Diagnostic Starting Point - Cellular Communication
Begin the diagnosis of the system by performing the Diagnostic System Check for the system in which the customer concern is apparent. Diagnostic System Check - Cellular Communication will direct you to the correct procedure for diagnosing the system and where the procedure is located.
Scan Tool Data List
| Scan Tool Parameter | Data List | Units Displayed | Typical Data Value |
|---|---|---|---|
| Ignition ON with engine OFF | |||
| 8-Digit GM Part Number | Module 2 | 8 Digits | 93807890 |
| Component Serial Number 13-16 | Module 1 | 4 Digits | 0007 |
| Electronic Serial Number | Module 2 | 11 Digits | 16832516749 |
| Julian Date of Build | Module 1 | 3 Digits | 067 |
| Module I.D. | Module 2 | Alpha-numeric | Generation 3 |
| Software I.D. | Module 1 | 3 Digits | 146 |
| VCI Module Station I.D. | Module 2 | 10 Digits | 0002086783 |
| Year Module Built | Module 1 | 4 Digits | 2001 |
Scan Tool Data List
Diagnostic Trouble Code (DTC) List
| DTC | Diagnostic Procedure | Module(s) |
|---|---|---|
| B2462 | DTC B2462 | OnStar® VIU |
| B2476 | DTC B2476 | OnStar® VIU |
| U1500 | DTC U1500 | OnStar® VIU |
Diagnostic Trouble Code (DTC) List
Circuit Description
This vehicle will be equipped with either a stand alone navigation antenna or a combination cellular and navigation antenna. The navigation antenna is connected to the VIU with a RG-174 coax cable. The VIU polls the data from the antenna every 2.5 seconds.
Conditions for Running the DTC
- The ignition must be in the RUN or ACC position.
- The system voltage is at least 9.5 volts and no more than 15.5 volts.
- All the above conditions are present for greater than 2.5 seconds.
Conditions for Setting the DTC
- The VIU does not detect a navigation signal.
- All the above conditions are present for greater than 2.5 seconds.
Action Taken When the DTC Sets
- The OnStar® status LED turns RED.
- The OnStar® Call Center cannot locate the vehicle.
Conditions for Clearing the DTC
- The VIU detects the presence of a navigation antenna.
- A history DTC clears after 50 malfunction free ignition cycles.
- The VIU receives the clear DTC command from the scan tool.
The OnStar® button assembly consists of three buttons, Call/Answer, OnStar® Call Center and OnStar® Emergency. Ten volts is supplied to the button assembly on the keypad supply voltage circuit. Each of the buttons, when pressed, completes the circuit across a resister allowing a specific voltage to be returned to the VIU on the keypad signal circuit. Depending upon the voltage range returned, the VIU is able to identify which button has been pressed.
- The ignition must be in the RUN or ACC position.
- The system voltage is at least 9.5 volts and no more than 15.5 volts.
- All the above conditions are present for greater than 300 ms.
- The keypad signal circuit voltage to the VIU is less than 2.8 volts or more than 3.2 volts.
- All the above conditions are present for greater than 300 ms.
- The VIU will ignore all inputs from the OnStar® button assembly.
- No calls can be placed.
- The OnStar® status LED turns RED.
- The keypad signal circuit voltage is between 2.8 volts and 3.2 volts.
- A history DTC clears after 50 malfunction free ignition cycles.
- The VIU receives the clear DTC command from the scan tool.
The Vehicle Communication Unit (VCU) and the Vehicle Interface Unit (VIU) communicate using the OnStar® Serial Data (-) circuit, OnStar® Serial Data (+) circuit and the OnStar® Serial Data Return circuit. DTC U1500 is set when the VIU detects no communication between the VIU and the VCU.
- The ignition must be in the RUN or ACC position.
- The system voltage is at least 9.5 volts and no more than 15.5 volts.
- All the above conditions are present for greater than 300 ms.
- The VIU detects an open, short to ground or short to B+ on the serial data return circuit.
- The VIU detects an open, short to ground or short to B+ on serial data (-) circuit.
- The VIU detects an open, short to ground or short to B+ on serial data (+) circuit.
- The VIU detects an open on the battery positive voltage circuit.
