Steering Wheel & Steering Column: Removal & Installation Chevrolet TrailBlazer I

Intermediate Steering Shaft Replacement - Upper

Tools Required

J 42640 Steering Column Lock Pin

Removal Procedure

Note. The front wheels of the vehicle must be maintained in the straight ahead position and the steering column must be in the LOCK position before disconnecting the steering column or intermediate shaft. Failure to follow these procedures will cause improper alignment of some components during installation and result in damage to the SIR coil assembly.

Scheme 19

Scheme 20

Scheme 21

1. Turn the steering wheel so that the front wheels are pointing straight ahead.
2. Turn the ignition switch to the lock position and remove the key.
3. Lock the steering column through the access hole in the lower steering column trim cover using J 42640.
4. Remove the knee bolster. Refer to KNEE BOLSTER REPLACEMENT in Instrument Panel, Gages and Console.
5. Disconnect the upper intermediate shaft boot from the lower intermediate shaft boot to gain access to the upper intermediate shaft to lower intermediate pinch bolt.
6. Remove the upper intermediate shaft to lower intermediate shaft pinch bolt.
7. Disconnect the upper intermediate shaft from the lower intermediate shaft. IMPORTANT: Note the direction of upper intermediate shaft to steering column pinch bolt for installation. The bolt must be installed in the same direction it was removed.
8. Remove the upper intermediate shaft to steering column pinch bolt.
9. Disconnect the upper intermediate shaft from the steering column.
10. Remove the upper intermediate shaft from the vehicle.

Scheme 22

Scheme 23

Scheme 24

1. Install the upper intermediate shaft to the vehicle.
2. Connect the upper intermediate shaft to the steering column. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices. IMPORTANT: The upper intermediate shaft to the steering column pinch bolt must be installed in the same direction it was removed or the pinch bolt will contact the steering column housing.
3. Install the upper intermediate shaft to the steering column pinch bolt and nut. Tighten Tighten the upper intermediate shaft to the steering column pinch bolt nut to 50 N.m (37 lb ft).
4. Connect the upper intermediate shaft to the lower intermediate shaft.
5. Install the upper intermediate shaft to the lower intermediate shaft pinch bolt. Tighten Tighten the upper intermediate shaft to the lower intermediate shaft pinch bolt to 50 N.m (37 lb ft). IMPORTANT: The upper intermediate shaft boot must completely cover the white insert of the lower intermediate shaft boot to ensure proper sealing.
6. Connect the upper intermediate shaft boot to the lower intermediate shaft boot.
7. Install the knee bolster. Refer to KNEE BOLSTER REPLACEMENT in Instrument Panel, Gages and Console. Unlock the steering column by removing J 42640 from the steering column lower trim cover access hole.

