Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Drive Link Screws | 5 N.m | 44 lb in |
| Rear Wiper Arm Nut | 25 N.m | 19 lb ft |
| Rear Wiper Motor Driveshaft Nut | 6 N.m | 53 lb in |
| Rear Wiper Motor Screws | 6 N.m | 53 lb in |
| Washer Solvent Container Screws | 6 N.m | 53 lb in |
| Wiper Arm Nut | 48 N.m | 35 lb ft |
| Wiper Drive System Module Screws | 10 N.m | 89 lb in |
| Wiper Motor Cover Screws | 2 N.m | 18 lb in |
| Wiper Motor Crank Arm Screw | 16 N.m | 12 lb ft |
| Wiper Motor Screws | 7 N.m | 62 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Wiper/Washer System Schematics
Scheme 2
Scheme 3
Scheme 3: Wiper/Washer System Component Views
| Callout | Component Name |
|---|
| 1 | Battery |
| 2 | C108 I/P Harness to Battery Cable Harness |
| 3 | Rear Window Washer Fluid Pump Relay |
| 4 | I/P Harness |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Fuse Block - Underhood |
| 2 | Windshield Wiper Motor |
| 3 | Brake Fluid Level Switch |
| 4 | Windshield Washer Fluid Pump |
| 5 | Rear Window Washer Fluid Pump |
Scheme 5
| Callout | Component Name |
|---|
| 1 | Rear Window Wiper Motor |
| 2 | Speakers - LR/RR |
| 3 | Door Jamb Switch - Liftgate |
| 4 | Door Lock Actuator - Liftgate |
| 5 | Liftgate Latch Assembly |
Scheme 6
Scheme 6: Rear Window Washer Fluid Pump
| Connector Part Information OEM: 12020599 Service: 12102664 Description: 2-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal: 12077411/Tray 2 Core/Insulation Crimp: 2/5 Release Tool/Test Probe: 12094430/J-35616-4A |
Wiper/Washer System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 1650 | Ground |
| B | D-GN | 392 | Rear Window Washer Pump Control |
Rear Window Washer Fluid Pump
Scheme 7
Scheme 7: Rear Window Washer Fluid Pump Relay
| Connector Part Information OEM: 12129716 Service: See Catalog Description: 4-Way F Metri-Pack 280 Series Flexlock (GY) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
Wiper/Washer System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 30 | YE | 643 | Accessory Voltage |
| 85 | L-GN | 2270 | Rear Window Washer Relay Control |
| 86 | YE | 643 | Accessory Voltage |
| 87 | D-GN | 392 | Rear Window Washer Pump Control |
Rear Window Washer Fluid Pump Relay
Scheme 8
Scheme 8: Rear Window Wiper Motor
| Connector Part Information OEM: 15326886 Service: 88988300 Description: 4-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal: 15304711/Tray 8 Core/Insulation Crimp: Pins A, B, D: 2/A Core/Insulation Crimp: Pin C: E/A Release Tool/Test Probe: 15315247/J-35616-4A |
Wiper/Washer System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | YE | 843 | Accessory Voltage |
| B | D-GN | 392 | Rear Window Washer Pump Control |
| C | GY | 391 | Rear Window Wiper Switch Signal |
| D | BK | 450 | Ground |
Scheme 9
Scheme 9: Windshield Washer Fluid Pump
| Connector Part Information OEM: 12052641 Service: 12102747 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal: 12048074/Tray 2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A |
Wiper/Washer System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | OG | 228 | Windshield Washer Pump Control |
| B | BK | 1650 | Ground |
Windshield Washer Fluid Pump
Scheme 10
Scheme 10: Windshield Wiper Motor
| Connector Part Information OEM: 10811710 Service: 88987987 Description: 4-Way F Timer JR-Power Sealed (BK) |
|---|
| Terminal Part Information Terminal: 4-964286-1/Tray 16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12093647/J-35616-4A |
Wiper/Washer System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | PU | 92 | Windshield Wiper Motor High Speed Control |
| 2 | D-GN | 95 | Windshield Wiper Motor Low Speed Control |
| 3 | YE | 196 | Windshield Wiper Motor Park Switch Signal |
| 4 | BK | 1650 | Ground |
