CONNECTOR/GROUND/SPLICE LOCATIONS

This information provides illustrations identifying connector, ground and splice locations in the vehicle. Connector, ground and splice indexes are provided. Use the wiring diagrams in each section for connector, ground and splice identification. Refer to the appropriate index for the proper figure number. For items that are not shown in this information, N/S is placed in the Fig. column.

CONNECTOR NAME/NUMBER	COLOR	LOCATION	FIG.
A/C Compressor Clutch	BK	Lower Left Side of Engine	(Scheme 20).
A/C Heater Control Module	BK	Center of Instrument Panel	(Scheme 25).
A/C Pressure Sensor	BK	Behind the Left Front Headlamp	N/S
Accelerator Pedal Position Sensor	BK	Top of Accelerator Pedal	N/S
Air Pump	BK	Center Top Engine	(Scheme 21).
Air Pump Relay		In the Relay Control Module	(Scheme 17).
Air Pump Switchover Solenoid	BK	Front of Engine	(Scheme 21).
Airbag Off Indicator Lamp	BK	Center of Instrument Panel	N/S
Ambient Temperature Sensor	BK	Lower Left Grille	N/S
Antenna C1 (ZH27)	BK	Left Rear Quarter Panel	N/S
Antenna C1 (Coupe)	BK	Underside Lower Liftgate	(Scheme 38).
Antenna C2	BK	Underside Lower Liftgate	(Scheme 38).
Anti-Theft Tow Sensor	BK	Right Rear Lower Luggage Compartment	(Scheme 14), (Scheme 36).
Ash Receiver Lamp	BK	Center of Instrument Panel	N/S
Backup Lamp Switch	BK	Right Side of Transmission	(Scheme 23).
BAS Brake Booster C1	BK	Left Rear of Engine Compartment	N/S
BAS Brake Booster C2	BK	Left Rear of Engine Compartment	N/S
Battery		Right Rear of Engine Compartment	(Scheme 19).
Blower Motor	BK	Under Passenger Side of Instrument Panel	N/S
Body Control Module C1	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Body Control Module C2	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Body Control Module C3	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Body Control Module C4	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Brake Fluid Level Switch	BK	Left Rear of Engine Compartment	(Scheme 15).
Brake Lamp Relay	YL	Left Rear of Engine Compartment at Rear of Underhood Accessory Fuse Block	(Scheme 16).
Brake Lamp Switch (A/T)	BK	Top of Brake Pedal	N/S
C100 (ZH27)	GN	Between the Instrument Panel and Body Harness	N/S
C100 (ZH29)	BK	Left of Steering Column Behind the Instrument Panel	N/S
C105	BK	Left Rear of Engine Compartment Under the Underhood Accessory Fuse Block	(Scheme 16).
C106	BK	In the Control Module Box at Right Rear of Engine Compartment	(Scheme 17).
C200	BK	Left of Steering Column Behind the Instrument Panel	N/S
C201	BK	Behind the Passenger Footwell	(Scheme 29).
C206	BK	Behind the Passenger Footwell	(Scheme 29).
C207 (A/T)	BK	Behind the Passenger Footwell	(Scheme 29).
C208	YL	Between the Instrument Panel and Body Harness	N/S
C210	YL	Behind the Passenger Footwell	(Scheme 29).
C211	NAT	Behind the Passenger Footwell	(Scheme 29).
C219	BL	Behind the Passenger Footwell	(Scheme 29).
C223 (MALE)	YL	Lower Driver Side Behind Kick Panel	N/S
C223 (FEMALE)	BK	Lower Driver Side Behind Kick Panel	N/S
C224 (MALE)	YL	Lower Passenger Side Behind Kick Panel	(Scheme 34).
C224 (FEMALE)	BK	Lower Passenger Side Behind Kick Panel	(Scheme 34).
C226		Left of Steering Column Behind the Instrument Panel	N/S
C228	BK	Lower Driver Side Behind Kick Panel	N/S
C229	BK	Lower Driver Side Behind Kick Panel	N/S
C230	BK	Lower Passenger Side Behind Kick Panel	(Scheme 34).
C231	BK	Lower Passenger Side Behind Kick Panel	(Scheme 34).
