DESCRIPTION
This article provides illustrations identifying connector, ground and splice locations in the vehicle. Connector, ground and splice indexes are provided. Use the wiring diagrams in each article for connector, ground and splice identification. Refer to the appropriate index for the proper figure number. For items that are not shown in this article, N/S is placed in the FIG. column.
| CONNECTOR NAME/NUMBER | COLOR | LOCATION | FIG. |
|---|---|---|---|
| A/C Compressor Clutch | BK | Lower Right Side of Engine Compartment On Engine | (Scheme 184), (Scheme 185), (Scheme 187), (Scheme 190). |
| A/C High Pressure Switch (Diesel) | LT GY | Lower Right Side Engine Compartment | N/S |
| A/C Low Pressure Switch (LHD) | BK | Right Rear of Engine Compartment | (Scheme 164), (Scheme 174), (Scheme 175), (Scheme 181). |
| A/C Low Pressure Switch (RHD) | BK | Left Rear of Engine Compartment | (Scheme 179). |
| A/C Pressure Transducer | GY | Lower Left Side of Engine Compartment on Engine | (Scheme 185), (Scheme 187), (Scheme 190). |
| A/C-Heater Control Switch | GY | Center of Instrument Panel | (Scheme 194). |
| Accelerator Pedal Position Sensor | BK | Right Side Engine Compartment | (Scheme 173), (Scheme 175), (Scheme 181). |
| Airbag Control Module (ORC) (Base) | YL | Under Center Console | (Scheme 206). |
| Airbag Control Module (ORC) C1 (Premium) | YL | Under Center Console | (Scheme 206). |
| Airbag Control Module (ORC) C2 (Premium) | YL | Under Center Console | (Scheme 206). |
| Ambient Temperature Sensor (Gas) | BK | Lower Left Front Fascia | (Scheme 164). |
| Ambient Temperature Sensor (Diesel) | BK | Left Front Engine Compartment | (Scheme 183). |
| Ambient Temperature Sensor (NGC) | BK | Left Front Engine Compartment | (Scheme 164). |
| Autostick Switch | WT | Center Console | (Scheme 206). |
| Back-Up Lamp Switch | GY | Left Side of Engine Compartment on Manual Transmission | (Scheme 184), (Scheme 185), (Scheme 187), (Scheme 189), (Scheme 190). |
| Battery Jump Post | Left Rear Engine Compartment | (Scheme 182). | |
| Battery Temperature Sensor (Diesel) | BK | Lower Passenger B-Pillar | (Scheme 227). |
| Battery Temperature Sensor (Gas) | BK | Left Front Engine Compartment | (Scheme 177). |
| Battery (+) (Diesel) | Under Left of Rear Seat | (Scheme 227). | |
| Battery (-) (Diesel) | Under Left of Rear Seat | (Scheme 227). | |
| Blower Motor | BK | Right Rear of Instrument Panel | N/S |
| Blower Motor Resistor Block | BK | Right Side of Cowl Panel | (Scheme 168), (Scheme 177), (Scheme 178), (Scheme 180). |
| Boost Pressure Sensor | BK | Lower Rear of Engine Compartment on Engine | (Scheme 184). |
| Brake Lamp Switch | GY | Left Side of Brake Pedal | (Scheme 177), (Scheme 178), (Scheme 180). |
| Brake Transmission Shift Interlock Solenoid | WT | Below Steering Column | (Scheme 191). |
| Brake Warning Indicator Switch (LHD) | BK | Left Rear of Engine Compartment | (Scheme 164), (Scheme 166), (Scheme 168), (Scheme 176). |
| Brake Warning Indicator Switch (RHD) | BK | Right Rear of Engine Compartment | (Scheme 173). |
| C102 | LT GY | Front Left Side of Engine Compartment | (Scheme 164), (Scheme 185), (Scheme 187), (Scheme 188). |
| C103 (2.4L) | DK GY | Front Side of Engine Compartment on Engine | (Scheme 185). |
| C103 (2.4L Turbo) | BK | Front Side of Engine Compartment on Engine | (Scheme 187). |
| C105 | WT | Left Side of Instrument Panel | (Scheme 177), (Scheme 178), (Scheme 180), (Scheme 192), (Scheme 198). |
| C106 | GY | Left Side of Instrument Panel | (Scheme 177), (Scheme 178), (Scheme 180), (Scheme 192), (Scheme 198). |
| C107 (Export) | BK | Left Front of Vehicle | (Scheme 167), (Scheme 168), (Scheme 176), (Scheme 179). |
| C108 (Export) | BK | Right Front of Vehicle | (Scheme 172), (Scheme 183). |
| C109 | BK | Lower Right Side of Engine Compartment | (Scheme 173), (Scheme 174), (Scheme 175), (Scheme 181). |
| C110 | BK | Lower Right Side of Engine Compartment | (Scheme 173), (Scheme 174), (Scheme 175), (Scheme 181). |
| C111 | LT GY | Left Front of Engine Compartment | (Scheme 168), (Scheme 190). |
| C112 | BK | Left Front of Engine Compartment | (Scheme 168), (Scheme 190). |
| C114 | DK GY | Left Front of Engine Compartment | (Scheme 168), (Scheme 190). |
| C121 | BK | Front of Engine Compartment | (Scheme 183), (Scheme 184). |
| C122 | LT GY | Front of Engine Compartment | (Scheme 183), (Scheme 184). |
| C124 | DK GY | Front of Engine Compartment | (Scheme 183), (Scheme 184). |
| C125 | BK | Front of Engine Compartment | (Scheme 176), (Scheme 179), (Scheme 184). |
| C126 | DK GY | Left Side of Engine Compartment | (Scheme 176), (Scheme 179). |
| C127 | BK | Left Rear of Engine Compartment | (Scheme 176), (Scheme 179), (Scheme 182). |
| C128 | BK | Left Rear of Engine Compartment | (Scheme 176), (Scheme 179), (Scheme 182). |
