Connector Pin-Outs Chrysler Crossfire I final

A/C Compressor Clutch Connector End View

A/C COMPRESSOR CLUTCH - BLACK 1-WAY CAV CIRCUIT FUNCTION 1 18BL/DG A/C COMPRESSOR CLUTCH CONTROL

Scheme 44

A/C Heater Control Module Connector End View

A/C HEATER CONTROL MODULE - BLACK 29-WAY CAV CIRCUIT FUNCTION 1 18RD/YL FUSED B(+) 2 - - 3 20BR/YL SENSOR GROUND 4 22DG/BK REAR DEFOGGER INDICATOR DRIVER 5 22BK/WT SERIAL COMMUNICATION K2 6 - - 7 20WT/PK BLOWER MOTOR CONTROL 8 20BR/DG COOLANT CIRCULATION PUMP CONTROL 9 20BR/VT LEFT COOLANT CIRCULATION VALVE CONTROL 10 20BR/RD RIGHT COOLANT CIRCULATION VALVE CONTROL 11 - - 12 16BR GROUND 13 22DG/BL REAR DEFOGGER SWITCH SENSE 14 22RD/WT A/C PRESSURE SENSOR 5 VOLT SUPPLY 15 - - 16 18BR/YL RECIRCULATED AIR SWITCHOVER VALVE CONTROL 17 22BK/BL SCI TRANSMIT 18 22YL/VT SERIAL COMMUNICATION K1 19 - - 20 18BL/DG A/C COMPRESSOR CLUTCH CONTROL 21 18PK/RD/BL FUSED IGNITION SWITCH OUTPUT 22 20BK/DG FUSED IGNITION SWITCH OUTPUT 23 - - 24 22GY/RD EVAPORATOR TEMPERATURE SENSOR SIGNAL 25 22GY/DG RIGHT HEATER CORE TEMPERATURE SENSOR SIGNAL 26 22GY/PK LEFT HEATER CORE TEMPERATURE SENSOR SIGNAL 27 22BL/RD A/C PRESSURE SENSOR SIGNAL 28 - - 29

Scheme 45

A/C Pressure Sensor Connector End View

A/C PRESSURE SENSOR - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18BR/YL SENSOR GROUND 2 18BL/RD A/C PRESSURE SENSOR SIGNAL 3 18RD/WT A/C PRESSURE SENSOR 5 VOLT SUPPLY

Accelerator Pedal Position Sensor Connector End View

ACCELERATOR PEDAL POSITION SENSOR - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 20YL/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT SUPPLY 2 - - 3 20OR SENSOR GROUND 4 20DG ACCELERATOR PEDAL POSITION SENSOR SIGNAL NO. 2 5 20GY ACCELERATOR PEDAL POSITION SENSOR SIGNAL NO. 1 6 20BK SENSOR GROUND

Scheme 46

Air Pump Connector End View

AIR PUMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 12RD/WT AIR PUMP RELAY OUTPUT 2 14BR GROUND

Scheme 47

Air Pump Switchover Solenoid Connector End View

AIR PUMP SWITCHOVER SOLENOID - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20GY/BR AIR PUMP SWITCHOVER SOLENOID CONTROL 2 20RD/DG FUSED ENGINE CONTROL RELAY OUTPUT

Airbag Off Indicator Lamp Connector End View

AIRBAG OFF INDICATOR LAMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BK AIRBAG OFF INDICATOR DRIVER 2 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT

Scheme 48

Ambient Temperature Sensor Connector End View

AMBIENT TEMPERATURE SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20DG AMBIENT TEMPERATURE SENSOR SIGNAL 2 20BR SENSOR GROUND

Antenna (Roadster Convertible) Connector End View (C1)

ANTENNA C1 - BLACK 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 - - 2 18BL/DG ENABLE SIGNAL TO AMPLIFIER

Scheme 49

Antenna (Coupe) Connector End View (C1)

ANTENNA C1 - BLACK 1-WAY (ZH29) CAV CIRCUIT FUNCTION 1 18BL/DG ENABLE SIGNAL TO AMPLIFIER

Antenna Connector End View (C2)

ANTENNA C2 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 24BK ANTENNA 2 BK SHIELD

Scheme 50

Anti Theft Tow Sensor Connector End View

ANTI-THEFT TOW SENSOR - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 22DG/GY SENSOR GROUND 5 18BR/DG ANTI-THEFT TOW SENSOR SIGNAL 6 18RD/GY FUSED B(+)

Scheme 51

Ash Receiver Lamp Connector End View

ASH RECEIVER LAMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY FUSED ILLUMINATION CONTROL MODULE OUTPUT 2 18GY FUSED ILLUMINATION CONTROL MODULE OUTPUT

Scheme 52

Backup Lamp Switch Connector End View

BACKUP LAMP SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20PK/RD FUSED IGNITION SWITCH OUTPUT 2 20GY/YL BACKUP LAMP SWITCH OUTPUT

Scheme 53

Base Brake Booster Connector End View (C1)

BAS BRAKE BOOSTER C1 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20PK/YL 5 VOLT SUPPLY 2 20VT/DG BAS TRAVEL SENSOR SIGNAL 3 20YL/DG SENSOR GROUND

Scheme 54

Base Brake Booster Connector End View (C2)

BAS BRAKE BOOSTER C2 - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 20GY BAS RELEASE SWITCH SENSOR (RELEASED) 2 20PK 12 VOLT SUPPLY 3 18YL/VT BAS RELEASE SWITCH SENSOR (APPLIED) 4 18DG/BL 5 VOLT SUPPLY 5 20BK/VT BAS CONTROL 6

Scheme 55

Blower Motor Resistor Connector End View

BLOWER MOTOR RESISTOR - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 14BR BLOWER MOTOR GROUND 2 20WT/PK BLOWER MOTOR CONTROL 3 14RD FUSED B(+)

Scheme 56

Body Control Module Connector End View (C1)

BODY CONTROL MODULE C1 - BLACK 2-WAY CAV CIRCUIT FUNCTION 50 20RD 12 VOLT SUPPLY 67 20BR CONTROL MODULE COOLING FAN CONTROL

Body Control Module Connector End View (C2)

BODY CONTROL MODULE C2 - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 14RD WIPER LOW SPEED CONTROL 2 14DG WIPER HIGH SPEED CONTROL 40 14WT WIPER PARK SWITCH SENSE 41 14BK 12 VOLT SUPPLY

Scheme 57

Body Control Module Connector End View (C3)

BODY CONTROL MODULE C3 - BLACK 9-WAY CAV CIRCUIT FUNCTION 45 16BK/BL TURN SIGNAL MONITORED GROUND 46 16BK/YL HAZARD SWITCH SIGNAL 47 22DG/BL REAR DEFOGGER SWITCH SENSE 48 22DG/BK REAR DEFOGGER INDICATOR DRIVER 49 20WT/DG DOOR LOCK SWITCH MUX 63 16GY WASHER PUMP MOTOR CONTROL 64 - - 65 18BL WIPER SWITCH MUX 66

Body Control Module Connector End View (C4)

BODY CONTROL MODULE C4 - BLACK 63-WAY CAV CIRCUIT FUNCTION 3 12PK/YL/DG FUSED IGNITION SWITCH OUTPUT 4 14RD/WT FUSED B(+) 5 12BR GROUND 6 - - 7 - - 8 - - 9 - - 10 14BK/WT RIGHT FRONT POWER WINDOW DRIVER (DOWN) 11 14DG/WT RIGHT FRONT POWER WINDOW DRIVER (UP) 12 14BK LEFT FRONT POWER WINDOW DRIVER (DOWN) 13 14DG LEFT FRONT POWER WINDOW DRIVER (UP) 14 16BR/WT REAR SPOILER DRIVER (UP) 15 16RD/WT REAR SPOILER DRIVER (DOWN) 16 - - 17 - - 18 18BL/BR DOME LAMP CONTROL 19 - - 20 - - 21 20BK/VT INSTRUMENT CLUSTER WAKE UP SIGNAL 22 - - 23 - - 24 - - 25 - - 26 - - 27 - - 28 20BR/GY SPOILER LIMIT SWITCH SIGNAL (UP) 29 20BR/YL SPOILER LIMIT SWITCH SIGNAL (DOWN) 30 20BK/DG ESP OFF SIGNAL 31 - - 32 - - 33 - - 34 20BK/WT SCI TRANSMIT 35 - - 36 - - 37 - - 38 20WT/BL RIGHT POWER WINDOW SWITCH SENSE 39 20DG/YL LEFT POWER WINDOW SWITCH SENSE 42 14BR GROUND 43 14BR GROUND 44 12RD/YL FUSED B(+) 51 - - 52 - - 53 - - 54 - - 55 22GY/BK DOOR UNLOCK SWITCH SENSE 56 20BL/DG WHEEL SPEED SENSOR OUTPUT 57 22BK/RD DOOR LOCK SWITCH SENSE 58 18PK/RD/BK FUSED IGNITION SWITCH OUTPUT 59 22GY/RD RKE STATUS OUTPUT 60 - - 61 16BR GROUND 62 20DG CAN B BUS (-) (ZH27) 62 22DG CAN B BUS (-) (ZH29) 68 20GY/WT REAR SPOILER DIAGNOSTIC LED CONTROL 69 - - 70 - - 71 20DG/WT REAR SPOILER SWITCH SENSE 72 - - 73 - - 74 20DG/WT WHEEL SPEED SENSOR OUTPUT 75 20RD/GY FUSED B(+) 76 - - 77 20BR GROUND 78 20WT CAN B BUS (+) (ZH27) 78 22WT CAN B BUS (+) (ZH29)

Brake Fluid Level Switch Connector End View

BRAKE FLUID LEVEL SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/WT BRAKE FLUID LEVEL SWITCH SENSE

Scheme 58

Brake Lamp Relay Connector End View

BRAKE LAMP RELAY - YELLOW 9-WAY CAV CIRCUIT FUNCTION 1 - - 2 18BK/RD BRAKE LAMP RELAY OUTPUT 3 - - 4 18RD/WT FUSED IGNITION SWITCH OUTPUT 4 18BK/WT FUSED IGNITION SWITCH OUTPUT 5 - - 6 20BK/YL BRAKE LAMP RELAY CONTROL 7 - - 8 18BK/WT FUSED IGNITION SWITCH OUTPUT 9

Scheme 59

Brake Lamp Switch (A/T) Connector End View

BRAKE LAMP SWITCH - BLACK 3-WAY (A/T) CAV CIRCUIT FUNCTION 1 - - 2 20RD/YL TRACTION SYSTEM RELAY OUTPUT 3 20RD/BL BTSI FEED

Scheme 60

Inline Connector End View (C100 )

C100 - NATURAL 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 18BK/WT LEFT TAIL LAMP OUTPUT 1 18BK/WT LEFT TAIL LAMP OUTPUT (EXPORT) 2 18BK/DG RIGHT TAIL LAMP OUTPUT 2 18BK/DG RIGHT TAIL LAMP OUTPUT (EXPORT) 3 22GY/BK DOOR UNLOCK SWITCH SENSE 4 22GY/RD RKE STATUS OUTPUT 5 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT (ZH27) 6 18PK/RD/WT FUSED B(+) (ZH27) 7 20WT/DG CAN INTERIOR BUS (125K) (+) 7 20WT/DG CAN INTERIOR BUS (125K) (+) 8 20BK/DG CAN INTERIOR BUS (125K) (-) 8 20BK/DG CAN INTERIOR BUS (125K) (-)

Scheme 61

C100 - NATURAL 8-WAY MALE CAV CIRCUIT FUNCTION 1 18BK/WT LEFT TAIL LAMP OUTPUT 2 18BK/DG RIGHT TAIL LAMP OUTPUT 3 22GY/BK DOOR UNLOCK SWITCH SENSE 4 22GY/RD RKE STATUS OUTPUT 5 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT (ZH27) 6 18PK/RD/WT FUSED B(+) (ZH27) 7 20BK/YL CAN INTERIOR BUS (125K) (+) 8 20BK/DG CAN INTERIOR BUS (125K) (-)

Scheme 62

Inline Connector End View (C105 )

C105 - BLACK 4-WAY FEMALE CAV CIRCUIT FUNCTION 1 18BR/RD HOOD AJAR SWITCH SENSE 2 20YL/RD SIREN SIGNAL OUTPUT 3 - - 4

C105 - BLACK 4-WAY MALE CAV CIRCUIT FUNCTION 1 18BR/RD HOOD AJAR SWITCH SENSE 2 20YL/RD SIREN SIGNAL OUTPUT 3 - - 4

Scheme 63

Inline Connector End View (C106 )

C106 - BLACK 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 20BR/VT AIR PUMP RELAY CONTROL 2 - - 3 18BL/DG A/C COMPRESSOR CLUTCH CONTROL 4 16BK/YL FUSED IGNITION SWITCH OUTPUT 5 18BL LOW BATTERY INDICATOR OUTPUT 6 14VT STARTER SOLENOID OUTPUT 7 - - 8

Scheme 64

C106 - BLACK 8-WAY MALE CAV CIRCUIT FUNCTION 1 20BR/VT AIR PUMP RELAY CONTROL 2 - - 3 18BL/DG A/C COMPRESSOR CLUTCH CONTROL 4 16BK/YL FUSED IGNITION SWITCH OUTPUT 5 20BL LOW BATTERY INDICATOR OUTPUT 6 14VT/WT STARTER SOLENOID OUTPUT 7 - - 8

Scheme 65

Inline Connector End View (C200 )

C200 - BLACK 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 18BK/DG RIGHT TURN SIGNAL OUTPUT 1 18BK/DG RIGHT TURN SIGNAL OUTPUT (EUROPE) 2 16VT FUSED IGNITION SWITCH OUTPUT 2 20VT FUSED IGNITION SWITCH OUTPUT 3 18BK/WT LEFT TURN SIGNAL OUTPUT 3 18BK/WT LEFT TURN SIGNAL OUTPUT (EUROPE) 4 22BK/BL SCI TRANSMIT 4 20BK/BL SCI TRANSMIT (EXCEPT EXPORT) 5 18RD/DG FUSED B(+) 6 20RD/YL SCI TRANSMIT 7 - - 8

Scheme 66

C200 - BLACK 8-WAY MALE CAV CIRCUIT FUNCTION 1 18BK/DG RIGHT TURN SIGNAL OUTPUT 2 16VT FUSED IGNITION SWITCH OUTPUT 3 18BK/WT LEFT TURN SIGNAL OUTPUT 4 22BK/BL SCI TRANSMIT 4 22BK/BL SCI TRANSMIT 5 18RD/DG FUSED B(+) 5 18RD/DG FUSED B(+) 6 22RD/YL SCI TRANSMIT 6 22RD/YL SCI TRANSMIT 7 - - 8

Scheme 67

Inline Connector End View (C201 )

C201 - BLACK 18-WAY FEMALE CAV CIRCUIT FUNCTION 1 20DG S-CAN (-) 2 20WT S-CAN (+) 3 20RD/DG 5 VOLT SUPPLY 4 20BR SENSOR GROUND 5 20BL/YL STEERING ANGLE SENSOR SIGNAL 6 20BK/DG ESP OFF SIGNAL 7 20GY/YL BACKUP LAMP SWITCH OUTPUT (M/T) 8 20BL LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 9 20BR LEFT REAR WHEEL SPEED SENSOR SIGNAL 10 20YL RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 11 20BR RIGHT REAR WHEEL SPEED SENSOR SIGNAL 12 20BK/BL ESP OFF SWITCH SENSE 13 20DG/VT PARK BRAKE SWITCH SENSE 14 20BL/DG WHEEL SPEED SENSOR OUTPUT 15 20DG/VT PARK BRAKE SWITCH SENSE 16 20BK/YL BRAKE LAMP RELAY CONTROL 17 - - 18 20DG/BK ENHANCED ACCIDENT REPORT DRIVER

