Engine Cooling System: Removal & Installation Chrysler 300M I

Cooling System (Mechanical) 2 illustrations ~611 words

REMOVAL - 3.2L & 3.5L

WARNINGDO NOT REMOVE PRESSURE CAP WITH THE SYSTEM HOT AND UNDER PRESSURE BECAUSE SERIOUS BURNS FROM COOLANT CAN OCCUR.

Scheme 2

Scheme 2
Scheme 2
  1. Disconnect negative cable from remote jumper terminal.
  2. Drain cooling system.
  3. Raise vehicle on hoist.
  4. Disconnect electrical connectors from engine oil and power steering pressure switches.
  5. Disconnect radiator and heater hoses from thermostat housing.
  6. Remove thermostat housing bolts. 1 - THERMOSTAT HOUSING/COOLANT INLET 2 - THERMOSTAT 3 - GASKET
  7. Remove housing, thermostat, and gasket. (Scheme 2)

INSTALLATION - 2.7L

  1. Clean gasket sealing surfaces.
  2. Install thermostat and gasket into the thermostat housing.
  3. Install thermostat and housing to cylinder block. Tighten attaching bolts to 12 N.m (105 in. lbs.).
  4. Connect the heater return and radiator lower hoses to the thermostat housing. Install hose clamps.
  5. Install the heater hose tube bracket bolt.
  6. Install the transaxle dipstick tube bracket attaching bolt.
  7. Install the generator support strut.
  8. Connect the generator electrical connector.
  9. Install the left engine mount.
  10. Lower vehicle.
  11. Inspect and replace dipstick O-ring as necessary. Install the engine oil dipstick and tube.
  12. Refill cooling system.
  13. Connect negative cable to remote jumper terminal.

INSTALLATION - 3.2L & 3.5L

  1. Clean gasket sealing surfaces.
  2. Install thermostat and gasket into thermostat housing. For ease of installation, install bolts in housing for thermostat and gasket retention.
  3. Install thermostat and housing to cylinder block. Tighten bolts to 12 N.m (105 in. lbs.).
  4. Connect heater and radiator hoses and install hose clamps.
  5. Connect electrical connectors to engine oil and power steering pressure switches.
  6. Lower vehicle and connect negative cable to remote jumper terminal.
  7. Refill cooling system .
  8. Connect negative cable to remote jumper terminal.

REMOVAL

Note. It is not necessary to discharge air conditioning system when removing the radiator.

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL
  1. Disconnect negative cable from remote jumper terminal.
  2. Drain cooling system.
  3. Remove radiator upper crossmember.
  4. Remove upper and lower coolant hoses from the radiator.
  5. Disconnect transmission hoses from cooler and plug.
  6. Disconnect engine oil cooler lines (if equipped).
  7. Disconnect the radiator fan electrical connector.
  8. Remove radiator fan. 1 - ELECTRICAL CONNECTOR 2 - FASTENERS 3- CLIPS
  9. Remove the air conditioning condenser attaching screws located at the front of the radiator. see scheme 4or see scheme 5. 1 - TRANS COOLER LINE BRACKET SCREW 2 - SCREW - CONDENSER TO RADIATOR 3- TRANS COOLER 4- SCREWS 1 - TRANSMISSION OIL COOLER LINE MOUNTING BRACKET 2 - A/C CONDENSER TO RADIATOR MOUNTING SCREWS
  10. Remove fastener attaching transmission cooler line bracket to left side of radiator.
  11. Lift condenser upward enough to disengage upper mounting clips. Allow condenser to rest on lower radiator crossmember. It is not necessary to discharge the air conditioning system.
  12. Radiator can now be lifted from engine compartment. Care should be taken not to damage radiator cooling fins or water tubes during removal.

INSTALLATION

  1. Position radiator into engine compartment. Seat the radiator assembly lower rubber isolators into the mounting holes in radiator lower support.
  2. Attach air conditioning condenser to mounting clips on radiator. Install mounting screws and tighten to 5 N.m (45 in. lbs.).
  3. Install the radiator lower hose and clamp.
  4. Install the transmission cooler line bracket and attaching fastener. see scheme 4or see scheme 5. Connect transmission hoses and tighten hose clamps to 3 N.m (28 in. lbs.).
  5. Install the radiator fan.
  6. Connect radiator fan motor electrical connector.
  7. Connect engine oil cooler lines (if equipped). Torque lines to 18 N.m (160 in. lbs.).
  8. Install the radiator upper hose. Align hose so it does not interfere with the accessory drive belt or engine. Position hose clamp so it will not interfere with the hood.
  9. Install the radiator upper support crossmember.
  10. Connect negative cable to remote jumper terminal.
  11. Fill cooling system with coolant.
  12. Operate engine until it reaches normal operating temperature. Check cooling system and automatic transmission for correct fluid levels.