C240	BK	Between Engine Compartment and Body Harness	N/S
C300 (ZH27)	NAT	Between the Body and Spoiler Harness	N/S
C301 (ZH27)	BK	Between the Body and Rear Window Defogger Harness	N/S
C302 (ZH27)	BK	Between the Body and Spoiler Harness	N/S
Camshaft Position Sensor	BK	Right Front of Engine	(Scheme 20), (Scheme 21).
Cargo Compartment Divider Switch (ZH27)	BK	In the Body harness	N/S
Cargo Lamp	BK	Left Rear of the Luggage Compartment	N/S
Center High Mounted Stop Lamp	BK	Top of the Liftgate	N/S
Central Locking Pump/Security System Module C1	WT	Right Rear of the Luggage Compartment	(Scheme 14), (Scheme 36).
Central Locking Pump/Security System Module C2	BK	Right Rear of the Luggage Compartment	(Scheme 14), (Scheme 36).
Central Locking Pump/Security System Module C3	BK	Right Rear of the Luggage Compartment	(Scheme 14), (Scheme 36).
Central Locking Pump/Security System Module C4	BK	Right Rear of the Luggage Compartment	(Scheme 14), (Scheme 36).
Charcoal Canister Shutoff Valve (Except Export)	BK	Under the Right Rear in Front of the Axle	N/S
Cigar Lighter	BK	Center of the Instrument Panel	N/S
Clockspring	DK. GN	Center of the Steering Wheel	N/S
Clutch Interlock Switch	BK	Top of the Clutch Pedal	N/S
Clutch Pedal Position Switch	BK	Top of the Clutch Pedal	N/S
Coil On Plug No. 1	BK	On the Right Valve Cover	N/S
Coil On Plug No. 2	BK	On the Right Valve Cover	N/S
Coil On Plug No. 3	BK	On the Right Valve Cover	N/S
Coil On Plug No. 4	BK	On the Left Valve Cover	(Scheme 20).
Coil On Plug No. 5	BK	On the Left Valve Cover	(Scheme 20).
Coil On Plug No. 6	BK	On the Left Valve Cover	(Scheme 20).
Console Switch Group	BK	Center of the Instrument Panel	(Scheme 25).
Controller Antilock Brake		Left Rear of Engine Compartment	(Scheme 14), (Scheme 15), (Scheme 19).
Coolant Circulation Pump	BK	Below Right Headlamp	N/S
Coolant Circulation Valve	BK	Right Rear of Engine Compartment in Front of Control Module Box	(Scheme 18), (Scheme 19).
Coolant Level Sensor	BK	Right Front of Engine Compartment Below Coolant Recovery Reservoir	N/S
Crankshaft Position Sensor	NAT	Rear of Engine	(Scheme 20), (Scheme 22).
Data Link Connector	BK	Under Driver Side Instrument Panel	N/S
Dome Lamp	BK	Top Center of Windshield	N/S
Driver Airbag Squib 1	YL	On Steering Wheel	N/S
Driver Airbag Squib 2	YL	On Steering Wheel	N/S
Driver Knee Blocker Airbag Squib	YL	Under Driver Side of Instrument Panel	N/S
Driver Cylinder Lock Switch (Except Europe)	BK	Driver Door	N/S
Driver Power Seat	BK	Side of Driver Seat	N/S
Driver Seat Belt Switch	BK	Side of Driver Seat	N/S
Driver Seat Belt Tensioner Squib	YL	Driver Seat Belt Tensioner	N/S
EGR Solenoid	BK	Rear of engine	(Scheme 22).
Engine Coolant Temperature Sensor	BK	Front of Engine	(Scheme 21).
Engine Fuse Block		Right Rear of Engine Compartment in Front of Battery	(Scheme 14), (Scheme 19).
Engine Starter Motor		Right Lower Side of Engine	N/S
ESP Brake Pressure Sensor 1	BK	Left Rear of Engine Compartment	N/S
ESP Off Switch	BK	Center of Instrument Panel	(Scheme 25).
	ESP Yaw Rate/Lateral Acceleration Sensor	Under the Center Console	(Scheme 28).