Intermediate Steering Shaft Replacement - Lower

Tools Required

J 42640 Steering Column Lock Pin

Note. The front wheels of the vehicle must be maintained in the straight ahead position and the steering column must be in the LOCK position before disconnecting the steering column or intermediate shaft. Failure to follow these procedures will cause improper alignment of some components during installation and result in damage to the SIR coil assembly.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Turn the steering wheel so that the front wheels are pointing straight ahead.
2. Turn the ignition switch to the lock position and remove the key.
3. Lock the steering column through the access hole in the lower steering column trim cover using J 42640.
4. Disconnect the upper intermediate shaft boot from the lower intermediate shaft boot to gain access to the upper intermediate shaft to lower intermediate pinch bolt.
5. Remove the lower intermediate shaft to upper intermediate shaft pinch bolt.
6. Disconnect the lower intermediate shaft from the upper intermediate shaft.
7. Disconnect the lower intermediate shaft boot from the power steering gear and remove lower intermediate shaft boot from the vehicle.
8. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. IMPORTANT: Note the relationship of the intermediate shaft to the power steering gear and the intermediate shaft to the steering column in order to ensure proper installation.
9. Remove the lower intermediate shaft to the power steering gear input shaft pinch bolt.
10. Disconnect the lower intermediate shaft from the power steering gear.
11. Remove the lower intermediate shaft from the vehicle.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Install the lower intermediate shaft to the vehicle.
2. Connect the lower intermediate shaft to the power steering gear. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
3. Install the lower intermediate shaft to the power steering gear input shaft pinch bolt. Tighten Tighten the lower intermediate shaft to the power steering gear input shaft pinch bolt to 40 N.m (29 lb ft).
4. Lower the vehicle.
5. Install the lower intermediate shaft boot and connect the lower intermediate shaft boot to the power steering gear.
6. Connect the lower intermediate shaft to the upper intermediate shaft. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
7. Install the lower intermediate shaft to the upper intermediate shaft pinch bolt. Tighten Tighten the lower intermediate shaft to the upper intermediate shaft pinch bolt to 50 N.m (37 lb ft). IMPORTANT: The upper intermediate shaft boot must completely cover the white insert of the lower intermediate shaft boot to ensure proper sealing.
8. Connect the upper intermediate shaft boot to the lower intermediate shaft boot.
9. Unlock the steering column by removing J 42640 from the steering column lower trim cover access hole.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Vehicles involved in accidents involving the following conditions may also have a damaged or misaligned steering column: Frame damage Major body or sheet metal damage Where the steering column has been impacted Where supplemental inflatable restraint systems deployed
2. Inspect the capsules on the steering column bracket assembly. All capsules must be securely seated in the bracket slots and inspected for any loose conditions when pushed or pulled by hand.
3. Observe how the bracket is attached to the jacket assembly. If the capsules are not securely seated and the bracket is bolted to the jacket assembly, replace only the bracket. If the capsules are not securely seated and the bracket is welded to the jacket assembly, replace only the jacket assembly.
4. Inspect for jacket assembly collapse by measuring the distance from the lower edge of the upper jacket to a defined point on the lower jacket. Replace the jacket assembly if the measured dimensions are not within specifications.
5. Inspect for tab (1) breakage on the bearing and adapter assembly.
6. Visually inspect the steering shaft for sheared injected plastic. If the steering shaft shows sheared plastic, replace the steering shaft.
7. Any frame damage that could cause a bent steering shaft must have the steering shaft runout checked. Using a dial indicator (1) at the lower end of the steering shaft, rotate the steering wheel. The runout must not exceed 1.60 mm (0.06 in).

Steering Column Trim Covers Replacement

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
3. Remove the tilt lever. Refer to «TILT LEVER REPLACEMENT»(ref-188488-S23545118312005090500000) . NOTE: Remove the closeout trim cover following the exact procedure listed below in order not to damage the snaps on the upper trim cover.
4. Disengage the closeout trim cover (2) from the upper trim cover (1) in the following order: Stand in front of the column from the drivers point of view. On the left side, gently pull downwards on the left side of the closeout trim cover to loosen 1 snap. Do NOT fully remove the closeout trim cover. On the right side, gently pull downwards on the right side of the closeout trim cover to loosen 1 snap. Do NOT fully remove the closeout trim cover. Starting from the left side of the trim covers, gently roll the closeout trim cover to the right to disengage the remaining 4 snaps. IMPORTANT: You must inspect for 2 pan head tapping screws (2) in the lower trim cover (1) before removal.
5. If necessary, remove the 2 pan head tapping screws (2) from the lower trim cover (1). Remove the lower trim cover (1).
6. If no screws are present in the lower trim cover, proceed to the next step.
7. Gently unsnap the lower trim cover from the upper trim cover. Important; You must inspect for 1 TORX® head screw (3) in the upper trim cover (1) before removal.
8. If necessary, remove 1 TORX® head screw (3) from the upper trim cover (1) and the closeout trim cover (2) for removal.
9. If no screw is present, remove the upper trim cover (1) with the closeout trim cover (2).

Installation Procedure

Note. Refer to FASTENER NOTICE in Cautions and Notices.

If there was not any damage done to the trim covers during the removal procedure and no screws were present, proceed to Step 6 .

