Object Sensor - LR Middle
| Connector Part Information OEM: 15324398 Service: 15306313 Description: 3-Way F MQS Sealed (BK) |
|---|
| Terminal Part Information Terminal: 962885-5/Tray 15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64A |
Object Detection Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | OG | 2376 | LR Middle Object Sensor Signal |
| 2 | GY | 2379 | Object Sensor Low Reference |
| 3 | D-BU | 2374 | Object Sensor Supply Voltage |
Object Sensor - LR Middle
Object Sensor - RR Corner
| Connector Part Information OEM: 15324398 Service: 15306313 Description: 3-Way F MQS Sealed (BK) |
|---|
| Terminal Part Information Terminal: 962885-5/Tray 15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64A |
Object Detection Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | PU | 2378 | RR Corner Object Sensor Signal |
| 2 | GY | 2379 | Object Sensor Low Reference |
| 3 | D-BU | 2374 | Object Sensor Supply Voltage |
Object Sensor - RR Corner
Object Sensor - RR Middle
| Connector Part Information OEM: 15324398 Service: 15306313 Description: 3-Way F MQS Sealed (BK) |
|---|
| Terminal Part Information Terminal: 962885-5/Tray 15 Core/Insulation Crimp: 6/6 Release Tool/Test Probe: 12094429/J-35616-64A |
Object Detection Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | D-GN | 2377 | RR Middle Object Sensor Signal |
| 2 | GY | 2379 | Object Sensor Low Reference |
| 3 | D-BU | 2374 | Object Sensor Supply Voltage |
Object Sensor - RR Middle
Scheme 7
Scheme 7: Rear Object Sensor Control Module
| Connector Part Information OEM: 12124957 Service: 88987946 Description: 26-Way F Amp MODULAR (BK) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
Object Detection Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | YE | 2375 | LR Corner Object Sensor Signal |
| 2 | OG | 2376 | LR Middle Object Sensor Signal |
| 3 | D-GN | 2377 | Right Rear Middle Object Sensor Signal |
| 4 | PU | 2378 | RR Corner Object Sensor Signal |
| 5 | D-BU | 2374 | Object Sensor Supply Voltage |
| 6 | GY | 2379 | Object Sensor Low Reference |
| 7-11 | | | Not Used |
| 12 | BK | 350 | Ground (Early Production) |
| BK | 850 | Ground (Late Production) |
| 13 | PK | 739 | Ignition 1 Voltage |
| 14 | GY | 2616 | Rear Parking Assist Disable Switch Signal |
| 15 | L-GN | 24 | Backup Lamp Supply Voltage |
| 16 | L-GN | 2525 | Rear Parking Assist Diagnostic Input |
| 17 | | | Not Used |
| 18 | D-GN | 389 | Vehicle Speed Signal |
| 19-21 | | | Not Used |
| 22 | L-BU | 2380 | Rear Parking Assist Chime Signal |
| 23 | WH | 2370 | Telltale Assembly Supply Voltage |
| 24 | GY | 2373 | Red Indicator Control |
| 25 | D-BU | 2372 | Center Amber Indicator Control |
| 26 | OG | 2371 | Left Amber Indicator Control |
Rear Object Sensor Control Module
Scheme 8
Scheme 8: Rear Parking Assist (RPA) Diagnostic Connector
| Connector Part Information OEM: 12047682 Service: 12101850 Description: 1-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal: 12064971/Tray 5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A |
Object Detection Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | L-GN | 2525 | Rear Parking Assist Diagnostic Input |
Rear Parking Assist (RPA) Diagnostic Connector
Scheme 9
Scheme 9: Rear Parking Assist (RPA) Display
| Connector Part Information OEM: 12045813 Service: See Catalog Description: 4-Way F Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Terminal: 12047767/Tray 2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A |
Object Detection Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | WH | 2370 | Telltale Assembly Supply Voltage |
| B | OG | 2371 | Left Amber Indicator Control |
| C | D-BU | 2372 | Center Amber Indicator Control |
| D | GY | 2373 | Red Indicator Control |
Rear Parking Assist (RPA) Display
Vehicle Moving
| IMPORTANT | The sequences will not clear if the rear parking assist diagnostic connector is grounded. |
- Drive the vehicle forward at least 24 km/h (15 mph).
- Stop the vehicle.
- Turn the ignition OFF.
Vehicle Stopped
| IMPORTANT | The sequences will not clear if the rear parking assist diagnostic connector is grounded. |
- Turn the ignition ON.
- Place foot on the brake.
- Shift the vehicle into REVERSE within 5 seconds.
- Turn the ignition OFF.
Symptoms - Ultrasonic Rear Parking Assist
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Object Detection Description and Operation . |
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.
