SIR Schematic Icons
SIR Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Zone Identification Views . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury or unnecessary SIR system repairs. IMPORTANT: Twisted-pair wires provide an effective shield that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires. The following specification applies to all twisted wires except within the body harness: The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.25 in). The following specification applies to all twisted wires within the body harness: The wires must be twisted a minimum of 12 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.25 in)
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
| Callout | Component Name |
|---|---|
| 1 | Hood Ajar Switch (AP3) |
| 2 | Inflatable Restraint Front End Sensor - Left |
| 3 | Horn - Left |
| 4 | Cooling Fan - Left |
| 5 | Cooling Fan - Right |
| 6 | Ambient Air Temperature Sensor (UH8 or UH9) |
| 7 | Horn - Right |
| 8 | Inflatable Restraint Front End Sensor - Right |
| 9 | Hood Ajar Switch Connector (AP3) |
Scheme 9
| Callout | Component Name |
|---|---|
| 1 | Steering Wheel Control Switch Assembly - Right (UK3) |
| 2 | Instrument Panel Cluster (IPC) |
| 3 | Multifunction Switch - I/P |
| 4 | Theft Light Emitted Diode (LED) (UA6) |
| 5 | Ambient Light Sensor |
| 6 | Hazard Switch |
| 7 | Inflatable Restraint PASSENGER AIR BAG ON/OFF Indicator |
| 8 | Inflatable Restraint I/P Module |
| 9 | Radio |
| 10 | HVAC Control Module |
| 11 | Cigar Lighter |
| 12 | Cruise Control Lever (K34) |
| 13 | Inflatable Restraint Steering Wheel Module |
| 14 | Steering Wheel Control Switch Assembly - Left (Uk3) |
| 15 | Headlamp Switch |
| 16 | Turn Signal/Multifunction Switch |
Scheme 10
| Callout | Component Name |
|---|---|
| 1 | Turn Signal/Multifunction Switch C3 |
| 2 | C279 Inflatable Restraint Steering Wheel Module Coil to Steering Wheel Harness |
| 3 | Inflatable Restraint Steering Wheel Module Coil C1 Connector |
| 4 | Inflatable Restraint Steering Wheel Module Coil C2 Connector |
| 5 | Turn Signal/Multifunction Switch C2 |
| 6 | Turn Signal/Multifunction Switch C1 |
| 7 | Rear Wiper/Washer Switch |
| 8 | Turn Signal/Multifunction Switch |
| 9 | Turn Signal/Multifunction Switch C4 |
| 10 | S277 and S279 |
| 11 | C277 Inflatable Restraint Steering Wheel Module Coil to Steering Column Harness |
| 12 | C275 Inflatable Restraint Steering Wheel Module Coil to Body Harness |
| 13 | C201 Steering Column Harness to I/P Harness |
| 14 | Steering Wheel Speed Position Sensor (JL4) |
| 15 | Theft Deterrent Exciter Module Connector (Pigtail) |
| 16 | Inflatable Restraint Steering Wheel Module Coil |
| 17 | Theft Deterrent Exciter Module |
| 18 | Ignition Switch |
| 19 | A/T Shift Lock Control Solenoid Connector |
Scheme 11
| Callout | Component Name |
|---|---|
| 1 | Seat Belt Switch - Left |
| 2 | Seat Back Cover |
| 3 | Heated Seat Element - Driver Back (KA1) |
| 4 | Inflatable Restraint Side Impact Module - Left (AJ7) |
| 5 | Memory Seat Module - Driver (AG0) |
| 6 | Seat Adjuster Motor Assembly - Driver (AG0 or AG1) |
| 7 | Seat Adjuster Switch - Driver (AG0 or AG1) (Typical) |
| 8 | Heated Seat Element - Driver Cushion (KA1) |
| 9 | Seat Cushion Cover |
Scheme 12
| Callout | Component Name |
|---|---|
| 1 | Inflatable Restraint Side Impact Module - Right (AJ7) |
| 2 | Seat Back Cover |
| 3 | Heated Seat Element - Passenger Back (KA1) |
| 4 | Seat Belt Switch - Right |
| 5 | Seat Cushion Cover |
| 6 | Heated Seat Element - Passenger Cushion (KA1) |
| 7 | Seat Adjuster Switch - Passenger (AG2 or AH8) |
| 8 | Seat Adjuster Motor Assembly - Passenger (AG2 or AH8) |
Scheme 13
| Callout | Component Name |
|---|---|
| 1 | Inflatable Restraint Front Passenger Presence System (PPS) Sensor |
| 2 | Inflatable Restraint Front Passenger Presence System (PPS) Module |
Scheme 14
| Callout | Component Name |
|---|---|
| 1 | G301 |
| 2 | Sliding Door Open/Close Switch - Left (E59) Connector |
| 3 | Inflatable Restraint Side Impact Module - Left (AJ7) |
| 4 | Inflatable Restraint Side Impact Sensing Module (SISM) - Left (AJ7) |
| 5 | Body Harness |
| 6 | C315 Left Side Impact Module Jumper Harness (AJ7) to Body Harness (AJ7) |
| 7 | C305 Fuel Tank Harness and Rear Cross-Car Jumper Harness to Body Harness |
| 8 | Seatbelt Pretensioner - LF |
| 9 | Door Contact Plate - Left C1 |
Scheme 15
| Callout | Component Name |
|---|---|
| 1 | Inflatable Restraint Side Impact Sensing Module (SISM) - Right (AJ7) |
| 2 | G302 |
| 3 | Door Contact Plate - Right C1 |
| 4 | Seatbelt Pretensioner - RF |
| 5 | Inflatable Restraint Sensing and Diagnostic Module (SDM) |
| 6 | Body Harness |
| 7 | C316 Inflatable Restraint Side Impact Module - Right Jumper Harness (AJ7) to the Body Harness (AJ7) |
| 8 | Inflatable Restraint Passenger Seat Belt Tension Retractor Sensor |
| 9 | Inflatable Restraint Side Impact Module - Right (AJ7) |
SIR Zone Identification Views
The SIR Zone Identification Views shown below illustrate the approximate location of all SIR components available for the vehicle. This will assist in determining the appropriate SIR disabling and enabling zones for a given service procedure. Refer to SIR Disabling and Enabling Zones .
