Antilock Brake System: Specifications Chevrolet TrailBlazer I

Anti-Lock/traction Control 16 illustrations ~119 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
EBCM to BPMV5 N.m39 lb in
EHCU to Bracket9 N.m7 lb ft
EHCU Bracket Mounting Bolts25 N.m18 lb ft
Front Brake Lines to BPMV24 N.m18 lb ft
Front Wheel Speed Sensor Mounting Bolt17 N.m12 lb ft
Master Cylinder brake lines to BPMV24 N.m18 lb ft
Rear Brake Line to BPMV24 N.m18 lb ft
Steering Knuckle to Front Hub/Bearing Mounting Bolts104 N.m77 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: ABS Schematic Icons

Scheme 2

Scheme 2: ABS Schematics

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5: ABS Component Views

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8: ABS Connector End Views

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Begin the system diagnosis with DIAGNOSTIC SYSTEM CHECK - ABS . The Diagnostic System Check will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
