Frame & Bumpers: Removal & Installation Chrysler Crossfire I

Frames, Subframes & Crossmembers 5 illustrations ~244 words

INSTALLATION

  1. Position the fascia on the vehicle and install the upper fascia retaining bolts (1).
  2. Position the front grille assembly and install the retaining bolts (1).
  3. Raise and support the vehicle.
  4. Install the left and right front fender to fascia retaining nuts and bolts. «(Refer to BODY/EXTERIOR/LEFT FRONT FENDER - INSTALLATION)»(ref-250612-S38561258412007031500000) .
  5. Install the lower fascia retaining nuts (1).
  6. Connect the ambient air temp sensor wire harness connector (2).
  7. Connect the front marker lamp wire harness connector (1).
  8. Connect the fog lamp wire harness connectors (1).
  9. Install the left and right front fascia access panel retaining nuts and screws (1).
  10. Install the lower splash shield and the retaining screws (1).

Scheme 8

Scheme 8: REMOVAL

Scheme 9

Scheme 9
  1. Remove the rear fascia assembly retaining screws (1, 2, and 3).
  2. Raise and support the vehicle.
  3. Remove the right and left lower fascia trim retaining screws (1).
  4. Remove the rear fascia from the vehicle.
  1. Position the rear fascia on the vehicle and install the retaining screws (1, 2, and 3).
  2. Install the lower fascia trim and the retaining screws (1).
  3. Lower the vehicle.

Scheme 10

Scheme 10: SPECIFICATIONS - FRAME DIMENSIONS

Scheme 11

Scheme 11

Scheme 12

Scheme 12: REMOVAL
  1. Raise and support the vehicle.
  2. Remove the bolts (2) from the support brace.
  3. Remove the brace (1) from the vehicle.
  1. Install the brace (1) to the vehicle.
  2. Install the bolts (2) to the vehicle. NOTE: Final torque must be made at curb weight.
  3. Lower the vehicle.
  4. Tighten the bolts to 60 N.m (44 ft. lbs.).