Scheme 16
| Callout | Component Name |
|---|---|
| 1 | Right Front End Sensor-Located on the front of the vehicle in the engine compartment |
| 2 | Vehicle Battery-Located under the hood on the right side |
| 3 | Front Hood Assist Rod-A gas shock located under the front hood on the passenger side |
| 4 | I/P Air Bag-Located at the top right under the instrument panel |
| 5 | Sensing and Diagnostic Module (SDM)-Located underneath the passenger front seat |
| 6 | Passenger Presence System (PPS)-Located on the passenger front seat underneath the seat bottom trim |
| 7 | RF Side Impact Air Bag-Located on the seat back of the passenger front seat |
| 8 | Right Seat Belt Retractor Pretensioner and Right Side Impact Sensor (SIS)-The right SIS is located above the right seat belt retractor pretensioner under the center pillar trim near the bottom on passenger side of vehicle |
| 9 | RR Side Impact Air Bag-Located on the seat back of the right rear bucket seat |
| 10 | Rear Compartment Lid Assist Rod-A gas shock is located under the rear trunk lid on the passenger side |
| 11 | Rear Compartment Lid Assist Rod-A gas shock is located under the rear trunk lid on the driver side |
| 12 | LR Side Impact Air Bag-Located on the seat back of the left rear bucket seat |
| 13 | Left Seat Belt Retractor Pretensioner and Left Side Impact Sensor (SIS)-The left SIS is located above the left seat belt retractor pretensioner under the center pillar trim near the bottom on driver side of vehicle |
| 14 | LF Side Impact Air Bag-Located on the seat back of the driver front seat |
| 15 | Steering Wheel Air Bag-Located on the steering wheel |
| 16 | Front Hood Assist Rod-A gas shock located under the front hood on the driver side |
| 17 | Left Front End Sensor-Located on the front of the vehicle in the engine compartment |
Scheme 17
| Connector Part Information OEM: 15356725 (Early Production) OEM: 15356722 (Late Production) Service: 88986455 Description: 2-Way F GT 150 Series Sealed (YE) |
|---|
| Terminal Part Information Terminal: 12191819/Tray 8 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | TN/OG | 5045 | Low Reference |
| B | YE | 354 | Discriminating Sensor - Left - Signal |
Inflatable Restraint Front End Sensor - Left
Scheme 18
| Connector Part Information OEM: 15356726 (Early Production) OEM: 15356724 (Late Production) Service: 15306362 Description: 2-Way F GT 150 Series Sealed (YE) |
|---|
| Terminal Part Information Terminal: 12191819/Tray 8 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | GY | 5600 | Low Reference |
| B | D-GN | 1409 | Discriminating Sensor - Right - Signal |
Inflatable Restraint Front End Sensor - Right
Scheme 19
| Connector Part Information OEM: 15431682 Service: Not Serviced Description: 18-Way F Micro-Pack 100W Series Sealed (BK) |
|---|
| Terminal Part Information Terminal: 15435885/Tray 20 Core/Insulation Crimp: W/W Release Tool/Test Probe: 12122523/J-35616-6 |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | D-BU | 2307 | Passenger Air Bag On Indicator Control |
| 2 | D-GN | 2308 | Passenger Air Bag Off Indicator Control |
| 3 | Not Used | ||
| 4 | GY | 2488 | Passenger Seat Belt Tension Sensor Signal |
| 5 | BK/WH | 1751 | Ground |
| 6 | YE | 1362 | Passenger Presence Sensor Signal |
| 7 | D-GN | 608 | 14-Volt Reference |
| 8 | Not Used | ||
| 9 | PK | 1139 | Ignition 1 Voltage |
| 10-13 | Not Used | ||
| 14 | L-BU | 1361 | Low Reference |
| 15 | GY | 1361 | Low Reference |
| 16 | PK | 608 | 14-Volt Reference |
| 17 | Not Used | ||
| 18 | PK | 5018 | Occupant Sensor Serial Data |
Inflatable Restraint Front Passenger Presence System (PPS) Module
Scheme 20
| Connector Part Information OEM: 15439374 Service: See Catalog Description: 3-Way F 1.5 Series Sealed (GY) |
|---|
| Terminal Part Information Terminal: 7116-4102-08/Tray 9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | D-GN | 608 | 14-Volt Reference |
| 2 | YE | 1362 | Passenger Presence Sensor Signal |
| 3 | GY | 1361 | Low Reference |
Inflatable Restraint Front Passenger Presence System (PPS) Sensor
Scheme 21
| Connector Part Information OEM: 54550267 Service: See Catalog Description: 2-Way F ABX-3 Code B (WH) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | YE | 3025 | I/P Module Stage 1 - High Control |
| B | OG | 3024 | I/P Module Stage 1 - Low Control |
Inflatable Restraint I/P Module C1
Scheme 22
| Connector Part Information OEM: 54550271 Service: See Catalog Description: 2-Way F ABX-3 Code G (WH) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | GY | 3027 | I/P Module Stage 2 - High Control |
| B | PU | 3026 | I/P Module Stage 2 - Low Control |
Inflatable Restraint I/P Module C2
Scheme 23
| Connector Part Information OEM: 15398877 Service: See Catalog Description: 5-Way F HCM Series (WH) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | D-BU | 2307 | Passenger Air Bag On Indicator Control |
| 2 | BK | 1551 | Ground |
| 3 | D-GN | 2308 | Passenger Air Bag Off Indicator Control |
| 4 | PK | 1139 | Ignition 1 Voltage |
| 5 | PU | 5234 | Passenger Seat Belt Indicator |
Inflatable Restraint PASSENGER AIR BAG ON/OFF Indicator
Scheme 24
| Connector Part Information OEM: 12110293 Service: 12117025 Description: 3-Way F Metri-Pack 150 Series Sealed (BK) |
|---|
| Terminal Part Information Terminal: 12048074/Tray 2 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 12094429/J-35616-2A |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | PK | 608 | 14-Volt Reference |
| B | L-BU | 1361 | Low Reference |
| C | GY | 2488 | Passenger Seat Belt Tension Sensor Signal |
Inflatable Restraint Passenger Seat Belt Tension Retractor Sensor
Scheme 25
| Connector Part Information OEM: 15357038 Service: See Catalog Description: 34-Way F Micro-Pack 100 W 2.5 CL Series (YE) |
|---|
| Terminal Part Information Terminal: 15435885/Tray 20 Core/Insulation Crimp: W/W Release Tool/Test Probe: 12122523/J-35616-6 |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A1 | TN | 3021 | Steering Wheel Module Stage 1 - High Control |
| A2 | BN | 3020 | Steering Wheel Module Stage 1 - Low Control |
| A3 | OG | 3024 | I/P Module Stage 1 - Low Control |
| A4 | YE | 3025 | I/P Module Stage 1 - High Control |
| A5 | TN/WH | 2118 | Seat Belt Pretensioner - Left - High Control |
| A6 | OG/BK | 2119 | Seat Belt Pretensioner - Left - Low Control |
| A7 | OG | 2117 | Seat Belt Pretensioner - Right - Low Control |
| A8 | L-GN | 2116 | Seat Belt Pretensioner - Right - High Control |
| A9 | BK/WH | 1751 | Ground |
| A10 | PK | 1139 | Ignition 1 Voltage |
| A11 | D-BU | 1128 | Class 2 Serial Data |
| A12 | Not Used | ||
| A13 | PK | 5018 | Occupant Sensor Serial Data |
| A14 | D-GN | 5016 | Seat Belt Switch - Left - Signal |
| A15 | L-GN | 5055 | Driver Seat Position Switch Signal (Early Production) |
| Not Used (Late Production) | |||
| A16 | OG | 1362 | Seat Belt Switch - Right - Signal |
| A17 | L-BU | 5056 | Passenger Seat Position Switch Signal (Early Production) |
| Not Used (Late Production) | |||
| A18 | PK | 5057 | Seat Position Switch Low Reference (Early Production) |
| Not Used (Late Production) | |||
| B1 | WH | 3023 | Steering Wheel Module Stage 2 - High Control |
| B2 | PK | 3022 | Steering Wheel Module Stage 2 - Low Control |
| B3 | PU | 3026 | I/P Module Stage 2 - Low Control |
| B4 | GY | 3027 | I/P Module Stage 2 - High Control |
| B5 | YE | 354 | Discriminating Sensor - Left - Signal |
| B6 | TN/OG | 5045 | Low Reference |
| B7 | GY | 5600 | Low Reference |
| B8 | D-GN | 1409 | Discriminating Sensor - Right - Signal |
| C1 | BN | 2137 | Side Impact Module - LF - High Control (AJ7) |
| C2 | YE/BK | 2138 | Side Impact Module - LF - Low Control (AJ7) |
| C3 | L-GN | 2136 | Side Impact Module - RF - Low Control (AJ7) |
| C4 | TN/WH | 2135 | Side Impact Module - RF - High Control (AJ7) |
| C5 | YE | 2131 | Side Impact Sensing Module - Left - Voltage (AJ7) |
| C6 | WH | 2132 | Side Impact Sensing Module - Left - Signal (AJ7) |
| C7 | D-GN | 2134 | Side Impact Sensing Module - Right - Signal (AJ7) |
| C8 | TN | 2133 | Side Impact Sensing Module - Right - Voltage (AJ7) |
Inflatable Restraint Sensing and Diagnostic Module (SDM)
Scheme 26
| Connector Part Information OEM: CA-252-92-5 Q Service: See Catalog Description: 2-Way F (YE) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
SIR Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | D-GN/WH | Side Impact Module - LF - Low Control | |
| 2 | D-GN/WH | Side Impact Module - LF - High Control |
Inflatable Restraint Side Impact Module - Left (AJ7)
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 5: This step tests for a short to ground, a high resistance or an open in the seat belt tension retractor sensor signal circuit.
