Power Window System: Diagnosis Chevrolet Tracker II

TROUBLE SHOOTING

Note. Some components incorporate a short wiring harness between component and harness connector. Wire color may be different from that used in main harness. See WIRING DIAGRAMS .

PRELIMINARY INSPECTION

Inspect P/W fuse (30-amp). Ensure ground (located behind left side of instrument panel, above junction block) is clean and tight. Ensure power window lock switch is in UNLOCK (released) position. Before component replacement, check for poor connections at related component and in-line harness connector terminals. If concern is still exists, diagnose by symptom. See SYMPTOM INDEX table under SYSTEM TESTS.

TEST A: ALL POWER WINDOWS INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000).
2. Turn ignition switch to RUN position. Check operation of all power windows with master power window switch and individual power window switches. If all power windows are inoperative from all power window switches, go to next step. If only one power window is inoperative, diagnose by symptom. See «SYMPTOM INDEX»(ref-121801-S04590128412001090800000) table. If power windows operate properly, diagnose intermittent concern. See appropriate BODY CONTROL MODULES article.
3. Disconnect master power window switch 11-pin harness connector. Measure voltage between ground and master power window switch harness connector terminal No. 1 (Blue/White wire). (Scheme 1) If battery voltage does not exist, go to next step. If battery voltage exists, go to step 5.
4. Repair open in Blue/White wire between master power window switch and junction block. After repair, go to step 6.
5. Repair open in Black wire between master power window switch and ground. Ground point is located under left side of instrument panel, above junction block. After repair, go to step 6.
6. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3.

Scheme 1

TEST B: LEFT FRONT POWER WINDOW INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000).
2. Turn ignition switch to RUN position. Check operation of left front power window switch. If left front power window is inoperative, go to next step. If left front power window is not inoperative, diagnose intermittent concern. See appropriate BODY CONTROL MODULES article.
3. With master power window switch in UP position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 11 (Yellow wire). With master power window switch in DOWN position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 10 (Red wire). (Scheme 1) If battery voltage exists at both terminals, go to next step. If battery voltage does not exist at either terminal, go to step 5.
4. Disconnect master power window switch 11-pin harness connector. Disconnect left front power window 2-pin harness connector. Measure resistance between master power window switch harness connector terminal No. 11 (Yellow wire) and left front power window harness connector terminal No. 1 (Green/Yellow wire). Measure resistance between master power window switch harness connector terminal No. 10 (Red wire) and left front power window harness connector terminal No. 2 (Red/Blue wire). (Scheme 1) If resistance is less than 2 ohms, go to step 6. If resistance is 2 ohms or more, go to step 7.
5. Inspect left front power window motor harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 9. After repair, go to step 10.
6. Inspect master power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 8. After repair, go to step 10.
7. Repair open in appropriate wire between left front power window motor and master power window switch. After repair, go to step 10.
8. Replace master power window switch. After repair, go to step 10.
9. Replace left front window motor. After repair, go to next step.
10. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3.

