to stored when the module sees a recovery from the shorted together for more than 2.6 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure that the battery is fully charged. NOTE: The scan tool, (special tool #8443A, SRS Load Tool), and DVOM are required to perform the following test. Turn the ignition on. Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 4
2. CHECK FOR SHORTED SQUIB CIRCUITS IN THE EPPM SQUIB 2 CIRCUITS WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM squib harness connector. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) to the Electronic Pedestrian Protection Hood Hinge Actuator harness connector. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the active EPPM DTCs. Does the scan tool display: B276C-2B-RIGHT HOOD HINGE PEDESTRIAN PROTECTION SQUIB - WIRES SHORTED TOGETHER - DTC? Yes Go To 3 No Replace the Electronic Pedestrian Protection Hood Hinge Actuator in accordance with the Service Information. Refer to «ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information__removal) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
3. CHECK THE (R179) EPPM SQUIB 2 LINE 1 CIRCUIT FOR A SHORT TO THE (R178) EPPM SQUIB 2 LINE 2 CIRCUIT WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the (special tool #8443A, SRS Load Tool) and the (special tool #8443-10, SRS Adapter) from the Electronic Pedestrian Protection Hood Hinge Actuator Squib harness connectors. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM connectors. Measure the resistance between the (R179) EPPM Squib 2 line 1 circuit cavity 19 of the 24way side and the (R178) EPPM Squib 2 line 2 circuit cavity 20 of the 24way side at the (special tool #8443-25, 56 Way ACM Adapter). Is the resistance below 1.24 - 1.71 Ohms? Yes Repair the (R179) EPPM Squib 2 line 1 circuit for a short to the (R178) EPPM Squib 2 line 2 circuit. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
4. CHECKING STORED OR INTERMITTENT CODES NOTE: Diagnose and repair all active codes before diagnosing stored codes. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for a complete list of EPPM system diagnostic procedures. With the scan tool, record and erase all EPPM System Module DTCs. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors for chafed, pierced, pinched, and partially broken wires, and for broken, bent, pushed out, corroded, and contaminated terminals. Repair as necessary. Reconnect all disconnected components and harness connectors. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, monitor for active codes while performing the following: Wiggle the wiring harness and connectors of the related EPPM circuit. Continue the test until either a code becomes active or the problem area is isolated. In the previous steps you have attempted to recreate the conditions responsible for setting the DTC in question/causing the intermittent condition. Are any ACTIVE DTCs present? Yes Select the appropriate diagnostic procedure from the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No No problem found at this time. Erase all codes before returning the vehicle to the customer.

U0002-CAN C BUS OFF PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When powered, the Electronic Pedestrian Protection module (EPPM) "listens" to the serial data bus for the broadcast of various serial data messages.

The EPPM checks for serial data message traffic at power up during the initialization process, and continuously through the ignition cycle. The EPPM repeats its check of Serial Data traffic every 20ms.

