HVAC Systems - Automatic: Overview Chevrolet TrailBlazer I

Test Description

The numbers below refer to the step numbers on the diagnostic table.

1. 3. Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 5. Determine if the HVAC Control Module, Body Control Module, Auxiliary HVAC Control Module or Powertrain Control Module have set DTCs which may affect HVAC operation are present.
3. 6. The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
4. 7. Answer Yes if the first 3 characters of the DTC name begins with B10; regardless of the last 2 characters.

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

The numbers below refer to the step numbers on the diagnostic table.

1. 2. If more than one DTC is set, observe all of the Door Actual parameters for each corresponding DTC. If the door actual parameter is not out of range, then the concern is with the control portion of the actuator.
2. 7. The purpose of this step is to try to determine which actuator is internally shorted or if the auxiliary HVAC control module is creating the fault. After DTC are cleared, it can take up to 4 minutes for DTC to set.
3. 8. After DTC are cleared, it can take up to 4 minutes for DTC to set. The purpose of this step is to try to determine which actuator is internally shorted or if the auxiliary HVAC control module is creating the fault. If both DTCs return the auxiliary control module is internally shorted.
4. 10. The purpose of this step is to try to determine which actuator is internally shorted or if the auxiliary HVAC control module is creating the fault. After DTC are cleared, it can take up to 4 minutes for DTC to set.
5. 11. After DTC are cleared, it can take up to 4 minutes for DTC to set. The purpose of this step is to try to determine which actuator is internally shorted or if the auxiliary HVAC control module is creating the fault. If both DTCs return the auxiliary HVAC control module is internally shorted.
6. 14. If the scan tool does not display all three DTC, then the answer is No.
7. 15. If the scan tool does not display both DTC, then the answer is No.
8. 17. This step tests the low reference circuit.
9. 18. If the fused jumper opens, then the appropriate signal circuit is shorted to a power.
10. 19. If the scan tool parameter reads lower than 5 counts then the appropriate signal circuit is shorted to a ground.
11. 20. This step tests the 5-volt reference circuit. Test can be done with any auxiliary actuator. The auxiliary air temperature actuator can be accessed the quickest.
12. 22. If the scan tool displays one DTC when an actuator is disconnected, then the actuator that was disconnected is the area of the fault.
13. 29. The procedure for both auxiliary mode actuators are within the same replacement procedure.
14. 30. After a circuit repair, a recalibration of the actuators must be performed to ensure proper performance from the auxiliary HVAC system.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Circuit/System Description

The actuators operate using 5 circuits. A 5-volt reference, low reference, signal circuit and two bi-directional 0 or 12 volt control circuits. The HVAC control module supplies a low reference and 5-volt reference to the potentiometer. The HVAC control module monitors the voltage drop across the potentiometer on the door position signal circuit. As the actuator door changes position the door position signal circuit voltage also changes. The two bi-directional control circuits enable the actuator to operate. Both circuits are set to 0 volts when the HVAC control module detects, from the feedback potentiometer, that the actuator is in the desired position. In order to move the actuator, the HVAC control module switches the appropriate control circuit to 12 volts.

1. DTC B0150 is for the auxiliary mode actuator
2. DTC B0433 is for the auxiliary air temperature actuator
3. DTC B3782 is for the auxiliary mode actuator

Description and Operation

1. «Air Delivery Description and Operation»(ref-188486-S10611363402005090500000)
2. «HVAC Schematics»(ref-188486-S12838975552005090500000)

The number below refers to the step number on the diagnostic table.

1. 2. Verifies that the condition that set the DTC is present.

Scheme 78

The numbers below refer to the step numbers on the diagnostic table.

1. 2. Verifies that the value displayed is not within the calibrated range.
2. 3. Tests for the proper operation of the circuit in the high voltage range.
3. 4. Tests for the proper operation of the circuit in the low voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to voltage.

Scheme 79

Scheme 80

The numbers below refer to the step numbers on the diagnostic table.

1. 2. Verifies that the value displayed is within the specified range.
2. 3. Tests for the proper operation of the circuit in the high voltage range.
3. 4. Tests for the proper operation of the circuit in the low voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to voltage.

Scheme 81

Scheme 82

The numbers below refer to the step numbers on the diagnostic table.

1. 2. Tests for the proper operation of the circuit in the high voltage range. If the jumper fuse opens when you perform this test, the circuit is shorted to ground.
2. 6. Tests for the proper operation of the circuit in the high voltage range. If the jumper fuse opens when you perform this test, the circuit is shorted to ground.
3. 7. Tests for a short to voltage in the 5-volt reference circuit.
4. 8. Tests for a high resistance or for an open in the low reference circuit.
5. 9. This step tests for an open on the low reference circuit that is common to all of the actuators.
6. Choose the easiest HVAC door actuator that set a DTC to start the diagnosis.
7. 10. Disconnecting each actuator, one at a time, isolates the disconnected actuators signal circuit from the 5 volt reference circuit that is common to all the actuators.