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Install the upper trim cover (1) with the closeout trim cover (2) and secure by using 1 TORX® head screw (3). Tighten Tighten the screw to 1.0 N.m (9 lb in).
2. Install the lower trim cover (1).
3. Connect the lower trim cover (1) to the closeout trim cover.
4. Install 2 pan head tapping screws (2). Tighten Tighten the screws to 3.5 N.m (31 lb in).
5. Install the upper and lower trim covers onto the steering column.
6. Gently snap the upper and lower trim covers together.
7. Install the closeout trim cover (2) onto the upper trim cover (1).
8. Install the tilt lever. Refer to «TILT LEVER REPLACEMENT»(ref-188488-S23545118312005090500000) .
9. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
10. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Ignition Switch Replacement

Tools Required

J 42759 Ignition Switch Connector Release Tool

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) . IMPORTANT: The abrasion sleeve located on the steering column wire harness assembly must be reinstalled. Make note of what connector is coming out of the abrasion sleeve for installation purposes.
3. Remove the wire harness strap (2) from the steering column and the wire harness assembly (1).
4. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly out of the bulkhead connector (1).
5. Rotate the key alarm connector (1) 90 degrees.
6. Pull the key alarm connector (1) out of the ignition lock cylinder case (2).
7. Remove the passkey connector from the ignition lock cylinder case (2).
8. Insert J 42759 into the ignition lock cylinder case (1) and slide the ignition switch (2) out.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Install the ignition lock cylinder case (1) and slide the ignition switch (2) in.
2. Push the key alarm connector (1) into the ignition lock cylinder case (2).
3. Rotate the key alarm connector (1) 90 degrees so that the key alarm connector (1) locks into place.
4. Install the passkey connector into the ignition lock cylinder case (2).
5. Slide the 2 connectors (2) of the turn signal and multifunction switch assembly into the bulkhead connector (1). IMPORTANT: The abrasion sleeve must be installed back onto the steering column wire harness assembly. The ignition lock cylinder case wires and connector must be hanging out of the middle of the abrasion sleeve.
6. Attach the wire harness strap (2) to the wire harness assembly (1) and the steering column.
7. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
8. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Ignition Lock Cylinder Replacement

Scheme 53

Scheme 54

1. Disconnect the battery negative cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE in Engine Electrical. CAUTION: Refer to «SIR CAUTION»(ref-175132-S12077789922005041500000) In Cautions and Notices.
2. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
3. Remove the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
4. Turn the ignition lock cylinder to the start position.
5. Insert the tip of an awl into the access hole (1) of the ignition lock cylinder.
6. Push down and hold the retaining pin of the ignition lock cylinder.
7. Release the ignition lock cylinder to the run position.
8. Remove the ignition lock cylinder by pulling the cylinder away from the steering column.

Scheme 55

1. Install the ignition lock cylinder by performing the following procedure: Align the positioning locking tab slot on the lock module to the positioning tab on the ignition lock cylinder. Push the lock cylinder in until the tab locks in the lock module.
2. Install the steering column trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
3. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
4. Connect the battery negative cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE in Engine Electrical.
5. Perform the Passlock learn procedure. Refer to PROGRAMMING THEFT DETERRENT SYSTEM COMPONENTS in Theft Deterrent.

Ignition Lock Cylinder Case Replacement

Scheme 56

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the turn signal cancel cam and upper bearing. Refer to «TURN SIGNAL CANCEL CAM AND STEERING SHAFT UPPER BEARING SPRING REPLACEMENT»(ref-188488-S41363995412005090500000) .
3. Remove the ignition switch assembly. Refer to «IGNITION SWITCH REPLACEMENT»(ref-188488-S20786684802005090500000) .
4. Remove 3 pan head tapping screws (2) from the ignition lock cylinder case assembly (1). Remove the ignition lock cylinder case from the steering column.

Scheme 57

1. Align the ignition lock cylinder case assembly (1) with the steering column tilt head assembly. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
2. Secure the ignition lock cylinder case assembly (1) to the steering column using 3 pan head tapping screws (2). Tighten Tighten the screws to 7 N.m (62 lb in).
3. Install the ignition switch assembly. Refer to «IGNITION SWITCH REPLACEMENT»(ref-188488-S20786684802005090500000) .
4. Install the turn signal cancel cam and upper bearing. Refer to «TURN SIGNAL CANCEL CAM AND STEERING SHAFT UPPER BEARING SPRING REPLACEMENT»(ref-188488-S41363995412005090500000) .
5. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Multifunction Turn Signal Switch Housing Replacement

Scheme 58

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the steering wheel from the column. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
3. Remove the ignition lock cylinder case assembly. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT»(ref-188488-S00394087222005090500000) .
4. Remove the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(ref-188488-S16486232682005090500000) .
5. Slide the turn signal switch housing off of the steering column shaft assembly.

