Ignition Control: Removal & Installation Chrysler Pacifica CS

INSTALLATION

1. Install the bolt to capacitor. see scheme 23 Make sure that the ground strap is in place.
2. Tighten bolt.
3. Install the electrical connector to capacitor.
4. Connect the negative battery cable.

REMOVAL

Failure to route the cables properly could cause the radio to reproduce ignition noise, cross ignition of the spark plugs or short circuit the cables to ground.

Remove spark plug cable from coil first.

Always remove the spark plug cable by grasping the top of the spark plug insulator, turning the boot 1/2 turn and pulling straight up in a steady motion.

Failure to route the cables properly could cause the radio to reproduce ignition noise, cross ignition of the spark plugs or short circuit the cables to ground. Install spark plug insulators over spark plugs. Ensure the top of the spark plug insulator covers the upper end of the spark plug tube, then connect the other end to coil pack.

The ignition switch attaches to the lock cylinder housing on the end opposite the lock cylinder. For ignition switch terminal and circuit identification, refer to SYSTEM WIRING DIAGRAMS .

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Disconnect negative cable from battery.
2. Remove the Knee Blocker Airbag, «(Refer to ELECTRICAL/RESTRAINTS/KNEE BLOCKER AIRBAG - REMOVAL)»(ref-245421-S08642355362006110200000).
3. Remove the Instrument Panel Center Bezel, «(Refer to BODY/INSTRUMENT PANEL/INSTRUMENT PANEL CENTER BEZEL - REMOVAL)»(ref-245423-S18120095492006110200000)
4. Remove the 2 switch mounting nuts. (Scheme 8)
5. Loosen the rear mounting nut. (Scheme 9) 1 - Switch Assembly 2 - Rear Mounting Nut 3 - Interlock Cable
6. Slide the assembly rearward. 1 - SKREEM Module 2 - Ignition Switch
7. Disconnect the electrical connector from the ignition Switch and SKREEM Module. (Scheme 10)
8. Remove the interlock cable by depressing the locking tab and pulling straight out. (Scheme 11) 1 - Retaining Tab for Cable
9. Interlocking cable removed. (Scheme 12)
10. Remove ignition switch mounting screw. (Scheme 13)
11. Squeeze the 2 locking tabs to remove ignition switch from the lockhousing. (Scheme 13)

Scheme 13

The ignition switch attaches to the lock cylinder housing on the end opposite the lock cylinder. For ignition switch terminal and circuit identification, refer to SYSTEM WIRING DIAGRAMS .

Scheme 14

1. A tab on the ignition switch indexes to a notch in the lock cylinder housing. Also, a slot in the end of the ignition switch fits over the shaft in the end of the lock cylinder housing. Use the ignition key to rotate the lock cylinder to align the ignition switch with lock cylinder housing.
2. Tighten the mounting screw, refer to the «TORQUE»(ref-245456-S19734689782006110200000) chart for specification.
3. Attach electrical connector to SKREEM Module.
4. Attach electrical connector to ignition switch.
5. Install the interlock cable into the switch assembly. (Scheme 11)
6. Install switch assembly into Instrument Panel. (Scheme 14) Make sure that the rear mounting nut is in the correct position. (Scheme 8)and (Scheme 9).
7. Tighten the 3 mounting nuts, refer to the «TORQUE»(ref-245456-S19734689782006110200000) chart for torque specification.
8. Install the Instrument Panel Center Bezel, «(Refer to BODY/INSTRUMENT PANEL/INSTRUMENT PANEL CENTER BEZEL - INSTALLATION)»(ref-245423-S12488567262006110200000).
9. Install the Knee Blocker Airbag, «(Refer to ELECTRICAL/RESTRAINTS/KNEE BLOCKER AIRBAG - INSTALLATION)»(ref-245421-S08151036822006110200000).
10. Connect the negative battery cable.

Scheme 15

Scheme 16

1. Disconnect the negative battery cable.
2. Remove bezel ignition switch ring.
3. Pull center console bezel loose from instrument panel. (Scheme 15)
4. Insert ignition key and turn to the "ON" position.
5. Depress the locking tab on the ignition switch housing. (Scheme 16)
6. Pull the key cylinder from the ignition switch housing. (Scheme 17)

Scheme 17

1. Install key in lock cylinder. Turn key to "ON" position (retaining tab on lock cylinder can be depressed). see scheme 45
2. The shaft at the end of the lock cylinder aligns with the socket in the end of the housing. To align the socket with the lock cylinder, ensure the socket is in the "ON" position.
3. Align the lock cylinder with the grooves in the housing. Slide the lock cylinder into the housing until the tab sticks through the opening in the housing.
4. Turn key to Off position and remove key. see scheme 46
5. Install center console bezel to instrument panel. see scheme 47
6. Install bezel ignition switch ring.
7. Connect the negative battery cable.
