Scheme 1
Scheme 1: Cigar Lighter/Power Outlet Schematics
Scheme 2
Scheme 2: Power Outlet Component Views
| Callout | Component Name |
|---|
| 1 | Rear Window Wiper/Washer Switch |
| 2 | Transfer Case Shift Control Switch (NP8) |
| 3 | Instrument Panel Harness |
| 4 | Auxiliary Power Outlet - Front |
| 5 | Cigar Lighter |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Rear Window Wiper/Washer Switch |
| 2 | Auxiliary Power Outlet - Front |
| 3 | Cigar Lighter |
| 4 | Transfer Case Shift Control Switch (NP8) |
| 5 | Instrument Panel Harness |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Cigar Lighter |
| 2 | Rear Window Wiper/Washer Switch |
| 3 | Instrument Panel Harness |
| 4 | Auxiliary Power Outlet - Front |
Scheme 5
| Callout | Component Name |
|---|
| 1 | Lower Console |
| 2 | HVAC Control Module - Auxiliary |
| 3 | Auxiliary Power Outlet - Console |
| 4 | Console Mode Actuator - Auxiliary |
| 5 | C309 |
| 6 | C307 |
Scheme 6
Scheme 6: Auxiliary Power Outlet - Console
| Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Pins: A, C Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet - Console Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | OG | 1040 | Battery Positive Voltage |
| B | | | Not Used |
| C | BK | 2250 | Ground |
Auxiliary Power Outlet - Console Connector Terminal Identification
