FRONT UPPER FASCIA
For Front Upper Fascia Procedures (Refer to FRAME & BUMPERS/BUMPERS/FRONT FASCIA - REMOVAL) and (Refer to FRAME & BUMPERS/BUMPERS/FRONT FASCIA - INSTALLATION) .
FRAME DIMENSIONS
Frame dimensions are listed in metric scale. All dimensions are from center to center of Principal Locating Point (PLP), or from center to center of PLP and fastener location.
VEHICLE PREPARATION
Position the vehicle on a frame alignment rack, refer to instructions provided with equipment being used. Adjust the vehicle PLP heights to the specified dimension above the work surface (datum line). Vertical dimensions can be taken from the datum line to the locations indicated were applicable.
| DESCRIPTION | FIGURE |
|---|---|
| FRAME | (Scheme 87) |
| ENGINE COMPARTMENT | (Scheme 88) |
| ENGINE CRADLE AND BODY DIMENSIONS | (Scheme 89) |
| ENGINE CRADLE CROSSMEMBER HEIGHT DIMENSIONS | (Scheme 90) |
| REAR CROSSMEMBER HEIGHT DIMENSIONS | (Scheme 91) |