This DTC sets when the EPPM fails to detect serial data message traffic for more than 2 seconds. In the event the EPPM detects serial data message traffic, this DTC will immediately transition to stored status taking no longer than 1 second.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read EPPM DTCs. Is the DTC active or stored? ORC - ACTIVE DTC Go To 2 ORC - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. CHECK (D222) CAN C BUS (-) CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the appropriate harness connector. Turn the ignition on. Measure the voltage of the (D222) CAN C BUS (-) circuit between the appropriate harness connector and ground. Is there any voltage present? Yes Repair the (D222) CAN C BUS (-) circuit for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 3
3. CHECK (D221) CAN C BUS (+) CIRCUIT FOR A SHORT TO VOLTAGE Measure the voltage of the (D221) CAN C BUS (+) circuit between the appropriate harness connector and ground. Is there any voltage present? Yes Repair the (D221) CAN C BUS (+) circuit for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 4
4. CHECK (D221) CAN C BUS (+) CIRCUIT FOR AN OPEN WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the EPPM harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (D221) CAN C BUS (+) circuit between the appropriate harness connector and the (special tool #8443-25, 56 Way ACM Adapter) cavity 24-1. Is resistance below 5.0 Ohms? Yes Go To 5 No Repair the (D221) CAN C BUS (+) circuit for an open in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
5. CHECK (D222) CAN C BUS (-) CIRCUIT FOR AN OPEN Measure the resistance of the (D222) CAN C BUS (-) circuit between the appropriate harness connector and the (special tool #8443-25, 56 Way ACM Adapter) cavity 24-2. Is resistance below 5.0 Ohms? Yes Go To 6 No Repair the (D222) CAN C BUS (-) circuit for an open in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
6. CHECK (D221) CAN C BUS (+) CIRCUIT FOR A SHORT TO GROUND Measure the resistance of the (D221) CAN C BUS (+) circuit between ground and the appropriate harness connector. Is the resistance below 100.0 Ohms? Yes Repair the (D221) CAN C BUS (+) circuit for a short to ground in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 7
7. CHECK (D222) CAN C BUS (-) CIRCUIT FOR A SHORT TO GROUND Measure the resistance of the (D222) CAN C BUS (-) circuit between ground and the appropriate harness connector. Is the resistance below 100.0 Ohms? Yes Repair the (D222) CAN C BUS (-) circuit for a short to ground in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

U0146-LOST COMMUNICATION WITH CENTRAL GATEWAY (TIPM)

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

The battery voltage between 10.0 and 16.0 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display active: U0146-LOST COMMUNICATION WITH CENTRAL GATEWAY? Yes Refer to «TOTALLY INTEGRATED POWER MODULE (TIPM) - DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/communication-devices/#totally-integrated-power-module-tipm-diagnostic-code-index) and perform the U0141-LOST COMMUNICATION WITH IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2010-2016/remont/communication-devices/#communication-non-dtc-based-diagnostics) and perform the STORED LOST COMMUNICATION DTCs diagnostic procedure.

U1110-00-LOST VEHICLE SPEED MESSAGE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Electronic Pedestrian Protection Module (EPPM) receives the vehicle speed signal over the CAN C bus from the Anti-lock Brake Module (ABS), Electronic Stability Program (ESP), and Electronic Stability Control (ESC).

Ignition on.

The EPPM does not receive a vehicle speed signal from the Anti-Lock Brake Module (ABS), Electronic Stability Program (ESP) and Electronic Stability Control (ESC) over the CAN C bus. The Airbag Warning Lamp (AWL) on while faulted condition is active. The AWL will go off as soon as the fault condition is removed and the fault causing the lamp to be "on" dematures.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Ignition on, engine not running. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Go To 2 No Perform the EPPM SYSTEM INTERMITTENT TEST diagnostic procedure. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. U0121-LOST COMMUNICATION WITH ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE ALSO SET With a scan tool, select View DTCs. Do any of the following DTCS or any DTCS set, DTC U0121-LOST COMMUNICATION WITH ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE, U0422-00-IMPLAUSIBLE DATA RECEIVED FROM BODY CONTROL MODULE (TIPM)? Yes Refer to «TOTALLY INTEGRATED POWER MODULE (TIPM) - DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/communication-devices/#totally-integrated-power-module-tipm-diagnostic-code-index) and perform the appropriate diagnostic procedure. No Replace and program the Electronic Pedestrian Protection Module (EPPM) in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

U1175-00-LOST IGNITION STATUS MESSAGE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Electronic Pedestrian Protection Module (EPPM) receives the ignition status message over the CAN C bus from the Electronic Ignition System.

Ignition on.

The EPPM doesn't receive a vehicle ignition switch status signal from the Electronic Ignition System (EIS) over the CAN C bus for 25 seconds to set the active code. The EPPM receives a vehicle speed signal for over one second to recover and change to a stored code. The Airbag Warning Lamp (AWL) is on while faulted condition is active.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to EPPM SYSTEM PRE-DIAGNOSTIC PROCEDURE .