| C200 | BK | Left Side of Instrument Panel | (Scheme 192), (Scheme 197). |
| C201 | BK | Right Side of Instrument Panel | (Scheme 193), (Scheme 198). |
| C202 (LHD) | WT | Left Kick Panel | (Scheme 192), (Scheme 219), (Scheme 221). |
| C202 (RHD) | GY | Left Kick Panel | (Scheme 197). |
| C203 (PT27) | LT GY | Lower Right Kick Panel | (Scheme 193), (Scheme 213). |
| C203 (PT44) | GN | Lower Right Kick Panel | (Scheme 193), (Scheme 198), (Scheme 212). |
| C204 | WT | Left Side of Instrument Panel | (Scheme 192), (Scheme 197), (Scheme 208), (Scheme 209), (Scheme 210), (Scheme 219). |
| C205 | WT | Upper Right Kick Panel | (Scheme 193), (Scheme 198), (Scheme 208), (Scheme 209), (Scheme 210), (Scheme 212). |
| C207 | RD | Right Side of Instrument Panel | (Scheme 205). |
| C208 | RD | Left Side of Instrument Panel | (Scheme 200), (Scheme 205). |
| C209 (LHD) | BK | Right Rear of Instrument Panel | (Scheme 193). |
| C209 (RHD) | BK | Left Rear of Instrument Panel | (Scheme 197). |
| C211 | WT | Below Driver Seat | N/S |
| C212 | BK | Center Of Instrument Panel | (Scheme 196). |
| C300 | BK | Left B-Pillar | (Scheme 211), (Scheme 220). |
| C301 | BK | Right B-Pillar | (Scheme 211), (Scheme 214). |
| C302 | WT | Top Left of Liftgate | (Scheme 224), (Scheme 233), (Scheme 234). |
| C303 | DK GY | Left Rear Quarter | (Scheme 222), (Scheme 235). |
| C304 | BK | Side of Fuel Tank | (Scheme 228). |
| C305 | YL | Left Rear of Front Console | (Scheme 206), (Scheme 212), (Scheme 213), (Scheme 219). |
| C306 | YL | Left Side of Front Console | (Scheme 206), (Scheme 212), (Scheme 219), (Scheme 221). |
| C307 | BK | Under Passenger Seat | (Scheme 206), (Scheme 212), (Scheme 213), (Scheme 219). |
| C308 | BK | Under Driver Seat | (Scheme 206), (Scheme 212), (Scheme 219), (Scheme 221). |
| C343 (PT27) | LT GY | Left Decklid | (Scheme 232). |
| C349 (PT27) | BL | Left Rear Cargo Area | (Scheme 225). |
| C362 (PT27) | LT GY | Left Side Body | (Scheme 223), (Scheme 229), (Scheme 230). |
| Camshaft Position Sensor | BK | On Engine Left Side of Engine Compartment | (Scheme 184), (Scheme 186), (Scheme 187), (Scheme 189). |
| Cargo Lamp | BK | Cargo Area | (Scheme 217), (Scheme 218). |
| Center High Mounted Stop Lamp (PT27) | WT | Top of Decklid | (Scheme 232). |
| Center High Mounted Stop Lamp (PT44) | BK | Top of Liftgate | (Scheme 233), (Scheme 234). |
| Center Stack Lamp | BK | Bottom Center of Instrument Panel | (Scheme 194). |
| Cigar Lighter | BK | Bottom Center of Instrument Panel | (Scheme 206). |
| Clockspring | GN | Bottom of Steering Wheel | (Scheme 191). |
| Clutch Pedal Position Switch (Up) | BK | Left Side of Steering Column | (Scheme 177), (Scheme 178), (Scheme 180). |
| Compass/Temperature Mirror Module | BK | Top Center Windshield | (Scheme 202), (Scheme 205). |
| Controller Antilock Brake | BK | Left Side of Engine Compartment | (Scheme 164), (Scheme 166), (Scheme 168), (Scheme 176), (Scheme 179). |
| Crankshaft Position Sensor (2.4L) | BK | Lower Rear of Engine Compartment On Engine | (Scheme 187). |
| Crankshaft Position Sensor (1.6L Gas/ 2.2L Diesel) | BK | Lower Front of Engine Compartment on Engine | (Scheme 184), (Scheme 190). |
| Data Link Connector | BK | Left Side of Instrument Panel | (Scheme 177), (Scheme 178), (Scheme 180). |
| Decklid Cylinder Lock Switch | LT GY | Decklid | (Scheme 232). |
| Decklid Handle Switch | WT | Decklid | (Scheme 232). |
| Decklid Release Motor | BK | Decklid | (Scheme 232). |
| Decklid Release Switch | BK | In Glove Box | (Scheme 193). |
| Dome Lamp | BK | Center of Headliner | N/S |
| Dome Lamp/Intrusion Sensor | WT | Center of Headliner | N/S |
| Driver Airbag | YL | Front of Steering Wheel | N/S |
| Driver Door Ajar Switch | BK | Left B-Pillar | N/S |
| Driver Door Handle Switch (PT27) | Driver Door | (Scheme 209). | |
| Driver Door Power Lock Motor/Ajar Switch (PT27) | BK | Driver Door | (Scheme 209). |
| Driver Door Power Lock Motor/Ajar Switch (PT44) | BK | Driver Door | (Scheme 208), (Scheme 210). |
| Driver Heated Seat Cushion | LT GY | Driver Seat | N/S |
| Driver Heated Seat Switch | RD | Driver Seat | N/S |
| Driver Seat Airbag | YL | Driver Seat | N/S |
| Driver Seat Belt Switch (LHD PT44) | BK | Lower Left B-Pillar | (Scheme 220). |
| Driver Seat Belt Switch (PT27) | BK | Left Side Body | (Scheme 221). |
| Driver Seat Belt Switch (RHD) | BK | Lower Right B-Pillar | (Scheme 214). |
| Driver Seat Belt Tensioner (LHD PT44) | YL | Left B-Pillar | (Scheme 220). |
| Driver Seat Belt Tensioner (PT27) | YL | Left Side Body | (Scheme 221). |
| Driver Seat Belt Tensioner (RHD) | YL | Right B-Pillar | (Scheme 214). |
| Driver Side Impact Sensor 1 (LHD) | GY | Lower Left B-Pillar | (Scheme 220). |
| Driver Side Impact Sensor 1 (RHD) | GY | Lower Right B-Pillar | (Scheme 214). |
| EGR Solenoid | GY | Rear of Engine Compartment on Engine | (Scheme 176), (Scheme 179). |