- All the above conditions are present for greater than 300 ms.
- The VIU does not communicate with the VCU.
- No calls can be placed.
- The OnStar® status LED turns RED.
- The VIU does not detect an open, short to ground or short to B+ on the serial data return circuit.
- The VIU does not detect an open, short to ground or short to B+ on serial data (-) circuit.
- The VIU does not detect an open, short to ground or short or B+ on serial data (+) circuit.
- The VIU does not detect an open on the battery positive voltage circuit.
- A history DTC clears after 50 malfunction free ignition cycles.
- The VIU receives the clear DTC command from the scan tool.
Diagnostic Aids
- The customer concern may have been due to a lack of cellular service in a given area or a failure in the National Cellular Network infrastructure that has since been corrected.
- If the prompt "OnStar request ended" is heard without depressing the white "dot" button at the end of the an OnStar® keypress, the OnStar® system at one time has made a successful cellular connection but was unable to complete the call. If repeated calls are placed with this result, contact the General Motors Technical Assistance Center.
- Inaccurate or aged GPS position may have been due to the temporary loss of GPS signal reception by the vehicle in instances such as driving through tunnels or parking structures which restrict the GPS antenna from a clear view of the satellites in the sky.
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Did you perform the Diagnostic System Check? | Go to Step 2 | Go to Diagnostic System Check - Cellular Communication |
| 2 | Turn ON the ignition, with the engine OFF. Observe the OnStar® status LED Does the LED turn Green? | Go to Step 3 | Go to OnStar Button LED Inoperative |
| 3 | Turn the radio ON Set volume to a comfortable level Press the OnStar® Call Center button Wait approximately 10 seconds then end the call by pressing the white "dot" button. Does both the OnStar® LED blink after the OnStar® keypress is made and the call ended after pressing the white "dot" button? | Go to Step 4 | Go to OnStar One or More Buttons Inoperative |
| 4 | After the OnStar® keypress does both the radio mute and is the "Connecting to OnStar" message heard playing through the audio system? | Go to Step 5 | Go to No (or Noisy) OnStar Audio |
| 5 | IMPORTANT: It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and GPS data can be received from satellites. Press the OnStar® Call Center button Wait for the system to either connect or end the call Is a connection made with OnStar? | Go to Step 6 | Go to Step 9 |
| 6 | IMPORTANT: : It is necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. Ask the OnStar® Call Center advisor if your voice can clearly be heard.Does the advisor clearly hear your voice? | Go to Step 7 | Go to Microphone Inoperative - Caller Cannot Be Heard |
| 7 | Ask the OnStar® Call Center Advisor if they have received any data from the customer vehicle. Did data transfer of the OnStar® call occur? | Go to Step 8 | Go to Step 11 |
| 8 | Ask the OnStar® Call Center advisor if the vehicle has ever been configured. Has the vehicle been configured? | Go to Step 10 | Go to Step 16 |
| 9 | Is the audio prompt "Unable to Contact OnStar" heard? | Go to Unable to Contact OnStar Call Center | Go to Step 12 |
| 10 | Ask the OnStar® Call Center advisor to verify the Vehicle Identification Number (VIN) which they have on record and ensure it matches the actual VIN. Does the Vehicle Identification Number at the OnStar® Call Center match the Vehicle Identification Number of the vehicle? | Go to Step 13 | Go to Step 15 |
| 11 | Ask the OnStar® Call Center advisor if this call was a "fail to voice". Was this call a fail to voice? | Use the scan tool to access the STID and ESN and contact the General Motors Technical Assistance Center | |
| 12 | Is the audio prompt "OnStar® Request Ended" heard? | Go to Diagnostic Aids | |
| 13 | Ask the OnStar® Call Center advisor to verify your position. Is the location provided by the OnStar® Call Center advisor within a reasonable distance from the actual location of the vehicle? | Go to Step 14 | Go to Global Positioning System (GPS) Data Not Current or Inaccurate |
| 14 | Ask the OnStar® Call Center Advisor if the GPS position is marked as "Current". Is the GPS position current? | Go to Step 17 | Go to Global Positioning System (GPS) Data Not Current or Inaccurate |