C201 - BLACK 18-WAY MALE CAV CIRCUIT FUNCTION 1 20DG S-CAN (-) 2 20WT S-CAN (+) 3 20RD/DG 5 VOLT SUPPLY 4 20BR SENSOR GROUND 5 20BL/YL STEERING ANGLE SENSOR SIGNAL 6 20BK/DG ESP OFF SIGNAL 7 20GY/YL BACKUP LAMP SWITCH OUTPUT (M/T) 8 20BL LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 9 20BR LEFT REAR WHEEL SPEED SENSOR SIGNAL 10 20YL RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 11 20BR RIGHT REAR WHEEL SPEED SENSOR SIGNAL 12 20BK/BL ESP OFF SWITCH SENSE 13 20DG/VT PARK BRAKE SWITCH SENSE 14 20BL/DG WHEEL SPEED SENSOR OUTPUT 15 20DG/VT PARK BRAKE SWITCH SENSE 16 20BK/YL BRAKE LAMP RELAY CONTROL 17 - - 18 20DG/BK ENHANCED ACCIDENT REPORT DRIVER

Inline Connector End View (C206 )

C206 - BLACK 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 22BK/RD DOOR LOCK SWITCH SENSE 2 20BL DRIVER CYLINDER LOCK SWITCH SENSE (LOCK) 3 20BK DRIVER CYLINDER LOCK SWITCH SENSE (UNLOCK) 4 20BR/GY GLOVE BOX SWITCH SENSE 5 20BK/WT SCI TRANSMIT 5 22BK/WT SCI TRANSMIT 6 18PK/RD/BK FUSED IGNITION SWITCH OUTPUT 7 22RD/YL SCI TRANSMIT 8 20DG SCI TRANSMIT

Scheme 68

C206 - BLACK 8-WAY MALE CAV CIRCUIT FUNCTION 1 22BK/RD DOOR LOCK SWITCH SENSE 2 20BL DRIVER CYLINDER LOCK SWITCH SENSE (LOCK) 3 20BK DRIVER CYLINDER LOCK SWITCH SENSE (UNLOCK) 4 20BR/GY GLOVE BOX SWITCH SENSE 5 20BK/WT SCI TRANSMIT 6 18PK/RD/BK FUSED IGNITION SWITCH OUTPUT 7 22RD/YL SCI TRANSMIT (A/T) 8 20DG SCI TRANSMIT (A/T) 8 22DG SCI TRANSMIT (A/T)

Scheme 69

Inline (A/T) Connector End View (C207)

C207 - BLACK 4-WAY (A/T) FEMALE CAV CIRCUIT FUNCTION 1 18RD/DG TRACTION SYSTEM RELAY OUTPUT 2 20DG/WT WHEEL SPEED SENSOR OUTPUT 3 20WT CAN C BUS (+) 4 20DG CAN C BUS (-)

C207 - BLACK 4-WAY (A/T) MALE CAV CIRCUIT FUNCTION 1 18RD/DG TRACTION SYSTEM RELAY OUTPUT 1 20RD/DG TRACTION SYSTEM RELAY OUTPUT 2 20DG/WT WHEEL SPEED SENSOR OUTPUT 3 22WT CAN C BUS (+) 4 22DG CAN C BUS (-)

Scheme 70

Inline Connector End View (C208 )

C208 - YELLOW 5-WAY CAV CIRCUIT FUNCTION 1 20VT DRIVER SQUIB 1 LINE 1 2 20DG DRIVER SQUIB 1 LINE 2 3 - - 4 20BL DRIVER SQUIB 2 LINE 2 5 20BK DRIVER SQUIB 2 LINE 1

Scheme 71

C208 - 5-WAY

Inline Connector End View (C210 )

C210 - YELLOW 5-WAY FEMALE CAV CIRCUIT FUNCTION 1 20BL/DG PASSENGER SQUIB LINE 2 2 20BR/DG PASSENGER SQUIB LINE 1 3 - - 4 20BL/WT PASSENGER KNEE BLOCKER SQUIB LINE 2 5 20BR/WT PASSENGER KNEE BLOCKER SQUIB LINE 1

Scheme 72

C210 - 5-WAY MALE

Inline Connector End View (C211 )

C211 - NATURAL 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 20DG/WT WHEEL SPEED SENSOR OUTPUT 2 18BR/DG OXYGEN SENSOR 2/2 HEATER CONTROL 3 16RD/WT FUSED B(+) 4 18BR/WT OXYGEN SENSOR 1/2 HEATER CONTROL 5 18BR SENSOR GROUND 6 20YL/BK OXYGEN SENSOR 1/2 SIGNAL 7 20YL/DG OXYGEN SENSOR 2/2 SIGNAL 8 16RD/DG FUSED ENGINE CONTROL RELAY OUTPUT

Scheme 73

C211 - NATURAL 8-WAY MALE CAV CIRCUIT FUNCTION 1 20DG/WT WHEEL SPEED SENSOR OUTPUT 2 18BR/DG OXYGEN SENSOR 2/2 HEATER CONTROL 3 14RD/WT FUSED B(+) 4 18BR/WT OXYGEN SENSOR 1/2 HEATER CONTROL 5 20BR SENSOR GROUND 5 20BR SENSOR GROUND 6 20YL/BK OXYGEN SENSOR 1/2 SIGNAL 7 20YL/DG OXYGEN SENSOR 2/2 SIGNAL 8 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 8 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT

Scheme 74

Inline Connector End View (C219 )

C219 - BLUE 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 20BK/RD 5 VOLT SUPPLY (EXCEPT EXPORT) 2 20BR/YL SENSOR GROUND (EXCEPT EXPORT) 2 20BR/YL SENSOR GROUND (EXCEPT EXPORT) 3 20DG FUEL TANK PRESSURE SENSOR SIGNAL (EXCEPT EXPORT) 3 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXPORT) 4 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT (EXCEPT EXPORT) 5 18BR/BL CHARCOAL CANISTER SHUTOFF VALVE CONTROL (EXCEPT EXPORT) 6 16RD/GY DRIVER SEAT BELT SWITCH SENSE (EXCEPT EXPORT) 7 - - 8 20BK/BL SCI TRANSMIT

Scheme 75

C219 - BLUE 8-WAY MALE CAV CIRCUIT FUNCTION 1 20BK/RD 5 VOLT SUPPLY (EXCEPT EXPORT) 2 20BR/YL SENSOR GROUND (EXCEPT EXPORT) 3 20DG FUEL TANK PRESSURE SENSOR SIGNAL (EXCEPT EXPORT) 3 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXPORT) 4 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT (EXCEPT EXPORT) 5 18BR/BL CHARCOAL CANISTER SHUTOFF VALVE CONTROL (EXCEPT EXPORT) 6 16RD/GY DRIVER SEAT BELT SWITCH SENSE (EXCEPT EXPORT) 7 - - 8 20BK/BL SCI TRANSMIT

Scheme 76

Inline Connector End View (C223 )

C223 - BLACK 2-WAY FEMALE CAV CIRCUIT FUNCTION 1 20BL/RD LEFT SIDE SQUIB LINE 2 2 20BL/GY LEFT SIDE SQUIB LINE 1

Scheme 77

C223 - YELLOW 2-WAY MALE CAV CIRCUIT FUNCTION 1 20BL/RD LEFT SIDE SQUIB LINE 2 2 20BL/GY LEFT SIDE SQUIB LINE 1

Scheme 78

Inline Connector End View (C224 )

C224 - BLACK 2-WAY FEMALE CAV CIRCUIT FUNCTION 1 20BL/BK RIGHT SIDE SQUIB LINE 1 2 20BL/WT RIGHT SIDE SQUIB LINE 2

Scheme 79

C224 - YELLOW 2-WAY MALE CAV CIRCUIT FUNCTION 1 20BL/RD RIGHT SIDE SQUIB LINE 1 2 20BL/GY RIGHT SIDE SQUIB LINE 2

Scheme 80

Inline Connector End View (C226 )

C226 - 18-WAY FEMALE CAV CIRCUIT FUNCTION 1 18GY WASHER PUMP MOTOR CONTROL 2 20BR/VT LEFT COOLANT CIRCULATION VALVE CONTROL 3 20BR/RD RIGHT COOLANT CIRCULATION VALVE CONTROL 4 20BR/DG COOLANT CIRCULATION PUMP CONTROL 5 22BL SCI TRANSMIT 6 18RD/WT A/C PRESSURE SENSOR 5 VOLT SUPPLY 7 18BL/DG A/C COMPRESSOR CLUTCH CONTROL 8 18BR/YL A/C PRESSURE SENSOR GROUND 9 18BL/RD A/C PRESSURE SENSOR SIGNAL 10 20DG/YL SCI RECEIVE 11 20BL/YL STEERING ANGLE SENSOR SIGNAL 12 - - 13 20RD/WT FUSED IGNITION SWITCH OUTPUT 14 20BR/YL SENSOR GROUND 15 - - 16 - - 17 - - 18

Scheme 81

C226 - 18-WAY MALE CAV CIRCUIT FUNCTION 1 18GY WASHER PUMP MOTOR CONTROL 2 20BR/VT LEFT COOLANT CIRCULATION VALVE CONTROL 3 20BR/RD RIGHT COOLANT CIRCULATION VALVE CONTROL 4 20BR/DG COOLANT CIRCULATION PUMP CONTROL 5 22BL SCI TRANSMIT 6 22RD/WT A/C PRESSURE SENSOR 5 VOLT SUPPLY 7 18BL/DG A/C COMPRESSOR CLUTCH CONTROL 8 20BR/YL A/C PRESSURE SENSOR GROUND 9 22BL/RD A/C PRESSURE SENSOR SIGNAL 10 20DG/YL SCI RECEIVE 11 20BL/YL STEERING ANGLE SENSOR SIGNAL 12 - - 13 20RD/WT FUSED IGNITION SWITCH OUTPUT 14 20BR/YL SENSOR GROUND 15 - - 16 - - 17 - - 18

Scheme 82

Inline Connector End View (C228 )

C228 - BLACK 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED HEATED MIRROR SUPPLY (HEATED MIRRORS) 2 18BR GROUND 3 18WT LEFT MIRROR HORIZONTAL DRIVER 4 18GY LEFT MIRROR COMMON DRIVER 5 18BK LEFT MIRROR VERTICAL DRIVER 6 20BR GROUND 7 20BL DRIVER CYLINDER LOCK SWITCH SENSE (LOCK) 8 20BK DRIVER CYLINDER LOCK SWITCH SENSE (UNLOCK)

Scheme 83

C228 - BLACK 8-WAY MALE CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED HEATED MIRROR SUPPLY (HEATED MIRRORS) 2 18BR GROUND 3 18WT LEFT MIRROR HORIZONTAL DRIVER 4 18GY LEFT MIRROR COMMON DRIVER 5 18BK LEFT MIRROR VERTICAL DRIVER 6 20BR GROUND 7 20BL DRIVER CYLINDER LOCK SWITCH SENSE (LOCK) 8 20BK DRIVER CYLINDER LOCK SWITCH SENSE (UNLOCK)

Scheme 84

Inline Connector End View (C229 )

C229 - BLACK 5-WAY FEMALE CAV CIRCUIT FUNCTION 1 18BK/BL LEFT DOOR SPEAKER (+) 1 16BK/BL LEFT DOOR SPEAKER (+) 2 18BR/DG LEFT DOOR SPEAKER (-) 2 16BR/DG LEFT DOOR SPEAKER (-) 3 14DG LEFT FRONT POWER WINDOW DRIVER (UP) 4 14BK LEFT FRONT POWER WINDOW DRIVER (DOWN) 5

Scheme 85

C229 - BLACK 5-WAY MALE CAV CIRCUIT FUNCTION 1 16BK/BL AMPLIFIED LEFT DOOR SPEAKER (+) (AMPLIFIER) 1 16WT LEFT DOOR SPEAKER (+) (EXCEPT AMPLIFIER) 2 16BR/DG AMPLIFIED LEFT DOOR SPEAKER (-) (AMPLIFIER) 2 16WT/YL LEFT DOOR SPEAKER (-) (EXCEPT AMPLIFIER) 3 14DG LEFT FRONT POWER WINDOW DRIVER (UP) 4 14BK LEFT FRONT POWER WINDOW DRIVER (DOWN) 5

Scheme 86

Inline Connector End View (C230 )

C230 - BLACK 8-WAY FEMALE CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 2 18BR GROUND 3 18WT RIGHT MIRROR VERTICAL DRIVER 4 18GY RIGHT MIRROR COMMON DRIVER 5 18BK RIGHT MIRROR HORIZONTAL DRIVER 6 - - 7 - - 8

Scheme 87

C230 - BLACK 8-WAY MALE CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 2 18BR GROUND 3 18WT RIGHT MIRROR VERTICAL DRIVER 4 18GY/VT RIGHT MIRROR COMMON DRIVER 5 18BK/VT RIGHT MIRROR HORIZONTAL DRIVER 6 - - 7 - - 8

Scheme 88

Inline Connector End View (C231 )

C231 - BLACK 5-WAY FEMALE CAV CIRCUIT FUNCTION 1 18BK/BL RIGHT DOOR SPEAKER (+) 1 16BK/BL RIGHT DOOR SPEAKER (+) 2 18BR/DG RIGHT DOOR SPEAKER (-) 2 16BR/DG RIGHT DOOR SPEAKER (-) 3 14DG RIGHT FRONT POWER WINDOW DRIVER (UP) 4 14BK RIGHT FRONT POWER WINDOW DRIVER (DOWN) 5

Scheme 89

C231 - BLACK 4-WAY MALE CAV CIRCUIT FUNCTION 1 16BK/PK AMPLIFIED RIGHT DOOR SPEAKER (+) (AMPLIFIER) 1 16YL RIGHT DOOR SPEAKER (+) (EXCEPT AMPLIFIER) 2 16BR/YL AMPLIFIED RIGHT DOOR SPEAKER (-) (AMPLIFIER) 2 16YL/BK RIGHT DOOR SPEAKER (-) (EXCEPT AMPLIFIER) 3 14DG/WT RIGHT FRONT POWER WINDOW DRIVER (UP) 4 14BK/WT RIGHT FRONT POWER WINDOW DRIVER (DOWN) 5

Scheme 90

Inline Connector End View (C240 )

C240 - BLACK 4-WAY FEMALE CAV CIRCUIT FUNCTION 1 20YL/BK LEFT FRONT IMPACT SENSOR SIGNAL 2 20BR GROUND 3 20YL/WT RIGHT FRONT IMPACT SENSOR SIGNAL 4 20BR GROUND

C240 - BLACK 4-WAY MALE CAV CIRCUIT FUNCTION 1 20YL/BK LEFT FRONT IMPACT SENSOR SIGNAL 2 20BR GROUND 3 20YL/WT RIGHT FRONT IMPACT SENSOR SIGNAL 4 20BR GROUND