| Electronic Throttle Control Module (1.6L) | BK | Center of Engine Compartment on Top of Engine | (Scheme 189), (Scheme 190). |
| Engine Control Module - C1 | BK | Left Side Engine Compartment | (Scheme 184). |
| Engine Control Module - C2 | BK | Left Side of Engine Compartment | (Scheme 184). |
| Engine Coolant Temperature Sensor | BK | Left Side of Engine Compartment on Engine | (Scheme 190). |
| Engine Oil Pressure Switch | LT GN | Right Rear of Engine Compartment | (Scheme 184), (Scheme 186), (Scheme 188), (Scheme 189). |
| Engine Starter Motor (1.6L) | Lower Rear of Engine Compartment on Engine | (Scheme 169), (Scheme 189). | |
| Engine Starter Motor (2.4L Except Turbo, 2.2L Diesel) | Lower Front of Engine Compartment on Engine | (Scheme 170), (Scheme 182), (Scheme 184), (Scheme 185). | |
| Engine Starter Motor (2.4L Turbo) | Rear Engine Compartment on Engine | (Scheme 171), (Scheme 187). | |
| EVAP/Purge Solenoid | BK | Lower Right Rear of Engine Compartment | (Scheme 164), (Scheme 168), (Scheme 174). |
| Front Power Window Switch | NAT | Top Center of Instrument Panel | (Scheme 194). |
| Front Washer Pump Motor | BK | Attached to Washer Reservoir | (Scheme 168), (Scheme 177), (Scheme 178), (Scheme 180). |
| Front Wiper Motor | BK | Center of Cowl Panel | (Scheme 168), (Scheme 177), (Scheme 178), (Scheme 180). |
| Front Wiper/Washer Switch | GY | Part of Multi-Function Switch | (Scheme 191). |
| Fuel Heater Module (Diesel) | WT | Rear of Engine Compartment | (Scheme 176), (Scheme 179). |
| Fuel Injector No.1 | BK | Center of Engine Compartment At Injector | (Scheme 184). |
| Fuel Injector No.2 | BK | Center of Engine Compartment At Injector | (Scheme 184). |
| Fuel Injector No.3 | BK | Center of Engine Compartment At Injector | (Scheme 184). |
| Fuel Injector No.4 | BK | Center of Engine Compartment At Injector | (Scheme 184), (Scheme 190). |
| Fuel Pressure Sensor | BK | Front of Engine Compartment on Engine | N/S |
| Fuel Pressure Solenoid | BK | Front of Engine Compartment Top of Engine | N/S |
| Fuel Pump Module | LT GY | On Fuel Tank | (Scheme 228). |
| Fuse Block | BK | Left Bottom of Instrument Panel | (Scheme 191), (Scheme 192), (Scheme 198). |
| Fusible Link (2.4L) | Front of Engine Compartment on Engine | N/S | |
| Generator | BK | Right Front of Engine Compartment on Engine | (Scheme 182), (Scheme 184), (Scheme 186), (Scheme 190). |
| Glow Plug No. 1 | Center of Engine Compartment Top of Engine | N/S | |
| Glow Plug No. 2 | Center of Engine Compartment Top of Engine | N/S | |
| Glow Plug No. 3 | Center of Engine Compartment Top of Engine | N/S | |
| Glow Plug No. 4 | Center of Engine Compartment Top of Engine | N/S | |
| Hands Free Module C1 | Left Center of Instrument Panel | (Scheme 195). | |
| Hands Free Module C2 | DK GY | Left Center of Instrument Panel | (Scheme 195). |
| Hands Free Module C3 | BK | Left Center of Instrument Panel | (Scheme 195). |
| Headlamp Leveling Switch | BK | Center of Instrument Panel | (Scheme 194). |
| Heated Seat Module | GR | Driver Seat | N/S |
| High Note Horn | BK | Left Inner Fender | (Scheme 164), (Scheme 172), (Scheme 183). |
| Hood Ajar Switch | BK | Left Rear Engine Compartment | (Scheme 164), (Scheme 168), (Scheme 176), (Scheme 179). |
| Idle Air Control Motor | BK | Center of Engine Compartment Top of Engine | (Scheme 186), (Scheme 187). |
| Ignition Coil | BK | Left Rear of Engine Compartment on Engine | (Scheme 186), (Scheme 189), (Scheme 190). |
| Ignition Switch C1 | BK | Right Side of Steering Column | (Scheme 191). |
| Ignition Switch C2 | WT | Right Side of Steering Column | (Scheme 191). |
| Inlet Air Temperature Sensor | BK | Left Side Engine Compartment on Engine | (Scheme 184), (Scheme 186), (Scheme 187), (Scheme 189), (Scheme 190). |
| Input Speed Sensor | GY | Front of Engine Compartment on Transmission | (Scheme 185), (Scheme 187). |
| Instrument Cluster C1 | BK | Driver's Side of Instrument Panel | (Scheme 191). |
| Instrument Cluster C2 | BK | Driver's Side of Instrument Panel | (Scheme 191). |
| Intake Air Temperature Sensor (Diesel) | BK | Left Top of Engine | N/S |
| Knock Sensor | BK | Front of Engine Compartment on Engine | (Scheme 185), (Scheme 187). |
| Leak Detection Pump (Except NGC) | BK | Near Fuel Tank Module | N/S |
| Left Back-Up Lamp | GY | Left Side of Rear Fascia | (Scheme 235). |
| Left City Lamp | GY | Left Front of Vehicle Near C107 | N/S |
| Left Cylinder Lock Switch | BK | Driver Door | (Scheme 208), (Scheme 210). |
| Left Dome Lamp | Left Sports Bar | (Scheme 216). | |
| Left Door Lock Switch (PT27) | BK | Driver Door | (Scheme 209). |
| Left Door Lock Switch (PT44) | BK | Driver Door | (Scheme 208), (Scheme 210). |
| Left Fog Lamp | GY | Lower Left Front Fascia | (Scheme 164), (Scheme 167), (Scheme 183). |