- 6: This step tests for a short to ground, a high resistance or an open in the seat belt tension retractor sensor 5-volt reference circuit.
- 7: This step tests for a short to ground, a high resistance or an open in the seat belt tension retractor sensor low reference circuit.
- 8: This step tests for a short to voltage in the seat belt tension retractor sensor signal circuit.
- 9: This step tests the seat belt tension retractor sensor signal circuit input voltage range.
- 10: This step tests for a short to voltage in the seat belt tension retractor sensor 5-volt reference circuit.
- 11: This step tests for a short to voltage in the seat belt tension retractor sensor low reference circuit.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | ||||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information | |
| 2 | Turn OFF the ignition. Disconnect the seat belt tension retractor sensor connector. Inspect the seat belt tension retractor sensor terminals and harness connector for damage or corrosion. Does the seat belt tension retractor sensor terminals or harness connector exhibit any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 | |
| 3 | If the seat belt tension retractor sensor terminals are damaged, replace the seat belt tension retractor sensor. Refer to Seat Belt Retractor Replacement - Right Front in Seat Belts. If the seat belt tension retractor sensor harness connector is damaged, replace the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the replacement? | Go to Step 15 | ||
| 4 | Disconnect the passenger presence system (PPS) module connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the PPS module connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 5 | |
| 5 | Test the seat belt tension retractor sensor signal circuit for high resistance, an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 6 | |
| 6 | Test the seat belt tension retractor sensor 5-volt reference circuit for high resistance, an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 7 | |
| 7 | Test the seat belt tension retractor sensor low reference circuit for high resistance, an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 8 | |
| 8 | Turn ON the ignition, with the engine OFF. Test the seat belt tension retractor sensor signal circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 9 | |
| 9 | Test the seat belt tension retractor sensor signal circuit input voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Does the voltage measure within the specified range ? | 0.05-4.5 V | Go to Step 10 | Go to Step 12 |
| 10 | Test the seat belt tension retractor sensor 5-volt reference circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 11 | |
| 11 | Test the seat belt tension retractor sensor low reference circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 15 | Go to Step 12 | |
| 12 | IMPORTANT: The seat belt tension retractor sensor is not serviced separately. Replace the seat belt tension retractor sensor. Refer to Seat Belt Retractor Replacement - Right Front in Seat Belts.Did you complete the replacement? | Go to Step 13 | ||
| 13 | Reconnect all supplemental inflatable restraint (SIR) and PPS system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 14 | System OK | |
| 14 | Replace the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 15 | ||
| 15 | Reconnect all SIR and PPS system components. Verify that all components, connectors and CPAs are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Rezero the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK | |
| IMPORTANT |
|---|
| The seat belt tension retractor sensor is not serviced separately. |
DTC 023
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step inspects the PPS module connector.
- 3: This step inspects the main seat harness connector.
- 4: This step tests the PPS ground circuit for an open or high resistance.
- 5: This step tests the PPS ignition 1 voltage circuit for a short to ground, an open or high resistance.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views and Power Seat Systems Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the passenger presence system (PPS) module connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the PPS module connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 3 |
| 3 | Disconnect the main seat harness connector located under the RF seat. Inspect both halves of the connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 4 |
| 4 | Test the PPS ground circuit for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 5 |
| 5 | Test the PPS ignition 1 voltage circuit for a short to ground, an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 6 |
| 6 | Replace the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 7 | |
| 7 | Reconnect all supplemental inflatable restraint (SIR) and PPS system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Rezero the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC 024
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step tests for current PPS DTCs.
- 8: This step tests for a short to ground, a high resistance or an open in the PPS class 2 serial data circuit.
- 9: This step tests for a short to voltage in the PPS class 2 serial data circuit.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views and Power Seat Systems Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, request the passenger presence system (PPS) to flash DTCs. Refer to Passenger Presence System Flash Code Procedures . Does the PPS indicate that DTC 064 is current? | Go to Step 3 | Go to Step 13 |
| 3 | With the scan tool request the supplemental inflatable restraint (SIR) DTCs. Does the scan tool indicate that DTC B0098 is current? | Go to DTC B0098 | Go to Step 4 |
| 4 | Turn OFF the ignition. Disconnect the PPS module connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the PPS module terminals and harness connector for damage or corrosion. Does the PPS module terminals or harness connector exhibit any signs of damage or corrosion? | Go to Step 5 | Go to Step 6 |
| 5 | If the PPS module terminals are damaged, replace the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. If the PPS harness connector is damaged, replace the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the replacement? | Go to Step 13 | |
| 6 | Disconnect the main seat harness connector located under the RF seat. Inspect both halves of the connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 7 |
| 7 | Disconnect the sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 8 |
| 8 | Test the PPS class 2 serial data circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 9 | Turn ON the ignition, with the engine OFF. Test the PPS class 2 serial data circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 10 |
| 10 | Replace the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 11 | |
| 11 | Reconnect all SIR and PPS system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Rezero the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 12 | System OK |
| 12 | Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 13 | |
| 13 | Reconnect all SIR and PPS system components. Verify that all components, connectors and CPAs are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Rezero the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC 064
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step inspects the PPS pressure sensor connector.
- 5: This step tests for a short to ground, a high resistance or an open in the PPS sensor signal circuit.
- 6: This step tests for a short to ground, a high resistance or an open in the PPS sensor 5-volt reference circuit.
- 7: This step tests for a short to ground, a high resistance or an open in the PPS sensor low reference circuit.