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Ignition on, engine not running. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Go To 2 No Perform the INTERMITTENT CONDITION diagnostic procedure. Refer to the appropriate Testing & Diagnostics article under Engine Performance .
2. U0121-LOST COMMUNICATION WITH ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE ALSO SET With a scan tool, select View DTCs. Is the DTC U0121-LOST COMMUNICATION WITH ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE OR ANY LOST COMMUNICATION DTCS also set? Yes Refer to «TOTALLY INTEGRATED POWER MODULE (TIPM) - DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/communication-devices/#totally-integrated-power-module-tipm-diagnostic-code-index) and perform the U0141-00-LOST COMMUNICATION WITH TIPM diagnostic procedure. No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Refer to «MODULE, POWERTRAIN CONTROL, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/communication-devices/#electronic-control-modules-service-information) . Perform the PCM/POWERTRAIN VERIFICATION TEST. Refer to the appropriate Testing & Diagnostics article under Engine Performance .

U119E-00-LOST COMMUNICATION W/LEFT-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The pedestrian protection impact sensors perform their own self test using power supplied by the Electronic Pedestrian Protection module (EPPM) then communicate this status back to the EPPM with periodic updates. The repair of this fault condition involves verifying the integrity of the wiring between the EPPM and the sensor. For EPPM Description information, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For EPPM Operation information, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION .

The EPPM monitors communication with the Left Pedestrian Protection Impact sensor continuously.

This DTC sets when the EPPM no longer receives notification of the status update from the left pedestrian protection satellite acceleration sensor. Once set, this DTC is latched for the entire ignition cycle. This code will set active if the loss of communication with the sensor has lasted for more then 2.5 seconds. The fault will go stored on the next key cycle upon the fault not setting for longer then 2.5 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read EPPM DTCs. Is the DTC active or stored? EPPM - ACTIVE DTC Go To 2 EPPM - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. CHECK FOR ADDITIONAL ACTIVE SATELLITE SENSOR DTCS NOTE: The scan tool, (special tool #8443-25, 56 Way ACM Adapter), and a DVOM are required to perform the following tests. With the scan tool, read all active EPPM DTCs. Is DTCS U119F-00-LOST COMMUNICATION W/RIGHT-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR and U11A0-00-LOST COMMUNICATION W/CENTER-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR also active? Yes Go To 8 No Go To 3
3. CHECK (R170) LEFT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR AN OPEN WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Left Pedestrian Impact Sensor harness connector. Disconnect the EPPM harness connectors. NOTE: Check the connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (R170) Left Pedestrian Impact Sensor Signal circuit between the Right Pedestrian Impact Sensor harness connector cavity 2 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 12. Is the resistance below 1.0 Ohm? Yes Go To 4 No Repair or replace the (R170) Left Pedestrian Impact Sensor Signal circuit for an open in accordance with the Service Information. Then, Go To 4
