Message Systems: Removal & Installation Chrysler Pacifica CS

REMOVAL - OVERHEAD CONSOLE

1. Disconnect and isolate the negative battery cable.
2. Open the storage bin and remove the T10 overhead console retaining screw.
3. Using your fingertips, grasp the sides of the overhead console and pull down and rearward evenly to disengage the unit.
4. Lower the overhead console far enough to access the wire harness connectors.
5. Disconnect the electronic module and the reading/courtesy lamps electrical connector.
6. Remove the overhead console from the vehicle.

Scheme 21

1. Remove the overhead console from the vehicle «(Refer to ELECTRICAL/OVERHEAD CONSOLE - REMOVAL)»(ref-245436-S14588370902006110200000).
2. Remove the two module retaining screws. (Scheme 21) 1 - Overhead Console Housing 2 - CMTC Module Retaining Screws 3 - Module Electrical Connector 4 - CMTC Module
3. Disconnect the module electrical connector. Depress the connector retaining tab and pull straight apart.
4. Remove the module from the overhead console.

INSTALLATION

1. Position the overhead console in the vehicle.
2. Connect the electronic module and the reading/courtesy lamps electrical connector.
3. Position the overhead console and install the overhead console retaining screw, located in the storage bin. Torque the screw to 1.2 N.m (10 in. lbs.).
4. Connect the negative battery cable.

Scheme 22

REMOVAL

1. Disconnect and isolate the battery negative cable.
2. Remove the front grille assembly from the vehicle. Refer to «GRILLE»(ref-245423-S39019002332006110200000) for the procedure.
3. Disconnect the sensor electrical connector. Depress the connector retaining tab and pull the connector straight off the ambient temperature sensor.
4. Remove the sensor retaining screw and remove the sensor from the vehicle.

1. Install the sensor and connect the sensor electrical connector.
2. Install the front grille assembly on the vehicle. Refer to «GRILLE»(ref-245423-S39019002332006110200000) for the procedure.
3. Connect the battery negative cable.

1. Disconnect and isolate the battery negative cable.
2. Remove overhead console. Refer to Overhead Console. «(Refer to ELECTRICAL/OVERHEAD CONSOLE - REMOVAL)»(ref-245436-S14588370902006110200000) .
3. Remove the screws holding the compass mini-trip computer (CMTC) module in the overhead console.
4. Disconnect the CMTC module electrical connector.
5. Remove CMTC module from console assembly.

Note. If the CMTC module is being replaced, the tire pressure monitoring system must be retrained. Refer to the TIRES/WHEELS detailed instructions.

1. Position the CMTC module in the overhead console and connect the electrical connector.
2. Install the screws holding the CMTC module in the overhead console.
3. Install the overhead console. «(Refer to ELECTRICAL/OVERHEAD CONSOLE - INSTALLATION)»(ref-245436-S26142799452006110200000) .
4. Connect the battery negative cable.

Note. If the CMTC module is being replaced, the tire pressure monitoring system must be retrained. Refer to TIRES/WHEELS for detailed instructions.

Note. If a new CMTC module has been installed, the compass will have to be calibrated and the variance set. Refer to STANDARD PROCEDURE - COMPASS VARIATION ADJUSTMENT .