- 8: This step tests for a short to voltage in the PPS sensor signal circuit.
- 9: This step tests the PPS sensor signal circuit input voltage range.
- 10: This step tests for a short to voltage in the PPS sensor 5-volt reference circuit.
- 11: This step tests for a short to voltage in the PPS sensor low reference circuit.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | ||||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information | |
| 2 | Turn OFF the ignition. Disconnect the passenger presence system (PPS) pressure sensor connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the pressure sensor terminals and harness connector for damage or corrosion. Does the PPS pressure sensor terminals or harness connector exhibit any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 | |
| 3 | If the PPS pressure sensor terminals are damaged, replace the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. If the PPS pressure sensor harness connector is damaged, replace the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the replacement? | Go to Step 13 | ||
| 4 | Disconnect the PPS module connector. Inspect the PPS module connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 5 | |
| 5 | Test the PPS sensor signal circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 6 | |
| 6 | Test the PPS sensor 5-volt reference circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 7 | |
| 7 | Test the PPS sensor low reference circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 8 | |
| 8 | Turn ON the ignition, with the engine OFF. Test the PPS sensor signal circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 9 | |
| 9 | Test the PPS sensor signal circuit input voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Does the voltage measure within the specified range? | 0.05-4.5 V | Go to Step 10 | Go to Step 12 |
| 10 | Test the PPS sensor 5-volt reference circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 11 | |
| 11 | Test the PPS sensor low reference circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 12 | |
| 12 | Replace the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 13 | ||
| 13 | Reconnect all supplemental inflatable restraint (SIR) and PPS system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Rezero the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK | |
DTC 065
The numbers below refer to the step numbers on the diagnostic table.
- 4: This step tests to see if the malfunction is caused by the I/P module.
- 6: This step tests to see what DTCs are present. If DTC B0012 or B0016 is present, test the I/P module for a short between high and low circuits in stage 1 or stage 2. If DTC B0013 or B0017 is present, test the I/P module high and low circuits for an open and for high resistance in stage 1 or stage 2. If DTC B0014 or B0018 is present, test the I/P module high and low circuits for a short to ground and for a short to voltage in stage 1 or stage 2.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect instrument panel (I/P) module inline connector. Refer to Inflatable Restraint Instrument Panel Module Replacement for location of connector. Inspect the component and harness sides of the inline connector for the I/P module for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does the connector exhibit any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the inline connector for the I/P module is damaged, the I/P module must be replaced. Refer to Inflatable Restraint Instrument Panel Module Replacement . If the wiring harness side of the I/P module connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 9 | |
| 4 | IMPORTANT: If scan tool displays multiple codes, diagnose the open code first. Use the J 38715-80 Adapter to connect the J 38715-A SIR Driver/Passenger Load Tool or Saturn SA9409Z-A to the harness side of the I/P module inline connector. See Special Tools . Use BASE of COLUMN and PASSENGER INFLATOR connectors located on the load tool. Turn ON the ignition, with the engine OFF. With the scan tool, request the SIR DTC display. Does the scan tool indicate that DTC B0012, B0013, B0014, B0016, B0017 or B0018 are current? | Go to Step 5 | Go to Step 7 |
| 5 | Turn OFF the ignition. Disconnect and remove both the J 38715-A or Saturn SA9409Z-A and adapter. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for damage or corrosion that may cause a malfunction in the I/P module stage 1 or stage 2 high and/or low circuits. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 6 | If DTC B0012 or B0016 is present, test the I/P module circuits for a short between the high and low circuits in stage 1 or stage 2. If DTC B0013 or B0017 is present, test the I/P module high and low circuits for an open and for high resistance in stage 1 or stage 2. If DTC B0014 or B0018 is present, test the I/P module high and low circuits for a short to ground and for a short to voltage in stage 1 or stage 2. All the above conditions refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Turn OFF the ignition. Replace the I/P module. Refer to Inflatable Restraint Instrument Panel Module Replacement . Did you complete the replacement? | Go to Step 9 | |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Connect all SIR components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If scan tool displays multiple codes, diagnose the open code first. |
DTC B0012, B0013, B0014, B0016, B0017 or B0018
The numbers below refer to the step numbers on the diagnostic table.
- 5: This step tests to see if the malfunction is caused by the steering wheel module or by the steering wheel module coil.
- 7: This step tests to see what DTCs are present. If DTC B0022 or B0042 is present, test the steering wheel module for a short between high and low circuits in stage 1 or stage 2. If DTC B0024 or B0043 is present, test the steering wheel module high and low circuits for an open and for high resistance in stage 1 or stage 2. If DTC B0026 or B0044 is present, test the steering wheel module high and low circuits for an open and for high resistance in stage 1 or stage 2.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the steering wheel module coil inline connector. Refer to Inflatable Restraint Steering Wheel Module Coil Replacement for location of connector. Inspect the component and harness sides of the inline connector for the steering wheel module coil for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does connector exhibits any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the inline connector for the steering wheel module coil is damaged, the steering wheel module coil must be replaced. Refer to Inflatable Restraint Steering Wheel Module Coil Replacement . If the wiring harness side of the steering wheel module coil inline connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 11 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Use the J 38715-80 Adapter to connect the J 38715-A SIR Driver/Passenger Load Tool or Saturn SA9409Z-A to the steering wheel module coil connector. See Special Tools . Use BASE of COLUMN and PASSENGER INFLATOR connectors located on the load tool. Turn ON the ignition, with the engine OFF. Use the scan tool to request SIR DTCs displayed. Does the scan tool indicate that DTC B0022, B0024, B0026, B0042, B0043 or B0044 are current? | Go to Step 6 | Go to Step 5 |
| 5 | Turn OFF the ignition. Disconnect and remove both the J 38715-A or Saturn SA9409Z-A and adapter. See Special Tools . Connect the steering wheel module coil inline connector. Remove the steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement . Install the load tool to the steering wheel coil connectors. Refer to the list below for procedure. When working on a Terraza, Montana SV6 or Uplander use the J 38715-120 adapter to connect the J 38715-A to the upper steering wheel module coil connector on top of the steering column. See Special Tools . Use the STEERING COLUMN and PASSENGER INFLATOR connectors. When working on a Saturn Relay connect the J 38715-A SA9409Z-A to the upper steering wheel module coil connectors on top of the steering column. See Special Tools . Use the EL 38715-130 adapter to connect the load tool DRIVER INFLATOR connector to the stage 1 connector. Use the J 38715-30A adapter to connect the load tool PASSENGER INFLATOR connector to the stage 2 connector. Turn ON the ignition, with the engine OFF. Use the scan tool to request SIR DTCs displayed. Does the scan tool indicate that DTC B0022, B0024, B0026, B0042, B0043 or B0044 are current? | Go to Step 9 | Go to Step 8 |
| 6 | Turn OFF the ignition. Disconnect and remove both the J 38715-A or SA9409Z-A and adapter. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for damage or corrosion that may cause a malfunction in the steering wheel module stage 1 or stage 2 high and/or low circuits. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 7 |
| 7 | If DTC B0022 or B0042 is present, test the steering wheel module circuits for a short between the high and low circuits in stage 1 or stage 2. If DTC B0024 or B0043 is present, test the steering wheel module high and low circuits for a short to ground and for a short to voltage in stage 1 or stage 2. If DTC B0026 or B0044 is present, test the steering wheel module high and low circuits for an open and for high resistance in stage 1 or stage 2. All the above conditions refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 10 |
| 8 | Turn OFF the ignition. Replace the steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement . Did you complete the replacement? | Go to Step 11 | |
| 9 | Turn OFF the ignition. Replace the steering wheel module coil. Refer to Inflatable Restraint Steering Wheel Module Coil Replacement . Did you complete the replacement? | Go to Step 11 | |
| 10 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 11 | |
| 11 | Connect all supplemental inflatable restraint (SIR) components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0022, B0024, B0026, B0042, B0043 or B0044
The number below refers to the step number on the diagnostic table.