Scheme 83

Scheme 84

Scheme 85

The numbers below refer to the step numbers on the diagnostic table.

1. 2. Determines if the HVAC door actuator is stalled.
2. 3. Applies control circuit voltages to the input of the HVAC door actuator.

Scheme 86

Scheme 87

The number below refers to the step number on the diagnostic table.

1. 3. Tests for the proper operation of the circuit in the low voltage range.

Scheme 88

Scheme 89

The numbers below refer to the step numbers on the diagnostic table.

1. 3. Tests for the proper operation of the circuit in the low voltage range.
2. 4. Tests for the proper operation of the circuit in the high voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to ground.
3. 5. Tests for a short to voltage in the 5-volt reference circuit.
4. 6. Tests for a high resistance or an open in the low reference circuit.

Scheme 90

Scheme 91

Scheme 92

1. Perform the «DIAGNOSTIC SYSTEM CHECK - HVAC SYSTEMS - AUTOMATIC»(ref-188486-S36099743792005090500000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control module(s) can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to the following information: «Air Delivery DESCRIPTION AND OPERATION»(ref-188486-S08152559522005090500000) «AIR TEMPERATURE DESCRIPTION AND OPERATION»(ref-188486-S04389379192005090500000)

The numbers below refer to the step numbers on the diagnostic table.

1. 2. The A/C compressor relay output is disabled if engine coolant temperature is above 123°C (253°F). The engine coolant indicator will illuminate at this temperature.
2. 3. This step ensures that the HVAC control module is receiving an input from the A/C switch.
3. 4. These actions will enable the A/C compressor to operate.
4. 5. This test ensures that there is sufficient refrigerant in the A/C system. The specific values come from the A/C System Performance Test in Heating, Ventilation and Air Conditioning.
5. 7. The A/C low pressure switch parameter is out of range when the HVAC control module interprets the signal being below 151 kPa (22 psi) or above 275 kPa (40 psi).
6. 8. This action will simulate a closed switch condition.
7. If the Pressure Cycle Switch parameter reads Low Pressure than there is a circuit condition or a condition with the HVAC control module.
8. 11. The A/C compressor relay output from the powertrain control module (PCM) is disabled if the A/C high side system pressure is interpreted to be higher than 2413 kPa (350 psi).

Scheme 93

Scheme 94

Scheme 95

Scheme 96

The number below refers to the step number on the diagnostic table.

1. 2. These actions will disable the HVAC control module output to powertrain control module (PCM).

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

The numbers below refer to the step numbers on the diagnostic table.

1. 6. The ambient air temperature display must be above 5°C (40°F) in order for this A/C compressor test to be run. Refer to «AMBIENT AIR TEMPERATURE UPDATE PROCEDURE»(ref-188486-S11474874212005090500000) if display reads less than 5°C (40°F).
2. 8. This step ensures that the lower air temperature sensors operate properly. The LH and RH Heater Duct Actual parameter count values should lower as the air temperature of the ducts get warmer. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
3. 9. This step ensures that the upper air temperature sensors operate properly. The LH and RH AC Duct Actual parameter count values should lower as the air temperature of the ducts get warmer.
4. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
5. 11. This action ensures that the internal fan of the inside air temperature sensor assembly is providing air flow across the internal sensor.
6. 14. Use the following table to determine that the recorded scan tool values are within range for the recorded probe temperatures of the J 43600 ACR Air Conditioning Service Center.

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

The number below refers to the step number in the diagnostic table.

1. 8. This step ensures that the lower air temperature sensors operate properly. The LH and RH Heater Duct Actual parameter count values should lower as the air temperature of the ducts get warmer. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
2. 9. This step ensures that the upper air temperature sensors operate properly. The LH and RH AC Duct Actual parameter count values should lower as the air temperature of the ducts get warmer.
3. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
4. 11. This action ensures that the internal fan of the inside air temperature sensor assembly is providing air flow across the internal sensor.
5. 15. Use the following table to determine that the recorded scan tool values are within range for the recorded probe temperatures of the J 43600 ACR Air Conditioning Service Center.

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This test resets HVAC control module and checks for current air temperature actuator DTC.
2. 4. This checks for proper airflow for each auxiliary blower motor speed position.

Scheme 129

The numbers below refers to the step number in the diagnostic table.

1. 7. To request A/C operation the primary HVAC controls must be set to enable the A/C compressor.
2. 11. If the test light remains illuminated the answer is No.
3. 19. The primary HVAC control module controls the coolant bypass valve. It receives a Class 2 message from the auxiliary HVAC control module for the proper position of valve.