Scheme 59

1. Slide the turn signal switch housing onto the steering column shaft assembly.
2. Install the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(ref-188488-S16486232682005090500000) .
3. Install the ignition lock cylinder case. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT»(ref-188488-S00394087222005090500000) .
4. Install the steering wheel onto the column. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
5. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Turn Signal Cancel Cam and Steering Shaft Upper Bearing Spring Replacement

Tools Required

1. J 23653-SIR Steering Column Lock Plate Compressor
2. J 42137 Steering Column Lock Plate Compressor Adapter

Scheme 60

Scheme 61

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the SIR coil. Refer to «SIR COIL ASSEMBLY»(ref-160362-S39076576712004021000000) in Air Bag Restraint Systems.
3. Remove and discard the bearing retainer using J 23653-SIR and J 42137 .
4. Remove J 23653-SIR and J 42137 from the steering shaft.
5. Remove the shaft lock (2) or the cam orientation plate (1). IMPORTANT: Do not wipe the lubricant off the turn signal cancel cam assembly.
6. Remove the turn signal cancel cam assembly (3).
7. Remove the upper bearing spring (4).
8. Remove the upper bearing inner race seat (5).
9. Remove the inner race (6).

Scheme 62

Scheme 63

1. Install the inner race (6).
2. Install the upper bearing inner race seat (5).
3. Install the upper bearing spring (4). IMPORTANT: The electrical contact of the turn signal and multifunction switch assembly must rest on the turn signal cancel cam assembly.
4. If replacing the turn signal cancel cam (3), lubricate the new turn signal cancel cam with GM P/N 12377900 (Canadian P/N 10953529). Install the turn signal cancel cam assembly (3).
5. Install the shaft lock (2) or the cam orientation plate (1).
6. Install the new bearing retainer using J 23653-SIR and J 42137 .
7. Remove J 23653-SIR and J 42137 from the steering shaft. CAUTION: Refer to «SIR INFLATOR MODULE COIL CAUTION»(ref-175132-S33913314732005041500000) In Cautions and Notices.
8. Install the SIR coil. Refer to «SIR COIL ASSEMBLY»(ref-160362-S39076576712004021000000) in Air Bag Restraint Systems.
9. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Multifunction, Turn Signal Switch Replacement

Scheme 64

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
3. Tilt the column to the CENTER position.
4. Disconnect the connectors from the turn signal and multifunction switch assembly. Remove 2 pan head tapping screws from the turn signal and multifunction switch assembly.
5. Remove the turn signal and multifunction switch assembly.

Scheme 65

1. Install the turn signal and multifunction switch assembly. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
2. Secure by using 2 pan head tapping screws. Tighten Tighten the screw on the top of the column to 3 N.m (27 lb in). Tighten the screw in the front to 7 N.m (62 lb in).
3. Connect the connectors to the turn signal and multifunction switch assembly.
4. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
5. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Pull the tilt steering column lever (1) out from the steering column (2).

Scheme 66

Align the tilt steering column lever (1) and push the lever into the steering column (2).

Scheme 67

Horn Switch Replacement

Scheme 68

Scheme 69

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the Inflatable Restraint Steering Wheel module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(ref-160362-S23010603142004021000000) in Air Bag Restraint Systems.
3. Remove the horn plunger from the steering column by pressing inward to the stop and rotating horn plunger 90 degrees.
4. Disconnect the horn contact plate (2) captured screws (1, 4) from the steering wheel (3).
5. Remove the horn switch (2) from the steering wheel (3).

Scheme 70

Scheme 71

1. Install the horn switch (2) to the steering wheel (3). NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
2. Connect the horn contact plate (2) captured screws (1, 4) to the steering wheel (3). Tighten Tighten the screws to 5.5 N.m (50 lb in).
3. Install the horn plunger to the steering column.
4. Install the inflator module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(ref-160362-S23010603142004021000000) in Air Bag Restraint Systems.
5. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Scheme 72

Scheme 73

Scheme 74

1. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
2. Remove the shroud retaining screws from the back of the steering wheel.
3. Remove the shroud from the steering wheel.
4. Position a blunt ended tool into the wire harness cavity (1) and apply moderate pressure in order to partially remove the steering wheel control switch from the steering wheel.
5. Disconnect the steering wheel control switch electrical connector. IMPORTANT: The bulbs in the steering wheel control switches are not serviceable. The switches should be replaced only as an assembly.
6. Remove the steering wheel control switch from the steering wheel.