Scheme 91

Inline (Roadster (Convertible)) Connector End View (C300)

C300 - NATURAL 8-WAY (ZH27) FEMALE CAV CIRCUIT FUNCTION 1 - - 2 20BR/BL LIFTGATE LOCK SWITCH SENSE (UNLOCK) 3 20BR/VT TRUNK LATCH LOCKED SIGNAL 4 20BK/VT TRUNK LATCH UNLOCKED SIGNAL 5 16BK/DG TRUNK LATCH ACTUATOR LOCK CONTROL 6 16RD/DG TRUNK LATCH ACTUATOR UNLOCK CONTROL 7 - - 8

Scheme 92

C300 - NATURAL 8-WAY (ZH27) MALE CAV CIRCUIT FUNCTION 1 - - 2 18BR/BL LIFTGATE LOCK SWITCH SENSE (UNLOCK) 2 20BR/BL LIFTGATE LOCK SWITCH SENSE (UNLOCK) 3 20BR/VT TRUNK LATCH LOCKED SIGNAL 4 20BK/VT TRUNK LATCH UNLOCKED SIGNAL 5 16BK/DG TRUNK LATCH ACTUATOR LOCK CONTROL 6 16RD/DG TRUNK LATCH ACTUATOR UNLOCK CONTROL 7 - - 8

Scheme 93

Inline (Roadster (Convertible)) Connector End View (C301)

C301 - BLACK 4-WAY (ZH27) FEMALE CAV CIRCUIT FUNCTION 1 14BK REAR WINDOW DEFOGGER GRID SUPPLY 2 20BK CARGO DIVIDER SENSE 3 20BK ROOF/CARGO DIVIDER SENSE 4

Scheme 94

C301 - BLACK 4-WAY (ZH27) MALE CAV CIRCUIT FUNCTION 1 14BK REAR WINDOW DEFOGGER GRID SUPPLY 2 20BR/BK CARGO DIVIDER SENSE 3 20BR/BL ROOF/CARGO DIVIDER SENSE 4

Inline (Roadster (Convertible)) Connector End View (C302)

C302 - BLACK 8-WAY (ZH27) FEMALE CAV CIRCUIT FUNCTION 1 16RD/WT REAR SPOILER DRIVER (DOWN) 2 16BR/WT REAR SPOILER DRIVER (UP) 3 20BR/GY SPOILER LIMIT SWITCH SIGNAL (UP) 4 20BR/YL SPOILER LIMIT SWITCH SIGNAL (DOWN) 5 20BK/BL BRAKE LAMP RELAY OUTPUT 6 18GY/VT FUSED ILLUMINATION CONTROL MODULE OUTPUT 7 18GY/YL FUSED ILLUMINATION CONTROL MODULE OUTPUT 8 14BR GROUND

Scheme 95

C302 - BLACK 8-WAY (ZH27) MALE CAV CIRCUIT FUNCTION 1 16RD/WT REAR SPOILER DRIVER (DOWN) 2 16BR/WT REAR SPOILER DRIVER (UP) 3 20BR/GY SPOILER LIMIT SWITCH SIGNAL (UP) 4 20BR/YL SPOILER LIMIT SWITCH SIGNAL (DOWN) 5 20BK/BL BRAKE LAMP RELAY OUTPUT 6 18GY/VT FUSED ILLUMINATION CONTROL MODULE OUTPUT 7 18GY/YL FUSED ILLUMINATION CONTROL MODULE OUTPUT 8 14BR GROUND

Scheme 96

Camshaft Position Sensor Connector End View

CAMSHAFT POSITION SENSOR - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20BR/DG SENSOR GROUND 2 20PK CAMSHAFT POSITION SENSOR SIGNAL 3 20RD/BL FUSED ENGINE CONTROL RELAY OUTPUT

Scheme 97

Cargo Compartment Divider Switch (Roadster (Convertible)) Connector End View

CARGO COMPARTMENT DIVIDER SWITCH - BLACK 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/BK CARGO DIVIDER SENSE

Scheme 98

Cargo Lamp Connector End View

CARGO LAMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BR/YL CARGO LAMP CONTROL 2 18RD/GY FUSED B(+)

Scheme 99

Center High Mounted Stop Lamp Connector End View

CENTER HIGH MOUNTED STOP LAMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BK/BL BRAKE LAMP RELAY OUTPUT

Central Locking Pump Module/Security System Module Connector End View (C1)

CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE C1 - WHITE 18-WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 - - 5 - - 6 - - 7 - - 8 20WT CAN B BUS (+) (ZH27) 8 22WT CAN B BUS (+) (ZH29) 9 20DG CAN B BUS (-) (ZH27) 9 22DG CAN B BUS (-) (ZH29) 10 - - 11 - - 12 - - 13 20BR/BL LIFTGATE LOCK SWITCH SENSE (UNLOCK) (ZH27) 13 20BR/YL LIFTGATE LOCK SWITCH SENSE (UNLOCK) (ZH29) 14 20BR/GY LEFT DOOR AJAR SWITCH SENSE 15 - - 16 20BR/PK RIGHT DOOR AJAR SWITCH SENSE 17 - - 18

Scheme 100

Central Locking Pump Module/Security System Module Connector End View (C2)

CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE C2 - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 14BK REAR WINDOW DEFOGGER GRID SUPPLY 2 12RD/DG FUSED B(+) 3 14BR GROUND 4 16BK/YL/WT FUSED B(+)

Central Locking Pump Module/Security System Module Connector End View (C3)

CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE C3 - BLACK 18-WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 22DG/GY SENSOR GROUND 5 18BR/RD HOOD AJAR SWITCH SENSE 6 20WT/DG TOW-AWAY ALARM SWITCH SENSE 7 20YL/RD SIREN SIGNAL OUTPUT 8 20YL INTRUSION SENSOR SIGNAL (EXPORT) 9 20BR/DG TONNEAU COVER SWITCH SENSE (ZH27) 10 - - 11 22RD/DG TOW-AWAY ALARM SWITCH LED CONTROL 12 - - 13 - - 14 - - 15 18BR/DG ANTI-THEFT TOW SENSOR SIGNAL 16 20BR/GY GLOVE BOX SWITCH SENSE 17 - - 18

Scheme 101

Central Locking Pump Module/Security System Module Connector End View (C4)

CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE C4 - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 14YL/BK FOG LAMP SWITCH OUTPUT 2 18GY/RD RIGHT TAIL LAMP OUTPUT (EXCEPT EXPORT) 2 18BK/DG RIGHT TAIL LAMP OUTPUT (EXPORT) 3 - - 4 18GY/BK LEFT TAIL LAMP OUTPUT (EXCEPT EXPORT) 4 18BK/WT LEFT TAIL LAMP OUTPUT (EXPORT)

Charcoal Canister Shutoff Valve (Except Export) Connector End View

CHARCOAL CANISTER SHUTOFF VALVE - BLACK 2-WAY (EXCEPT EXPORT) CAV CIRCUIT FUNCTION 1 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18BR/BL CHARCOAL CANISTER SHUTOFF VALVE CONTROL

Scheme 102

Cigar Lighter Connector End View

CIGAR LIGHTER - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 16BR GROUND 2 - - 3 16BK/BL FUSED IGNITION SWITCH OUTPUT

Scheme 103

Clockspring Connector End View

CLOCKSPRING - DK. GREEN 6-WAY CAV CIRCUIT FUNCTION 1 20BK DRIVER SQUIB 2 LINE 1 2 20VT DRIVER SQUIB 1 LINE 1 3 20BL DRIVER SQUIB 2 LINE 2 4 20BR HORN GROUND 5 20YL HORN RELAY CONTROL 6 20DG DRIVER SQUIB 1 LINE 2

Scheme 104

Clutch Interlock Switch Connector End View

CLUTCH INTERLOCK SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20VT FUSED IGNITION SWITCH OUTPUT 2 20VT CLUTCH INTERLOCK SWITCH OUTPUT 2 20VT CLUTCH INTERLOCK SWITCH OUTPUT

Clutch Pedal Position Switch Connector End View

CLUTCH PEDAL POSITION SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20RD/BK CLUTCH PEDAL POSITION SWITCH SIGNAL

Scheme 105

Coil On Plug 1 Connector End View

COIL ON PLUG NO. 1 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18BK COIL ON PLUG DRIVER NO. 1 2 18BK/DG FUSED IGNITION SWITCH OUTPUT 3 18BK/WT COIL ON PLUG DRIVER NO. 1

Scheme 106

Coil On Plug 2 Connector End View

COIL ON PLUG NO. 2 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18YL COIL ON PLUG DRIVER NO. 2 2 18BK/DG FUSED IGNITION SWITCH OUTPUT 3 18YL/WT COIL ON PLUG DRIVER NO. 2

Coil On Plug 3 Connector End View

COIL ON PLUG NO. 3 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18DG COIL ON PLUG DRIVER NO. 3 2 18BK/DG FUSED IGNITION SWITCH OUTPUT 3 18DG/WT COIL ON PLUG DRIVER NO. 3

Scheme 107

Coil On Plug 4 Connector End View

COIL ON PLUG NO. 4 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18BL COIL ON PLUG DRIVER NO. 4 2 18BK/YL FUSED IGNITION SWITCH OUTPUT 3 18BL/WT COIL ON PLUG DRIVER NO. 4

Scheme 108

Coil On Plug 5 Connector End View

COIL ON PLUG NO. 5 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18VT COIL ON PLUG DRIVER NO. 5 2 18BK/YL FUSED IGNITION SWITCH OUTPUT 3 18VT/WT COIL ON PLUG DRIVER NO. 5

Coil On Plug 6 Connector End View

COIL ON PLUG NO. 6 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 18GY COIL ON PLUG DRIVER NO. 6 2 18BK/YL FUSED IGNITION SWITCH OUTPUT 3 18GY/WT COIL ON PLUG DRIVER NO. 6

Scheme 109

Console Switch Group Connector End View

CONSOLE SWITCH GROUP - BLACK 11-WAY CAV CIRCUIT FUNCTION 1 18BK/WT LEFT TURN SIGNAL OUTPUT 2 18BK/DG RIGHT TURN SIGNAL OUTPUT 3 16BK/BL TURN SIGNAL MONITORED GROUND 4 20BR GROUND 5 16BK/YL HAZARD SWITCH SIGNAL 6 16RD/YL FUSED B(+) 7 16BK/WT/BL FUSED IGNITION SWITCH OUTPUT 8 20WT/DG DOOR LOCK SWITCH MUX 9 20GY/BL FUSED ILLUMINATION FEED 10 - - 11

Scheme 110

Antilock Brake Controller Connector End View

CONTROLLER ANTILOCK BRAKE - 47-WAY CAV CIRCUIT FUNCTION 1 12BK FUSED B(+) 2 20RD/YL SCI TRANSMIT 3 20YL/DG SENSOR GROUND 4 18RD/YL TRACTION SYSTEM RELAY OUTPUT 5 20VT/DG BAS TRAVEL SENSOR SIGNAL 6 20RD/DG 5 VOLT SUPPLY 7 20PK/YL 5 VOLT SUPPLY 8 - - 9 - - 10 20BL/DG WHEEL SPEED SENSOR OUTPUT 11 20WT CAN C BUS (+) 12 20BK/DG ESP OFF SIGNAL 13 - - 14 20DG/WT WHEEL SPEED SENSOR OUTPUT 15 20DG CAN C BUS (-) 16 12BR GROUND 17 18DG/BL 5 VOLT SUPPLY 18 20BK/RD/WT 5 VOLT SUPPLY 19 20BR/BL SENSOR GROUND 20 20BL/WT ESP BRAKE PRESSURE SENSOR 1 SIGNAL 21 - - 22 - - 23 20BK/YL BRAKE LAMP RELAY CONTROL 24 20BR SENSOR GROUND 25 20DG S-CAN (-) 26 - - 27 20GY BAS RELEASE SWITCH SENSOR (RELEASED) 28 20BK/VT BAS CONTROL 29 20WT S-CAN (+) 30 20PK 12 VOLT SUPPLY 31 18YL/VT BAS RELEASE SWITCH SENSOR (APPLIED) 32 12BK FUSED B(+) 33 20WT RIGHT FRONT WHEEL SPEED SENSOR SIGNAL 34 20BR RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT SUPPLY 35 - - 36 20BL LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 37 20BR LEFT REAR WHEEL SPEED SENSOR SIGNAL 38 18BR/DG BRAKE PAD WEAR INDICATOR DRIVER 39 20DG/VT PARK BRAKE SWITCH SENSE 40 20BK/BL ESP OFF SWITCH SENSE 41 - - 42 20BR RIGHT REAR WHEEL SPEED SENSOR SIGNAL 43 20YL RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 44 - - 45 20DG LEFT FRONT WHEEL SPEED SENSOR 12 VOLT SUPPLY 46 20BR LEFT FRONT WHEEL SPEED SENSOR SIGNAL 47 12BR GROUND

Scheme 111

Coolant Circulation Pump Connector End View

COOLANT CIRCULATION PUMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20RD/YL FUSED B(+) 2 20BR/DG COOLANT CIRCULATION PUMP CONTROL

Scheme 112

Coolant Circulation Valve Connector End View

COOLANT CIRCULATION VALVE - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20BR/VT LEFT COOLANT CIRCULATION VALVE CONTROL 2 20RD/YL FUSED B(+) 2 18RD/YL FUSED B(+) 3 20BR/RD RIGHT COOLANT CIRCULATION VALVE CONTROL

Scheme 113

Coolant Level Sensor Connector End View

COOLANT LEVEL SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR/BL COOLANT/WASHER LEVEL COMBINATION 2 20BR/YL COOLANT/WASHER LEVEL SIGNAL

Crankshaft Position Sensor Connector End View

CRANKSHAFT POSITION SENSOR - NATURAL 2-WAY CAV CIRCUIT FUNCTION 1 20DG CRANKSHAFT POSITION SENSOR SIGNAL 2 2 20DG/WT CRANKSHAFT POSITION SENSOR SIGNAL 1

Scheme 114

Data Link Connector, Connector End View

DATA LINK CONNECTOR - BLACK 16-WAY CAV CIRCUIT FUNCTION 1 20BK/WT SCI TRANSMIT 2 - - 3 20DG/YL SCI RECEIVE 4 18BR GROUND 5 20BR/YL SENSOR GROUND 6 - - 7 22BL SCI TRANSMIT 8 20RD/WT FUSED IGNITION SWITCH OUTPUT 9 22RD/YL SCI TRANSMIT 10 - - 11 20DG SCI TRANSMIT 12 20WT/DG CAN INTERIOR BUS (125K) (+) 13 20BK/DG CAN INTERIOR BUS (125K) (-) 14 - - 15 22BK/BL SCI TRANSMIT 16 18RD/DG FUSED B(+)

Dome Lamp Connector End View

DOME LAMP - BLACK 5-WAY CAV CIRCUIT FUNCTION 1 18BR/YL CARGO LAMP CONTROL 2 18BR GROUND 3 18BL/BR DOME LAMP CONTROL 4 18RD/GY FUSED B(+) 5

Driver Airbag Squib 1 Connector End View

DRIVER AIRBAG SQUIB 1 - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 - DRIVER SQUIB 1 LINE 2 2 - DRIVER SQUIB 1 LINE 1

