Lighting System: Specifications Chevrolet Volt I

Exterior Lights 8 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Back Up Lamp to Rear Bumper Fascia Bolt/Screw2.5 N.m22 lb in
Back Up Lamp to Rear Energy Absorber Bolt/Screw2.5 N.m22 lb in
Brake Pedal Position Sensor Bolt9 N.m80 lb in
Front Turn Signal Lamp Screw2.5 N.m22 lb in
Headlamp Bolt/Screw2.5 N.m22 lb in
High Mount Stop Lamp Screw2.5 N.m22 lb in
Rear Reflector Bolt9 N.m80 lb in
Tail Lamp Bolt/Screw2.5 N.m22 lb in
Tail Lamp Nut4.7 N.m42 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Daytime Running Lamps and Low Beams Wiring Schematics
Scheme 1: Daytime Running Lamps and Low Beams Wiring Schematics

Scheme 2

Scheme 2: High Beams Wiring Schematics
Scheme 2: High Beams Wiring Schematics

Scheme 3

Scheme 3: Park, Tail, and License Lamps Wiring Schematics
Scheme 3: Park, Tail, and License Lamps Wiring Schematics

Scheme 4

Scheme 4: Front Turn Signals and Controls Wiring Schematics
Scheme 4: Front Turn Signals and Controls Wiring Schematics

Scheme 5

Scheme 5: Rear Turn Signals, Stop Lamps, and Backup Lamp Wiring Schematics
Scheme 5: Rear Turn Signals, Stop Lamps, and Backup Lamp Wiring Schematics

Scheme 6

Scheme 6: Interior Lights Wiring Schematics
Scheme 6: Interior Lights Wiring Schematics

Scheme 7

Scheme 7: Display Dimming Wiring Schematics
Scheme 7: Display Dimming Wiring Schematics

Scheme 8

Scheme 8: Controls Dimming Wiring Schematics
Scheme 8: Controls Dimming Wiring Schematics