Scheme 75

Scheme 76

1. Position the steering wheel control switch to the steering wheel.
2. Connect the electrical connector to the steering wheel control switch.
3. Install the steering wheel control switch into the steering wheel, ensuring the retaining tabs are fully seated.
4. Install the shroud to the steering wheel. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
5. Install the shroud retaining screws to the steering wheel. Tighten Tighten the screws to 2 N.m (18 lb in).
6. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .

Steering Wheel Replacement

Tools Required

1. J 1859-A Steering Wheel Puller
2. J-36541-A Steering Wheel Puller Adapter

Scheme 77

Scheme 78

Scheme 79

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the inflator module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(ref-160362-S23010603142004021000000) in Air Bag Restraint Systems.
3. Remove the horn plunger from the steering column by pressing inward to the stop and rotating horn plunger 90 degrees.
4. Disconnect the steering wheel electrical connector.
5. Remove the retaining nut which secures the steering wheel to the steering wheel shaft. NOTE: When removing the steering wheel, use only the specified steering wheel puller. Do not hammer on the end of the steering column shaft. Hammering could loosen the plastic injections which maintain the steering column rigidity.
6. Install J 1859-A and J-36541-A to the steering wheel.
7. Remove the steering wheel using J 1859-A and J-36541-A.

Scheme 80

Scheme 81

1. Install the steering wheel to the steering wheel shaft. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
2. Install the retaining nut that secures the steering wheel to the steering wheel shaft. Tighten Tighten the retaining nut to 41 N.m (30 lb ft).
3. Connect the steering wheel electrical connector.
4. Install the horn plunger to the steering column.
5. Install the inflator module. Refer to «REMOVAL & INSTALLATION (DRIVER-SIDE)»(ref-160362-S23010603142004021000000) in Air Bag Restraint Systems.
6. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Steering Wheel Theft Deterrent Lock Replacement

Scheme 82

Scheme 83

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
3. Remove the connector (2) from the lock (1).
4. Pry the electric park lock (2) off of the ignition lock cylinder case assembly (1).

Scheme 84

Scheme 85

1. Snap the electric park lock (2) onto the ignition lock cylinder case assembly (1). CAUTION: Refer to «SIR INFLATOR MODULE COIL CAUTION»(ref-175132-S33913314732005041500000) In Cautions and Notices.
2. Reconnect the connector (2) to the electric park lock (1).
3. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
4. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Tilt Spring Replacement

Scheme 86

Scheme 87

Scheme 88

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
3. Use the tilt lever to tilt the column to the UP position. CAUTION: The tilt spring and the spring guide are under pressure. The tilt spring and the spring guide may become a projectile. Secure the spring with locking pliers during removal. Secure the spring with locking pliers during installation. Bodily Injury may result during removal and Installation of the tilt spring and the spring guide. Always use caution during removal and Installation of the tilt spring and the spring guide.
4. Remove one end of the tilt spring (1) from the steering column support assembly (2) and the other end from the steering column tilt head assembly (3) by using the following procedure: Pry up the tilt spring (1) until a bulge occurs and most of the tilt spring tension is removed. Secure the tilt spring (1) with locking pliers. Continue prying up the tilt spring (1) until the tilt spring disengages from the post on the steering column support assembly (2) and from the steering column tilt head assembly (3).
5. Remove the spring guide (1) from the tilt spring (2).

Scheme 89

Scheme 90

Scheme 91

1. Use the tilt lever to tilt the column to the UP position.
2. Install the spring guide (1) into the tilt spring (2).
3. Install the tilt spring (1) onto the steering column support assembly (2) and onto the steering column tilt head assembly by using the following procedure: Install the tilt spring (1) onto the steering column tilt head assembly. Install the tilt spring (1) onto the post on the steering column support assembly (2).
4. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
5. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Steering Column Tilt Head Housing Replacement