4. CHECK (R171) LEFT PEDESTRIAN IMPACT SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (R171) Left Pedestrian Impact Sensor Ground circuit between the Left Pedestrian Impact Sensor harness connector cavity 1 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 10. Is the resistance below 1.0 Ohm? Yes Go To 5 No Repair or replace the (R171) Left Pedestrian Impact Sensor Ground circuit for an open in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
5. CHECK (R170) LEFT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO THE (R171) LEFT PEDESTRIAN IMPACT SENSOR GROUND CIRCUIT Measure the resistance between the (R170) Left Pedestrian Impact Sensor Signal circuit cavity 2 and the (R171) Left Pedestrian Impact Sensor Ground circuit cavity 1 at the Right Pedestrian Impact Sensor harness connector. Is the resistance below 5K Ohms? Yes Repair or replace the (R170) Left Pedestrian Impact Sensor Signal circuit for a short to the (R171) Left Pedestrian Impact Sensor Ground circuit in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 6
6. CHECK (R170) LEFT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance of the (R170) Left Pedestrian Impact Sensor Signal circuit between ground and the Left Pedestrian Impact Sensor cavity 2 harness connector. Is the resistance below 6K Ohms? Yes Repair or replace the (R170) Left Pedestrian Impact Sensor Signal circuit for a short to ground in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 7
7. CHECK (R170) LEFT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (R170) Left Pedestrian Impact Sensor Signal circuit between the Left Pedestrian Impact Sensor Signal harness connector cavity 2 and ground. Is there any voltage present? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair or replace the (R170) Left Pedestrian Impact Sensor Signal circuit for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If DTC U119F-00-LOST COMMUNICATION W/RIGHT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR is still active, go to step 8 . Otherwise, test complete.
8. CHECK (R172) RIGHT PEDESTRIAN IMPACT SIGNAL CIRCUIT AND (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT AND (R170) LEFT PEDESTRIAN IMPACT SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Center Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the Right Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the Left Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the EPPM harness connectors. NOTE: Check the connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (R174) Center Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 32- 29 and ground. Measure the voltage of the (R170) Left Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 12 and ground. Measure the voltage of the (R172) Right Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 9 and ground. Is there any voltage present? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair or replace the impact sensor circuit with voltage present for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 9
9. CHECK OPERATION OF LEFT PEDESTRIAN IMPACT SENSOR WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Left Pedestrian Impact Sensor. Refer to «SENSOR, IMPACT, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Reconnect the vehicle body harness to the impact sensor. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase all codes in the EPPM. Perform EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Did the active DTC U119E-00-LOST COMMUNICATION W/LEFT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR return? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair is complete. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