| Left Front Door Speaker (PT27) | BK | Left Door | (Scheme 209). |
| Left Front Door Speaker (PT44) | BK | Left Door | (Scheme 208), (Scheme 210). |
| Left Front Door Window Module | BK | Center of Left Front Door | (Scheme 209). |
| Left Front Park/Turn Signal Lamp | NAT | Left Front of Vehicle | (Scheme 176), (Scheme 179). |
| Left Front Power Window Motor | BK | Left Front Door | (Scheme 208), (Scheme 210). |
| Left Front Side Marker (Export) | BK | Left Front Wheel Opening | (Scheme 167), (Scheme 176), (Scheme 179). |
| Left Front Turn Signal Lamp | NAT | Left Front of Vehicle | (Scheme 167). |
| Left Front Wheel Speed Sensor | GY | Left Front Wheel Opening | (Scheme 164), (Scheme 168), (Scheme 176), (Scheme 179). |
| Left Headlamp Leveling Module | BK | Left Front of Vehicle Near C107 | N/S |
| Left High Beam Headlamp | BK | At Headlamp Assembly | (Scheme 166), (Scheme 167), (Scheme 178), (Scheme 180). |
| Left Instrument Panel Speaker | BK | Left Upper Instrument Panel | N/S |
| Left License Lamp (Export) | NAT | Left Side of Rear Fascia | (Scheme 235). |
| Left Low Beam Headlamp | GY | At Headlamp Assembly | (Scheme 167), (Scheme 168), (Scheme 176), (Scheme 179). |
| Left Power Mirror (PT27) | NAT | Left Front Door | (Scheme 209). |
| Left Power Mirror (PT44) | NAT | Left Front Door | (Scheme 208), (Scheme 210). |
| Left Rear Door Ajar Switch | Above Left Rear Wheel Well | (Scheme 222). | |
| Left Rear Door Power Lock Motor | BK | Rear of Left Rear Door | (Scheme 211). |
| Left Rear Fog Lamp (LHD) | GY | Left Side of Rear Fascia | N/S |
| Left Rear Power Window Motor (PT27) | BK | Left Side Body | (Scheme 221). |
| Left Rear Power Window Motor (PT44) | BK | Left Rear Door | (Scheme 211). |
| Left Rear Power Window Switch | LT GY | Rear of Front Center Console | (Scheme 206). |
| Left Rear Speaker (PT27) | Left Side Body | (Scheme 221). | |
| Left Rear Speaker (PT44) | BK | Left C-Pillar | (Scheme 224). |
| Left Rear Turn Signal Lamp | GY | In Rear Lamp Assembly | (Scheme 222), (Scheme 235). |
| Left Rear Wheel Speed Sensor | GY | Left Rear Wheel Opening | N/S |
| Left Side Impact Sensor 1 (PT27) | GY | Left Side Body | (Scheme 221). |
| Left Tail/Stop Lamp | BK | In Rear Lamp Assembly | (Scheme 222), (Scheme 235). |
| Left Turn Signal Indicator | BK | Left Top Side of Instrument Panel | (Scheme 196). |
| Left Visor/Vanity Lamp | BK | Left Front Side of Headliner | (Scheme 204), (Scheme 205). |
| License Lamp (Except Export) | NAT | Center of Rear Fascia | (Scheme 235). |
| Liftgate Ajar Switch | BK | Bottom of Liftgate | (Scheme 231). |
| Liftgate Cylinder Lock Switch | LT GY | Inside Liftgate | (Scheme 231). |
| Liftgate Power Lock Motor | BK | Inside Liftgate | (Scheme 231). |
| Low Note Horn | BK | Left Inner Fender | (Scheme 164), (Scheme 172), (Scheme 183). |
| Manifold Absolute Pressure Sensor | BK | Rear of Engine Compartment Top of Engine | (Scheme 186), (Scheme 188), (Scheme 189). |
| Map/Reading Lamps | BK | Front Headliner | (Scheme 203). |
| Mass Air Flow Sensor | BK | Left Side of Engine Compartment on Engine | (Scheme 184). |
| Mega Fuse | Below Passenger Seat | (Scheme 227). | |
| Multifunction Switch | GY | Steering Column | (Scheme 191). |
| Natural Vacuum Leak Detection Assembly (NGC) | BK | Right Front Fuel Tank | (Scheme 228). |
| Noise Suppressor (1.6L) | Rear of Engine | (Scheme 189). | |
| Noise Suppressor (2.4L) | Left Side Engine Compartment on Engine | (Scheme 186), (Scheme 188). | |
| Output Speed Sensor | GY | Front of Engine Compartment on Transmission | (Scheme 185), (Scheme 187). |
| Overhead Console Module | BK | Front Center of Headliner | (Scheme 203). |
| Oxygen Sensor 1/1 Upstream | GY | Left Side Engine Compartment | (Scheme 186), (Scheme 188), (Scheme 189). |
| Oxygen Sensor 1/2 Downstream | BK | Left Side Engine Compartment | (Scheme 186), (Scheme 188), (Scheme 189), (Scheme 190). |
| Parking Brake Switch | Rear of Front Center Console | (Scheme 206). | |
| Passenger Airbag | YL | Passenger Side of Instrument Panel | (Scheme 193), (Scheme 197), (Scheme 199). |
| Passenger Door Handle Switch (PT27) | Passenger Door | (Scheme 209). | |
| Passenger Door Power Lock Motor/Ajar Switch (PT27) | BK | Passenger Door | (Scheme 209). |
| Passenger Door Power Lock Motor/Ajar Switch (PT44) | BK | Passenger Door | (Scheme 208), (Scheme 210). |
| Passenger Heated Seat Cushion | LT GY | Passenger Seat | N/S |
| Passenger Heated Seat Switch | RED | Passenger Seat | N/S |
| Passenger Seat Airbag | YL | Passenger Seat | N/S |
| Passenger Seat Belt Switch (LHD) | BK | Lower Right B-Pillar | (Scheme 214). |
| Passenger Seat Belt Switch (RHD) | BK | Lower Left B-Pillar | (Scheme 220). |
| Passenger Seat Belt Tensioner (PT27) | YL | Right Side Body | (Scheme 215). |
| Passenger Seat Belt Tensioner (LHD) | YL | Right B-Pillar | (Scheme 214). |