Tools Required

J 21854-01 Pivot Pin Remover

Scheme 92

Scheme 93

Scheme 94

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(ref-188488-S21259298782005090500000) .
3. Remove the ignition lock cylinder case assembly. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT»(ref-188488-S00394087222005090500000) .
4. Remove the turn signal and multifunction switch assembly. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(ref-188488-S16486232682005090500000) .
5. Remove the turn signal switch housing. Refer to «MULTIFUNCTION TURN SIGNAL SWITCH HOUSING REPLACEMENT»(ref-188488-S14200042222005090500000) .
6. Remove the tilt spring. Refer to «TILT SPRING REPLACEMENT»(ref-188488-S01938091632005090500000) .
7. Remove the 2 pivot pins (3) from the steering column tilt head assembly (1) using J 21854-01 .
8. Install the tilt lever into the steering column tilt head assembly (1).
9. Pull back on the tilt lever and at the same time pull the steering column tilt head assembly (1) down and away from the steering column.
10. Remove the steering column tilt head assembly (1) with the steering shaft assembly (3) from the steering column jacket assembly (2).
11. Remove the tilt lever.
12. Remove the steering shaft (1) from the steering column tilt head assembly.

Scheme 95

Scheme 96

Scheme 97

1. Install the steering shaft (1) into the steering column tilt head assembly.
2. Install the steering shaft (3) into the steering column tilt head assembly (1). Install the tilt head assembly (1) and the steering shaft (3) into the steering column jacket assembly (2). IMPORTANT: The steering wheel lock shoes teeth must be resting on the bar in the steering column jacket assembly.
3. Align the steering column tilt head assembly with the pivot pin holes on the steering column jacket assembly.
4. Lubricate the pivot pins with GM P/N 12346293 (Canadian P/N 992723). Install the 2 pivot pins into the steering column support assembly.
5. Stake the pins in 3 places.
6. Install the tilt spring assembly only. Refer to «TILT SPRING REPLACEMENT»(ref-188488-S01938091632005090500000) .
7. Install the turn signal switch housing only. Refer to «MULTIFUNCTION TURN SIGNAL SWITCH HOUSING REPLACEMENT»(ref-188488-S14200042222005090500000) .
8. Install the turn signal and multifunction switch assembly only. Refer to «MULTIFUNCTION, TURN SIGNAL SWITCH REPLACEMENT»(ref-188488-S16486232682005090500000) .
9. Install the ignition lock cylinder case assembly. Refer to «IGNITION LOCK CYLINDER CASE REPLACEMENT»(ref-188488-S00394087222005090500000) .
10. Install the steering column to the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(ref-188488-S21259298782005090500000) .
11. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Steering Column Replacement

Tools Required

J 42640 Steering Column Lock Pin

Note. Once the steering column is removed from the vehicle, the column is extremely susceptible to damage. Dropping the column assembly on the end could collapse the steering shaft or loosen the plastic injections, which maintain column rigidity.

Leaning on the column assembly could cause the jacket to bend or deform. Any of the above damage could impair the columns collapsible design. Do NOT hammer on the end of the shaft, because hammering could loosen the plastic injections, which maintain column rigidity. If you need to remove the steering wheel, refer to the Steering Wheel Replacement procedure in this section.

Note. The front wheels of the vehicle must be maintained in the straight ahead position and the steering column must be in the LOCK position before disconnecting the steering column or intermediate shaft. Failure to follow these procedures will cause improper alignment of some components during installation and result in damage to the SIR coil assembly.

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Lock the steering column through the access hole in the lower steering column trim cover using J 42640 .
3. Remove the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
4. Remove the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(ref-188875-S16055466122005090300000) in Instrument Panel, Gages and Console.
5. Disconnect the steering column electrical connector.
6. Disconnect the body wiring harness connector from the steering column lower bracket.
7. Remove the retaining screw (2) from the left HVAC floor duct (1).
8. Disconnect the left HVAC floor duct temperature sensor and remove the left HVAC floor duct.
9. Remove the intermediate shaft bolt from the steering column.
10. Remove the steering column mounting nuts.
11. Remove the steering column from the vehicle.