Driver Airbag Squib 2 Connector End View

DRIVER AIRBAG SQUIB 2 - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 - DRIVER SQUIB 2 LINE 2 2 - DRIVER SQUIB 2 LINE 1

Scheme 115

Driver Cylinder Lock Switch (Except Europe) Connector End View

DRIVER CYLINDER LOCK SWITCH - BLACK 3-WAY (EXCEPT EUROPE) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BL DRIVER CYLINDER LOCK SWITCH SENSE (LOCK) 3 20BK DRIVER CYLINDER LOCK SWITCH SENSE (UNLOCK)

Scheme 116

Driver Knee Blocker Airbag Squib Connector End View

DRIVER KNEE BLOCKER AIRBAG SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20YL/DG DRIVER KNEE BLOCKER SQUIB LINE 2 2 20VT/BR DRIVER KNEE BLOCKER SQUIB LINE 1

Scheme 117

Driver Power Seat Connector End View

DRIVER POWER SEAT - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 14RD/BK FUSED POWER SEAT RELAY OUTPUT 2 14BR GROUND

Scheme 118

Driver Seat Belt Switch Connector End View

DRIVER SEAT BELT SWITCH - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20GY/DG DRIVER SEAT BELT SWITCH SENSE 3 20BR GROUND 4 20BR/DG DRIVER SEAT BELT SWITCH SENSE

Scheme 119

Driver Seat Belt Tensioner Squib Connector End View

DRIVER SEAT BELT TENSIONER SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20BL DRIVER SEAT BELT SQUIB LINE 2 2 20BR/YL DRIVER SEAT BELT SQUIB LINE 1

Scheme 120

EGR Solenoid Connector End View

EGR SOLENOID - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20GY/WT EGR SOLENOID CONTROL 2 20RD/DG FUSED ENGINE CONTROL RELAY OUTPUT

Scheme 121

Engine Coolant Temperature Sensor Connector End View

ENGINE COOLANT TEMPERATURE SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20DG/RD ENGINE COOLANT TEMPERATURE SENSOR SIGNAL 2 20BR/WT SENSOR GROUND

Scheme 122

Engine Fuse Block Fuses Connector End View

ENGINE FUSE BLOCK FUSES CAV CIRCUIT FUNCTION 1 - - 2 8BK FUSED B(+) 3 12BK FUSED B(+) 3 10BK FUSED B(+) 4 10BK FUSED B(+) 4 10BK FUSED B(+) 5

Scheme 123

ENGINE FUSE BLOCK FUSES CAV CIRCUIT FUNCTION 1 - - 2 8BK FUSED B(+) 3 12BK FUSED B(+) 3 10BK FUSED B(+) 4 10BK FUSED B(+) 4 10BK FUSED B(+) 5

Electronic Stability Program Brake Pressure Sensor 1 Connector End View

ESP BRAKE PRESSURE SENSOR 1 - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20BR/BL SENSOR GROUND 2 20BL/WT ESP BRAKE PRESSURE SENSOR 1 SIGNAL 3 20BK/RD/WT 5 VOLT SUPPLY

Scheme 124

Electronic Stability Program Off Switch Connector End View

ESP OFF SWITCH - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 - - 2 20BK/BL ESP OFF SWITCH SENSE 3 - - 4 - - 5 - - 6

Scheme 125

Electronic Stability Program Yaw Rate Lateral Acceleration Sensor Connector End View

ESP YAW RATE/LATERAL ACCELERATION SENSOR - 6-WAY CAV CIRCUIT FUNCTION 1 20DG S-CAN (-) 2 20WT S-CAN (+) 3 20RD/DG 5 VOLT SUPPLY 4 - - 5 20BR SENSOR GROUND 6 20BL/YL STEERING ANGLE SENSOR SIGNAL

Scheme 126

EVAP Purge Solenoid Connector End View

EVAP PURGE SOLENOID - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18BR/RD EVAP PURGE SOLENOID CONTROL

Scheme 127

Evaporator Temperature Sensor Connector End View

EVAPORATOR TEMPERATURE SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR/YL SENSOR GROUND 2 22GY/RD EVAPORATOR TEMPERATURE SENSOR SIGNAL

Fuel Injector 1 Connector End View

FUEL INJECTOR NO. 1 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY/BK FUSED ENGINE CONTROL RELAY OUTPUT 2 18GY/BK FUEL INJECTOR NO. 1 CONTROL

Scheme 128

Fuel Injector 2 Connector End View

FUEL INJECTOR NO. 2 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY/RD FUSED ENGINE CONTROL RELAY OUTPUT 2 18GY/RD FUEL INJECTOR NO. 2 CONTROL

Scheme 129

Fuel Injector 3 Connector End View

FUEL INJECTOR NO. 3 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18GY/DG FUEL INJECTOR NO. 3 CONTROL

Scheme 130

Fuel Injector 4 Connector End View

FUEL INJECTOR NO. 4 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY/BL FUSED ENGINE CONTROL RELAY OUTPUT 2 18GY/BL FUEL INJECTOR NO. 4 CONTROL

Scheme 131

Fuel Injector 5 Connector End View

FUEL INJECTOR NO. 5 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY/YL FUSED ENGINE CONTROL RELAY OUTPUT 2 18GY/YL FUEL INJECTOR NO. 5 CONTROL

Scheme 132

Fuel Injector 6 Connector End View

FUEL INJECTOR NO. 6 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY/VT FUSED ENGINE CONTROL RELAY OUTPUT 2 18GY/VT FUEL INJECTOR NO. 6 CONTROL

Scheme 133

Fuel Level Sensor Connector End View

FUEL LEVEL SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR/GY FUEL LEVEL SENSOR RETURN 2 20BL/BK FUEL LEVEL SENSOR SIGNAL

Fuel Tank Pressure Sensor (Except Export) Connector End View

FUEL TANK PRESSURE SENSOR - BLACK 3-WAY (EXCEPT EXPORT) CAV CIRCUIT FUNCTION 1 20DG FUEL TANK PRESSURE SENSOR SIGNAL 2 20BR/YL SENSOR GROUND 3 20BK/RD 5 VOLT SUPPLY

Scheme 134

Garage Door Opener (Europe) Connector End View

GARAGE DOOR OPENER - BLACK 3-WAY (EUROPE) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 - - 3 20PK/YL/BK FUSED IGNITION SWITCH OUTPUT

Scheme 135

Generator Connector End View

GENERATOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BL LOW BATTERY INDICATOR OUTPUT 2

Scheme 136

Glove Box Lamp Connector End View

GLOVE BOX LAMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 1 20BR GROUND 2 16BK/BL FUSED B(+) 2 16BK/BL FUSED B(+)

Scheme 137

Glove Box Switch Connector End View

GLOVE BOX SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/GY GLOVE BOX SWITCH SENSE

Scheme 138

Headlamp Leveling Switch (Export) Connector End View

HEADLAMP LEVELING SWITCH - BLACK 10-WAY (EXPORT) CAV CIRCUIT FUNCTION 1 - - 2 - - 3 18BR GROUND 4 - - 5 18YL/VT HEADLAMP ADJUST SIGNAL 5 18YL/VT HEADLAMP ADJUST SIGNAL 6 - - 7 - - 8 - - 9 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT 10

Heated Seat Module Connector End View

HEATED SEAT MODULE - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 16BK/VT RIGHT HEATED SEAT OUTPUT 2 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 3 16BK/GY LEFT HEATED SEAT OUTPUT 4 14RD/YL FUSED B(+)

Heated Washer Nozzles Connector End View

HEATED WASHER NOZZLES - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED IGNITION SWITCH OUTPUT 2 18BR GROUND

Scheme 139

Heater Core Temperature Sensor Connector End View

HEATER CORE TEMPERATURE SENSOR - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 22GY/DG RIGHT HEATER CORE TEMPERATURE SENSOR SIGNAL 2 20BR/YL SENSOR GROUND 3 22GY/PK LEFT HEATER CORE TEMPERATURE SENSOR SIGNAL

Scheme 140

Hood Ajar Switch Connector End View

HOOD AJAR SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BR/RD HOOD AJAR SWITCH SENSE 2 18BR GROUND

Scheme 141

Ignition Switch Connector End View

IGNITION SWITCH - BLACK 7-WAY CAV CIRCUIT FUNCTION 1 12PK/RD FUSED IGNITION SWITCH OUTPUT 2 18DG/WT FUSED IGNITION SWITCH OUTPUT 3 12PK/YL FUSED IGNITION SWITCH OUTPUT 4 16VT FUSED IGNITION SWITCH OUTPUT 5 12RD FUSED B(+) 6 20PK/DG FUSED IGNITION SWITCH OUTPUT 7 12RD FUSED B(+)

Scheme 142

Illumination Control Module A Connector End View

ILLUMINATION CONTROL MODULE A - BLACK 21-WAY CAV CIRCUIT FUNCTION 1 20GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (LHD A/T) 1 20GY/YL BACKUP LAMP SWITCH OUTPUT (LHD M/T) 1 18RD/WT FUSED IGNITION SWITCH OUTPUT (RHD) 2 18BK/RD BRAKE LAMP RELAY OUTPUT (LHD) 2 20GY/YL BACKUP LAMP SWITCH OUTPUT (RHD M/T) 3 18GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (LHD A/T) 3 18GY/YL BACKUP LAMP SWITCH OUTPUT (LHD M/T) 4 18GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (LHD A/T) 4 18GY/YL BACKUP LAMP SWITCH OUTPUT (LHD M/T) 4 20PK/RD FUSED IGNITION SWITCH OUTPUT (RHD) 5 20BK/BL BRAKE LAMP RELAY OUTPUT (LHD) 6 18BK/YL BRAKE LAMP RELAY OUTPUT (LHD) 6 18GY/DG FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 7 18BK/RD BRAKE LAMP RELAY OUTPUT (LHD) 8 14YL/BK FOG LAMP SWITCH OUTPUT 9 20GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (RHD A/T) 9 20GY/YL BACKUP LAMP SWITCH OUTPUT (RHD M/T) 10 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (LHD) 10 18BK/RD BRAKE LAMP RELAY OUTPUT (RHD) 11 18GY/RD FUSED RIGHT STANDING/PARK LAMPS OUTPUT (LHD) 11 18BK/RD BRAKE LAMP RELAY OUTPUT (RHD) 12 18GY/VT FUSED ILLUMINATION CONTROL MODULE OUTPUT 13 18GY/YL FUSED ILLUMINATION CONTROL MODULE OUTPUT 14 18GY/DG REAR FOG LAMP SWITCH OUTPUT (LHD EXPORT) 14 18GY/BK FUSED LEFT STANDING/PARK LAMPS OUTPUT (RHD) 15 20PK/RD FUSED IGNITION SWITCH OUTPUT (LHD) 16 18RD/WT FUSED IGNITION SWITCH OUTPUT (LHD) 16 18GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (RHD A/T) 16 18GY/YL BACKUP LAMP SWITCH OUTPUT (RHD M/T) 17 - - 18 18GY/BK FUSED LEFT STANDING/PARK LAMPS OUTPUT (LHD) 18 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 19 18BL/BR FUSED LEFT STANDING/PARK LAMPS OUTPUT (LHD) 19 20BK/BL BRAKE LAMP RELAY OUTPUT (RHD) 20 18BK/YL BRAKE LAMP RELAY OUTPUT (RHD) 21 18BK/VT FUSED RIGHT STANDING/PARK LAMPS OUTPUT (LHD) 21 18GY/RD FUSED RIGHT STANDING/PARK LAMPS OUTPUT (RHD)

Scheme 143

Illumination Control Module B Connector End View

ILLUMINATION CONTROL MODULE B - BLACK 21-WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 16YL FUSED LOW BEAM OUTPUT 4 16WT FUSED HIGH BEAM OUTPUT (LHD) 4 16YL/BK FUSED LOW BEAM OUTPUT (RHD) 5 16YL/BK FUSED LOW BEAM OUTPUT (LHD) 5 18GY/RD FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 6 16WT/BK FUSED HIGH BEAM OUTPUT (LHD) 6 18GY/YL FUSED FOG LAMP OUTPUT (RHD) 7 18GY/RD FUSED ILLUMINATION CONTROL MODULE OUTPUT (LHD) 7 18GY/YL FUSED FOG LAMP OUTPUT (RHD) 8 - - 9 - - 10 - - 11 - - 12 - - 13 - - 14 18DG FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXCEPT EXPORT) 15 - - 16 - - 17 - - 18 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXCEPT EXPORT) 19 18GY/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT (LHD) 19 16WT FUSED HIGH BEAM OUTPUT (RHD) 20 18GY/YL FUSED FOG LAMP OUTPUT (LHD) 20 18GY/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 21 18GY/YL FUSED FOG LAMP OUTPUT (LHD) 21 16WT/BK FUSED HIGH BEAM OUTPUT (RHD)

Scheme 144

Illumination Control Module D Connector End View

ILLUMINATION CONTROL MODULE D - BLACK 10-WAY CAV CIRCUIT FUNCTION 1 16BK/WT/BL FUSED IGNITION SWITCH OUTPUT 2 16WT/YL HEADLAMP SUPPLY 3 18DG/WT FUSED IGNITION SWITCH OUTPUT (LHD) 3 20BL/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 4 20BR/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT (LHD) 4 18DG/WT FUSED IGNITION SWITCH OUTPUT (RHD) 5 16BR GROUND (LHD) 5 20BR/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 6 20BL/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (LHD) 6 16BR GROUND (RHD) 7 20WT/BK HIGH BEAM INDICATOR LAMP (LHD) 8 20WT/BK HIGH BEAM INDICATOR LAMP (RHD) 9 16WT HEADLAMP HIGH BEAM SUPPLY (LHD) 9 18GY FUSED ILLUMINATION CONTROL MODULE OUTPUT (RHD) 10 18GY FUSED ILLUMINATION CONTROL MODULE OUTPUT (LHD) 10 16WT HEADLAMP HIGH BEAM SUPPLY (RHD)

Illumination Control Module E Connector End View

ILLUMINATION CONTROL MODULE E - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 12RD FUSED B(+) 2 20DG/VT PARK BRAKE SWITCH SENSE 3 - - 4 12PK/RD FUSED IGNITION SWITCH OUTPUT

Scheme 145

Illumination Control Module Fuses Connector End View

ILLUMINATION CONTROL MODULE FUSES CAV CIRCUIT FUNCTION 1 - - 2 18RD/WT FUSED IGNITION SWITCH OUTPUT 3 INTERNAL HIGH BEAM INDICATOR LAMP OUTPUT 4 INTERNAL FUSED IGNITION SWITCH OUTPUT 5 16WT/BK HIGH BEAM INDICATOR LAMP OUTPUT 6 16YL FUSED ILLUMINATION CONTROL MODULE OUTPUT 7 INTERNAL FUSED ILLUMINATION CONTROL MODULE OUTPUT 8 16YL/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT 9 INTERNAL FUSED ILLUMINATION CONTROL MODULE OUTPUT 10 INTERNAL FUSED ILLUMINATION CONTROL MODULE OUTPUT 11 INTERNAL FUSED ILLUMINATION CONTROL MODULE OUTPUT 12 18GY/DG FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXPORT)

Scheme 146

Instrument Cluster Connector End View (C1)