- 7: This step tests to see what DTCs are present. If DTC B0028 is present, test the side impact module RF for a short between high and low circuits. If DTC B0029 is present, test the side impact module RF high and low circuits for an open and for high resistance. If DTC B0030 is present, test the side impact module RF high and low circuits for a short to ground or a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the side impact module RF connector. Refer to Inflatable Restraint Side Impact Module Replacement - Front . Inspect the component and harness sides of the side impact module RF connector for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does connector exhibits any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the component side of the side impact module RF connector is damaged, the side impact module RF must be replaced. Refer to Inflatable Restraint Side Impact Module Replacement - Front . If the harness side of the side impact module RF connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 9 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Connect the J 38715-A SIR Driver/Passenger Load Tool or SA9409Z-A to the harness side of the side impact module RF wiring harness connector. See Special Tools . Use the PASSENGER INFLATOR connector. Turn ON the ignition, with the engine OFF. Use the scan tool to request SIR DTCs displayed. Does the scan tool indicate that DTC B0028, B0029 or B0030 are current? | Go to Step 6 | Go to Step 5 |
| 5 | Turn OFF the ignition. Disconnect and remove the J 38715-A . See Special Tools . Replace the side impact module RF. Refer to Inflatable Restraint Side Impact Module Replacement - Front . Did you complete the replacement? | Go to Step 9 | |
| 6 | Turn OFF the ignition. Disconnect and remove the J 38715-A or SA9409Z-A. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for damage or corrosion that may cause a malfunction in the side impact module RF high and/or low circuits. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 7 |
| 7 | If DTC B0028 is present, test the side impact module RF circuits for a short between the high and low circuits. If DTC B0029 is present, test the side impact module RF high and low circuits for an open and for high resistance. If DTC B0030 is present, test the side impact module RF high and low circuits for a short to ground and for a short to voltage. All the above conditions refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Connect all SIR components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0028, B0029 or B0030
The number below refers to the step number on the diagnostic table.
- 6: This step tests to see what DTCs are present. If DTC B0040 is present, test the side impact module LF for a short between high and low circuits. If DTC B0041 is present, test the side impact module LF high and low circuits for an open and for high resistance. If DTC B0045 is present, test the side impact module LF high and low circuits for a short to ground or a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the LF side impact module in-line connector. Refer to Inflatable Restraint Side Impact Module Replacement - Front . Inspect the component and harness sides of the in-line connector for the side impact module LF for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does connector exhibits any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the LF side impact module harness connector exhibits any of the above conditions, replace the side impact module wiring harness. Refer to Inflatable Restraint Side Impact Module Replacement - Front . Replace the harness side of the LF side impact module in-line connector. Refer to Connector Repairs in Wiring Systems. Did you complete the replacement? | Go to Step 9 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Install the J 38715-A SIR Driver/Passenger Load Tool or SA9409Z-A to the harness side of the side impact module LF in-line connector. See Special Tools . Use the PASSENGER INFLATOR connector. Turn ON the ignition, with the engine OFF. With a scan tool, request the SIR DTC display. Does the scan tool indicate that either DTC B0040, B0041 or B0045 is current? | Go to Step 5 | Go to Step 7 |
| 5 | Turn OFF the ignition. Remove the J 38715-A or SA9409Z-A. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 6 | If DTC B0040 is present, test the side impact module LF circuits for a short between the high and low circuits. If DTC B0041 is present, test the side impact module LF high and low circuits for an open and for high resistance. If DTC B0045 is present, test the side impact module LF high and low circuits for a short to ground and for a short to voltage. All the above conditions refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Turn OFF the ignition. Replace the side impact module LF. Refer to Inflatable Restraint Side Impact Module Replacement - Front . Did you complete the replacement? | Go to Step 9 | |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Reconnect all SIR system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0040, B0041 or B0045
The numbers below refer to the step numbers on the diagnostic table.
- 4: This step tests to see if the malfunction is caused by the seat belt pretensioner RF.
- 6: This step tests to see what DTCs are present. If DTC B0057 is present, test the seat belt pretensioner RF for a short between high and low circuits. If DTC B0058 is present, test the seat belt pretensioner RF high and low circuits for an open and for high resistance. If DTC B0059 is present, test the seat belt pretensioner RF high and low circuits for a short to ground and for a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the seat belt retractor pretensioner RF inline connector. Refer to Seat Belt Retractor Pretensioner Replacement - Right Front . Inspect the component and harness sides of the inline connector for the seat belt pretensioner for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does the connector exhibit any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the connector for the seat belt pretensioner RF is damaged, the seat belt pretensioner must be replaced. Refer to Seat Belt Retractor Pretensioner Replacement - Right Front . If the wiring harness side of the seat belt pretensioner connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 9 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Using the J 38715-30A, connect the J 38715-A SIR Driver/Passenger Load Tool or SA9409Z-A to the harness side of the seat belt pretensioner RF connector. See Special Tools . Use the PASSENGER INFLATOR connector. Turn ON the ignition, with the engine OFF. With the scan tool, request the SIR DTC display. Does the scan tool indicate that DTC B0057, B0058 or B0059 are current? | Go to Step 5 | Go to Step 7 |
| 5 | Turn OFF the ignition. Disconnect and remove the J 38715-A or SA9409Z-A and adapter. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for damage or corrosion that may cause a malfunction in the seat belt pretensioner RF high and/or low circuits. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 6 | If DTC B0057 is present, test the seat belt pretensioner RF for a short between the high and low circuits. If DTC B0058 is present, test the seat belt pretensioner RF high and low circuits for an open and for high resistance. If DTC B0059 is present, test the seat belt pretensioner RF high and low circuits for a short to ground and for a short to voltage. All the above conditions refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Turn OFF the ignition. Replace the seat belt pretensioner RF. Refer to Seat Belt Retractor Pretensioner Replacement - Right Front . Did you complete the replacement? | Go to Step 9 | |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Connect all SIR components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0057, B0058 or B0059
The numbers below refer to the step numbers on the diagnostic table.
- 4: This step tests to see if the malfunction is caused by the seat belt pretensioner LF.
