Engine Cooling System: Overview Chrysler 300M I

Scheme 1

1. Disconnect negative cable from remote jumper terminal.
2. Drain cooling system
3. Remove the engine oil dipstick and tube. To prevent coolant from entering engine, cover the dipstick tube opening in crankcase with a suitable plug.
4. Raise vehicle on hoist.
5. Support the engine and remove the left engine mount.
6. Remove generator support strut.
7. Disconnect generator electrical connector.
8. Remove the transaxle dipstick tube bracket attaching bolt.
9. Remove the lower heater hose tube bracket bolt.
10. Remove the lower heater hose from thermostat housing.
11. Remove radiator lower hose from thermostat housing.
12. Remove thermostat housing bolts. (Scheme 1) 1 - THERMOSTAT AND GASKET 2 - THERMOSTAT HOUSING/COOLANT INLET
13. Remove thermostat and housing.