INSTRUMENT CLUSTER C1 - BLACK 30-WAY CAV CIRCUIT FUNCTION 1A 20BK/WT LEFT TURN SIGNAL OUTPUT 1B 20BL LOW BATTERY INDICATOR OUTPUT 2B - - 2A 20WT/BK HIGH BEAM INDICATOR LAMP 3A 18BR GROUND 3B - - 4A 20BL/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT 4B 20BR/YL COOLANT/WASHER LEVEL SIGNAL 5B 20DG AMBIENT TEMPERATURE SENSOR SIGNAL 5A 18GY/BL FUSED ILLUMINATION FEED 6B 20BR AMBIENT TEMPERATURE SENSOR GROUND 6A 20BR/GY KEY-IN IGNITION SWITCH SENSE 7A 20BR/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT 7B 20BR/WT BRAKE FLUID LEVEL SWITCH SENSE 8B - - 8A 22YL/VT SERIAL COMMUNICATION K1 9A 18PK/RD/BL FUSED IGNITION SWITCH OUTPUT 9B 20WT CAN C BUS (+) 10A 20BK/DG RIGHT TURN SIGNAL OUTPUT 10B 20DG CAN C BUS (-) 11A 20RD/YL FUSED B(+) 11B 22BK/BL SCI TRANSMIT 12A 18BR GROUND 12B 20BR COOLANT/WASHER LEVEL RETURN 13A 18GY FUSED ILLUMINATION CONTROL MODULE OUTPUT 14A - - 15A - - 16A - - 17A 22BK/WT SERIAL COMMUNICATION K2 18A

Instrument Cluster Connector End View (C2)

INSTRUMENT CLUSTER C2 - BLACK 25-WAY CAV CIRCUIT FUNCTION 1A - - 1B - - 1C 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 1D - - 1E - - 1F 20GY/YL LOW TIRE PRESSURE WARNING INDICATOR CONTROL 1G - - 1H - - 1I 20BR/DG DRIVER SEAT BELT SWITCH SENSE 1K 20BK/BR TELESCOPING STEERING SWITCH SENSE 1L 20BK/VT INSTRUMENT CLUSTER WAKE UP SIGNAL 1M - - 1N - - 2M - - 2N 20DG/VT FUSED IGNITION SWITCH OUTPUT 2D - - 2C 20PK AIRBAG WARNING INDICATOR DRIVER 2B - - 2A - - 2L 22BR/GY LEFT DOOR AJAR SWITCH SENSE (LHD) 2L 22BR/PK RIGHT DOOR AJAR SWITCH SENSE (RHD) 3L - - 3D - - 4L 20BL/BK FUEL LEVEL SENSOR SIGNAL 5L 20BR/GY FUEL LEVEL SENSOR RETURN 6L

Scheme 147

Intrusion Sensor (Export) Connector End View

INTRUSION SENSOR - 4-WAY (EXPORT) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20YL INTRUSION SENSOR SIGNAL 3 20PK/RD/WT FUSED B(+) 4 20RD/YL FUSED B(+)

Scheme 148

Key In Ignition Switch Connector End View

KEY-IN IGNITION SWITCH - WHITE 2-WAY CAV CIRCUIT FUNCTION 1 20BR/GY KEY-IN IGNITION SWITCH SENSE 2 20RD/YL FUSED B(+)

Scheme 149

Kick Down Switch Connector End View

KICK DOWN SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BK KICKDOWN SWITCH SIGNAL

Scheme 150

Retainer Switch Latch (Roadster (Convertible)) Connector End View

LATCH RETAINER SWITCH - BLACK 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20DG/WT LATCH RETAINER SWITCH SENSE

Scheme 151

Left Door Ajar Switch Connector End View

LEFT DOOR AJAR SWITCH - WHITE 3-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/GY LEFT DOOR AJAR SWITCH SENSE 2 20BR/GY LEFT DOOR AJAR SWITCH SENSE 3

Left Door Speaker Connector End View

LEFT DOOR SPEAKER - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 16BR/DG AMPLIFIED LEFT DOOR SPEAKER (-) 2 16BK/BL AMPLIFIED LEFT DOOR SPEAKER (+)

Left Door Tweeter Connector End View

LEFT DOOR TWEETER - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BR/DG AMPLIFIED LEFT DOOR SPEAKER (-) 2 18BK/BL AMPLIFIED LEFT DOOR SPEAKER (+)

Scheme 152

Left Fog Lamp Connector End View

LEFT FOG LAMP - NATURAL 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY/YL FUSED FOG LAMP OUTPUT

Scheme 153

Left Front Impact Sensor Connector End View

LEFT FRONT IMPACT SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20YL/BK LEFT FRONT IMPACT SENSOR SIGNAL 2 20BR GROUND

Scheme 154

Left Front Lamp Assembly Connector End View

LEFT FRONT LAMP ASSEMBLY - 6-WAY CAV CIRCUIT FUNCTION 1 18BK/WT LEFT TURN SIGNAL OUTPUT 2 16BR GROUND 3 16YL/BK FUSED LOW BEAM OUTPUT 4 16WT/BK FUSED HIGH BEAM OUTPUT 5 - - 6

Scheme 155

Left Front Power Window Motor Connector End View

LEFT FRONT POWER WINDOW MOTOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 14DG LEFT FRONT POWER WINDOW DRIVER (UP) 2 14BK LEFT FRONT POWER WINDOW DRIVER (DOWN)

Scheme 156

Left Front Power Window Switch Connector End View

LEFT FRONT POWER WINDOW SWITCH - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20DG/YL LEFT POWER WINDOW SWITCH SENSE 3 - - 4 - - 5 20DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT 6

Scheme 157

Left Front Side Marker Lamp (Except Export) Connector End View

LEFT FRONT SIDE MARKER LAMP - 2-WAY (EXCEPT EXPORT) CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY/BK SWITCHED FUSED B(+)

Scheme 158

Left Front WSS Brake Pad Wear Sensor Connector End View

LEFT FRONT WSS/BRAKE PAD WEAR SENSOR - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/DG BRAKE PAD WEAR INDICATOR DRIVER 3 20DG LEFT FRONT WHEEL SPEED SENSOR 12 VOLT SUPPLY 4 20BR LEFT FRONT WHEEL SPEED SENSOR SIGNAL

Scheme 159

Left Headlamp Leveling Motor (Export) Connector End View

LEFT HEADLAMP LEVELING MOTOR - BLACK 3-WAY (EXPORT) CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18YL/VT HEADLAMP ADJUST SIGNAL 3 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT

Scheme 160

Left Heated Seat Back Heated Seat Cushion Connector End View

LEFT HEATED SEAT BACK/HEATED SEAT CUSHION - 2-WAY CAV CIRCUIT FUNCTION 1 16BR GROUND 2 16BK/GY LEFT HEATED SEAT OUTPUT

Left Knock Sensor Connector End View

LEFT KNOCK SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BK SENSOR GROUND 2 20YL LEFT KNOCK SENSOR SIGNAL

Scheme 161

Left Park Lamp Connector End View

LEFT PARK LAMP - 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXCEPT EXPORT) 2 18GY/BK FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXPORT)

Scheme 162

Left Power Mirror Connector End View

LEFT POWER MIRROR - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 2 18BR GROUND 3 - - 4 18WT LEFT MIRROR HORIZONTAL DRIVER 5 18GY LEFT MIRROR COMMON DRIVER 6 18BK LEFT MIRROR VERTICAL DRIVER

Left Rear Lamp Assembly Connector End View

LEFT REAR LAMP ASSEMBLY - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY/BK LEFT STANDING/PARK LAMPS OUTPUT 2 18GY/BK LEFT TAIL LAMP OUTPUT 3 18BK/WT LEFT TURN SIGNAL OUTPUT 4 18BK/RD BRAKE LAMP RELAY OUTPUT 5 18GY/YL BACKUP LAMP SWITCH OUTPUT 6 18GY/DG REAR FOG LAMPS SWITCH OUTPUT (LHD EXPORT)

Scheme 163

Left Rear Side Marker Lamp Connector End View

LEFT REAR SIDE MARKER LAMP - 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18BL/BR FUSED LEFT STANDING/PARK LAMPS OUTPUT

Scheme 164

Left Rear Speaker Connector End View

LEFT REAR SPEAKER - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 16PK AMPLIFIED LEFT REAR SPEAKER (+) 2 16DG AMPLIFIED LEFT REAR SPEAKER (-) 3 16BL LEFT REAR SPEAKER SUPPLY VOLTAGE 4 16BK/RD LEFT REAR SPEAKER GROUND

Scheme 165

Left Rear Wheel Speed Sensor Connector End View

LEFT REAR WHEEL SPEED SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR LEFT REAR WHEEL SPEED SENSOR SIGNAL 2 20BL LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY

Scheme 166

Left Rotation Relay (Roadster (Convertible)) Connector End View

LEFT ROTATION RELAY - 9-WAY (ZH27) CAV CIRCUIT FUNCTION 1 - - 2 RD FUSED B(+) 3 - - 4 BK ROTATION RELAY GROUND 5 BK GROUND 6 DG LEFT ROTATION RELAY CONTROL 7 - - 8 BK LEFT ROTATION RELAY OUTPUT 9

Left Side Airbag Squib Connector End View

LEFT SIDE AIRBAG SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20BL/GY LEFT SIDE SQUIB LINE 1 2 20BL/RD LEFT SIDE SQUIB LINE 2

Left Side Impact Sensor Connector End View

LEFT SIDE IMPACT SENSOR - YELLOW 3-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 - - 3 20BL/YL LEFT SIDE IMPACT SENSOR SIGNAL

Scheme 167

Left Turn Signal Lamp (Export) Connector End View

LEFT TURN SIGNAL LAMP - 2-WAY (EXPORT) CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18BK/WT LEFT TURN SIGNAL OUTPUT

Scheme 168

License Lamp 1 Connector End View

LICENSE LAMP NO. 1 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 18GY/VT FUSED ILLUMINATION CONTROL MODULE OUTPUT

Scheme 169

License Lamp 2 Connector End View

LICENSE LAMP NO. 2 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 18GY/YL FUSED ILLUMINATION CONTROL MODULE OUTPUT

Scheme 170

Liftgate Lock Switch Connector End View

LIFTGATE LOCK SWITCH - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/BL LIFTGATE LOCK SWITCH SENSE (UNLOCK) (ZH27) 2 20BR/YL LIFTGATE LOCK SWITCH SENSE (UNLOCK) (ZH29) 3 - - 4

Scheme 171

Mass Air Flow Sensor/Intake Air Sensor Temperature Connector End View

MAF/IAT SENSOR - WHITE 5-WAY CAV CIRCUIT FUNCTION 1 20YL/DG IAT SENSOR SIGNAL 2 20RD/BL FUSED ENGINE CONTROL RELAY OUTPUT 3 20BR SENSOR GROUND 4 20BR/YL 5 VOLT SUPPLY 5 20YL/WT MAF SENSOR SIGNAL

Scheme 172

Manifold Absolute Pressure Sensor Connector End View

MANIFOLD ABSOLUTE PRESSURE SENSOR - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20BR/GY SENSOR GROUND 2 20RD/DG MAP SENSOR SIGNAL 3 20PK/BK 5 VOLT SUPPLY

Multifunction Switch Connector End View

MULTI-FUNCTION SWITCH - BLACK 12-WAY CAV CIRCUIT FUNCTION 1 16WT/YL HEADLAMP SUPPLY 2 16WT HEADLAMP HIGH BEAM SUPPLY 3 - - 4 18BK/BL TURN SIGNAL MONITORED GROUND 5 - - 6 - - 7 18BL WIPER SWITCH MUX 8 18GY WASHER PUMP MOTOR CONTROL 8 16GY WASHER PUMP MOTOR CONTROL 9 18BK/DG RIGHT TURN SIGNAL OUTPUT 10 18BK/WT LEFT TURN SIGNAL OUTPUT 11 16BK/YL/DG FUSED IGNITION SWITCH OUTPUT 12

Scheme 173

Occupant Classification Module Connector End View

OCCUPANT CLASSIFICATION MODULE - NATURAL 4-WAY CAV CIRCUIT FUNCTION 1 20RD/YL FUSED B(+) 2 20BR GROUND 3 20WT/DG CAN INTERIOR BUS (125K) (+) 4 20BK/DG CAN INTERIOR BUS (125K) (-)

Occupant Restraint Controller Connector End View

OCCUPANT RESTRAINT CONTROLLER - 84-WAY CAV CIRCUIT FUNCTION 1 20PK/RD FUSED IGNITION SWITCH OUTPUT (EXCEPT EXPORT) 2 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 3 20BK/DG CAN INTERIOR BUS (125K) (-) 4 20WT/DG CAN INTERIOR BUS (125K) (+) 5 - - 6 - - 7 - - 8 - - 9 - - 10 - - 11 - - 12 - - 13 - - 14 - - 15 - - 16 - - 17 - - 18 - - 19 - - 20 - - 21 - - 22 - - 23 - - 24 - - 25 - - 26 - - 27 - - 28 - - 29 - - 30 - - 31 - - 32 - - 33 20DG DRIVER SQUIB 1 LINE 2 34 20VT DRIVER SQUIB 1 LINE 1 35 20BL DRIVER SQUIB 2 LINE 2 36 20BK DRIVER SQUIB 2 LINE 1 37 20BL/DG PASSENGER SQUIB LINE 2 38 20BR/DG PASSENGER SQUIB LINE 1 39 - - 40 - - 41 20BL/RD LEFT SIDE SQUIB LINE 2 42 20BL/GY LEFT SIDE SQUIB LINE 1 43 20BL/WT RIGHT SIDE SQUIB LINE 2 44 20BL/BK RIGHT SIDE SQUIB LINE 1 45 20YL/DG DRIVER KNEE BLOCKER SQUIB LINE 2 46 20VT/BR DRIVER KNEE BLOCKER SQUIB LINE 1 47 20BR/WT PASSENGER KNEE BLOCKER SQUIB LINE 1 48 20BL/WT PASSENGER KNEE BLOCKER SQUIB LINE 2 49 - - 50 - - 51 - - 52 - - 53 - - 54 - - 55 20PK AIRBAG WARNING INDICATOR DRIVER 56 20BR GROUND 57 20BL DRIVER SEAT BELT SQUIB LINE 2 58 20BR/YL DRIVER SEAT BELT SQUIB LINE 1 59 20BR PASSENGER SEAT BELT SQUIB LINE 1 60 20BL PASSENGER SEAT BELT SQUIB LINE 2 61 - - 62 - - 63 - - 64 - - 65 - - 66 - - 67 - - 68 - - 69 20GY/BL PASSENGER SEAT BELT SWITCH SENSE 70 20BL/DG WHEEL SPEED SENSOR OUTPUT 71 20BL/WT AIRBAG ON/OFF SWITCH SENSE (ON) 72 20DG/WT WHEEL SPEED SENSOR OUTPUT 73 20GY/DG DRIVER SEAT BELT SWITCH SENSE 74 20YL/WT RIGHT FRONT IMPACT SENSOR SIGNAL 75 20GY AIRBAG ON/OFF SWITCH SENSE (OFF) 76 20BL/YL LEFT SIDE IMPACT SENSOR SIGNAL 77 20BK AIRBAG OFF INDICATOR DRIVER 78 20WT/YL RIGHT SIDE IMPACT SENSOR SIGNAL 79 - - 80 20YL/BK LEFT FRONT IMPACT SENSOR SIGNAL 81 - - 82 20DG/BK ENHANCED ACCIDENT REPORT DRIVER 83 - - 84 20BR GROUND