EVAP Purge Solenoid	BK	Left Side of Engine Compartment	(Scheme 15).
Evaporator Temperature Sensor	BK	Right Side of Driver Footwell	N/S
Fuel Injector No. 1	BK	Right Side of Intake Manifold	N/S
Fuel Injector No. 2	BK	Right Side of Intake Manifold	N/S
Fuel Injector No. 3	BK	Right Side of Intake Manifold	N/S
Fuel Injector No. 4	BK	Left Side of Intake Manifold	(Scheme 20).
Fuel Injector No. 5	BK	Left Side of Intake Manifold	(Scheme 20).
Fuel Injector No. 6	BK	Left Side of Intake Manifold	(Scheme 20).
Fuel Level Sensor	BK	Top of Fuel Tank	N/S
Fuel Tank Pressure Sensor (Except Export)	BK	Top of Fuel Tank	N/S
Garage Door Opener (Europe)	BK	Rear View Mirror	N/S
Generator	BK	Right Front of Engine	(Scheme 20).
Glove Box Lamp	BK	Passenger Side of Instrument Panel	N/S
Glove Box Switch	BK	Passenger Side of Instrument Panel	N/S
Headlamp Leveling Switch (Export)	BK	Left Side of Dash	(Scheme 26).
Heated Seat Module	BK	Center of Instrument Panel to the Rear of the Heated Seat Switches	N/S
Heated Washer Nozzles	BK	Under Cowl	N/S
Heater Core Temperature Sensor	BK	Behind the Center of the Instrument Panel	N/S
Hood Ajar Switch	BK	Part of the Hood Latch	N/S
Ignition Switch	BK	Right of Steering Column	N/S
Illumination Control Module A	BK	Left of Steering Column	N/S
Illumination Control Module B	BK	Left of Steering Column	N/S
Illumination Control Module D	BK	Left of Steering Column	N/S
Illumination Control Module E	BK	Left of Steering Column	N/S
		Illumination Control Module Fuses	N/S
Instrument Cluster C1	BK	Above Steering Column	N/S
Instrument Cluster C2	BK	Above Steering Column	N/S
Intrusion Sensor (Export)		In Body Harness	N/S
Key-In Ignition Switch	WT	Under Ignition Key Cylinder	N/S
Kickdown Switch	BK	Under Accelerator Pedal	N/S
Latch Retainer Switch (ZH27)	BK	In Body Harness	N/S
Left Door Ajar Switch	WT	Rear of Left Door	N/S
Left Door Speaker	BK	Left Door	N/S
Left Door Tweeter	BK	Left Door	N/S
Left Fog Lamp	NAT	Left Front of Fascia Below Headlamp	N/S
Left Front Impact Sensor	BK	Left Front of Engine Compartment	N/S
Left Front Lamp Assembly	BK	Left Front of Vehicle	N/S
Left Front Power Window Motor	BK	Left Door	N/S
Left Front Power Window Switch	BK	In Body Harness	(Scheme 25).
	Left Front Side Marker Lamp (Except Export)	Left Front Side	N/S
Left Front WSS/Brake Pad Wear Sensor	BK	Left Front Brake Caliper	N/S
Left Headlamp Leveling Motor (Export)	BK	Left Front	N/S
Left Heated Seat Back/Heated Seat Cushion		Left Front Seat	N/S
Left Knock Sensor	BK	Left Side of Engine	N/S
	Left Park Lamp	Left Side	N/S
Left Power Mirror	BK	Left Door	N/S
Left Rear Lamp Assembly	BK	Left Rear	N/S
	Left Rear Side Marker Lamp	Left Rear	N/S
Left Rear Speaker	BK	Left Door	N/S
Left Rear Wheel Speed Sensor	BK	Left Rear Wheel	N/S
Left Rotation Relay (ZH27)		In Body Harness	N/S
Left Side Airbag Squib	YL	Rear of Left Door	N/S
Left Side Impact Sensor	YL	Under Carpet Below Left Seat	(Scheme 28).
Left Turn Signal Lamp (Export)		Left Engine Compartment	N/S
License Lamp No. 1	BK	Below Liftgate	N/S
License Lamp No. 2	BK	Below Liftgate	N/S
Liftgate Lock Switch	BK	Below Liftgate Hinge	(Scheme 37).