- 6: This step tests to see what DTCs are present. If DTC B0064 is present, test the seat belt pretensioner LF for a short between high and low circuits. If DTC B0065 is present, test the seat belt pretensioner LF high and low circuits for an open and for high resistance. If DTC B0066 is present, test the seat belt pretensioner LF high and low circuits for a short to ground and for a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the seat belt retractor pretensioner LF inline connector. Refer to Seat Belt Retractor Pretensioner Replacement - Left Front . Inspect the component and harness sides of the inline connector for the seat belt pretensioner for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does the connector exhibit any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the connector for the seat belt pretensioner LF is damaged, the seat belt pretensioner must be replaced. Refer to Seat Belt Retractor Pretensioner Replacement - Left Front . If the wiring harness side of the seat belt pretensioner connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 9 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Using the J 38715-30A, connect the J 38715-A SIR Driver/Passenger Load Tool or SA9409Z-A to the harness side of the seat belt pretensioner LF connector. See Special Tools . Use the PASSENGER INFLATOR connector. Turn ON the ignition, with the engine OFF. With the scan tool, request the SIR DTC display. Does the scan tool indicate that DTC B0064, B0065 or B0066 are current? | Go to Step 5 | Go to Step 7 |
| 5 | Turn OFF the ignition. Disconnect and remove the J 38715-A or SA9409Z-A and adapter. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for damage or corrosion that may cause a malfunction in the seat belt pretensioner LF high and/or low circuits. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 6 | If DTC B0064 is present, test the seat belt pretensioner LF for a short between the high and low circuits. If DTC B0065 is present, test the seat belt pretensioner LF high and low circuits for an open and for high resistance. If DTC B0066 is present, test the seat belt pretensioner LF high and low circuits for a short to ground and for a short to voltage. All the above conditions refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Turn OFF the ignition. Replace the seat belt pretensioner LF. Refer to Seat Belt Retractor Pretensioner Replacement - Left Front . Did you complete the replacement? | Go to Step 9 | |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Connect all SIR components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0064, B0065 or B0066
The numbers below refer to the step numbers on the diagnostic table.
- 7: This step tests the SIS signal and SIS voltage circuits for an open or high resistance.
- 8: This step tests between the SIS signal and SIS voltage circuits for continuity.
- 9: This step tests the SIS signal and SIS voltage circuits for a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. Use the scan tool to request SIR DTCs displayed. Does the scan tool indicate that DTC B0079, B0080, B0081 or B0082 is current? | Go to Step 10 | Go to Step 3 |
| 3 | Turn OFF the ignition. If DTC B0077 is current, disconnect the inflatable restraint side impact sensor (SIS) - LF connector. If DTC B0078 is current, disconnect the SIS - RF connector. Refer to Inflatable Restraint Side Impact Sensor Replacement . Inspect both the component and harness sides of the connector for damage or corrosion. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems. Does the connector exhibit any signs of damage or corrosion? | Go to Step 4 | Go to Step 5 |
| 4 | If the component side of the SIS connector is damaged, the SIS must be replaced. Refer to Inflatable Restraint Side Impact Sensor Replacement . If the harness side of the SIS connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 11 | |
| 5 | Turn OFF the ignition. Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect both the component and harness sides of the SDM connector for damage or corrosion. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems. Does the connector exhibit any signs of damage or corrosion? | Go to Step 6 | Go to Step 7 |
| 6 | If the component side of the SDM connector is damaged, the SDM must be replaced. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. If the harness side of the SDM connector is damaged, replace the harness side of the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the repair? | Go to Step 11 | |
| 7 | If DTC B0077 is current, disconnect the SIS - LF connector. If DTC B0078 is current, disconnect the SIS - RF connector. Test both the SIS signal and SIS voltage circuits for an open or high resistance between the SDM connector and the SIS connector. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 8 |
| 8 | Test for continuity between the SIS signal circuit and the SIS voltage circuit on the SDM connector. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 9 |
| 9 | Turn ON the ignition, with the engine OFF. Test both SIS signal and SIS voltage circuits for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | Go to Step 10 |
| 10 | Turn OFF the ignition. If DTC B0077, B0079 or B0080 was current, replace the SIS - LF. If DTC B0078, B0081 or B0082 was current, replace the SIS - RF. Refer to Inflatable Restraint Side Impact Sensor Replacement . Did you complete the replacement? | Go to Step 11 | |
| 11 | Reconnect all SIR components. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the text. Does the DTC reset? | Go to Step 12 | System OK |
| 12 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 13 | |
| 13 | Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B0077, B0078, B0079, B0080, B0081 or B0082
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step checks the PPS for any current or history DTCs.
- 5: Test the occupant sensor serial data circuit for an open or high resistance.
- 6: Test the PPS ignition 1 voltage circuit for a short to ground, a high resistance or an open.
- 7: Test the PPS ground circuit for an open or high resistance.
- 8: Test the PPS ground circuit for a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. IMPORTANT: If the passenger presence system (PPS) has any current or history DTCs stored, you must address the PPS DTCs before continuing with this diagnostic table. Use the scan tool to request the PPS DTCs. Refer to Passenger Presence System Flash Code Procedures . Does the PPS flash any current or history DTCs? | Go to Diagnostic Trouble Code (DTC) List - Vehicle in Vehicle DTC Information | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the PPS module connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the PPS module connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 4 |
| 4 | Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for damage or corrosion. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 5 |
| 5 | Test the occupant sensor serial data circuit for an open or high resistance between the PPS and SDM connector. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 6 |
| 6 | Test the PPS ignition 1 voltage circuit for one of the following: An open High resistance Short to ground Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 7 |
| 7 | Test the PPS ground circuit for an open or high resistance. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 8 |
| 8 | Turn ON the ignition, with the engine OFF. Test the PPS ground circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 9 |
| 9 | Turn OFF the ignition. IMPORTANT: The PPS is a calibrated system. The PPS must be rezero after replacement. Replace the PPS. The PPS is only serviceable as a PPS and seat bottom foam assembly. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 10 | |
| 10 | Reconnect all SIR and PPS system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Rezero the PPS. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the passenger presence system (PPS) has any current or history DTCs stored, you must address the PPS DTCs before continuing with this diagnostic table. |
| IMPORTANT |
|---|
| The PPS is a calibrated system. The PPS must be rezero after replacement. |
DTC B0092
The numbers below refer to the step numbers on the diagnostic table.
- 3: Inspect the PPS to verify the correct part number was installed in the vehicle.
- 5: This test checks the PPS data communications circuit for an open or high resistance.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Was the passenger presence system (PPS) replaced? | Go to Step 3 | Go to Step 4 |
| 3 | Inspect the PPS to verify that the correct part number was installed in the vehicle. Was the correct PPS part number installed in the vehicle? | Go to Step 4 | Go to Step 6 |
| 4 | Was the inflatable restraint sensing and diagnostic module (SDM) replaced? | Go to Step 5 | Go to Step 6 |
| 5 | Inspect the SDM to ensure that the correct part number was installed in the vehicle. Was the correct SDM part number installed in the vehicle? | Go to Step 6 | Go to Step 8 |
| 6 | Turn OFF the ignition. IMPORTANT: The PPS is a calibrated system. The PPS must be rezero after replacement. Replace the PPS. The PPS is only serviceable as a PPS and seat bottom foam assembly. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 7 | |
| 7 | Reconnect all SIR and PPS components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the text. Does the DTC reset? | Go to Step 8 | System OK |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Reconnect all SIR and PPS components. Verify that all components, connectors and CPAs are properly mounted. Use the scan tool in order to clear the SIR and PPS DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| The PPS is a calibrated system. The PPS must be rezero after replacement. |
DTC B0098
The numbers below refer to the step numbers on the diagnostic table
- 2: Tests the communication status of both front end sensors.