Scheme 174

Oil Sensor Connector End View

OIL SENSOR - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20GY/BL OIL SENSOR SIGNAL 2 20BR/BK SENSOR GROUND 3 20RD/YL 5 VOLT SUPPLY

Scheme 175

Upstream Oxygen Sensor 1/1 Connector End View

OXYGEN SENSOR 1/1 UPSTREAM - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18BR/GY OXYGEN SENSOR 1/1 HEATER CONTROL 3 20DG SENSOR GROUND 4 20BK OXYGEN SENSOR 1/1 SIGNAL

Scheme 176

Downstream Oxygen Sensor 1/2 Connector End View

OXYGEN SENSOR 1/2 DOWNSTREAM - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18BR/WT OXYGEN SENSOR 1/2 HEATER CONTROL 3 20BR SENSOR GROUND 4 20YL/BK OXYGEN SENSOR 1/2 SIGNAL

Scheme 177

Upstream Oxygen Sensor 2/1 Connector End View

OXYGEN SENSOR 2/1 UPSTREAM - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18BR/BK OXYGEN SENSOR 2/1 HEATER CONTROL 3 20DG SENSOR GROUND 4 20BK OXYGEN SENSOR 2/1 SIGNAL

Scheme 178

Downstream Oxygen Sensor 2/2 Connector End View

OXYGEN SENSOR 2/2 DOWNSTREAM - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 2 18BR/DG OXYGEN SENSOR 2/2 HEATER CONTROL 3 20BR SENSOR GROUND 4 20YL/DG OXYGEN SENSOR 2/2 SIGNAL

Scheme 179

Passenger Airbag On Off Switch Connector End View

PASSENGER AIRBAG ON/OFF SWITCH - 6-WAY CAV CIRCUIT FUNCTION 1 20BL/WT AIRBAG ON/OFF SWITCH SENSE (ON) 2 20GY AIRBAG ON/OFF SWITCH SENSE (OFF) 3 20BR GROUND 4 - - 5 - - 6

Scheme 180

Passenger Airbag Squib Connector End View

PASSENGER AIRBAG SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20BL/DG PASSENGER SQUIB LINE 2 2 20BR/DG PASSENGER SQUIB LINE 1

Scheme 181

Passenger Knee Blocker Airbag Squib Connector End View

PASSENGER KNEE BLOCKER AIRBAG SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20BL/WT PASSENGER KNEE BLOCKER SQUIB LINE 2 2 20BR/WT PASSENGER KNEE BLOCKER SQUIB LINE 1

Passenger Power Seat Connector End View

PASSENGER POWER SEAT - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 14RD/DG FUSED POWER SEAT RELAY OUTPUT 2 14BR GROUND

Passenger Seat Belt Switch Connector End View

PASSENGER SEAT BELT SWITCH - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20GY/BL PASSENGER SEAT BELT SWITCH SENSE 2 20BR GROUND 3 - - 4

Scheme 182

Passenger Seat Belt Tensioner Squib Connector End View

PASSENGER SEAT BELT TENSIONER SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20BL PASSENGER SEAT BELT SQUIB LINE 2 2 20BR PASSENGER SEAT BELT SQUIB LINE 1

Scheme 183

Power Amplifier A Connector End View

POWER AMPLIFIER A - BLACK 12-WAY CAV CIRCUIT FUNCTION 1 18BL RIGHT DOOR SPEAKER (-) 2 18BL/BR LEFT DOOR SPEAKER (+) 3 18BL/BR LEFT DOOR SPEAKER (+) 4 16BR GROUND 5 18BL/DG ENABLE SIGNAL TO AMPLIFIER 6 18YL/VT LEFT REAR SPEAKER (+) 7 18YL RIGHT REAR SPEAKER (-) 8 18BL RIGHT DOOR SPEAKER (-) 9 18YL/VT LEFT REAR SPEAKER (+) 10 18YL RIGHT REAR SPEAKER (-) 11 16BR GROUND 12

Scheme 184

Power B Amplifier Connector End View

POWER AMPLIFIER B - BLACK 18-WAY CAV CIRCUIT FUNCTION 1 16RD/YL FUSED B(+) 2 18BL/DG ENABLE SIGNAL TO AMPLIFIER (ZH27) 3 20DG/WT WHEEL SPEED SENSOR OUTPUT 4 16BK/RD LEFT REAR SPEAKER GROUND 5 16BL/RD AMPLIFIED RIGHT REAR SPEAKER (+) 6 16PK AMPLIFIED LEFT REAR SPEAKER (+) 7 16BK/PK AMPLIFIED RIGHT DOOR SPEAKER (+) 8 16BK/BL AMPLIFIED LEFT DOOR SPEAKER (+) 9 16RD/YL FUSED B(+) 10 - - 11 - - 12 16BL LEFT REAR SPEAKER SUPPLY VOLTAGE 13 16RD/YL RIGHT REAR SPEAKER GROUND 14 16VT RIGHT REAR SPEAKER SUPPLY VOLTAGE 15 16BK/YL AMPLIFIED RIGHT REAR SPEAKER (-) 16 16DG AMPLIFIED LEFT REAR SPEAKER (-) 17 16BR/YL AMPLIFIED RIGHT DOOR SPEAKER (-) 18 16BR/DG AMPLIFIED LEFT DOOR SPEAKER (-)

Scheme 185

Power Mirror Switch Connector End View

POWER MIRROR SWITCH - BLACK 8-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 - - 3 18GY LEFT MIRROR COMMON DRIVER 4 18GY/VT RIGHT MIRROR COMMON DRIVER 5 18WT RIGHT MIRROR VERTICAL DRIVER 5 18BK LEFT MIRROR VERTICAL DRIVER 6 18PK/RD/WT FUSED B(+) 7 18WT LEFT MIRROR HORIZONTAL DRIVER 8 18BK/VT RIGHT MIRROR HORIZONTAL DRIVER

Scheme 186

Power Seat Relay Connector End View

POWER SEAT RELAY - BLACK 9-WAY CAV CIRCUIT FUNCTION 1 20BR/GY LEFT DOOR AJAR SWITCH SENSE 2 14RD/WT POWER SEAT RELAY SWITCHED OUTPUT 3 18RD FUSED B(+) 4 18PK/YL FUSED IGNITION SWITCH OUTPUT 5 - - 6 18BR GROUND 7 20BR/PK RIGHT DOOR AJAR SWITCH SENSE 8 14RD FUSED B(+) 9

Power Top Control Module (Roadster (Convertible)) Connector End View (C1)

POWER TOP CONTROL MODULE C1 - 28-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20WT REAR BOW CYLINDER TRAVEL SENSOR (ROD) + 2 20GY REAR BOW CYLINDER TRAVEL SENSOR (BASE) + 3 - - 4 20DG MAIN CYLINDER TRAVEL SENSOR (ROD) + 5 20GY/OR REAR BOW SENSE 6 20YL MAIN CYLINDER TRAVEL SENSOR (BASE) + 7 20BR/BL ROOF/CARGO DIVIDER SENSE 8 20WT/VT POWER TOP SWITCH SIGNAL 9 - - 10 14RD/YL FUSED B(+) 11 14BR GROUND 12 - - 13 20WT CAN B BUS (+) 14 20DG CAN B BUS (-) 15 - - 16 20DG/WT LATCH RETAINER SWITCH SENSE 17 20BR/DG TONNEAU COVER SWITCH SENSE 18 16RD/DG TRUNK LATCH ACTUATOR UNLOCK CONTROL 19 16BK/DG TRUNK LATCH ACTUATOR LOCK CONTROL 20 20BR/YL POWER TOP SWITCH INDICATOR DRIVER 21 20BR/VT TRUNK LATCH LOCKED SIGNAL 22 20BK/VT TRUNK LATCH UNLOCKED SIGNAL 23 20YL/RD MAIN CYLINDER TRAVEL SENSOR (BASE) - 24 20DG/YL MAIN CYLINDER TRAVEL SENSOR (ROD) - 25 - - 26 20GY/VT REAR BOW CYLINDER TRAVEL SENSOR (BASE) - 27 20WT/YL REAR BOW CYLINDER TRAVEL SENSOR (ROD) - 28 20DG SCI TRANSMIT

Scheme 187

Power Top Control Module (Roadster (Convertible)) Connector End View (C2)

POWER TOP CONTROL MODULE C2 - 12-WAY (ZH27) CAV CIRCUIT FUNCTION 1 BR TONNEAU COVER TRAVEL SENSOR (-) 2 RD TONNEAU COVER TRAVEL SENSOR (+) 3 BK S3/S4 SOLENOID GROUND 4 BK S1/S2 SOLENOID GROUND 5 BK ROTATION RELAY GROUND 6 - - 7 GY S4 SOLENOID SUPPLY VOLTAGE 8 YL S3 SOLENOID SUPPLY VOLTAGE 9 OR S2 SOLENOID SUPPLY VOLTAGE 10 BL S1 SOLENOID SUPPLY VOLTAGE 11 BR RIGHT ROTATION RELAY CONTROL 12 DG LEFT ROTATION RELAY CONTROL

Scheme 188

Power Top Hydraulic Assembly (Roadster (Convertible)) Connector End View

POWER TOP HYDRAULIC ASSEMBLY - BLACK 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 12BR GROUND 2 12RD/YL FUSED B(+)

Scheme 189

Power Top Switch (Roadster (Convertible)) Connector End View

POWER TOP SWITCH - BLACK 6-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/YL POWER TOP SWITCH INDICATOR DRIVER 3 - - 4 - - 5 20DG/WT FUSED ILLUMINATION FEED 6 20WT/VT POWER TOP SWITCH SIGNAL

Scheme 190

Power Top Travel Sensors (Roadster (Convertible)) Connector End View

POWER TOP TRAVEL SENSORS - BLACK 8-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20YL MAIN CYLINDER TRAVEL SENSOR (BASE) + 2 20YL/RD MAIN CYLINDER TRAVEL SENSOR (BASE) - 3 20DG MAIN CYLINDER TRAVEL SENSOR (ROD) + 4 20DG/YL MAIN CYLINDER TRAVEL SENSOR (ROD) - 5 20GY REAR BOW CYLINDER TRAVEL SENSOR (BASE) + 6 20GY/VT REAR BOW CYLINDER TRAVEL SENSOR (BASE) - 7 20WT REAR BOW CYLINDER TRAVEL SENSOR (ROD) + 8 20WT/YL REAR BOW CYLINDER TRAVEL SENSOR (ROD)

Scheme 191

Powertrain Control Module Connector End View (C1)

POWERTRAIN CONTROL MODULE C1 - BLACK 9-WAY CAV CIRCUIT FUNCTION 1 - - 2 18BK/WT COIL ON PLUG DRIVER NO. 1 3 18BL THROTTLE CONTROL MOTOR 1 4 18GY/WT COIL ON PLUG DRIVER NO. 6 5 18BL/WT COIL ON PLUG DRIVER NO. 4 6 18BK THROTTLE CONTROL MOTOR 2 7 18DG/WT COIL ON PLUG DRIVER NO. 3 8 - - 9 18YL/WT COIL ON PLUG DRIVER NO. 2

Scheme 192

Powertrain Control Module Connector End View (C2)

POWERTRAIN CONTROL MODULE C2 - BLACK 24-WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 - - 5 - - 6 - - 7 20GY/WT EGR SOLENOID CONTROL 8 - - 9 - - 10 - - 11 - - 12 18VT/WT COIL ON PLUG DRIVER NO. 5 13 20GY/BR AIR PUMP SWITCHOVER SOLENOID CONTROL 14 20DG/VT SHORT RUNNER VALVE SOLENOID CONTROL 15 18BR/GY OXYGEN SENSOR 1/1 HEATER CONTROL 16 - - 17 - - 18 18GY/VT FUEL INJECTOR NO. 6 CONTROL 19 18GY/DG FUEL INJECTOR NO. 3 CONTROL 20 - - 21 18GY/YL FUEL INJECTOR NO. 5 CONTROL 22 18GY/RD FUEL INJECTOR NO. 2 CONTROL 23 - - 24 18BR/BK OXYGEN SENSOR 2/1 HEATER CONTROL

Scheme 193

Powertrain Control Module Connector End View (C3)

POWERTRAIN CONTROL MODULE C3 - BLACK 52-WAY CAV CIRCUIT FUNCTION 1 - - 2 20PK CAMSHAFT POSITION SENSOR SIGNAL 3 20BK SENSOR GROUND 4 20VT RIGHT KNOCK SENSOR SIGNAL 5 20DG/RD ENGINE COOLANT TEMPERATURE SENSOR SIGNAL 6 20DG SENSOR GROUND 7 20BK OXYGEN SENSOR 1/1 SIGNAL 8 - - 9 20BR/DG SENSOR GROUND 10 20RD/DG MAP SENSOR SIGNAL 11 20YL/WT MAF SENSOR SIGNAL 12 20BR SENSOR GROUND 13 20DG/WT CRANKSHAFT POSITION SENSOR SIGNAL 1 14 - - 15 20GY/BL OIL SENSOR SIGNAL 16 20BK SENSOR GROUND 17 20YL LEFT KNOCK SENSOR SIGNAL 18 - - 19 20GY SENSOR GROUND 20 20WT THROTTLE POSITION SENSOR SIGNAL 2 21 20YL THROTTLE POSITION SENSOR SIGNAL 1 22 20VT 5 VOLT SUPPLY 23 20BK OXYGEN SENSOR 2/1 SIGNAL 24 - - 25 20BR/YL 5 VOLT SUPPLY 26 20DG CRANKSHAFT POSITION SENSOR SIGNAL 2 27 18GY/BK FUEL INJECTOR NO. 1 CONTROL 28 18GY/BL FUEL INJECTOR NO. 4 CONTROL 29 - - 30 - - 31 - - 32 - - 33 - - 34 - - 35 - - 36 - - 37 - - 38 - - 39 20RD/YL 5 VOLT SUPPLY 40 - - 41 - - 42 - - 43 - - 44 18GY COIL ON PLUG DRIVER NO. 6 45 18DG COIL ON PLUG DRIVER NO. 3 46 18BL COIL ON PLUG DRIVER NO. 4 47 18BK COIL ON PLUG DRIVER NO. 1 48 - - 49 18VT COIL ON PLUG DRIVER NO. 5 50 18YL COIL ON PLUG DRIVER NO. 2 51 - - 52

Scheme 194

Powertrain Control Module Connector End View (C4)