U119F-00-LOST COMMUNICATION W/RIGHT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The pedestrian protection impact sensors perform their own self test using power supplied by the Electronic Pedestrian Protection module (EPPM) then communicate this status back to the EPPM with periodic updates. The repair of this fault condition involves verifying the integrity of the wiring between the EPPM and the sensor. For EPPM Description information, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For EPPM Operation information, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION .

The EPPM monitors communication with the Right Pedestrian Protection Impact sensor continuously.

This DTC sets when the EPPM no longer receives notification of the status update from the right pedestrian protection satellite acceleration sensor. Once set, this DTC is latched for the entire ignition cycle. This code will set active if the loss of communication with the sensor has lasted for more then 2.5 seconds. This fault is latched for the full ignition cycle. The fault will go stored on the next key cycle upon the fault not setting for longer then 2.5 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. Using the scan tool, read EPPM DTCs. Is the DTC active or stored? EPPM - ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Go To 2 EPPM - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. CHECK FOR ADDITIONAL ACTIVE SATELLITE SENSOR DTCS NOTE: The scan tool, (special tool #8443-25, 56 Way ACM Adapter), and a DVOM are required to perform the following tests. Using the scan tool, read all active EPPM DTCs. Is DTCS U119E-00-LOST COMMUNICATION W/LEFT-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR and U11A0-00-LOST COMMUNICATION W/CENTER-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR also active? Yes Go To 8 No Go To 3
3. CHECK (R172) RIGHT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR AN OPEN WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Right Pedestrian Impact Sensor harness connector. Disconnect the EPPM harness connectors. NOTE: Check the connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (R172) Right Pedestrian Impact Sensor Signal circuit between the Right Pedestrian Impact Sensor harness connector cavity 2 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 9. Is the resistance below 1.0 Ohm? Yes Go To 4 No Repair or replace the (R172) Right Pedestrian Impact Sensor Signal circuit for an open in accordance with the Service Information. Then, Go To 4
4. CHECK (R173) RIGHT PEDESTRIAN IMPACT SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (R173) Right Pedestrian Impact Sensor Ground circuit between the Right Pedestrian Impact Sensor harness connector cavity 1 and the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 10. Is the resistance below 1.0 Ohm? Yes Go To 5 No Repair or replace the (R173) Right Pedestrian Impact Sensor Ground circuit for an open in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
5. CHECK (R172) RIGHT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO THE (R173) RIGHT PEDESTRIAN IMPACT SENSOR GROUND CIRCUIT Measure the resistance between the (R172) Right Pedestrian Impact Sensor Signal circuit cavity 2 and the (R173) Right Pedestrian Impact Sensor Ground circuit cavity 1 at the Right Pedestrian Impact Sensor harness connector. Is the resistance below 5K Ohms? Yes Repair or replace the (R172) Right Pedestrian Impact Sensor Signal circuit for a short to the (R173) Right Pedestrian Impact Sensor Ground circuit in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 6
6. CHECK (R172) RIGHT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance of the (R172) Right Pedestrian Impact Sensor Signal circuit between ground and the Right Pedestrian Impact Sensor cavity 2 harness connector. Is the resistance below 6K Ohms? Yes Repair or replace the (R172) Right Pedestrian Impact Sensor Signal circuit for a short to ground in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 7
7. CHECK (R172) RIGHT PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (R172) Right Pedestrian Impact Sensor Signal circuit between the Right Pedestrian Impact Sensor Signal harness connector cavity 2 and ground. Is there any voltage present? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair or replace the (R172) Right Pedestrian Impact Sensor Signal circuit for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If DTC U119F-00-LOST COMMUNICATION W/RIGHT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR is still active, go to step 8 . Otherwise, test complete.
8. CHECK (R172) RIGHT PEDESTRIAN IMPACT SIGNAL CIRCUIT AND (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT AND (R170) LEFT PEDESTRIAN IMPACT SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Center Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the Right Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the Left Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the EPPM harness connectors. NOTE: Check the connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (R174) Center Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 32- 29 and ground. Measure the voltage of the (R170) Left Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 12 and ground. Measure the voltage of the (R172) Right Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 9 and ground. Is there any voltage present? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair or replace the impact sensor circuit with voltage present for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 9
9. CHECK OPERATION OF RIGHT PEDESTRIAN IMPACT SENSOR WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Right Pedestrian Impact Sensor. Refer to «SENSOR, IMPACT, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Reconnect the vehicle body harness to the impact sensor. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase all codes in the EPPM. Perform EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Did the active DTC U119F-00-LOST COMMUNICATION W/RIGHT PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR return? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair is complete. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

U11A0-00-LOST COMMUNICATION W/CENTER-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The pedestrian protection impact sensors perform their own self test using power supplied by the Electronic Pedestrian Protection module (EPPM) then communicate this status back to the EPPM with periodic updates. The repair of this fault condition involves verifying the integrity of the wiring between the EPPM and the sensor. For EPPM Description information, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION . For EPPM Operation information, refer to MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION .

The EPPM monitors communication with the Center Pedestrian Protection Impact sensor continuously.