Scheme 130

Scheme 131

Scheme 132

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This test resets HVAC control module and checks for current air temperature actuator DTC.
2. 4. This checks for proper airflow for each auxiliary blower motor speed position.

Scheme 133

The number below refers to the step number in the diagnostic table.

1. 16. The primary HVAC control module controls the coolant bypass valve. It receives a Class 2 message from the auxiliary HVAC control module for the proper position of valve.

Scheme 134

Scheme 135

Air Delivery Description and Operation

The air delivery description and operation is divided into 7 areas

1. HVAC Control Components
2. Air Speed
3. Auxiliary Air Speed
4. Air Delivery
5. Auxiliary Air Delivery
6. Recirculation Operation
7. Automatic Operation

Recirculation Operation

The HVAC control module controls the air intake through the recirculation actuator. The recirculation switch closes the recirculation door in order to circulate the air within the vehicle. The outside air switch opens the recirculation door in order to route outside air into the vehicle. Regardless of the blower motor switch position, recirculation is available only in the panel and bi-level mode switch positions. Including the OFF position. The mode switch must be placed in either the panel or bi-level position before the blower motor switch is placed in the OFF position. In order to reduce windshield fogging, outside air is circulated when the mode switch is in the defrost or defog positions. If the recirculation switch is pressed into the ON position when the mode switch is in an unavailable mode position, then the recirculation switch LED will flash 3 times. If the HVAC control module detects a fault with the recirc door the HVAC control module will try to drive the actuator for a predetermined amount of time, to outside air, which is the defaulted position for the recirculation actuator.

Automatic Operation

In automatic operation, the HVAC control module will maintain the comfort level inside of the vehicle by controlling the A/C compressor clutch, the blower motor, the air temperature actuators, mode actuator and recirculation.

To place the HVAC system in Automatic mode, the following is required

1. The Auto switch must be activated
2. The air temperature switch must be in any other position other than full hot or full cold position

Once the desired temperature is reached, the blower motor, mode, recirculation and temperature actuators will automatically be adjusted to maintain the temperature selected. The HVAC control module performs the following functions to maintain the desired air temperature

1. Monitor the following sensors: Inside air temperature sensor Ambient Air Temperature Sensor Lower Left Air Temperature Sensor Lower Right Air Temperature Sensor Upper Left Air Temperature Sensor Upper Right Air Temperature Sensor
2. Regulate blower motor speed
3. Position the air temperature actuator
4. Position the mode actuator
5. Position the recirculation actuator
6. Request A/C operation

Air Temperature Description and Operation

The air temperature controls are divided into 7 areas

1. HVAC Control Components
2. Heating and A/C Operation
3. Auxiliary Heating and A/C Operation
4. Automatic Operation
5. Steering Wheel Controls
6. Engine Coolant
7. A/C Cycle

Heating and A/C Operation

The purpose of the heating and A/C system is to provide heated and cooled air to the interior of the vehicle. The A/C system will also remove humidity from the interior and reduce windshield fogging. The vehicle operator can determine the passenger compartment temperature by adjusting the air temperature switch. The vehicle passenger can offset the passenger temperature as much as 16.7°C (30°F). Regardless of the temperature setting, the following can effect the rate that the HVAC system can achieve the desired temperature

1. Recirculation actuator setting
2. Difference between inside and desired temperature
3. Difference between ambient and desired temperature
4. Blower motor speed setting
5. Mode setting
6. Auxiliary HVAC settings

The control module makes the following actions when automatic operation is not selected, and an air temperature setting is selected

1. When the air temperature switch is placed in the warmest position, the control module commands the air temperature door to divert maximum air past the heater core.
2. When the air temperature switch is placed in the coldest position, the control module commands the air temperature door to direct air to bypass the heater core.
3. When the air temperature switch is placed between the warmest and coldest positions, the control module monitors the following sensor inputs to determine the air temperature door position that diverts the appropriate amount of air past the heater core in order to achieve the desired temperature: Sunload Duct temperatures Ambient temperature Inside temperature

The A/C system can be engaged by either pressing the A/C switch or during automatic operation. The HVAC control module sends a class 2 message to the PCM for A/C compressor engagement. The PCM will provide a ground for the A/C compressor relay enabling it to close its internal contacts to send battery voltage to the A/C compressor clutch coil. The A/C compressor diode will prevent a voltage spike, resulting from the collapse of the magnetic field of the coil, from entering the vehicle electrical system when the compressor is disengaged.