| Passenger Seat Belt Tensioner (RHD) | YL | Left B-Pillar | (Scheme 220). |
| Passenger Side Impact Sensor 1 (LHD) | GY | Lower Right B-Pillar | (Scheme 214). |
| Passenger Side Impact Sensor 1 (RHD) | GY | Lower Left B-Pillar | (Scheme 220). |
| PCV Heater | BK | Rear Center of Engine Compartment | (Scheme 176), (Scheme 179). |
| Power Distribution Center | BK | Left Side of Engine Compartment | (Scheme 168), (Scheme 169), (Scheme 170), (Scheme 176), (Scheme 179). |
| Power Mirror Switch (LHD) | BK | Left Side of Instrument Panel | (Scheme 192). |
| Power Mirror Switch (RHD) | GY | Right Side of Instrument Panel | (Scheme 198). |
| Power Outlet | BK | Top of Front Console | (Scheme 194). |
| Power Seat Motor | GY | Inside Driver Seat | N/S |
| Power Seat Switch | WT | Below Driver Seat | N/S |
| Power Steering Pressure Switch | GY | Left Rear Engine Compartment | (Scheme 164), (Scheme 168). |
| Power Sunroof Module C1 | NAT | Right Side of Sunroof | (Scheme 207). |
| Power Sunroof Module C2 | BK | Sunroof | N/S |
| Power Top Motor | Trunk | (Scheme 229). | |
| Power Top Relay | BK | Trunk | (Scheme 229). |
| Power Top Switch | Left of Radio | (Scheme 194). | |
| Powertrain Control Module (1.6L) | BK | Left Rear of Engine | (Scheme 189), (Scheme 190). |
| Powertrain Control Module C1 (2.4L) | BK | Left Side Engine Compartment | (Scheme 164). |
| Powertrain Control Module C2 (2.4L) | GY | Left Side Engine Compartment | (Scheme 186), (Scheme 187). |
| Powertrain Control Module C2 (2.4L Turbo) | GY | Left Side Engine Compartment | (Scheme 188). |
| Powertrain Control Module C3 (2.4L) | WT | Left Side Engine Compartment | N/S |
| Powertrain Control Module C4 (2.4L) | GN | Left Side Engine Compartment | (Scheme 186), (Scheme 187). |
| Powertrain Control Module C4 (2.4L Turbo) | GN | Left Side Engine Compartment | (Scheme 188). |
| Radiator Fan Motor | BK | Front Center Engine Compartment | (Scheme 164), (Scheme 166), (Scheme 183). |
| Radio C1 | WT | Center of Instrument Panel | (Scheme 194). |
| Radio C2 | DK GY | Center of Instrument Panel | (Scheme 194). |
| Radio Antenna (LHD) | Right Rear Instrument Panel | (Scheme 193). | |
| Radio Antenna (RHD) | Left Rear Instrument Panel | (Scheme 197), (Scheme 219). | |
| Radio Antenna Cable | Center Instrument Panel | (Scheme 194). | |
| Radio Ground | Center Instrument Panel | N/S | |
| Rear Power Outlet | RD | Right Rear Cargo Area | (Scheme 217), (Scheme 218). |
| Rear View Mirror C1 | BK | Center Top Windshield | (Scheme 201). |
| Rear View Mirror C2 | BK | Center Top Windshield | (Scheme 202). |
| Rear Window Defogger (PT27) | Rear Window | (Scheme 229). | |
| Rear Window Defogger (PT44) | Left Rear Liftgate | (Scheme 233). | |
| Rear Window Defogger Ground (PT27) | Rear Window | (Scheme 229). | |
| Rear Window Defogger Ground (PT44) | Right Rear Liftgate | (Scheme 233). | |
| Rear Window Defogger Switch | BK | Lower Center Instrument Panel | (Scheme 194). |
| Rear Wiper Motor | LT GY | Center of Liftgate | (Scheme 231). |
| Rear Wiper Switch | GY | Lower Center Instrument Panel | (Scheme 194). |
| Remote Keyless Entry Antenna (Japan) | BK | Center of Instrument Panel | N/S |
| Remote Keyless Entry Module | BK | Upper Center Instrument Panel | (Scheme 196). |
| Right Back-Up Lamp | GY | Right Side of Rear Fascia | (Scheme 235). |
| Right City Lamp | GY | Right Front of Vehicle Near C108 | N/S |
| Right Cylinder Lock Switch | BK | Passenger Door | (Scheme 208), (Scheme 210). |
| Right Dome Lamp | Right Sports Bar | (Scheme 216). | |
| Right Door Lock Switch (PT27) | BK | Passenger Door | (Scheme 209). |
| Right Door Lock Switch (PT44) | BK | Passenger Door | (Scheme 208), (Scheme 210). |
| Right Fog Lamp | GY | Lower Right Front Fascia | (Scheme 164), (Scheme 172), (Scheme 175), (Scheme 183). |
| Right Front Door Speaker (PT27) | BK | Right Door | (Scheme 209). |
| Right Front Door Speaker (PT44) | BK | Right Door | (Scheme 208), (Scheme 210). |
| Right Front Door Window Module | BK | Center of Right Front Door | (Scheme 209). |
| Right Front Park/Turn Signal Lamp | NAT | Right Front of Vehicle | (Scheme 164), (Scheme 172). |
| Right Front Power Window Motor | BK | Right Front Door | (Scheme 208), (Scheme 210). |
| Right Front Side Marker (Export) | BK | Right Front Wheel Opening | (Scheme 164), (Scheme 172), (Scheme 183). |
| Right Front Turn Signal Lamp | NAT | Right Front of Vehicle | (Scheme 183). |
| Right Front Wheel Speed Sensor | GY | Right Front Wheel Opening | (Scheme 173), (Scheme 174), (Scheme 175), (Scheme 181). |
| Right Headlamp Leveling Module | BK | Right Front of Vehicle Near C108 | N/S |
| Right High Beam Headlamp | BK | Right Front Headlamp Assembly | (Scheme 164), (Scheme 172), (Scheme 175), (Scheme 183). |
| Right Instrument Panel Speaker | BK | Right Upper Instrument Panel | N/S |
