Body Control Modules: Component Locations Chrysler 300M I

Body, Cab Control Systems 5 illustrations

COMPONENT LOCATIONS

Note. For component locations (Scheme 3)- (Scheme 7).

ComponentLocation
Ambient Temperature SensorIn Front Of Radiator
Body Control ModuleOn Back Of Junction Block
Combination FlasherBetween Junction Block & Brake Pedal
Controller Anti-Lock BrakeLeft Side Of Engine Compartment
C308 Black ConnectorUnder Right Side Of Rear Seat
Data Link ConnectorUnder Left Side Of Instrument Panel, Above Brake Pedal
Deck Lid Release SwitchLeft Side Of Instrument Panel, Above Parking Brake Release
Door Lock SwitchOn Appropriate Door Panel
Headlight SwitchLeft Side Of Instrument Panel, Above Deck Lid Release Switch
Heated Seat Back HeaterUnder Seat Back Cover
Heated Seat Cushion HeaterUnder Seat Cushion Cover
Heated Seat SwitchOn Outboard Side Of Appropriate Seat
Ignition SwitchIn Right Side Of Steering Column
Instrument Panel Component ConnectorsBehind Instrument Panel
Junction BlockBehind Left End Of Instrument Panel
Memory Heated Seat/Mirror ModuleUnder Driver Seat
Memory Set SwitchOn Outboard Side Of Driver Seat
Multifunction SwitchOn Left Side Of Steering Column
Occupant Restraint ControllerOn Tunnel Floor Pan, Forward Of Center Console
Overhead Travel Information System ModuleFront Center Of Headliner
Power Distribution CenterLeft Side Of Engine Compartment
Power Seat SwitchOn Outboard Side Of Appropriate Seat
Powertrain Control ModuleLeft Side Of Engine Compartment
Rear Window Defogger RelayRight Side Of Trunk
Remote Keyless Entry ModuleBetween BCM & Junction Block, On Back Of Junction Block
Seat Motor SensorsOn Seat Motors, Under Appropriate Seat
Sentry Key Immobilizer ModuleIn Steering Column, By Ignition Switch
Speed Proportional Steering Solenoid ConnectorUnder Brake Master Cylinder
Sun Sensor/Vehicle Theft Security System IndicatorTop Center Of Instrument Panel
Transmission Control ModuleLeft Side Of Engine Compartment
Traction Control SwitchIn Right Upper Trim Bezel, To Right Of Steering Column
Turn Signal/Hazard SwitchOn Top Of Steering Column
Washer Fluid Level SwitchIn Washer Fluid Reservoir, Left Front Corner Of Engine Compartment
Washer Pump MotorIn Bottom Of Washer Reservoir, Left Front Corner Of Engine Compartment
Washer ReservoirLeft Front Corner Of Engine Compartment
Wiper/Washer SwitchPart Of Multifunction Switch, On Left Side Of Steering Column

COMPONENT LOCATIONS

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7