This DTC sets when the EPPM no longer receives notification of the status update from the center pedestrian protection satellite acceleration sensor. Once set, this DTC is latched for the entire ignition cycle. This code will set active if the loss of communication with the sensor has lasted for more then 2.5 seconds. This fault is latched for the full ignition cycle. The fault will go stored on the next key cycle upon the fault not setting for longer then 2.5 seconds.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read EPPM DTCs. Is the DTC active or stored? EPPM - ACTIVE DTC Go To 2 EPPM - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. CHECK FOR ADDITIONAL ACTIVE SATELLITE SENSOR DTCS NOTE: The scan tool, (special tool #8443-25, 56 Way ACM Adapter), and a DVOM are required to perform the following tests. With the scan tool, read all active EPPM DTCs. Is DTC U119E-00-LOST COMMUNICATION W/LEFT-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR and U119F-00-LOST COMMUNICATION W/RIGHT-PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR also active? Yes Go To 8 No Go To 3
3. CHECK (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR AN OPEN WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Center Pedestrian Impact Sensor harness connector. Disconnect the EPPM harness connectors. NOTE: Check the connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. Measure the resistance of the (R174) Center Pedestrian Impact Sensor Signal circuit between the Center Impact Sensor harness connector to the (special tool #8443-25, 56 Way ACM Adapter) connector cavity 32 - 29. Is the resistance below 1.0 Ohm? Yes Go To 4 No Repair or replace the (R174) Center Pedestrian Impact Sensor Signal circuit for an open in accordance with the Service Information. Then, Go To 4
4. CHECK (R175) CENTER PEDESTRIAN IMPACT SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (R175) Center Pedestrian Impact Sensor ground circuit between the Center Front Impact Sensor harness connector and the (special tool #8443-25, 56 Way ACM Adapter) connector cavity 32 - 30. Is the resistance below 1.0 Ohm? Yes Go To 5 No Repair or replace the (R175) Center Pedestrian Impact Sensor ground circuit for an open in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
5. CHECK (R175) CENTER PEDESTRIAN IMPACT SENSOR GROUND CIRCUIT FOR A SHORT TO THE (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT Measure the resistance between the (R174) Center Pedestrian Impact Sensor Signal circuit cavity 2 and the (R175) Center Pedestrian Impact Sensor ground circuit cavity 1 at the Center Pedestrian Impact Sensor harness connector. Is the resistance below 5K Ohms? Yes Repair or replace the (R174) Center Pedestrian Impact Sensor Signal circuit for a short to the (R175) Center Pedestrian Impact Sensor ground circuit in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 6
6. CHECK (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance of the (R174) Center Pedestrian Impact Sensor Signal circuit between ground and the Center Pedestrian Impact Sensor harness connector cavity 2. Is the resistance below 6K Ohms? Yes Repair or replace the (R174) Center Pedestrian Impact Sensor Signal circuit for a short to ground in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 7
7. CHECK (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (R174) Center Pedestrian Impact Sensor Signal circuit between the Left Front Impact Sensor harness connector cavity 2 and ground. Is there any voltage present? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair or replace the (R174) Center Pedestrian Impact Sensor Signal circuit for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . If DTC U11A0-00-LOST COMMUNICATION W/CENTER PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR is still active, go to step 9 . Otherwise, test complete.
8. CHECK (R172) RIGHT PEDESTRIAN IMPACT SIGNAL CIRCUIT AND (R174) CENTER PEDESTRIAN IMPACT SENSOR SIGNAL CIRCUIT AND (R170) LEFT PEDESTRIAN IMPACT SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Center Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the Right Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the Left Pedestrian Impact Sensor Signal circuit harness connector. Disconnect the EPPM harness connectors. NOTE: Check the connectors - Clean and repair as necessary. Connect the (special tool #8443-25, 56 Way ACM Adapter) to the EPPM harness connectors. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage of the (R174) Center Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 32 - 29 and ground. Measure the voltage of the (R170) Left Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 12 and ground. Measure the voltage of the (R172) Right Pedestrian Impact Sensor Signal circuit between the (special tool #8443-25, 56 Way ACM Adapter) cavity 24 - 9 and ground. Is there any voltage present? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Repair or replace the impact sensor circuit with voltage present for a short to voltage in accordance with the Service Information. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Go To 9
9. CHECK OPERATION OF CENTER PEDESTRIAN IMPACT SENSOR WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Center Pedestrian Impact Sensor. Refer to «SENSOR, IMPACT, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Reconnect the vehicle body harness to the impact sensor. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase all codes in the EPPM. Perform EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Did the active DTC U11AO-00-LOST COMMUNICATION W/CENTER PEDESTRIAN PROTECTION SATELLITE ACCELERATION SENSOR return? Yes WARNING: If the Electronic Pedestrian Protection Module (EPPM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental actuator deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair is complete. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

U1415-00-IMPLAUSIBLE/MISSING VEHICLE CONFIGURATION DATA

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When powered, the Electronic Pedestrian Protection Module (EPPM) performs an internal self test. The repair of this fault does not involve any external circuitry and centers on verifying that the module is configured correctly for the vehicle's restraint system components.