| Right License Lamp | NAT | Right Side of Rear Fascia | (Scheme 235). |
| Right Low Beam Headlamp | GY | Right Front Headlamp Assembly | (Scheme 164), (Scheme 172), (Scheme 183). |
| Right Power Mirror (PT27) | NAT | Right Front Door | (Scheme 209). |
| Right Power Mirror (PT44) | WT | Right Front Door | (Scheme 208), (Scheme 210). |
| Right Rear Door Ajar Switch | Right C-Pillar | (Scheme 217). | |
| Right Rear Door Power Lock Motor | BK | Right Rear Door | (Scheme 211). |
| Right Rear Fog Lamp (RHD) | GY | Right Side of Rear Fascia | N/S |
| Right Rear Power Window Motor (PT27) | BK | Right Side Body | (Scheme 215). |
| Right Rear Power Window Motor (PT44) | BK | Right Rear Door | (Scheme 211). |
| Right Rear Power Window Switch | BK | Rear of Front Center Console | (Scheme 206). |
| Right Rear Speaker (PT27) | Right Side Body | (Scheme 215). | |
| Right Rear Speaker (PT44) | BK | Right Side Shelf Panel | (Scheme 217). |
| Right Rear Turn Signal Lamp | GY | In Rear Lamp Assembly | (Scheme 217), (Scheme 218). |
| Right Rear Wheel Speed Sensor | BK | Right Rear Wheel Opening | N/S |
| Right Side Impact Sensor 1 | GY | Base of Right B-Pillar | (Scheme 213). |
| Right Tail/Stop Lamp | BK | In Rear Lamp Assembly | (Scheme 217), (Scheme 218). |
| Right Turn Signal Indicator | BK | Right Side of Instrument Panel | (Scheme 196). |
| Right Visor/Vanity Lamp | BK | Right Front Headliner | (Scheme 204), (Scheme 205). |
| Satellite Radio Antenna No. 1 | Left Rear Body | (Scheme 226). | |
| Satellite Radio Antenna No. 2 | Left Rear Body | (Scheme 226). | |
| Satellite Radio Receiver | BK | Left Rear Body | (Scheme 226). |
| Sentry Key Immobilizer Module | BK | Right of Steering Column | (Scheme 191). |
| Siren | BK | Left Front Wheel Opening | (Scheme 167), (Scheme 176), (Scheme 179). |
| Speed Control Servo | BK | Right Rear Corner of Engine Compartment | (Scheme 164), (Scheme 174). |
| Speed Control Switch | YL | At Steering Wheel | N/S |
| Sunroof Motor | NAT | Right Side of Sunroof Assembly | N/S |
| Sunroof Switch | BK | Part of Overhead Console | N/S |
| Surge Solenoid | BK | Right Rear Engine Compartment | (Scheme 174). |
| Swirl Solenoid | BK | Rear Side of Engine Compartment | (Scheme 173), (Scheme 181). |
| Throttle Inlet Pressure Sensor | NAT | Right Rear Engine Compartment | (Scheme 174). |
| Throttle Inlet Pressure Solenoid (2.4L Turbo) | BK | Right Rear Engine Compartment | (Scheme 174). |
| Throttle Position Sensor | NAT | On Throttle Body | (Scheme 186), (Scheme 187). |
| Traction Control Switch | WT | Lower Center of Instrument Panel | (Scheme 194). |
| Transmission Range Indicator Illumination (PRNDL) | BK | Left Side of Transmission Selection Lever | (Scheme 206). |
| Transmission Range Sensor (2.4L) | DK GY | Front of Engine Compartment on Transmission | (Scheme 185), (Scheme 187). |
| Transmission Solenoid/Pressure Switch Assembly (2.4L) | BK | Front of Engine Compartment on Transmission | (Scheme 185), (Scheme 187). |
| Vehicle Speed Sensor (Gas) | BK | Front of Engine Compartment on Transmission | (Scheme 186), (Scheme 187), (Scheme 189), (Scheme 190). |
| Vehicle Speed Sensor (Diesel) | BK | Left Side of Engine Compartment on Engine | (Scheme 184). |
| Wastegate Solenoid | BK | Rear Side of Engine Compartment | (Scheme 173), (Scheme 174), (Scheme 181). |
CONNECTORS
| GROUND | LOCATION | FIG. |
|---|---|---|
| G100 (Gas) | Left Front Engine Compartment | (Scheme 166), (Scheme 169), (Scheme 170), (Scheme 171). |
| G100 (Diesel) | Below Passenger Seat | (Scheme 227). |
| G101 | At Battery Tray | (Scheme 169), (Scheme 170), (Scheme 171). |
| G102 | Left Front Fender | (Scheme 164), (Scheme 178), (Scheme 180). |
| G104 | Right Fender Area | (Scheme 173), (Scheme 174), (Scheme 175), (Scheme 181). |
| G105 | Left Front Inner Fender | (Scheme 166), (Scheme 177), (Scheme 178), (Scheme 180). |
| G106 | In T/O for Powertrain Control Module | (Scheme 189), (Scheme 190). |
| G200 | Center Rear of Instrument Panel | (Scheme 196). |
| G201 | Center Rear of Instrument Panel | (Scheme 192), (Scheme 198). |
| G202 | Left Kick Panel Near T/O for Airbag Control Module | N/S |
| G203 | Center Rear of Instrument Panel | (Scheme 196). |
| G300 (PT27) | Left Side Body | (Scheme 221). |
| G300 (PT44) | Left Rear Quarter | (Scheme 222), (Scheme 224). |
| G301 (PT27) | Right Side Body | (Scheme 215). |
| G301 (PT44) | Right Rear Quarter | (Scheme 217). |
GROUNDS
| SPLICE | LOCATION | FIG. |
|---|---|---|
| S100 | Near T/O for Fuel Injectors | N/S |
| S101 | Near Engine Starter Eyelet | (Scheme 185). |
| S102 | Near T/O for Inline C103 | (Scheme 185), (Scheme 186). |
| S104 | In T/O for PCM C4 | (Scheme 186), (Scheme 187), (Scheme 188). |
| S106 | Near T/O for Oxygen Sensor 1/1 Upstream | (Scheme 186). |
| S107 | Near T/O for C103, Left Side of Engine | (Scheme 187). |
