Seat System: Specifications Chevrolet Uplander I

Seats 15 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Cup Holder Screws9 N.m80 lb in
Finish Cover Screws2 N.m18 lb in
Front Seat Anchor Nuts40 N.m30 lb ft
Front Seat Recliner Bolts48 N.m35 lb ft
Lateral Release Bezel Screw2 N.m18 lb in
Lumbar Actuator Screws2 N.m18 lb in
Recliner Bolts32 N.m24 lb ft
Recliner Cover Screws2 N.m18 lb in
Riser Bolts (Bucket)45 N.m33 lb ft
Riser Bolts (Split Benches)32 N.m24 lb ft
Seat Adjuster Bolts32 N.m24 lb ft
Sit-N-Lift Seat - Chain Cover Screws2 N.m18 lb in
Sit-N-Lift Seat - Foot Rest Bolt33 N.m25 lb ft
Sit-N-Lift Seat - Foot Rest Cover Screws2 N.m18 lb in
Sit-N-Lift Seat - Lock Bolts20 N.m15 lb ft
Sit-N-Lift Seat - Seat Belt Anchor Bolt43 N.m32 lb ft
Sit-N-Lift Seat Module2 N.m18 lb in
Sit-N-Lift Upper and Lower Stay Bracket Bolt50 N.m35 lb ft
Sit-N-Lift Upper Limit Switch Bracket5.8 N.m50 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Driver Seat Schematics
Scheme 1: Driver Seat Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Passenger Seat Schematics
Scheme 5: Passenger Seat Schematics

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8: Rear Seat Schematics
Scheme 8: Rear Seat Schematics

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: Power Seat Systems Component Views
Scheme 11: Power Seat Systems Component Views
CalloutComponent Name
1Seat Belt Switch - Left
2Seat Back Cover
3Heated Seat Element - Driver Back (KA1)
4Inflatable Restraint Side Impact Module - Left (AJ7)
5Memory Seat Module - Driver (AG0)
6Seat Adjuster Motor Assembly - Driver (AG0 or AG1)
7Seat Adjuster Switch - Driver (AG0 or AG1) (Typical)
8Heated Seat Element - Driver Cushion (KA1)
9Seat Cushion Cover

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Inflatable Restraint Side Impact Module - Right (AJ7)
2Seat Back Cover
3Heated Seat Element - Passenger Back (KA1)
4Seat Belt Switch - Right
5Seat Cushion Cover
6Heated Seat Element - Passenger Cushion (KA1)
7Seat Adjuster Switch - Passenger (AG2 or AH8)
8Seat Adjuster Motor Assembly - Passenger (AG2 or AH8)

Scheme 13

Scheme 13
Scheme 13
CalloutComponent Name
1Outside Rearview Mirror Switch - Left Connector
2Window Switch - Driver Connector
3Door Lock Switch - Driver Connector
4Outside Rearview Mirror - Driver
5C301 Driver Door Harness to Body Harness
6Window Motor - Driver
7Speaker - LF
8S555
9Memory Seat Switch - Driver (AG0) Connector
10S551
11Driver Door Key Switch Connector
12Door Latch Assembly - Driver
13Driver Door Key Switch (AU6)

Scheme 14

Scheme 14: Heated Seat Element - Driver Back (KA1)
Scheme 14: Heated Seat Element - Driver Back (KA1)
Connector Part Information OEM: 12059253 Service: 12125690 Description: 2-Way F Metri-Pack 150 Series (L-GN)
Terminal Part Information Terminal: 12047767/Tray 2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A

Power Seat Systems Connector End Views

PinWire ColorCircuit No.Function
APK2077Driver Heated Seat Element Supply Voltage (AG0)
AWH2077Driver Heated Seat Element Supply Voltage (AG1)
BBK650Ground

Heated Seat Element - Driver Back (KA1)

Scheme 15

Scheme 15: Heated Seat Element - Driver Cushion (KA1)
Scheme 15: Heated Seat Element - Driver Cushion (KA1)
Connector Part Information OEM: 12047785 Service: 12102900 Description: 4-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Pins: A, B Terminal: 12047767/Tray 2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A Pins: C, D Terminal: 12064971/Tray 5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A

Power Seat Systems Connector End Views

PinWire ColorCircuit No.Function
APK2077Driver Heated Seat Element Supply Voltage (AG0)
AWH2077Driver Heated Seat Element Supply Voltage (AG1)
BPK2077Driver Heated Seat Element Supply Voltage
CYE2080Low Reference
DYE/BK2079Driver Heated Seat Cushion Temperature Sensor Signal

Heated Seat Element - Driver Cushion (KA1)