With the ignition on. The EPPM on board diagnostics loads the EPPM Configuration Data from the TIPM CAN Bus message.

This DTC will set if the CAN Bus message was received but the information is invalid or corrupt.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read EPPM DTCs. Is the DTC active or stored? ORC - ACTIVE DTC Go To 2 ORC - STORED DTC Perform the EPPM SYSTEM INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .
2. REPLACE THE TOTALLY INTEGRATED POWER MODULE (TIPM) Turn the ignition Off. Replace the Totally Integrated Power Module (TIPM) in accordance with the service information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(/chrysler/town-country/v-2010-2016/remont/body-electrical/#power-distribution) . Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase all codes in the EPPM. NOTE: The EPPM Reset Function must be performed after the repair to force the module to retest for this DTC. Perform the EPPM module reset. Access the Diagnostic Procedures menu from the EPPM ECU Overview screen on the scan tool to perform this operation. Wait one minute, and read active codes. Does the U1415-00-Implausible/Missing Vehicle Configuration Data DTC return? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the EPPM in accordance with the Service Information. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No Repair complete. Perform the EPPM SYSTEM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) .

EPPM SYSTEM INTERMITTENT TEST

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. RECORD AND ERASE ALL ELECTRONIC PEDESTRIAN PROTECTION MODULE (EPPM) SYSTEM DTCS With the scan tool, record and erase all DTCs from the EPPM system module. Monitor for any active codes as you work through the following steps. Review the code monitored and set conditions for any DTCs that are stored and attempt to reproduce the conditions listed. WARNING: Maintain a safe distance from both of the Electronic Pedestrian Protection Hood Hinge Actuators located under the rear hood area while performing the following steps. Failure to follow these instructions may result in possible serious or fatal injury. Wiggle the wiring harness and connectors of the related airbag circuit, sensor, or component. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect components and inspect the harness and connectors for damage. Reconnect components and ensure they are properly seated. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If codes are related to the Driver Airbag circuits, rotate the steering wheel from stop to stop. Turn the ignition off. Perform any Technical Service Bulletins (TSBs) that may apply. Was the source of the customer complaint found or did any DTCs appear and stay active? Yes Make the appropriate repairs and either perform the EPPM SYSTEM VERIFICATION TEST. Refer to «EPPM SYSTEM VERIFICATION TEST»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) for the appropriate diagnostic procedure. No Go To 2
2. ATTEMPT TO REPRODUCE THE CONDITION In the event the customer complaint cannot be duplicated due to an intermittent condition in the restraints system, the following may aid in attempting to reproduce the condition. WARNING: Turn the ignition off, disconnect the battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors related to the stored code or component in question. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Reconnect any disconnected components and harness connectors and ensure they are properly seated. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If numerous trouble codes were set, use a schematic and inspect any common ground or supply circuits. Was the source of the intermittent condition located? Yes Make the appropriate repairs and perform the EPPM SYSTEM VERIFICATION PROCEDURE. Refer to «EPPM SYSTEM VERIFICATION TEST»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics) . No The problem cannot be found at this time.