MAF/IAT Sensor	WT	Rear of Engine	N/S
Manifold Absolute Pressure Sensor	BK	Front of Engine	(Scheme 21).
Multi-Function Switch	BK	Left Side of Steering Column	N/S
Occupant Classification Module	NAT	Behind the Passenger Footwell	(Scheme 30).
Occupant Restraint Controller		Under the Center Console	(Scheme 14), (Scheme 28).
Oil Sensor	BK	Lower Right Side of Engine Oil Pan	N/S
Oxygen Sensor 1/1 Upstream	BK	Rear of Left Exhaust Manifold	N/S
Oxygen Sensor 1/2 Downstream	BK	Exhaust Pipe Rear of Catalytic Converter	N/S
Oxygen Sensor 2/1 Upstream	BK	Rear of Right Exhaust Manifold	N/S
Oxygen Sensor 2/2 Downstream	BK	Exhaust Pipe Rear of Catalytic Converter	N/S
Passenger Airbag ON/OFF Switch		Right Side of Dash	N/S
Passenger Airbag Squib	YL	Passenger Side of Instrument Panel	N/S
Passenger Knee Blocker Airbag Squib	YL	Right Lower Instrument Panel	N/S
Passenger Power Seat	BK	Side of Passenger Seat	N/S
Passenger Seat Belt Switch	BK	Passenger Seat Belt Tensioner	N/S
Passenger Seat Belt Tensioner Squib	YL	Passenger Seat Belt Tensioner	N/S
Power Amplifier A	BK	Behind the Passenger Footwell	(Scheme 14), (Scheme 29).
Power Amplifier B	BK	Behind the Passenger Footwell	(Scheme 14), (Scheme 29).
Power Mirror Switch	BK	Center Console	(Scheme 25).
Power Seat Relay	BK	Left Side of Steering Column Under Instrument Panel	N/S
Power Top Control Module C1 (ZH27)		Rear of Trunk	(Scheme 32).
Power Top Control Module C2 (ZH27)		Rear of Trunk	(Scheme 32).
Power Top Hydraulic Assembly (ZH27)	BK	Rear of Trunk	N/S
Power Top Switch (ZH27)	BK	Dash	N/S
Power Top Travel Sensors (ZH27)	BK	Rear of Trunk	N/S
Powertrain Control Module C1	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Powertrain Control Module C2	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Powertrain Control Module C3	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Powertrain Control Module C4	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Powertrain Control Module C5	WT	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Pulse Module A	BK	Left Rear of Engine Compartment at Side of Underhood Accessory Fuse Block	(Scheme 14), (Scheme 15), (Scheme 16), (Scheme 19).
Pulse Module B	BK	Left Rear of Engine Compartment at Side of Underhood Accessory Fuse Block	(Scheme 14), (Scheme 15), (Scheme 16), (Scheme 19).
Pulse Module F		Left Rear of Engine Compartment at Side of Underhood Accessory Fuse Block	(Scheme 14), (Scheme 15), (Scheme 19).
Radiator Fan Control Module	NAT	Left Front of Engine Compartment	(Scheme 14), (Scheme 19).
Radiator Fan Motor	BK	Front of Engine Compartment	N/S
Radio	BK	Center of the Instrument Panel	N/S
Radio D	BK	In Body Harness	N/S
Rear Bow Switch (ZH27)		In Body Harness	N/S
Rear Spoiler Limit Switch	BK	Rear of Vehicle	N/S
Rear Spoiler Motor	BL	Rear of Vehicle	N/S
Rear Spoiler Switch	BK	Rear of Vehicle	N/S
	Rear Window Defogger	Left Rear Quarter Panel	(Scheme 38).
Recirculated Air Switchover Valve	GY	Lower Passenger Instrument Panel	N/S
Relay Control Module A	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Relay Control Module B	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Relay Control Module C	BK	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Relay Control Module D	GY	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
Relay Control Module E	GY	In Control Module Box at Right Rear of Engine Compartment	(Scheme 14), (Scheme 17).