- 6: Tests for a short to ground, a high resistance or an open in the front end sensor signal circuit.
- 7: Tests for a short to ground, a high resistance or an open in the front end sensor low reference circuit.
- 8: Tests for a short to voltage in the front end sensor signal and low reference circuits.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, request the SIR DTC display. Does the scan tool indicate that either DTC B0101, B0102, B0104 or B0105 is current? | Go to Step 12 | Go to Step 3 |
| 3 | Turn OFF the ignition. If DTC B0100 is current, disconnect the left front end sensor connector. If DTC B0103 is current, disconnect the right front end sensor connector. Refer to Inflatable Restraint Front End Sensor Replacement . Inspect both front end sensor and harness connector terminals for damage or corrosion. Do the front end sensor terminals or harness connector exhibit any signs of damage or corrosion? | Go to Step 4 | Go to Step 5 |
| 4 | If the front end sensor terminals are damaged, replace the front end sensor. Refer to Inflatable Restraint Front End Sensor Replacement . If the front end sensor harness connector is damaged, replace the connector. Refer to Connector Repairs in Wiring Systems. Did you complete the replacement? | Go to Step 13 | |
| 5 | Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the SDM connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 6 |
| 6 | If DTC B0100 is current, test the left front end sensor signal circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. If DTC B0103 is current, test the right front end sensor signal circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 7 |
| 7 | If DTC B0100 is current, test the left front end sensor low reference circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. If DTC B0103 is current, test the right front end sensor low reference circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 8 |
| 8 | Turn ON the ignition, with the engine OFF. If DTC B0100 is current, test the left front end sensor signal and low reference circuits for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. If DTC B0103 is current, test the right front end sensor signal and low reference circuits for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 9 | For DTC B0100 replace the left front end sensor. For DTC B0103 replace the right front end sensor. Refer to Inflatable Restraint Front End Sensor Replacement . Did you complete the replacement? | Go to Step 10 | |
| 10 | Reconnect all SIR system components. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 11 | System OK |
| 11 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 13 | |
| 12 | For DTC B0101 and B0102 replace the left front end sensor. For DTC B0104 and B0105 replace the right front end sensor. Refer to Inflatable Restraint Front End Sensor Replacement . Did you complete the replacement? | Go to Step 13 | |
| 13 | Reconnect all SIR system components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B0100, B0101, B0102, B0103, B0104 or B0105
The number below refers to the step number on the diagnostic table.
- 6: This step tests to see what DTCs are present. If DTC B0109 is present, test the side impact module LR for a short between high and low circuits. If DTC B0110 is present, test the side impact module LR high and low circuits for an open and for high resistance. If DTC B0111 is present, test the side impact module LR high and low circuits for a short to ground or a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Turn OFF the ignition. Disconnect the LR side impact module in-line connector. Refer to Inflatable Restraint Side Impact Module Replacement - Rear . Inspect the component and harness sides of the in-line connector for the side impact module LR for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Does connector exhibits any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the LR side impact module harness connector exhibits any of the above conditions, replace the side impact module wiring harness. Refer to Inflatable Restraint Side Impact Module Replacement - Rear . Replace the harness side of the LR side impact module in-line connector. Refer to Connector Repairs . Did you complete the replacement? | Go to Step 9 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Install the J 38715-A SIR Driver/Passenger Load Tool or SA9409Z-A to the harness side of the side impact module LR in-line connector. See Special Tools . Use the PASSENGER INFLATOR connector. Turn ON the ignition, with the engine OFF. With a scan tool, request the SIR DTC display. Does the scan tool indicate that either DTC B0109, B0110 or B0111 is current? | Go to Step 5 | Go to Step 7 |
| 5 | Turn OFF the ignition. Remove the J 38715-A or SA9409Z-A. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References for replacement, setup and programming. Inspect the SDM connector for corrosion or damage. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 6 | If DTC B0109 is present, test the side impact module LR circuits for a short between the high and low circuits. If DTC B0110 is present, test the side impact module LR high and low circuits for an open and for high resistance. If DTC B0111 is present, test the side impact module LR high and low circuits for a short to ground and for a short to voltage. All the above conditions refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Turn OFF the ignition. Replace the side impact module LR. Refer to Inflatable Restraint Side Impact Module Replacement - Rear . Did you complete the replacement? | Go to Step 9 | |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Reconnect all SIR System components. Verify that all components, connectors and connector position assurances (CPAs) are properly mounted. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0109, B0110 or B0111
The number below refers to the step number on the diagnostic table.
- 7: This step tests to see what DTCs are present. If DTC B0112 is present, test the side impact module RR for a short between high and low circuits. If DTC B0113 is present, test the side impact module RR high and low circuits for an open and for high resistance. If DTC B0114 is present, test the side impact module RR high and low circuits for a short to ground or a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Turn OFF the ignition. Disconnect the side impact module RR connector. Refer to Inflatable Restraint Side Impact Module Replacement - Rear . Inspect the component and harness sides of the side impact module RR connector for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Does connector exhibits any signs of damage or corrosion? | Go to Step 3 | Go to Step 4 |
| 3 | If the component side of the side impact module RR connector is damaged, the side impact module RR must be replaced. Refer to Inflatable Restraint Side Impact Module Replacement - Rear . If the harness side of the side impact module RR connector is damaged, replace the harness side of the connector. Refer to Connector Repairs . Did you complete the repair? | Go to Step 9 | |
| 4 | IMPORTANT: If the scan tool displays multiple codes, diagnose the open code first. Connect the J 38715-A SIR Driver/Passenger Load Tool or SA9409Z-A to the harness side of the side impact module RR wiring harness connector. See Special Tools . Use the PASSENGER INFLATOR connector. Turn ON the ignition, with the engine OFF. Use the scan tool to request SIR DTCs displayed. Does the scan tool indicate that DTC B0112, B0113 or B0114 are current? | Go to Step 6 | Go to Step 5 |
| 5 | Turn OFF the ignition. Disconnect and remove the J 38715-A . See Special Tools . Replace the side impact module RR. Refer to Inflatable Restraint Side Impact Module Replacement - Rear . Did you complete the replacement? | Go to Step 9 | |
| 6 | Turn OFF the ignition. Disconnect and remove the J 38715-A or SA9409Z-A. See Special Tools . Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Control Module References for replacement, setup and programming. Inspect the SDM connector for damage or corrosion that may cause a malfunction in the side impact module RR high and/or low circuits. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 9 | Go to Step 7 |
| 7 | If DTC B0112 is present, test the side impact module RR circuits for a short between the high and low circuits. If DTC B0113 is present, test the side impact module RR high and low circuits for an open and for high resistance. If DTC B0114 is present, test the side impact module RR high and low circuits for a short to ground and for a short to voltage. All the above conditions refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 8 | Turn OFF the ignition. Replace the SDM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Connect all SIR components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| If the scan tool displays multiple codes, diagnose the open code first. |
DTC B0112, B0113 or B0114
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step tests to see if the correct VIN is programmed in the PCM.