Scheme 103

Scheme 104

Scheme 105

Scheme 106

1. Install the steering column to the vehicle and connect the column to the intermediate shaft. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
2. Install the steering column mounting nuts. Tighten Tighten the nuts to 27 N.m (20 lb ft).
3. Install the intermediate shaft bolt to the steering column. Tighten Tighten the bolt to 50 N.m (37 lb ft).
4. Connect the left HVAC floor duct temperature sensor and install the left HVAC floor duct (1).
5. Install the mounting screw (2) to the left HVAC floor duct. Tighten Tighten the screw to 1.9 N.m (17 lb in).
6. Connect the body wiring harness connector to the steering column lower bracket.
7. Connect the steering column electrical connector to the vehicle wiring harness. Tighten Tighten the screw to 6 N.m (53 lb ft).
8. Install the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(ref-188875-S16055466122005090300000) in Instrument Panel, Gages and Console
9. Install the steering wheel. Refer to «STEERING WHEEL REPLACEMENT»(ref-188488-S03247854882005090500000) .
10. Unlock the steering column by removing J 42640 from the lower trim cover access hole.
11. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Steering Column Jacket Replacement

Scheme 107

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the steering column from the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(ref-188488-S21259298782005090500000) .
3. Inspect the steering column for accident damage. Refer to STEERING COLUMN ACCIDENT DAMAGE INSPECTION .
4. Remove the steering column tilt head. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT»(ref-188488-S23093722942005090500000) .
5. Remove the jacket.

Scheme 108

1. Install the jacket.
2. Install the steering column tilt head (1). Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT»(ref-188488-S23093722942005090500000) .
3. Install the steering column to the vehicle. Refer to «STEERING COLUMN REPLACEMENT»(ref-188488-S21259298782005090500000) .
4. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Steering Column Shaft Replacement

Scheme 109

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the steering column tilt head. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT»(ref-188488-S23093722942005090500000) .
3. Remove the steering shaft (1) from the steering column tilt head assembly.
4. Inspect the steering column for accident damage. Refer to «STEERING COLUMN ACCIDENT DAMAGE INSPECTION»(ref-188488-S34776594692005090500000) .

Scheme 110

1. Install the steering shaft (1) into the steering column tilt head assembly.
2. Install the steering column tilt head. Refer to «STEERING COLUMN TILT HEAD HOUSING REPLACEMENT»(ref-188488-S23093722942005090500000) .
3. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.

Steering Column Wire Harness Assembly Replacement

Scheme 111

Scheme 112

Scheme 113

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
2. Remove the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
3. Remove the wire harness strap.
4. Remove the steering wheel theft deterrent lock. Refer to «STEERING WHEEL THEFT DETERRENT LOCK REPLACEMENT»(ref-188488-S15991440502005090500000) .
5. Rotate the key alarm connector (1) 90 degrees.
6. Gently pull the key alarm connector (1) out of the ignition lock cylinder case assembly (2).
7. Disconnect the connector from the ignition switch assembly.
8. Remove the wires encased in the ignition switch clip, which is located on the side of the ignition switch. IMPORTANT: If the steering wheel has steering wheel controls, the SIR coil and the wire harness assembly must come off as one piece. Refer to «SIR COIL ASSEMBLY»(ref-160362-S39076576712004021000000) in Air Bag Restraint Systems.
9. Disconnect all connectors attached to the wire harness assembly.

Scheme 114

Scheme 115

Scheme 116

1. If the steering wheel has steering wheel controls, install the SIR coil. Refer to «SIR COIL ASSEMBLY»(ref-160362-S39076576712004021000000) in Air Bag Restraint Systems.
2. Connect all of the connectors from the new wire harness assembly.
3. Push the key alarm connector (1) into the ignition lock cylinder case assembly (2).
4. Rotate the key alarm connector (1) 90 degrees so that the key alarm connector (1) locks into place.
5. Install the steering wheel theft deterrent lock. Refer to «STEERING WHEEL THEFT DETERRENT LOCK REPLACEMENT»(ref-188488-S15991440502005090500000) . CAUTION: Refer to «SIR INFLATOR MODULE COIL CAUTION»(ref-175132-S33913314732005041500000) In Cautions and Notices.
6. Install the wires back into the ignition switch clip (located on the side of the ignition switch).
7. Install the wire harness strap.
8. Install the upper and lower trim covers. Refer to «STEERING COLUMN TRIM COVERS REPLACEMENT»(ref-188488-S00044326322005090500000) .
9. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160362-S00740615442004021000000) in Air Bag Restraint Systems.