DIAGNOSTIC PRE-TEST

1. Before attempting to repair any electronic pedestrian protection (EPPM) system, technicians should be familiar with and fully understand the system operation. Refer to EPPM System Description and Operation for complete details. Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, DESCRIPTION»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . Refer to «MODULE, ELECTRONIC PEDESTRIAN PROTECTION, OPERATION»(/chrysler/town-country/v-2010-2016/remont/airbag/#restraints-service-information) . The following should be used as a checklist to be completed in its entirety prior to referencing specific EPPM Diagnostic Procedures. FOLLOW THE BASIC OUTLINE SET FORTH IN THE SIX-STEP TROUBLESHOOTING PROCEDURE Verification of complaint. Verification of any related symptoms. Symptom analysis. Problem isolation. Repair of isolated problem. Verification of proper operation. TAKE INTO ACCOUNT CURRENT VEHICLE CONDITION, REPAIR HISTORY, AND TECHNICAL SERVICE BULLETINS (TSBs) Verify that there are no outward signs of vehicle damage or effects from a collision that could impact the proper operation of the EPPM system. Check for aftermarket vehicle accessories that may have been installed improperly or could interfere with the system. Check the vehicle repair history for repairs that may relate to the current condition. Check for current Technical Service Bulletins (TSBs) for the EPPM system related to the customer concern. If a TSB applies, follow the procedure outlined in the TSB. DIAGNOSE ONLY THOSE FAILURES THAT ARE ACTIVE AND CAN BE REPRODUCED Check the control module central to the subsystem that is exhibiting the condition for active DTCs. For an intermittent failure that is not active at the time of vehicle inspection, perform the EPPM SYSTEM INTERMITTENT TEST diagnostic procedure and document the event on the repair order. Refer to «EPPM SYSTEM INTERMITTENT TEST»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__eppm-system-intermittent-test) . ADDRESS ACTIVE DIAGNOSTIC TROUBLE CODES (DTCs) IN THE CORRECT ORDER Low/High Voltage and Serial Data Loss of Communication Codes. Module Internal Failure and Configuration Mismatch Codes. Circuit specific DTC failures. Should the malfunction still be present after conducting this Pre-diagnostic Procedure, technicians should continue to the appropriate DTC procedure. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . Was the Pre-Test reviewed and is the DTC still present? Yes Perform the appropriate DTC procedure. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . No Test Complete.

1. Perform the EPPM System Verification Test NOTE: If the EPPM has been replaced, the EPPM Initialization Procedure must be performed to clear the EPPM Unlocked DTC and bring the module to a full state of readiness. Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) . Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the keyless ignition, use this ignition on warning for EPPM. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the EPPM fuse, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the EPPM fuse. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase stored DTCs in all airbag system modules. Perform module reset. NOTE: If equipped with an Airbag On - Off switch, read the DTCs in all switch positions. Exercise the EPPM System to duplicate the appropriate monitor conditions for any DTCs that were set. Wait one minute, and read active codes, if there are none present, read the stored codes. If the scan tool shows any active or stored codes, return to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) and follow the path specified for that trouble code. If no active or stored codes are present, the repair is complete. Are any DTCs present or, is the original condition still present? Yes Refer to the «DIAGNOSTIC CODE INDEX»(/chrysler/town-country/v-2010-2016/remont/collisionavoidance/#electronic-pedestrian-protection-epp-module-electrical-diagnostics__diagnostic-code-index) and perform the appropriate diagnostic procedure. No If the battery was disconnected for any reason, you must perform the Battery Reconnection procedure. Refer to the appropriate Service Information. Repair is complete.

See also:
• MODULE, ELECTRONIC PEDESTRIAN PROTECTION, REMOVAL
• STANDARD PROCEDURE
• ACTUATOR, ELECTRONIC PEDESTRIAN PROTECTION HOOD HINGE, REMOVAL
• TOTALLY INTEGRATED POWER MODULE (TIPM) - DIAGNOSTIC CODE INDEX
• DIAGNOSIS AND TESTING
• MODULE, POWERTRAIN CONTROL, REMOVAL
• MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL
• B1BC7-00
• B212C-16
• B212C-17
• B222A
• B22A6-00
• B22A7-00
• B22A8-00
• B2736-49
• B2736-78
• B2737-49
• B2737-78
• B2738-49
• B2738-78
• B276A-00
• B276B-11
• B276B-12
• B276B-13
• B276B-2B
• B276C-11
• B276C-12
• B276C-13
• B276C-2B
• U0002
• U0146
• U1110-00
• U1175-00
• U119E-00
• U119F-00
• U11A0-00
• U1415-00
• DIAGNOSTIC CODE INDEX
• EPPM SYSTEM INTERMITTENT TEST