POWERTRAIN CONTROL MODULE C4 - BLACK 40-WAY CAV CIRCUIT FUNCTION 1 20WT CAN C BUS (+) 2 - - 3 20GY/YL BACKUP LAMP SWITCH OUTPUT 4 20RD/BK CLUTCH PEDAL POSITION SWITCH SIGNAL (M/T) 5 18BR SENSOR GROUND 6 20BK SENSOR GROUND 7 20DG ACCELERATOR PEDAL POSITION SENSOR SIGNAL NO. 2 8 20GY ACCELERATOR PEDAL POSITION SENSOR SIGNAL NO. 1 9 - - 10 20BR/YL SENSOR GROUND 11 20DG CAN C BUS (-) 12 20DG/BK ENHANCED ACCIDENT REPORT DRIVER 13 - - 14 20BK KICKDOWN SWITCH SIGNAL (A/T) 15 20YL/BK OXYGEN SENSOR 1/2 SIGNAL 16 20YL/DG OXYGEN SENSOR 2/2 SIGNAL 17 20DG FUEL TANK PRESSURE SENSOR SIGNAL 18 20OR SENSOR GROUND 19 20YL/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT SUPPLY 20 - - 21 - - 22 20GY OFF SIGNAL 23 20DG/RD ACCEL/SET SIGNAL 24 - - 25 20VT FUSED IGNITION SWITCH OUTPUT (A/T) 25 20VT CLUTCH INTERLOCK SWITCH OUTPUT (M/T) 26 20DG/BL ON SIGNAL 27 - - 28 20YL/DG DECEL/SET SIGNAL 29 22BL SCI TRANSMIT 30 20BL/RD RESUME SIGNAL 31 - - 32 20DG/YL SCI RECEIVE 33 - - 34 - - 35 20PK/RD SENSOR GROUND 36 18BL/RD FUEL PUMP RELAY CONTROL 37 18BR/BL CHARCOAL CANISTER SHUTOFF VALVE CONTROL 38 20BR/VT AIR PUMP RELAY CONTROL 39 20GY RADIATOR FAN CONTROL 40 20BK/RD 5 VOLT SUPPLY

Scheme 195

Powertrain Control Module Connector End View (C5)

POWERTRAIN CONTROL MODULE C5 - WHITE 9-WAY CAV CIRCUIT FUNCTION 1 18BR/DG OXYGEN SENSOR 2/2 HEATER CONTROL 2 18BR/RD EVAP PURGE SOLENOID CONTROL 3 18BK/DG FUSED B(+) 4 18BR/WT OXYGEN SENSOR 1/2 HEATER CONTROL 5 16BR GROUND 6 16BR GROUND 7 16BR GROUND 8 16BR GROUND 9 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT

Scheme 196

Pulse Module A Connector End View

PULSE MODULE A - BLACK 5-WAY CAV CIRCUIT FUNCTION 1 12BK FUSED B(+) 2 20PK/RD SENSOR GROUND 3 - - 4 - - 5 12BR GROUND

Scheme 197

Pulse Module F Connector End View

PULSE MODULE F - 1-WAY CAV CIRCUIT FUNCTION 1 14VT/WT STARTER SOLENOID OUTPUT

Pulse Module B Connector End View

PULSE MODULE B - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 16VT FUSED IGNITION SWITCH OUTPUT (A/T) 1 20VT CLUTCH INTERLOCK SWITCH OUTPUT (M/T) 2 14PK/RD FUSED IGNITION SWITCH OUTPUT

Scheme 198

Radiator Fan Control Module Connector End View

RADIATOR FAN CONTROL MODULE - NATURAL 7-WAY CAV CIRCUIT FUNCTION 1 8BR/BK RADIATOR FAN CONTROL MODULE GROUND 2 8BR GROUND 3 8BK FUSED B(+) 4 8BK/DG RADIATOR FAN CONTROL MODULE OUTPUT 5 20GY RADIATOR FAN CONTROL 6 20PK/RD FUSED IGNITION SWITCH OUTPUT 7

Scheme 199

Radiator Fan Motor Connector End View

RADIATOR FAN MOTOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 8BR/BK RADIATOR FAN CONTROL MODULE GROUND 2 8BK/DG RADIATOR FAN CONTROL MODULE OUTPUT

Scheme 200

Radio Connector End View

RADIO - BLACK 16-WAY CAV CIRCUIT FUNCTION 1B - - 1A 20DG/WT WHEEL SPEED SENSOR OUTPUT (NAVIGATION) 2B - - 2A 20GY/YL BACKUP LAMP SWITCH OUTPUT (M/T EXCEPT NAVIGATION) 2A 20GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (NAVIGATION) 2A 20GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE (NAVIGATION) 3A - - 3B 18YL RIGHT REAR SPEAKER (-) (AMPLIFIER) 3B 16YL RIGHT DOOR SPEAKER (+) (EXCEPT AMPLIFIER) 4A 14RD/DG FUSED B(+) 4B 18YL/VT LEFT REAR SPEAKER (+) (AMPLIFIER) 4B 16YL/BK RIGHT DOOR SPEAKER (-) (EXCEPT AMPLIFIER) 5A 18BL/DG ENABLE SIGNAL TO AMPLIFIER 5B 18BL RIGHT DOOR SPEAKER (-) (AMPLIFIER) 5B 16WT LEFT DOOR SPEAKER (+) (EXCEPT AMPLIFIER) 6A 20GY/BL FUSED ILLUMINATION FEED 6B 18BL/BR LEFT DOOR SPEAKER (+) (AMPLIFIER) 6B 16WT/YL LEFT DOOR SPEAKER (-) (EXCEPT AMPLIFIER) 7B - - 7A 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT 8B - - 8A 14BR GROUND

Radio D (Except Navigation) Connector End View

RADIO D - BLACK 2-WAY (EXCEPT NAVIGATION) CAV CIRCUIT FUNCTION 1 24BK ANTENNA 2 BK SHIELD

Scheme 201

Radio D (Navigation) Connector End View

RADIO D - BLACK 2-WAY (NAVIGATION) CAV CIRCUIT FUNCTION 1 24BK ANTENNA 2 BK SHIELD

Scheme 202

Rear Bow Switch (Roadster (Convertible)) Connector End View

REAR BOW SWITCH - 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20GY/OR REAR BOW SENSE

Rear Spoiler Limit Switch Connector End View

REAR SPOILER LIMIT SWITCH - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/YL SPOILER LIMIT SWITCH SIGNAL (DOWN) 3 20BR/GY SPOILER LIMIT SWITCH SIGNAL (UP) 4

Rear Spoiler Motor Connector End View

REAR SPOILER MOTOR - BLUE 2-WAY CAV CIRCUIT FUNCTION 1 16BR/WT REAR SPOILER DRIVER (UP) 2 16RD/WT REAR SPOILER DRIVER (DOWN)

Scheme 203

Rear Spoiler Switch Connector End View

REAR SPOILER SWITCH - BLACK 3-WAY CAV CIRCUIT FUNCTION 2 20GY/WT REAR SPOILER DIAGNOSTIC LED CONTROL 4 - - 6 20DG/WT REAR SPOILER SWITCH SENSE

Scheme 204

Recirculated Air Switchover Valve Connector End View

RECIRCULATED AIR SWITCHOVER VALVE - GRAY 2-WAY CAV CIRCUIT FUNCTION 1 18BR/YL RECIRCULATED AIR SWITCHOVER VALVE CONTROL 2 18PK/RD/BL FUSED IGNITION SWITCH OUTPUT

Scheme 205

Relay Control Module A Connector End View

RELAY CONTROL MODULE A - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BR/VT AIR PUMP RELAY CONTROL 2 16RD/BL FUSED ENGINE CONTROL RELAY OUTPUT 3 16RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 4 12RD/WT AIR PUMP RELAY OUTPUT

Scheme 206

Relay Control Module B Connector End View

RELAY CONTROL MODULE B - BLACK 5-WAY CAV CIRCUIT FUNCTION 1 12RD FUSED B(+) 2 12RD FUSED B(+) 3 14RD/DG FUEL PUMP RELAY OUTPUT 4 14RD FUSED B(+) 5 18BR GROUND

Scheme 207

Relay Control Module C Connector End View

RELAY CONTROL MODULE C - BLACK 5-WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 18RD/YL TRACTION SYSTEM RELAY OUTPUT 5 18RD/DG TRACTION SYSTEM RELAY OUTPUT

Scheme 208

Relay Control Module D Connector End View

RELAY CONTROL MODULE D - GRAY 3-WAY CAV CIRCUIT FUNCTION 1 20YL HORN RELAY CONTROL 2 18PK/RD FUSED IGNITION SWITCH OUTPUT 3

Scheme 209

Relay Control Module E Connector End View

RELAY CONTROL MODULE E - GRAY 7-WAY CAV CIRCUIT FUNCTION 1 16BK/PK FUSED HORN RELAY OUTPUT 2 20RD/WT FUSED IGNITION SWITCH OUTPUT 3 18BL/RD FUEL PUMP RELAY CONTROL 4 18BK/DG FUSED B(+) 5 16RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 6 18RD/DG FUSED ENGINE CONTROL RELAY OUTPUT 7

Scheme 210

Relay Control Module Fuses Connector End View

RELAY CONTROL MODULE FUSES CAV CIRCUIT FUNCTION 1 INTERNAL FUSED B(+) 2 INTERNAL FUSED ENGINE CONTROL RELAY OUTPUT 3 INTERNAL FUSED ENGINE CONTROL RELAY OUTPUT 4 INTERNAL FUSED B(+) 5 INTERNAL FUSED B(+) 6 INTERNAL FUSED B(+)

Remote Keyless Entry Relay Connector End View

REMOTE KEYLESS ENTRY RELAY - BLACK 9-WAY CAV CIRCUIT FUNCTION 1 - - 2 18BK/WT REMOTE KEYLESS ENTRY RELAY OUTPUT 3 - - 4 18RD/YL FUSED B(+) 5 18BK/DG REMOTE KEYLESS ENTRY RELAY OUTPUT 6 20BK/YL REMOTE KEYLESS ENTRY RELAY CONTROL 7 - - 8 14RD/YL FUSED B(+) 9

Scheme 211

Right Door Ajar Switch Connector End View

RIGHT DOOR AJAR SWITCH - WHITE 3-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/PK RIGHT DOOR AJAR SWITCH SENSE 2 20BR/PK RIGHT DOOR AJAR SWITCH SENSE 3

Right Door Speaker Connector End View

RIGHT DOOR SPEAKER - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 16BR/DG AMPLIFIED RIGHT DOOR SPEAKER (-) 2 16BK/BL AMPLIFIED RIGHT DOOR SPEAKER (+)

Right Door Tweeter Connector End View

RIGHT DOOR TWEETER - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BR/DG AMPLIFIED RIGHT DOOR SPEAKER (-) 2 18BK/BL AMPLIFIED RIGHT DOOR SPEAKER (+)

Right Fog Lamp Connector End View

RIGHT FOG LAMP - NATURAL 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY/YL FUSED FOG LAMP OUTPUT

Right Front Impact Sensor Connector End View

RIGHT FRONT IMPACT SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20YL/WT RIGHT FRONT IMPACT SENSOR SIGNAL 2 20BR GROUND

Scheme 212

Right Front Lamp Assembly Connector End View

RIGHT FRONT LAMP ASSEMBLY - 6-WAY CAV CIRCUIT FUNCTION 1 18BK/DG RIGHT TURN SIGNAL OUTPUT 2 16BR GROUND 3 16YL FUSED LOW BEAM OUTPUT 4 16WT FUSED HIGH BEAM OUTPUT 5 - - 6

Right Front Power Window Motor Connector End View

RIGHT FRONT POWER WINDOW MOTOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 14DG RIGHT FRONT POWER WINDOW DRIVER (UP) 2 14BK RIGHT FRONT POWER WINDOW DRIVER (DOWN)

Scheme 213

Right Front Power Window Switch Connector End View

RIGHT FRONT POWER WINDOW SWITCH - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20WT/BL RIGHT POWER WINDOW SWITCH SENSE 3 - - 4 - - 5 20DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT 6

Scheme 214

Right Front Side Marker Lamp (Except Export) Connector End View

RIGHT FRONT SIDE MARKER LAMP - BLACK 2-WAY (EXCEPT EXPORT) CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY/RD SWITCHED FUSED B(+)

Scheme 215

Right Front WSS Brake Pad Wear Sensor Connector End View

RIGHT FRONT WSS/BRAKE PAD WEAR SENSOR - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BR/DG BRAKE PAD WEAR INDICATOR DRIVER 3 20BR RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT SUPPLY 4 20WT RIGHT FRONT WHEEL SPEED SENSOR SIGNAL

Right Headlamp Leveling Motor (Export) Connector End View

RIGHT HEADLAMP LEVELING MOTOR - BLACK 3-WAY (EXPORT) CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18YL/VT HEADLAMP ADJUST SIGNAL 3 18DG/WT FUSED ILLUMINATION CONTROL MODULE OUTPUT

Right Heated Seat Back Heated Seat Cushion Connector End View

RIGHT HEATED SEAT BACK/HEATED SEAT CUSHION - 2-WAY CAV CIRCUIT FUNCTION 1 16BR GROUND 2 16BK/VT RIGHT HEATED SEAT OUTPUT

Scheme 216

Right Knock Sensor Connector End View

RIGHT KNOCK SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BK SENSOR GROUND 2 20VT RIGHT KNOCK SENSOR SIGNAL

Scheme 217

Right Park Lamp Connector End View

RIGHT PARK LAMP - 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18DG FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXCEPT EXPORT) 2 18GY/RD FUSED ILLUMINATION CONTROL MODULE OUTPUT (EXPORT)

Scheme 218

Right Power Mirror Connector End View

RIGHT POWER MIRROR - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 2 18BR GROUND 3 - - 4 18WT RIGHT MIRROR VERTICAL DRIVER 5 18GY RIGHT MIRROR COMMON DRIVER 6 18BK RIGHT MIRROR HORIZONTAL DRIVER

Scheme 219

Right Rear Lamp Assembly Connector End View

RIGHT REAR LAMP ASSEMBLY - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18GY/RD FUSED STANDING/PARK LAMPS OUTPUT 2 18GY/RD RIGHT TAIL LAMP OUTPUT 3 18BK/DG RIGHT TURN SIGNAL OUTPUT 4 18BK/YL BRAKE LAMP RELAY OUTPUT 5 18GY/YL BACKUP LAMP SWITCH OUTPUT 6

Scheme 220

Right Rear Side Marker Lamp Connector End View

RIGHT REAR SIDE MARKER LAMP - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18BK/VT FUSED RIGHT STANDING/PARK LAMPS OUTPUT

Scheme 221

Right Rear Speaker Connector End View

RIGHT REAR SPEAKER - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 16BL/RD AMPLIFIED RIGHT REAR SPEAKER (+) 2 16BK/YL AMPLIFIED RIGHT REAR SPEAKER (-) 3 16VT RIGHT REAR SPEAKER SUPPLY VOLTAGE 4 16RD/YL RIGHT REAR SPEAKER GROUND

Scheme 222

Right Rear Wheel Speed Sensor Connector End View

RIGHT REAR WHEEL SPEED SENSOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20YL RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 2 20BR RIGHT REAR WHEEL SPEED SENSOR SIGNAL

Scheme 223

Right Rotation Relay (Roadster (Convertible)) Connector End View

RIGHT ROTATION RELAY - 9-WAY (ZH27) CAV CIRCUIT FUNCTION 1 - - 2 RD FUSED B(+) 3 - - 4 BK ROTATION RELAY GROUND 5 BK GROUND 6 BR RIGHT ROTATION RELAY CONTROL 7 - - 8 RD RIGHT ROTATION RELAY OUTPUT 9

Right Side Airbag Squib Connector End View

RIGHT SIDE AIRBAG SQUIB - YELLOW 2-WAY CAV CIRCUIT FUNCTION 1 20BL/GY RIGHT SIDE SQUIB LINE 2 2 20BL/RD RIGHT SIDE SQUIB LINE 1

Right Side Impact Sensor Connector End View

RIGHT SIDE IMPACT SENSOR - YELLOW 3-WAY CAV CIRCUIT FUNCTION 1 20BR GROUND 2 - - 3 20WT/YL RIGHT SIDE IMPACT SENSOR SIGNAL