TEST C: RIGHT FRONT POWER WINDOW INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000).
2. Turn ignition switch to RUN position. Check operation of right front power window switch. If right front power window is inoperative, go to next step. If right front power window is not inoperative, diagnose intermittent concern. See appropriate BODY CONTROL MODULES article.
3. If right front power window is inoperative from right front power window switch only, go to next step. If right front power window is inoperative from master power window switch and right front power window switch, go to step 5.
4. Disconnect right front power window switch harness connector. Measure voltage between ground and right front power window switch harness connector terminal No. 3 (Blue/White wire). If battery voltage exists, go to step 7. If battery voltage does not exist, go to step 12.
5. While lifting right front power window switch in UP position, measure voltage between ground and right front power window switch harness connector by backprobing terminal No. 1 (Green/Black wire). While pressing right front power window switch in DOWN position, measure voltage between ground and right front power window switch harness connector by backprobing terminal No. 4 (Red/Black wire). If battery voltage does not exist at both terminals, go to next step. If battery voltage exists at both terminals, go to step 7.
6. While lifting master power window switch in UP position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 7 (Green/Black wire). While pressing master power window switch in DOWN position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 6 (Red/Black wire). (Scheme 1) If battery voltage exists at both terminals, go to step 9. If battery voltage does not exist at both terminals, go to step 14.
7. Turn ignition switch to lock position. Disconnect right front power window harness connector. Measure resistance between terminals No. 4 and 5, and between terminals No. 1 and 2 at right front power window switch with switch in NEUTRAL position. Measure resistance between terminals No. 3 and 5 at right front power window switch with switch in DOWN position and between terminals No. 2 and 3 at right front power window switch with switch in UP position. If resistance is less than 2 ohms for any test, go to next step. If resistance is 2 ohms or more for any test, go to step 10.
8. Disconnect master power window switch 11-pin harness connector. Disconnect right front power window 2-pin harness connector. Measure resistance between right front power window switch harness connector terminal No. 2 (Yellow wire) and right front power window motor harness connector terminal No. 1 (Green/Yellow wire). Measure resistance between right front power window switch harness connector terminal No. 5 (Red wire) and right front power window motor harness connector terminal No. 2 (Red/Blue wire). If resistance is less than 2 ohms, go to step 11. If resistance is 2 ohms or more, go to step 13.
9. Inspect master power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 16. After repair, go to step 18.
10. Inspect right front power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 15. After repair, go to step 18.
11. Inspect right front power window motor harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 17. After repair, go to step 18.
12. Repair open in Blue/White wire between right front window switch and junction block. After repair, go to step 18.
13. Repair open in appropriate wire between right front power window switch and right front power window motor. After repair, go to step 18.
14. Repair open in appropriate wire between master power window switch and right front power window switch. After repair, go to step 18.
15. Replace right front power window switch. After repair, go to step 18.
16. Replace master power window switch. After repair, go to step 18.
17. Replace right front power window motor. After repair, go to next step.
18. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3.

TEST D: LEFT REAR POWER WINDOW INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000) .
2. Turn ignition switch to RUN position. Check operation of left rear power window switch. If left rear power window is inoperative, go to next step. If left front power window is not inoperative, diagnose intermittent concern. See appropriate BODY CONTROL MODULES article.
3. If left rear power window is inoperative from left rear power window switch only, go to next step. If left rear power window is inoperative from master power window switch and left rear power window switch, go to step 5 .
4. Measure voltage between ground and left rear power window switch harness connector by backprobing terminal No. 3 (Blue/White wire). If battery voltage exists, go to step 7 . If battery voltage does not exist, go to step 12 .
5. While lifting master power window switch in UP position, measure voltage between ground and left rear power window switch harness connector by backprobing terminal No. 1 (Green/Black wire). While pressing master power window switch in DOWN position, measure voltage between ground and left rear power window switch harness connector by backprobing terminal No. 4 (Red/Black wire). If battery voltage does not exist at both terminals, go to next step. If battery voltage exists at both terminals, go to step 7 .
6. While lifting master power window switch in UP position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 5 (Green/Yellow wire). While pressing master power window switch in DOWN position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 4 (Red/Yellow wire). If battery voltage exists at both terminals, go to step 9 . If battery voltage does not exist at both terminals, go to step 14 .
7. Turn ignition switch to lock position. Disconnect left rear power window harness connector. Measure resistance between terminals No. 4 and 5, and between terminals No. 1 and 2 at left rear power window switch with switch in NEUTRAL position. Measure resistance between terminals No. 3 and 5 at left rear power window switch with switch in DOWN position and between terminals No. 2 and 3 at left rear power window switch in with switch in UP position. If resistance is less than 2 ohms for any test, go to next step. If resistance is 2 ohms or more for any test, go to step 10 .
8. Disconnect master power window switch 11-pin harness connector. Disconnect left rear power window 2-pin harness connector. Measure resistance between left rear power window switch harness connector terminal No. 2 (Yellow wire) and left rear power window motor harness connector terminal No. 1 (Green/Yellow wire). Measure resistance between left rear power window switch harness connector terminal No. 5 (Red wire) and left rear power window motor harness connector terminal No. 2 (Red/Blue wire). If resistance is less than 2 ohms, go to step 11 . If resistance is 2 ohms or more, go to step 13 .
9. Inspect master power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 16 . After repair, go to step 18 .
10. Inspect left rear power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 15 . After repair, go to step 18 .
11. Inspect left rear power window motor harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 17 . After repair, go to step 18 .
12. Repair open in Blue/White wire between left rear window switch and junction block. After repair, go to step 18 .
13. Repair open in appropriate wire between left rear power window switch and left rear power window motor. After repair, go to step 18 .
14. Repair open in appropriate wire between master power window switch and left rear power window switch. After repair, go to step 18 .
15. Replace left rear power window switch. After repair, go to step 18
16. Replace master power window switch. After repair, go to step 18 .
17. Replace left rear power window motor. After repair, go to next step.
18. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3 .

