BELT ADJUSTMENT - CARS
| Application | Specification |
|---|
| Serpentine Belt | (1) 30-50 Lbs. (13.6-22.7 kg.) |
| Deflection @ 22 Lbs. (10.0 kg.) |
| Except Serpentine Belt |
| Metro & Firefly (Canadian) |
| A/C Compressor & Power Steering Pump | .28-.35" (7.0-9.0 mm) |
| Generator | .24-.31" (6-8 mm) |
| (1) Serpentine belt is automatically adjusted by tensioner. Tension is checked with belt tension gauge. If tension is not as specified, check belt length and tensioner operating range. Replace belt or tensioner as necessary. |
| (1) | Serpentine belt is automatically adjusted by tensioner. Tension is checked with belt tension gauge. If tension is not as specified, check belt length and tensioner operating range. Replace belt or tensioner as necessary. |
BELT ADJUSTMENT - TRUCKS
| Application | (1) Lbs. (kg) |
|---|
| All Models | (1) |
| (1) Serpentine belt tension is maintained automatically by a spring-tensioned idler pulley. No adjustment is necessary. |
| (1) | Serpentine belt tension is maintained automatically by a spring-tensioned idler pulley. No adjustment is necessary. |
SERPENTINE BELT ROUTING & ALIGNMENT
Note. For serpentine belt routing, see underhood label or refer to appropriate illustrations.
Scheme 1
Scheme 1: Serpentine Belt Routing (1.8L Prizm)
Scheme 2
Scheme 2: Serpentine Belt Routing (1.9L Saturn DOHC)
Scheme 3
Scheme 3: Serpentine Belt Routing (1.9L Saturn SOHC)
Scheme 4
Scheme 4: Serpentine Belt Routing (2.0L Tracker)
Scheme 5
Scheme 5: Serpentine Belt Routing (2.2L "J" Body)
Scheme 6
Scheme 7
Scheme 7: Serpentine Belt Routing (2.2L "S" Series)
Scheme 8
Scheme 8: Serpentine Belt Routing (2.2L Saturn)
Scheme 9
Scheme 9: Serpentine Belt Routing (2.4L "J" & "N" Bodies)
Scheme 10
Scheme 10: Serpentine Belt Routing (2.5L Tracker)
Scheme 11
Scheme 11: Serpentine Belt Routing (3.0L Saturn)
Scheme 12
Scheme 12: Serpentine Belt Routing (3.0L "V" Body)
Scheme 13
Scheme 13: Serpentine Belt Routing (3.1 "W" Body)
Scheme 14
Scheme 14: Serpentine Belt Routing (3.4L "N", "W" & "Z" Bodies, & "A", "B" & "U" Series)
Scheme 15
Scheme 15: Serpentine Belt Routing (3.5L "N" & "W" Bodies)
Scheme 16
Scheme 16: Serpentine Belt Routing (3.8L "C", "G", "H" & "W" Bodies)
Scheme 17
Scheme 17: Serpentine Belt Routing (3.8L "F" Body)
Scheme 18
Scheme 18: Serpentine Belt Routing (4.0L "G" Body & 4.6L "E" & "K" Bodies)
Scheme 19
Scheme 19: Serpentine Belt Routing (4.3L, 5.0L, 5.7L & 7.4L, "S" & "T" Series)
Scheme 20
Scheme 20: Serpentine Belt Routing (4.8L, 5.3L & 6.0L "C" & "K" Series)
Scheme 21
Scheme 21: Serpentine Belt Routing (5.7L "F" Body)
Scheme 22
Scheme 22: Serpentine Belt Routing (5.7L "Y" Body)
Scheme 23
Scheme 23: Serpentine Belt Routing (6.5L Turbo-Diesel "C", "G" & "K" Series With Dual Generators)
Scheme 24
Scheme 24: Serpentine Belt Routing (6.5L Turbo-Diesel "C", "G" & "K" Series Without Dual Generators)
Scheme 25
Scheme 25: Serpentine Belt Routing (6.6L Turbo-Diesel "C" & "K" Series)
Scheme 26
Scheme 26: Serpentine Belt Routing (8.1L "C", "G" &"K" Series )