| 15 | Ask the OnStar® Call Center advisor to update the customer account with the correct information. Has the customer account been updated? | Go to Step 16 | |
| 16 | Ask the OnStar® Call Center advisor to perform a Reconfiguration on the vehicle. Was the Reconfiguration successful? | Go to Step 18 | Ask the OnStar® Call Center advisor why the reconfiguration was not successful, use the scan tool to access the STID and ESN and contact the General Motors Technical Assistance Center |
| 17 | Is the customer concern with the inability of the OnStar® Call Center to perform remote functions? | Go to OnStar Call Center Remote Function Requests Inoperative | Go to Diagnostic Aids |
| 18 | Operate the system in order to verify the customer concern has been corrected. Has the customer concern been corrected? | System OK | Go to Step 2 |
| IMPORTANT |
|---|
| It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and GPS data can be received from satellites. |
| IMPORTANT |
|---|
| It is necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. |
OnStar Symptom Diagnosis
Symptoms - Cellular Communication
| IMPORTANT | The following steps must be completed before using the symptom tables. |
- Perform the «Diagnostic System Check - Cellular Communication»(ref-189228-S28641353172005090700000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
- Review the system operation in order to familiarize yourself with the system functions. Refer to «OnStar Description and Operation»(ref-189228-S37924554612005090700000) .
Visual/Physical Inspection
- Inspect for aftermarket devices which could affect the operation of the system. Refer to «CHECKING AFTERMARKET ACCESSORIES»(ref-175720-S08180388062005042600000) .
- Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
Symptom List
Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom
- «OnStar One or More Buttons Inoperative»(ref-189228-S23177476832005090700000)
- «Unable to Contact OnStar Call Center»(ref-189228-S37209516372005090700000)
- «OnStar Call Center Unable to Configure OnStar (R) System»(ref-189228-S33932142502005090700000)
- «OnStar Button LED Inoperative»(ref-189228-S11790003852005090700000)
- «No (or Noisy) OnStar Audio»(ref-189228-S02916422942005090700000)
- «Microphone Inoperative - Caller Cannot Be Heard»(ref-189228-S10674584172005090700000)
- «OnStar Always On»(ref-189228-S00591105952005090700000)
- «Voice Recognition Inoperative»(ref-189228-S00662533802005090700000)
- «OnStar Reconfiguration»(ref-189228-S01889989182005090700000)
- «Global Positioning System (GPS) Data Not Current or Inaccurate»(ref-189228-S10292022302005090700000)
- «OnStar Call Center Remote Function Requests Inoperative»(ref-189228-S36660065152005090700000)
The customer concern may have been due to a lack of cellular service in a given area or a failure in the National Cellular Network infrastructure that has since been corrected.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: OnStar Schematics Connector End View Reference: Cellular Communication Connector End Views | |||
| 1 | Did you perform the Cellular Communication Diagnostic System Check? | Go to Step 2 | Go to Diagnostic System Check - Cellular Communication |
| 2 | Attempt to honk the horn, operate the lights and lock or unlock the doors on the vehicle. Does the applicable system operate properly? | Go to Step 3 | Go to DIAGNOSTIC STARTING POINT - HORNS DIAGNOSTIC STARTING POINT - LIGHTING SYSTEMS DIAGNOSTIC STARTING POINT - DOORS |
| 3 | IMPORTANT: It is necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. Contact the OnStar® Call Center by pressing the blue OnStar® button. Ask the OnStar® advisor to perform a remote function (door lock/unlock, light flash, or horn honk). Was the attempt successful? | Go to Diagnostic Aids | Use the scan tool to access the STID and ESN and contact the General Motors Technical Assistance Center |
| IMPORTANT |
|---|
| It is necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. |
OnStar Call Center Remote Function Requests Inoperative
- The customer concern may have been due to a lack of cellular service in a given area. A failure in the National Cellular Network infrastructure at the time of the customer's failed connection that has since been repaired may also have been the cause.
- If an OnStar Emergency call is able to successfully connect the vehicle to the OnStar Call Center when an OnStar Call Center button press is not, there may be a failure in the ability of the OnStar system in the vehicle to be recognized by the local cellular carrier.