The following conditions must be met in order for the A/C compressor clutch to turn on

1. Ambient air temperature above 1°C (35°F)
2. A/C low pressure switch signal circuit is grounded
3. A/C refrigerant pressure sensor parameter is less than 2413 kPa (350 psi)
4. A/C compressor temperature switch contacts are closed
5. PCM receives an A/C request from the HVAC control module
6. Engine coolant temperature (ECT) is less than 123°C (253°F)
7. The engine RPM is more than 550 RPM
8. The throttle position is less than 100%

The HVAC control module monitors the A/C low pressure switch signal circuit. If the voltage signal on this circuit has no voltage drop the module will interpret this condition as a low pressure, disabling the A/C request. The A/C low pressure switch will open its internal contacts at 151 kPa (22 psi). Then close the contacts at 275 kPa (40 psi) to resume A/C operation. This switch assists in cycling the A/C compressor and prevents A/C compressor operation if system has a low refrigerant level.

The PCM monitors the A/C refrigerant pressure sensor signal circuit. The voltage signal on this circuit is proportional to the refrigerant pressure inside the A/C high side pressure line. As the pressure inside the line increases, so does the voltage signal. If the pressure is above 2413 kPa (350 psi), the A/C compressor output is disabled. When the pressure lowers to 1578 kPa (229 psi), the PCM enables the compressor to operate.

The sensor information is used by the PCM to determine the following

1. The A/C high side pressure
2. An A/C system load on the engine
3. An excessive A/C high side pressure
4. The heat load at the A/C condenser

The A/C compressor has an A/C compressor temperature switch. This switch protects the compressor from over heating. The switch interrupts power to the compressor clutch coil. When the compressor core temperature rises above 135°C (275°F) the switch opens, disabling the compressor clutch coil. When the temperature lowers to 120°C (248°F) the switch closes, enabling the compressor clutch coil. This switch is not a serviceable part, it is integral to the A/C compressor.

Once engaged, the compressor clutch will be disengaged for the following conditions

1. Ambient air temperature is less than 1°C (35°F)
2. A/C compressor temperature switch contacts are open
3. Throttle position is 100%
4. The A/C low pressure switch is open
5. A/C high side pressure is more than 2413 kPa (350 psi)
6. A/C low side pressure is less than 151 kPa (22 psi)
7. Engine coolant temperature (ECT) is more than 123°C (253°F)
8. Engine speed is more than 5500 RPM
9. Transmission shift
10. PCM detects excessive torque load
11. PCM detects insufficient idle quality
12. PCM detects a hard launch condition

Auxiliary Heating and A/C Operation

There are two separate controls for the auxiliary HVAC system. There is the front auxiliary blower motor switch and the auxiliary HVAC control module. If the front auxiliary blower motor switch is in any other position than OFF or REAR, then the auxiliary air temperature actuator mimics the set passenger temperature. The auxiliary mode will mimic the primary mode. If the front auxiliary blower motor switch is in the REAR position, then the system will only function with inputs to the auxiliary HVAC control module. If the front auxiliary blower motor switch is in the OFF position, then the auxiliary HVAC control module does not respond to input. The auxiliary HVAC control module can not request A/C operation from the PCM.

Pressing the UP air temperature switch to the warmest position diverts most of the airflow through the heater core, which increases the outlet air temperature. Pressing the DOWN air temperature switch to the coolest position diverts most of the airflow around the heater core, which decreases the outlet air temperature.

The auxiliary air temperature actuator shares a control circuit with the auxiliary mode actuator. If change of position is required for both actuators, then the module positions the auxiliary air temperature actuator first. All control circuits for the auxiliary actuators are at a low voltage potential until a change of position is required. The module then applies a high voltage potential to the appropriate control circuit, which will rotate the actuator.

The coolant bypass valve controls coolant flow to the auxiliary heater core. If a cool air temperature is selected, the auxiliary HVAC control module sends a class 2 message to the HVAC control module to close the valve. When the HVAC control module applies 12 volts to the coolant bypass solenoid control circuit, the solenoid opens. When the solenoid is open, a diaphragm closes the water valve when vacuum is applied. This action restricts coolant flow to the auxiliary heater core. The coolant bypass valve is a normally open valve.

In automatic operation, the HVAC control module will maintain the comfort level inside of the vehicle by controlling the A/C compressor clutch, the blower motor, the air temperature actuators, mode actuator and recirculation.

To place the HVAC system in Automatic mode, the following is required

1. The Auto switch must be activated
2. The air temperature switch must be in any other position other than full hot or full cold position

Once the desired temperature is reached, the blower motor, mode, recirculation and temperature actuators will automatically be adjusted to maintain the temperature selected. The HVAC control module performs the following functions to maintain the desired air temperature

1. Monitor the following sensors: Inside air temperature sensor Ambient Air Temperature Sensor Lower Left Air Temperature Sensor Lower Right Air Temperature Sensor Upper Left Air Temperature Sensor Upper Right Air Temperature Sensor
2. Regulate blower motor speed
3. Position the air temperature actuator
4. Position the mode actuator
5. Position the recirculation actuator
6. Request A/C operation