TEST E: RIGHT REAR POWER WINDOW INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000).
2. Turn ignition switch to RUN position. Check operation of right rear power window. If right rear power window is inoperative, go to next step. If right rear power window is not inoperative, diagnose intermittent concern. See appropriate BODY CONTROL MODULES article.
3. If right rear power window is inoperative from right rear door switch only, go to next step. If right rear power window is inoperative from both door and master power window switch, go to step 5.
4. Measure voltage between ground and right rear power window switch harness connector by backprobing terminal No. 3 (Blue/White wire). If battery voltage exists, go to step 7. If battery voltage does not exist, go to step 12.
5. While lifting master power window switch in UP position, measure voltage between ground and right rear power window switch harness connector by backprobing terminal No. 1 (Green/Black wire). While pressing master power window switch in DOWN position, measure voltage between ground and right rear power window switch harness connector by backprobing terminal No. 4 (Red/Black wire). If battery voltage does not exist at both terminals, go to next step. If battery voltage exists at both terminals, go to step 10.
6. While lifting master power window switch in UP position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 3 (Green/White wire). While pressing master power window switch in DOWN position, measure voltage between ground and master power window switch harness connector by backprobing terminal No. 2 (Red/White wire). (Scheme 1) If battery voltage exists at both terminals, go to step 9. If battery voltage does not exist at both terminals, go to step 14.
7. Turn ignition switch to lock position. Disconnect right rear power window harness connector. Measure resistance between terminals No. 4 and 5, and between terminals No. 1 and 2 at right rear power window switch with switch in NEUTRAL position. Measure resistance between terminals No. 3 and 5 at right rear power window switch with switch in DOWN position and between terminals No. 2 and 3 at right rear power window switch in with switch in UP position. If resistance is less than 2 ohms for all test, go to next step. If resistance is 2 ohms or more for any test, go to step 10.
8. Disconnect master power window switch 11-pin harness connector. Measure resistance between right rear power window switch harness connector terminal No. 2 (Yellow wire) and right rear power window motor harness connector terminal No. 1 (Green/Yellow wire). Measure resistance between right rear power window switch harness connector terminal No. 5 (Red wire) and right rear power window motor harness connector terminal No. 2 (Red/Blue wire). If resistance is less than 2 ohms for both tests, go to step 11. If resistance is 2 ohms or more for either test, go to step 13.
9. Inspect master power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 16. After repair, go to step 18.
10. Inspect right rear power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 15. After repair, go to step 18.
11. Inspect right rear power window motor harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to step 17. After repair, go to step 18.
12. Repair open in Blue/White wire between right rear window switch and junction block. After repair, go to step 18.
13. Repair open in appropriate wire between right rear power window switch and right rear power window motor. After repair, go to step 18.
14. Repair open in appropriate wire between master power window switch and right rear power window switch. After repair, go to step 18.
15. Replace right rear power window switch. After repair, go to step 18
16. Replace master power window switch. After repair, go to step 18.
17. Replace right rear power window motor. After repair, go to next step.
18. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3.

TEST F: AUTO DOWN FUNCTION INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000) .
2. Turn ignition switch to RUN position. Check operation of AUTO DOWN function. If only AUTO DOWN function is inoperative, go to next step. If other power window systems are inoperative, diagnose by symptom. See «SYMPTOM INDEX»(ref-121801-S04590128412001090800000) table.
3. Inspect master power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to next step.
4. Replace master power window switch. After repair, go to next step.
5. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3 .

TEST G: LOCK-OUT FUNCTION INOPERATIVE

Note. To identify harness connectors and terminals, see WIRING DIAGRAMS .

1. Review description and operation of power window system, then go to next step. See «DESCRIPTION & OPERATION»(ref-121801-S09468190622001090600000) .
2. Turn ignition switch to RUN position. Check operation of lock-out function. If only lock-out function is inoperative, go to next step. If other power windows are inoperative, diagnose by symptom. See «SYMPTOM INDEX»(ref-121801-S04590128412001090800000) table.
3. Inspect master power window switch harness connector for poor connections or intermittent condition. See appropriate BODY CONTROL MODULES article. If concern still exists, go to next step.
4. Replace master power window switch. After repair, go to next step.
5. Operate system to verify repair. If concern does not exist, system is okay. If concern still exists, go to step 3 .