| S109 | Near T/O for Camshaft Position Sensor | (Scheme 186), (Scheme 187), (Scheme 188). |
| S111 (MTX) | Near T/O for Back-up Lamp Switch | (Scheme 185), (Scheme 187). |
| S111 (EATX) | Near T/O for Input Speed Sensor | (Scheme 185), (Scheme 187). |
| S113 (LHD) | Near T/O for Brake Warning Indicator Switch | (Scheme 165), (Scheme 176). |
| S114 | In T/O for Camshaft Position Sensor | (Scheme 186), (Scheme 187). |
| S115 (Except 2.4L Turbo) | Left Engine Compartment | (Scheme 165), (Scheme 166). |
| S115 (2.4L Turbo) | In PDC | (Scheme 171). |
| S116 (1.6L) | In T/O for Left Low Beam Headlamp | (Scheme 167). |
| S117 | Near T/O for Radiator Fan Motor | (Scheme 165), (Scheme 177), (Scheme 179), (Scheme 183). |
| S118 | Left Front Engine Compartment | (Scheme 165), (Scheme 177), (Scheme 183). |
| S119 (RHD) | Near T/O for Controller Antilock Brake | (Scheme 165), (Scheme 178), (Scheme 180). |
| S119 (LHD 1.6L/Diesel) | Near T/O for Data Link Connector | (Scheme 177), (Scheme 178), (Scheme 180). |
| S120 | Near T/O for Right Headlamp Assembly | (Scheme 165), (Scheme 173), (Scheme 181), (Scheme 183). |
| S121 | Right Side Engine Compartment | (Scheme 173), (Scheme 174), (Scheme 181). |
| S122 | In T/O for Data Link Connector | (Scheme 177). |
| S123 (IN PDC) | Inside of Power Distribution Center (PDC) | (Scheme 169), (Scheme 170), (Scheme 171), (Scheme 176), (Scheme 179). |
| S124 (IN PDC) | Inside of Power Distribution Center (PDC) | (Scheme 169), (Scheme 170), (Scheme 176), (Scheme 179). |
| S125 (IN PDC) | Inside of Power Distribution Center (PDC) | (Scheme 169), (Scheme 170), (Scheme 171), (Scheme 176), (Scheme 179). |
| S126 | Near Data Link Connector | (Scheme 177), (Scheme 178), (Scheme 180). |
| S128 (LHD Diesel) | Near T/O for PCV Heater | N/S |
| S128 (Gas, RHD Diesel) | Near T/O for Powertrain Control Module - C2 | (Scheme 173). |
| S129 (IN PDC) (RHD, LHD Diesel) | Inside of Power Distribution Center (PDC) | (Scheme 169), (Scheme 170), (Scheme 171), (Scheme 176), (Scheme 179). |
| S131 | Near T/O for Powertrain Control Module - C2 | (Scheme 165), (Scheme 176), (Scheme 179). |
| S132 | Right Front Engine Compartment | (Scheme 165), (Scheme 183). |
| S134 (LHD) | Near T/O for Left Front Fog Lamp | (Scheme 165), (Scheme 177). |
| S134 (RHD) | Right Front Engine Compartment | (Scheme 165), (Scheme 173), (Scheme 183). |
| S136 | In T/O for Powertrain Control Module C2 and C4 | (Scheme 186), (Scheme 187), (Scheme 188). |
| S138 | In T/O for Siren | (Scheme 167), (Scheme 176), (Scheme 179). |
| S141 | Near T/O for EVAP Purge Solenoid | (Scheme 165), (Scheme 166), (Scheme 176), (Scheme 183). |
| S142 | Near T/O for Radiator Fan Motor | (Scheme 165), (Scheme 177), (Scheme 179), (Scheme 183). |
| S144 | Near T/O for Left Low Beam Headlamp | (Scheme 165), (Scheme 177), (Scheme 179). |
| S146 (LHD) | Near T/O for Left Low Beam Headlamp | (Scheme 177), (Scheme 179). |
| S146 (RHD) | Left Side Engine Compartment | (Scheme 165). |
| S147 (1.6L) | Near T/O for Ignition Coil | (Scheme 189). |
| S148 | Near T/O for Manifold Absolute Pressure Sensor | (Scheme 189). |
| S149 | Near T/O for Engine Control Module C1 | (Scheme 184). |
| S150 | Near Power Distribution Center | (Scheme 176), (Scheme 179). |
| S151 | Near T/O for Fuel Pressure Solenoid | (Scheme 184). |
| S152 | Near T/O for Fuel Pressure Solenoid | (Scheme 184). |
| S153 | Near T/O for C126 | (Scheme 176), (Scheme 179). |
| S154 (LHD) | Near T/O for PCV Heater | (Scheme 176). |
| S154 (RHD) | Near T/O for PCV Heater | (Scheme 183). |
| S155 | Near T/O for C122 | (Scheme 184). |
| S156 | Near T/O for Engine Control Module C1 | (Scheme 184). |
| S157 | Near T/O for Fuel Pressure Solenoid | (Scheme 184). |
| S158 | Near T/O for Mass Air Flow Sensor | (Scheme 184). |
| S159 | Near T/O for Starter Motor | (Scheme 184). |
| S160 | Near T/O for C124 | (Scheme 184). |
| S161 | Near T/O for C121 | (Scheme 184). |
| S162 | Near Engine Control Module - C2 | (Scheme 184). |
| S163 | Near Engine Control Module - C3 | (Scheme 184). |
| S164 (Diesel) | Near T/O for C128 | (Scheme 182). |
| S165 (Diesel) | Near Fusible Link | (Scheme 182). |
| S167 (Diesel) | Near T/O for C128 | (Scheme 182). |
| S168 (Diesel) | Near T/O for C128 | (Scheme 182). |
| S169 (Diesel) | Near T/O for C128 | (Scheme 182). |
| S170 (1.6L) | Near Fusible Link | N/S |
| S171 (1.6L) | Near Fusible Link | N/S |
| S172 | Front Engine Compartment | (Scheme 165). |
| S173 | Near PDC | (Scheme 165), (Scheme 171). |
| S174 (Gas) | Left Front Fender | (Scheme 167). |
| S174 (Diesel) | Right Front Fender | (Scheme 173), (Scheme 183). |
| S175 (Gas) | Right Engine Compartment | (Scheme 165). |
| S175 (Diesel) | Right Front Fender | (Scheme 165), (Scheme 173), (Scheme 181), (Scheme 183). |
| S176 (LHD Diesel) | Left Rear Engine Compartment | (Scheme 176). |