- 4: This step tests to see if the BCM has been replaced.
- 5: This step tests to see if the correct VIN is programmed in the BCM.
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. With a scan tool, verify that the powertrain control module (PCM) is programmed with the correct VIN by comparing the VIN that is stored in the PCM to the VIN plate of the vehicle. Does the scan tool indicate that the PCM is programmed with the correct VIN? | Go to Step 4 | Go to Step 3 |
| 3 | Use a scan tool and/or the techline machine to program the correct VIN into the PCM. Did you complete the action? | Go to Step 9 | |
| 4 | Was the body control module (BCM) replaced? | Go to Step 6 | Go to Step 5 |
| 5 | With a scan tool, verify that the BCM is programmed with the correct VIN by comparing the VIN that is stored in the BCM to the VIN that is stored in the PCM. Does the scan tool indicate that the BCM is programmed with the correct VIN? | Go to Step 7 | Go to Step 6 |
| 6 | Follow the instructions on the scan tool under BCM SPECIAL FUNCTIONS to properly reprogram the BCM and setup the inflatable restraint sensing and diagnostic module (SDM) part number. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the action? | Go to Step 7 | |
| 7 | Reconnect all SIR components. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 8 | Go to Step 9 |
| 8 | Replace the SDM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Reconnect all SIR components. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B1001
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step checks for any current PPS DTCs.
- 3: This step checks for the presence of DTC B1530.
- 4: This step replaces the SDM.
- 5: This step performs the SDM setup procedure.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. IMPORTANT: If the sensing and diagnostic module (SDM) has DTC B0092 or DTC B0098 stored as current, you must address those DTCs before continuing with this diagnostic table. With a scan tool, check for DTC B0092 or DTC B0098 is a current DTC. Is DTC B0092 or DTC B0098 stored as current DTC? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 3 |
| 3 | If the passenger presence system (PPS) has been replaced then DTC B1530 will automatically be cleared. If the PPS was repaired and DTC B1530 is current, the SDM will have to be replaced. Is DTC B1530 a current DTC? | Go to Step 4 | System OK |
| 4 | Replace the SDM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 5 | |
| 5 | Perform the Setup SDM Serial Number in body control module (BCM) procedure. Refer to Control Module References for replacement, setup and programming. Did you complete the setup procedure? | System OK | |
| IMPORTANT |
|---|
| If the sensing and diagnostic module (SDM) has DTC B0092 or DTC B0098 stored as current, you must address those DTCs before continuing with this diagnostic table. |
DTC B1530
The numbers below refer to the step numbers on the diagnostic table.
- 4: Tests the Passenger AIR BAG ON/OFF indicator ignition 1 voltage circuit for a short to ground, high resistance or an open.
- 5: Tests the passenger air bag OFF indicator control circuit for a short to ground, a high resistance or an open.
- 6: Tests the passenger air bag ON indicator control circuit for a short to ground, a high resistance or an open.
- 7: Tests the PPS module for proper operation.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: SIR Schematics (AK5 or AJ7) or SIR Schematics (AW9) Connector End View Reference: SIR Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the Passenger Presence System (PPS) module connector located under the passenger seat. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Inspect the PPS module connector for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does connector exhibits any signs of damage or corrosion? | Go to Step 10 | Go to Step 3 |
| 3 | Disconnect the Passenger AIR BAG ON/OFF Indicator connector. Refer to Indicator Replacement - Inflatable Restraint IP Module . Inspect the Passenger AIR BAG ON/OFF indicator connector for damage or corrosion that may cause the malfunction. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Does connector exhibits any signs of damage or corrosion? | Go to Step 10 | Go to Step 4 |
| 4 | Turn OFF the ignition. Test the Passenger AIR BAG ON/OFF indicator ignition 1 voltage circuit for a short to ground, a high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 5 |
| 5 | Test the PASSENGER AIR BAG OFF indicator control circuit between the Passenger AIR BAG ON/OFF indicator and the PPS for a short to voltage, high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 6 |
| 6 | Test the PASSENGER AIR BAG ON indicator control circuit between the Passenger AIR BAG ON/OFF indicator and the PPS for a short to voltage, high resistance or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 7 |
| 7 | Turn OFF the ignition. Connect a test lamp between the ignition 1 voltage circuit and the passenger air bag OFF indicator control circuit on the Passenger AIR BAG ON/OFF indicator connector. Empty the front passenger seat. Turn ON the ignition, with the engine OFF. Does the test lamp illuminate? | Go to Step 8 | Go to Step 9 |
| 8 | Turn OFF the ignition. Replace the Passenger AIR BAG ON/OFF indicator. Refer to Indicator Replacement - Inflatable Restraint IP Module . Did you complete the replacement? | Go to Step 10 | |
| 9 | Turn OFF the ignition. IMPORTANT: The PPS is a calibrated system. The PPS must be rezero after replacement. Replace the PPS, the PPS is only serviceable as PPS, heated seat element and seat bottom foam assembly. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 10 | |
| 10 | Connect all SIR and PPS components. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| The PPS is a calibrated system. The PPS must be rezero after replacement. |
Passenger Presence System Indicator Circuit Malfunction
Frontal SIR System Description
The frontal supplemental inflatable restraint (SIR) system consists of the following components
- AIR BAG indicator located in the instrument panel cluster (IPC)
- Driver and passenger knee bolsters
- Inflatable restraint instrument panel (I/P) module.
- Inflatable restraint sensing and diagnostic module (SDM)
- Steering wheel and column
- Inflatable restraint steering wheel module
- Inflatable restraint steering wheel module coil
- Inflatable restraint wiring harnesses
- Inflatable restraint front end sensor (left/right)
- Inflatable restraint Passenger AIR BAG ON/OFF indicator
- Inflatable restraint passenger presence system (PPS)
- Inflatable restraint seat belt retractors pretensioner (left/right)
A frontal collision of sufficient force up to 30 degrees off the longitudinal centerline of the vehicle will deploy the frontal air bags. The SDM contains a sensing device that converts vehicle velocity changes to an electrical signal. In the event of a frontal collision, the SDM receives a signal from the front end sensor, which assists the SDM in determining the severity of the collision. The SDM compares these signals to a value stored in memory. When the generated signals exceed the stored value, the SDM will cause current to flow through the frontal deployment loops simultaneously deploying the frontal air bags. The SDM, I/P module, steering wheel module, steering wheel module coil and the connecting wires makeup the frontal deployment loops. The SDM continuously monitors the deployment loops for malfunctions and turns the AIR BAG indicator ON if a fault is detected.
Side SIR System Description
The Side Supplemental Inflatable Restraint (SIR) System consists of the following components
- AIR BAG indicator located in the instrument panel cluster (IPC)
- Inflatable restraint sensing and diagnostic module (SDM)
- Inflatable restraint side impact sensors (SIS) (left/right)
- Inflatable restraint side impact modules (left/right), front and rear (w/rear bucket seats)
- Inflatable restraint wiring harnesses
