Steering Wheel & Steering Column: Specifications Chevrolet TrailBlazer I

Ignition Switch/steering Lock 6 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
HVAC Floor Duct Mounting Screw1.9 N.m17 lb in
Horn Contact Plate Screws5.5 N.m50 lb in
Intermediate Shaft to the Steering Gear Pinch Bolt40 N.m29 lb ft
Ignition Lock Cylinder Case Screws7 N.m62 lb in
Steering Column Trim Cover Screws Lower3.5 N.m31 lb in
Turn signal Multifunction Switch Screws Side7 N.m62 lb in
Turn signal Multifunction Switch Screws T3 N.m27 lb in
Steering Column Electrical Connector Screw6 N.m53 lb in
Steering Column Mounting Huts27 N.m20 lb ft
Steering Wheel Shroud Screws2 N.m18 lb in
Steering Wheel Nut41 N.m30 lb ft
Intermediate Shaft to the Steering Column Pinch Bolt50 N.m37 lb ft
Steering Column Trim Cover Screws Upper1 N.m9 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Column/Ignition Lock Schematics
Scheme 1: Column/Ignition Lock Schematics

Scheme 2

Scheme 2: Tilt Steering Column
Scheme 2: Tilt Steering Column

Scheme 3

Scheme 3: Steering Column Components
Scheme 3: Steering Column Components

Scheme 4

Scheme 4: Ignition Lock Cylinder Control Actuator
Scheme 4: Ignition Lock Cylinder Control Actuator

Scheme 5

Scheme 5: Automatic Transmission Shift Lock Actuator
Scheme 5: Automatic Transmission Shift Lock Actuator

Scheme 6

Scheme 6: Ignition Lock Cylinder Control Actuator
Scheme 6: Ignition Lock Cylinder Control Actuator