| S176 (RHD Diesel) | Near T/O for Ambient Temperature Sensor | (Scheme 183). |
| S177 | Right Top Engine | (Scheme 188). |
| S178 | Left Front Engine Compartment | (Scheme 184). |
| S179 (Export) | Near Right City Lamp | N/S |
| S180 (Export) | Near Left City Lamp | N/S |
| S191 | In PDC | (Scheme 176), (Scheme 179). |
| S192 | Near T/O for C125 | (Scheme 176), (Scheme 179). |
| S201 | Near T/O for C212 | (Scheme 191), (Scheme 196). |
| S203 | Near T/O for C212 | (Scheme 191), (Scheme 196). |
| S204 | Near T/O for A/C-Heater Control Module | (Scheme 194), (Scheme 196). |
| S205 | Near T/O for Rear Window Defogger Switch | (Scheme 194). |
| S206 | Below Steering Column | (Scheme 191). |
| S207 | Top Center Stack | (Scheme 191). |
| S208 | Below Steering Column | (Scheme 191). |
| S209 | Near T/O for Brake Shift Interlock Solenoid | (Scheme 191), (Scheme 194), (Scheme 196). |
| S211 | Near T/O for Brake Shift Interlock Solenoid | (Scheme 191), (Scheme 196). |
| S212 | Near T/O for Instrument Cluster - C1 | (Scheme 191). |
| S213 | Near T/O for Rear Window Defogger and Rear Wiper Switches | (Scheme 194). |
| S216 | In T/O for Radio | (Scheme 194). |
| S220 | Near T/O for C212 | (Scheme 191), (Scheme 196). |
| S224 | Near T/O for Brake Shift Interlock Solenoid | (Scheme 191), (Scheme 196). |
| S225 | Between T/O for Brake Shift Interlock Solenoid and Ignition Switch | (Scheme 191), (Scheme 196). |
| S226 | Between T/O for Brake Shift Interlock Solenoid and Ignition Switch | (Scheme 191). |
| S228 | Near T/O for Power Mirror Switch | (Scheme 198). |
| S232 (LHD) | In T/O for G201 | (Scheme 191), (Scheme 196). |
| S232 (RHD) | Near T/O for Rear Window Defogger Switch | (Scheme 194), (Scheme 196). |
| S233 | Near T/O for G201 | (Scheme 191), (Scheme 196), (Scheme 197). |
| S235 | In T/O for Passenger Airbag | (Scheme 191), (Scheme 193), (Scheme 196), (Scheme 197). |
| S237 (LHD) | Near T/O for Instrument Cluster C1 | (Scheme 191). |
| S239 (LHD) | Near T/O for Instrument Cluster C1 | (Scheme 191). |
| S239 (RHD) | Near T/O for Ground G200/G203 | (Scheme 196). |
| S240 | Near T/O for Ground G201 | (Scheme 191), (Scheme 196), (Scheme 198). |
| S241 | Near T/O for Ground G200/G203 | (Scheme 196). |
| S242 (RHD) | In T/O for Power Mirror Switch | (Scheme 198). |
| S244 | Near T/O for Visor/Vanity Lamp | N/S |
| S246 | Between Splices S248 and S244 | N/S |
| S247 | Near T/O for Brake Transmission Shift Interlock Solenoid | (Scheme 191), (Scheme 196). |
| S248 | Near T/O for Overhead Console | N/S |
| S249 | In T/O for Overhead Console | N/S |
| S250 | In T/O for Power Mirror Switch | N/S |
| S254 (RHD) | Near T/O for Instrument Cluster - C1 | (Scheme 191). |
| S256 | In T/O for Instrument Cluster C1 | (Scheme 191). |
| S260 | In T/O for Radio | (Scheme 194). |
| S261 | Near T/O for Instrument Cluster C1 | (Scheme 191), (Scheme 196). |
| S262 | Near T/O for Instrument Cluster C1 | (Scheme 191), (Scheme 192). |
| S301 | Front of Left Rear Wheel Housing | (Scheme 206), (Scheme 212), (Scheme 219). |
| S302 | In Trough Near Left Rear Door | (Scheme 206), (Scheme 212), (Scheme 219). |
| S305 | Near T/O for Left Rear Door Ajar Switch | (Scheme 206), (Scheme 212), (Scheme 213), (Scheme 219). |
| S306 | Near T/O for License Lamp | N/S |
| S307 | Near T/O for Left Rear Door Ajar Switch | (Scheme 206), (Scheme 212), (Scheme 213), (Scheme 219). |
| S308 | Near T/O for License Lamp | N/S |
| S309 | Near T/O for Left Front Door Lock Switch | (Scheme 208), (Scheme 210). |
| S310 | Near T/O for Rear Window Defogger (Ground) | N/S |
| S311 | Near T/O for Right Front Door Lock Switch | (Scheme 208), (Scheme 210). |
| S312 | Near T/O for Licence Lamp | N/S |
| S313 | Near T/O for Passenger Heated Seat Module | (Scheme 206), (Scheme 219). |
| S314 | Near T/O for Passenger Heated Seat Module | N/S |
| S315 | Near T/O for Passenger Heated Seat Module | N/S |
| S316 | Near T/O for Passenger Heated Seat Module | N/S |
| S320 | On Fuel Tank in T/O for Natural Vacuum Leak Detection Pump | (Scheme 228). |
| S321 | Near Left Rear Power Window Switch | (Scheme 206), (Scheme 212). |
| S322 | Center Header Near Rearview Mirror | (Scheme 202), (Scheme 205). |
| S323 | Center Header Near Rearview Mirror | (Scheme 202), (Scheme 205). |
| S324 | Center Header Near Rearview Mirror | (Scheme 202), (Scheme 205). |
| S325 | Right Rear Body | (Scheme 215). |
| S326 | Right Rear Body | (Scheme 215). |
| S327 | Lower Decklid | (Scheme 232). |
| S328 | Left Front Door | (Scheme 209). |
| S329 | Right Front Door | (Scheme 209). |
| S330 | Left Front Door | (Scheme 209). |
| S331 | Right Front Door | (Scheme 209). |
| S332 | Left Front Door | (Scheme 209). |
| S333 | Right Front Door | (Scheme 209). |
| S334 | Left Front Door | (Scheme 209). |
| S335 | Right Front Door | (Scheme 209). |
| S336 | Left Front Door | (Scheme 209). |
SPLICES
