Cellular Systems, Entertainment Systems & Navigation Systems: Specifications Chevrolet Tahoe III

Entertainment Systems 19 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Amplifier Screw9 N.m80 lb in
Antenna Assembly Screw5 N.m44 lb in
Antenna Mast6 N.m53 lb in
Antenna Module Bolt9 N.m80 lb in
Antenna Module Ground Strap2 N.m18 lb in
Communication Interface Module Screw2 N.m18 lb in
Digital Radio Antenna Retaining Bolt9 N.m80 lb in
Front Floor Console Screw9 N.m80 lb in
Front Floor Console Bracket Screw9 N.m80 lb in
Front Floor Console Speaker Nut9 N.m80 lb in
Front Speaker Screw6 N.m53 lb in
Front Door Speaker Screw3 N.m25 lb in
Mobile Telephone Antenna Screw2 N.m18 lb in
Radio Retaining Screws2 N.m18 lb in
Rear Speaker Screw3 N.m25 lb in
Rear Door Speaker Screw3 N.m25 lb in
Roof Console Screw2 N.m18 lb in
Video Display Assembly Screw2 N.m18 lb in

Scheme 1

Scheme 1: Radio/Navigation System Schematics
Scheme 1: Radio/Navigation System Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: OnStar Schematics
Scheme 11: OnStar Schematics

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: Video System Schematics
Scheme 13: Video System Schematics

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19
