Auxiliary Power Outlet - Front
| Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Pins: A, C Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet - Front Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | OG | 1040 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 2250 | Ground |
Auxiliary Power Outlet - Front Connector Terminal Identification
Scheme 7
| Connector Part Information OEM: 12176445 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (NA) |
|---|
| Terminal Part Information Pins: A, C Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Cigar Lighter Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | OG | 640 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 2250 | Ground |
Cigar Lighter Connector Terminal Identification
Tools Required
J 42059 Cigar Lighter Socket Remover. See Special Tools .