Scheme 224

Right Turn Signal Lamp (Export) Connector End View

RIGHT TURN SIGNAL LAMP - 2-WAY (EXPORT) CAV CIRCUIT FUNCTION 1 18BR GROUND 2 18BK/DG RIGHT TURN SIGNAL OUTPUT

Scheme 225

Roof Open Switch (Roadster (Convertible)) Connector End View

ROOF OPEN SWITCH - BLACK 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20BK CARGO DIVIDER SENSE 2 20BK ROOF/CARGO DIVIDER SENSE

Scheme 226

Sentry Key Remote Entry Module Connector End View (C1)

SENTRY KEY REMOTE ENTRY MODULE C1 - BLACK 18-WAY CAV CIRCUIT FUNCTION 1 22GY/BK DOOR UNLOCK SWITCH SENSE 2 20BK/YL REMOTE KEYLESS ENTRY RELAY CONTROL 3 22GY/RD RKE STATUS OUTPUT 4 - - 5 - - 6 22WT RKE ANTENNA 7 SHIELD SHIELD 8 20BK DRIVER CYLINDER LOCK SWITCH SENSE (UNLOCK) 9 20BL DRIVER CYLINDER LOCK SWITCH SENSE (LOCK) 10 18PK/RD/BL FUSED IGNITION SWITCH OUTPUT 11 22BK/RD DOOR LOCK SWITCH SENSE 12 - - 13 - - 14 - - 15 - - 16 18BR GROUND 17 22BK/WT SCI TRANSMIT 18 20RD/YL FUSED B(+)

Scheme 227

Sentry Key Remote Entry Module Connector End View (C2)

SENTRY KEY REMOTE ENTRY MODULE C2 - NATURAL 2-WAY CAV CIRCUIT FUNCTION 1 20DG CAN C BUS (-) 2 20WT CAN C BUS (+)

Scheme 228

Sentry Key Remote Entry Module Connector End View (C3)

SENTRY KEY REMOTE ENTRY MODULE C3 - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 16BK SENTRY KEY ANTENNA 2 SHIELD SHIELD

Scheme 229

Shift Lever Assembly Connector End View

SHIFT LEVER ASSEMBLY - BLACK 10-WAY CAV CIRCUIT FUNCTION 1 - - 2 20GY/BL FUSED ILLUMINATION FEED 3 22RD/YL SCI TRANSMIT 4 20BR GROUND 5 20RD/BL BTSI FEED 6 22WT CAN C BUS (+) 7 22DG CAN C BUS (-) 8 20RD/DG TRACTION SYSTEM RELAY OUTPUT 9 20PK/RD FUSED IGNITION SWITCH OUTPUT 10 20GY/YL SHIFT LEVER ASSEMBLY REVERSE SUPPLY VOLTAGE

Short Runner Valve Solenoid Connector End View

SHORT RUNNER VALVE SOLENOID - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20DG/VT SHORT RUNNER VALVE SOLENOID CONTROL 2 20RD/DG FUSED ENGINE CONTROL RELAY OUTPUT

Scheme 230

Siren Connector End View

SIREN - BLACK 3-WAY CAV CIRCUIT FUNCTION 1 20RD/GY FUSED B(+) 2 20BR GROUND 3 20YL/RD SIREN SIGNAL OUTPUT

Scheme 231

Speed Control Switch Connector End View

SPEED CONTROL SWITCH - BROWN 8-WAY CAV CIRCUIT FUNCTION 1 20GY OFF SIGNAL 2 18BK/RD FUSED IGNITION SWITCH OUTPUT 3 20YL/DG DECEL/SET SIGNAL 4 20DG/RD ACCEL/SET SIGNAL 5 20BL/RD RESUME SIGNAL 6 20DG/BL ON SIGNAL 7 - - 8

Scheme 232

Steering Angle Sensor Connector End View

STEERING ANGLE SENSOR - BLACK 4-WAY CAV CIRCUIT FUNCTION 1 20BL/YL STEERING ANGLE SENSOR SIGNAL 2 20PK/RD FUSED IGNITION SWITCH OUTPUT 3 20BR GROUND 4 18RD/DG FUSED B(+)

Scheme 233

Throttle Body Connector End View

THROTTLE BODY - BLACK 6-WAY CAV CIRCUIT FUNCTION 1 18BL THROTTLE CONTROL MOTOR 1 2 20VT 5 VOLT SUPPLY 3 20GY SENSOR GROUND 4 18BK THROTTLE CONTROL MOTOR 2 5 20WT THROTTLE POSITION SENSOR SIGNAL 2 6 20YL THROTTLE POSITION SENSOR SIGNAL 1

Scheme 234

Tonneau Cover Switch (Roadster (Convertible)) Connector End View

TONNEAU COVER SWITCH - 4-WAY (ZH27) CAV CIRCUIT FUNCTION 1 - - 2 - - 3 20BR GROUND 4 20BR/DG TONNEAU COVER SWITCH SENSE 4 20BR/DG TONNEAU COVER SWITCH SENSE

Tow Away Alarm Switch Connector End View

TOW-AWAY ALARM SWITCH - BLACK 3-WAY CAV CIRCUIT FUNCTION 2 22RD/DG TOW-AWAY ALARM SWITCH LED CONTROL 4 - - 6 20WT/DG TOW-AWAY ALARM SWITCH SENSE

Scheme 235

Transmission Control Module Connector End View (C1)

TRANSMISSION CONTROL MODULE C1 - BLACK 18-WAY CAV CIRCUIT FUNCTION 1 22DG SCI TRANSMIT 2 - - 3 - - 4 - - 5 - - 6 - - 7 - - 8 - - 9 - - 10 - - 23 - - 24 - - 25 - - 26 - - 27 - - 28 - - 29 18RD/DG TRACTION SYSTEM RELAY OUTPUT 30 18BR GROUND

Transmission Control Module Connector End View (C2)

TRANSMISSION CONTROL MODULE C2 - BLACK 12-WAY CAV CIRCUIT FUNCTION 12 20WT N2 INPUT SPEED SENSOR 13 20BL/DG SENSOR SUPPLY VOLTAGE 14 20GY/RD 1-2/4-5 SOLENOID CONTROL 15 20GY/VT 3-4 SOLENOID CONTROL 16 20GY/DG 2-3 SOLENOID CONTROL 17 20GY/BK TCC SOLENOID CONTROL 33 20BR SENSOR GROUND 34 20BL/YL TEMP SENSOR P/N SWITCH 35 20BK N3 INPUT SPEED SENSOR 36 20DG/YL MODULATION PRESSURE SOLENOID CONTROL 37 20DG SHIFT PRESSURE SOLENOID CONTROL 38 18RD SOLENOID SUPPLY VOLTAGE H - - L

Scheme 236

Transmission Control Module Connector End View (C3)

TRANSMISSION CONTROL MODULE C3 - BLACK 2-WAY CAV CIRCUIT FUNCTION H 20WT CAN C BUS (+) L 20DG CAN C BUS (-)

Transmission Solenoid Assembly Connector End View

TRANSMISSION SOLENOID ASSEMBLY - BLACK 13-WAY CAV CIRCUIT FUNCTION 1 20BK N3 INPUT SPEED SENSOR 2 20DG/YL MODULATION PRESSURE SOLENOID CONTROL 3 20WT N2 INPUT SPEED SENSOR 4 20BL/YL TEMP SENSOR P/N SWITCH 5 - - 6 18RD SOLENOID SUPPLY VOLTAGE 7 20BL/DG SENSOR SUPPLY VOLTAGE 8 20GY/DG 2-3 SOLENOID CONTROL 9 20GY/VT 3-4 SOLENOID CONTROL 10 20DG SHIFT PRESSURE SOLENOID CONTROL 11 20GY/BK TCC SOLENOID CONTROL 12 20BR SENSOR GROUND 13 20GY/RD 1-2/4-5 SOLENOID CONTROL

Scheme 237

Trunk Latch Assembly (Roadster (Convertible)) Connector End View (C1)

TRUNK LATCH ASSEMBLY C1 - 3-WAY (ZH27) CAV CIRCUIT FUNCTION 1 20BR GROUND 2 20BK/VT TRUNK LATCH UNLOCKED SIGNAL 3 20BR/VT TRUNK LATCH LOCKED SIGNAL

Scheme 238

Trunk Latch Assembly (Roadster (Convertible)) Connector End View (C2)

TRUNK LATCH ASSEMBLY C2 - BLACK 2-WAY (ZH27) CAV CIRCUIT FUNCTION 1 16RD/DG TRUNK LATCH ACTUATOR UNLOCK CONTROL 2 16BK/DG TRUNK LATCH ACTUATOR LOCK CONTROL

Scheme 239

Underhood Accessory Fuse Block Fuses Connector End View

UNDERHOOD ACCESSORY FUSE BLOCK FUSES CAV CIRCUIT FUNCTION 1 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 1 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 1 20RD/YL FUSED IGNITION SWITCH OUTPUT (A/T) 1 20PK/YL/BK FUSED IGNITION SWITCH OUTPUT (EUROPE) 2 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 3 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 3 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 4 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 4 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 5 14RD/YL FUSED B(+) (ZH27) 5 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT (ZH29) 6 12RD/YL FUSED B(+) (ZH27) 6 18PK/RD/WT FUSED B(+) (ZH29) 7 20RD/YL FUSED B(+) 7 20PK/RD/WT FUSED B(+) (EXPORT) 8 14RD/DG FUSED B(+) 9 20PK/RD FUSED IGNITION SWITCH OUTPUT (EXCEPT EXPORT) 9 16RD/YL FUSED B(+) (EXPORT) 9 16RD/GY FUSED B(+) (EXPORT) 10 18BK/RD FUSED IGNITION SWITCH OUTPUT 11 16BK/YL FUSED IGNITION SWITCH OUTPUT 12 18PK/RD/WT FUSED IGNITION SWITCH OUTPUT 13 16RD/GY FUSED B(+) (EXCEPT EXPORT) 13 20RD/GY FUSED B(+) (EXCEPT EXPORT) 14 18RD/DG FUSED B(+) 15 18RD/YL FUSED B(+) 16 16RD/WT FUSED B(+) 17 12BK FUSED B(+) 18 12BK FUSED B(+) 19 12RD/YL FUSED B(+) 20 12PK/YL/DG FUSED IGNITION SWITCH OUTPUT 21 14RD/DG POWER SEAT RELAY OUTPUT (LHD) 21 14RD/BK POWER SEAT RELAY OUTPUT (RHD) 22 14RD/BK POWER SEAT RELAY OUTPUT (LHD) 22 14RD/DG POWER SEAT RELAY OUTPUT (RHD) 23 14RD/YL FUSED B(+) 24 14RD/YL FUSED B(+) 25 12RD/DG FUSED B(+) 26 16BK/YL/WT FUSED B(+) 27 - - 28 - - 29 - - 30 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT (ZH27) 31 16BK/BL FUSED IGNITION SWITCH OUTPUT 32 16BK/YL/DG FUSED IGNITION SWITCH OUTPUT 33 20BK/DG FUSED IGNITION SWITCH OUTPUT 34 14RD FUSED B(+) (ZH27) 35 14RD/YL FUSED B(+) 36 18PK/RD/WT FUSED B(+) (ZH27) 36 14RD FUSED B(+) (ZH29) 37 18PK/RD/BK FUSED IGNITION SWITCH OUTPUT 37 18PK/RD/BL FUSED IGNITION SWITCH OUTPUT

Scheme 240

UNDERHOOD ACCESSORY FUSE BLOCK FUSES CAV CIRCUIT FUNCTION 1 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 1 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 1 20RD/YL FUSED IGNITION SWITCH OUTPUT (A/T) 1 20PK/YL/BK FUSED IGNITION SWITCH OUTPUT (EUROPE) 2 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 3 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 3 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 4 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 4 18PK/RD/WT FUSED HEATED MIRROR SUPPLY 5 14RD/YL FUSED B(+) (ZH27) 5 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT (ZH29) 6 12RD/YL FUSED B(+) (ZH27) 6 18PK/RD/WT FUSED B(+) (ZH29) 7 20RD/YL FUSED B(+) 7 20PK/RD/WT FUSED B(+) (EXPORT) 8 14RD/DG FUSED B(+) 9 20PK/RD FUSED IGNITION SWITCH OUTPUT (EXCEPT EXPORT) 9 16RD/YL FUSED B(+) (EXPORT) 9 16RD/GY FUSED B(+) (EXPORT) 10 18BK/RD FUSED IGNITION SWITCH OUTPUT 11 16BK/YL FUSED IGNITION SWITCH OUTPUT 12 18PK/RD/WT FUSED IGNITION SWITCH OUTPUT 13 16RD/GY FUSED B(+) (EXCEPT EXPORT) 13 20RD/GY FUSED B(+) (EXCEPT EXPORT) 14 18RD/DG FUSED B(+) 15 18RD/YL FUSED B(+) 16 16RD/WT FUSED B(+) 17 12BK FUSED B(+) 18 12BK FUSED B(+) 19 12RD/YL FUSED B(+) 20 12PK/YL/DG FUSED IGNITION SWITCH OUTPUT 21 14RD/DG POWER SEAT RELAY OUTPUT (LHD) 21 14RD/BK POWER SEAT RELAY OUTPUT (RHD) 22 14RD/BK POWER SEAT RELAY OUTPUT (LHD) 22 14RD/DG POWER SEAT RELAY OUTPUT (RHD) 23 14RD/YL FUSED B(+) 24 14RD/YL FUSED B(+) 25 12RD/DG FUSED B(+) 26 16BK/YL/WT FUSED B(+) 27 - - 28 - - 29 - - 30 16PK/YL/DG FUSED IGNITION SWITCH OUTPUT (ZH27) 31 16BK/BL FUSED IGNITION SWITCH OUTPUT 32 16BK/YL/DG FUSED IGNITION SWITCH OUTPUT 33 20BK/DG FUSED IGNITION SWITCH OUTPUT 34 14RD FUSED B(+) (ZH27) 35 14RD/YL FUSED B(+) 36 18PK/RD/WT FUSED B(+) (ZH27) 36 14RD FUSED B(+) (ZH29) 37 18PK/RD/BK FUSED IGNITION SWITCH OUTPUT 37 18PK/RD/BL FUSED IGNITION SWITCH OUTPUT

Universal Garage Door Opener Tire Pressure Monitor Connector End View

UNIVERSAL GARAGE DOOR OPENER/TIRE PRESSURE MONITOR - NATURAL 6-WAY CAV CIRCUIT FUNCTION 1 20PK/YL/DG FUSED IGNITION SWITCH OUTPUT 2 20GY/YL LOW TIRE PRESSURE WARNING INDICATOR CONTROL 3 20BR GROUND 4 20BK/BL SCI TRANSMIT 5 20RD/GY FUSED B(+) 6

Scheme 241

Washer Fluid Level Switch Connector End View

WASHER FLUID LEVEL SWITCH - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 20BR COOLANT/WASHER LEVEL RETURN 2 20BR/BL COOLANT/WASHER LEVEL COMBINATION

Scheme 242

Washer Pump Motor Connector End View

WASHER PUMP MOTOR - BLACK 2-WAY CAV CIRCUIT FUNCTION 1 18GY WASHER PUMP MOTOR CONTROL 2 18BR GROUND