		Relay Control Module Fuses	N/S
Remote Keyless Entry Relay	BK	Left Rear of Engine Compartment at Rear of Underhood Accessory Fuse Block	(Scheme 16).
Right Door Ajar Switch	WT	Rear of Right Door	(Scheme 34).
Right Door Speaker	BK	Right Door	(Scheme 34).
Right Door Tweeter	BK	Right Door	(Scheme 34).
Right Fog Lamp	NAT	Right Front of Fascia Below Headlamp	N/S
Right Front Impact Sensor	BK	Right Front of Engine Compartment	N/S
Right Front Lamp Assembly		Right Front	N/S
Right Front Power Window Motor	BK	Right Front	(Scheme 34).
	Right Front Power Window Switch	BK	(Scheme 25).
Right Front Side Marker Lamp (Except Export)	BK	Right Front Side	N/S
Right Front WSS/Brake Pad Wear Sensor	BK	Right Front Brake Caliper	N/S
Right Headlamp Leveling Motor (Export)	BK	Right Front	N/S
Right Heated Seat Back/Heated Seat Cushion		Right Seat Cushion	N/S
Right Knock Sensor	BK	Under Intake Manifold	N/S
Right Park Lamp		Right Corner of Lamp Assembly	N/S
Right Power Mirror	BK	Top Front of Right Door	(Scheme 34).
Right Rear Lamp Assembly	BK	Right Rear of Vehicle	(Scheme 36).
Right Rear Side Marker Lamp	BK	Right Corner of Rear Fascia	(Scheme 36).
Right Rear Speaker	BK	In Back of Right Seat	N/S
Right Rear Wheel Speed Sensor	BK	Right Brake Backing Plate	N/S
Right Rotation Relay (ZH27)		In Body Harness	N/S
Right Side Airbag Squib	YL	Rear of Right Door	N/S
Right Side Impact Sensor	YL	Under Carpet Below Right Seat	N/S
Right Turn Signal Lamp (Export)		Right Front of Engine Compartment	N/S
Roof Open Switch (ZH27)	BK	In Rear Window Defogger Harness	N/S
Sentry Key Antenna Ring	BK	On Ignition Key Cylinder	N/S
Sentry Key Remote Entry Module C1	BK	Behind Instrument Cluster	(Scheme 14).
Sentry Key Remote Entry Module C2	NAT	Behind Instrument Cluster	(Scheme 14).
Sentry Key Remote Entry Module C3	BK	Behind Instrument Cluster	(Scheme 14).
Shift Lever Assembly	BK	Center Console	(Scheme 28).
Short Runner Valve Solenoid	BK	Front of Engine	N/S
Siren	BK	Base of Windshield Under Cowl Grille	N/S
Speed Control Switch	BN	Left Side of Steering Column	N/S
Steering Angle Sensor	BK	Left Side of Steering Column	N/S
Throttle Body	BK	Rear of Engine	(Scheme 22).
	Tonneau Cover Switch (ZH27)	Behind Rear Seat (Trunk)	(Scheme 33).
Tow-Away Alarm Switch	BK	Center Panel	(Scheme 27).
Transmission Control Module C1	BK	Behind the Passenger Footwell	(Scheme 14), (Scheme 29).
Transmission Control Module C2	BK	Behind the Passenger Footwell	(Scheme 14), (Scheme 29).
Transmission Control Module C3	BK	Behind the Passenger Footwell	(Scheme 14), (Scheme 29).
Transmission Solenoid Assembly	BK	Bottom of Automatic Transmission	(Scheme 24).
Trunk Latch Assembly C1 (ZH27)		In Spoiler Harness	(Scheme 39).
Trunk Latch Assembly C2 (ZH27)	BK	In Spoiler Harness	(Scheme 39).
Underhood Accessory Fuse Block		Left Rear of Engine Compartment	(Scheme 14), (Scheme 15), (Scheme 19).
Universal Garage Door Opener/Tire Pressure Monitor	NAT	Top Center of Windshield	(Scheme 14).
Washer Fluid Level Switch	BK	Behind Right Front Wheelwell Splash Shield	N/S
Washer Pump Motor	BK	In Engine Compartment Harness	N/S

CONNECTORS

GROUND	LOCATION	FIG.
G100	Left Side of Engine Compartment	(Scheme 19).
G101	Right Side of Engine Compartment	(Scheme 17).
G104	Top Front of Engine	N/S
G107	Right Side of Engine Compartment, Battery Negative Ground	(Scheme 17).
G200	Behind Left Side of Instrument Panel at Base of Windshield	N/S
G201	Lower Left Footwell Behind Kick Panel	(Scheme 31).
G202	Under the Center Console at the Occupant Restraint Controller	(Scheme 28).
G203	Under the Center Console	(Scheme 28).
G204	Lower Right Footwell Behind Kick Panel	(Scheme 34).
G205	Upper Left Rear Passenger Compartment	(Scheme 35).
G206	Lower Right Footwell Behind Kick Panel	(Scheme 34).
G300	Left Luggage Compartment Behind Trim Panel	(Scheme 35).
G301	Lower Right Luggage Compartment Behind Trim Panel	(Scheme 36).
G302	Upper Liftgate	(Scheme 38).

GROUNDS

SPLICE	LOCATION	FIG.
S101	Engine Compartment on Top Left of Intake Manifold	N/S
S104	Engine Compartment on Top Left of Intake Manifold	N/S
S105	Engine Compartment at the Front of Intake Manifold	N/S
S107	Engine Compartment on Top Left of Intake Manifold	N/S
S108	Engine Compartment Behind the Engine	N/S
S113	Engine Compartment Behind the Engine	N/S
S114	Right Rear of Engine Compartment in the Control Module Box	(Scheme 18).
S116	Left of Steering Column Behind the Instrument Panel	N/S
S117	Left of Steering Column Behind the Instrument Panel	N/S
S118	Right Rear of Engine Compartment in the Control Module Box	(Scheme 18).
S119	Right Rear of Engine Compartment in the Control Module Box	(Scheme 18).
S121	Engine Compartment at the Front of Intake Manifold	N/S
S122	Engine Compartment Behind the Engine	N/S
S123	Engine Compartment Behind the Engine	N/S
S125 (A/T)	Engine Compartment Behind the Engine	N/S
S200	In The Engine Compartment	N/S
S211	Behind the Instrument Cluster	N/S
S212	Behind the Instrument Cluster	N/S
S213	Behind the Instrument Cluster	N/S
S215	Behind the Upper Instrument Panel	N/S
S217	Behind the Upper Instrument Panel	N/S
S218	At the End of the Sentry Key Remote Entry Module (SKREEM) Antenna	N/S
S221	Behind the Lower Instrument Panel	N/S
S224	Behind the Lower Instrument Panel	N/S
S225	Behind Passenger Footwell	N/S
S226	Behind Passenger Footwell	N/S
S232	Under the Center Console	(Scheme 28).
S233	Lower Passenger Side Behind Kick Panel	N/S
S235	Behind Passenger Footwell	N/S
S236	Behind Passenger Footwell	N/S
S239	Behind Passenger Footwell	N/S
S240	Behind the Lower Instrument Panel	N/S
S241	Part of the Left Seat Assembly	N/S
S242	Part of the Left Seat Assembly	N/S
S243	Part of the Right Seat Assembly	N/S
S244	Part of the Right Seat Assembly	N/S
S246 (M/T)	Behind Passenger Footwell	N/S
S247	In The Body Harness	N/S
S248	In The Body Harness	N/S
S249	In The Body Harness	N/S
S300	In The Body Harness	N/S
S301	In The Body Harness	N/S
S302	In The Body Harness	N/S
S305	Right Rear Passenger Compartment Behind Headliner	N/S
S330	In The Body Harness	N/S
S331	In The Body Harness	N/S
S332	In The Body Harness	N/S
S339	In The Body Harness	N/S
Splice Block 100	Left Rear of Engine Compartment Behind the Underhood Accessory Fuse Block	(Scheme 16).
Splice Block 101	Left Rear of Engine Compartment Behind the Underhood Accessory Fuse Block	(Scheme 16).
Splice Block 102	Left Rear of Engine Compartment Behind the Underhood Accessory Fuse Block	(Scheme 16).
Splice Block 200	Under the Center Console	(Scheme 28).