- If the prompt "OnStar request ended" is heard without depressing the white "Dot" button at the end of the an OnStar keypress, the OnStar system at one time has made a successful cellular connection but was unable to complete the call. If repeated calls are placed with this result, contact the General Motors Technical Assistance Center.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: OnStar Schematics DEFINITION: When the OnStar® Call Center button is pressed, no connection is made to the OnStar® Call Center. | ||||
| 1 | Did you perform the Cellular Communication Diagnostic System Check? | Go to Step 2 | Go to Diagnostic System Check - Cellular Communication | |
| 2 | IMPORTANT: It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and GPS data can be received from satellites. Hold down the answer/end call button (button with a white dot) until the LED turns from green to red and back to green. Press the OnStar® Call Center button. Wait for the system to either connect or end the call. Is a connection made with the OnStar Call Center? | Go to Diagnostic Aids | Go to Step 3 | |
| 3 | Other than the prompt "Unable to Contact OnStar", were any other tones or messages heard? | Go to Step 4 | Go to Step 6 | |
| 4 | Was a fast, busy beep heard? | Go to Step 7 | Go to Step 5 | |
| 5 | Were any cellular messages heard? | Record all cellular messages, use the scan tool to access the STID, ESN, and Transceiver I.D. and contact the General Motors Technical Assistance Center | Go to Step 8 | |
| 6 | Was the prompt "OnStar Request Ended" heard? | Go to Diagnostic Aids | ||
| 7 | IMPORTANT: Placing an emergency call to the OnStar Call Center should only be made if the diagnosis of the system leads to this step. Immediately after an OnStar advisor picks up the call, they should be told that this call is for diagnostic purposes only and there is no emergency. Press the OnStar® Emergency button.Does the emergency keypress call make a connection to the OnStar® Call Center within 10 minutes? | Go to Diagnostic Aids | Go to Step 8 | |
| 8 | Inspect the Cellular antenna for exterior damage. Is the antenna assembly damaged? | Go to Step 12 | Go to Step 9 | |
| 9 | Disconnect the Cellular antenna coax from the Vehicle Communication Unit. Disconnect the Cellular antenna coax from the cellular antenna. Measure the resistance from the center conductor of the coax to the metal outer shield. Does the meter read out of limits? | Go to Step 10 | Go to Step 11 | |
| 10 | Measure the resistance of the cellular antenna coax center conductor from end to end. Does the resistance measure greater than the specified value? | 1ohms | Go to Step 11 | Go to Step 13 |
| 11 | Replace the Cellular antenna coax. Did you complete the replacement? | Go to Step 14 | ||
| 12 | Replace the Cellular antenna assembly. Did you complete the replacement? | Go to Step 14 | ||
| 13 | Test the following circuits for an open: OnStar® Serial data return OnStar® Serial data (-) OnStar® Serial data (+) Refer to CIRCUIT TESTING in Wiring Systems. Did you find and correct the condition? | Go to Step 14 | Contact the General Motors Technical Assistance Center | |
| 14 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 | |
| IMPORTANT |
|---|
| It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and GPS data can be received from satellites. |
| IMPORTANT |
|---|
| Placing an emergency call to the OnStar Call Center should only be made if the diagnosis of the system leads to this step. Immediately after an OnStar advisor picks up the call, they should be told that this call is for diagnostic purposes only and there is no emergency. |
Unable to Contact OnStar Call Center
- The GPS Signal title on the scan tool will display a "Yes" or "No" dependant upon whether or not the module sees an increment of the seconds transmitted by GPS signals to the Vehicle Interface Unit. Upon entering this screen, the "GPS Signal" title will automatically display "Yes", regardless of the presence of time increment, for at least two seconds, while the algorithm in the scan tool determines the status of the clock. If increment is found, "Yes" is continually displayed. If the clock remains static, "No" is displayed. The scan tool looks for increment every second, regardless of current display.
- Inaccurate or aged GPS position concerns made by a customer which are no longer present may have been due to the temporary loss of GPS signal reception by the vehicle. Conditions such as driving through tunnels or parking structures while making an OnStar® keypress will restrict the navigation antenna from a clear view of the satellites in the sky and may have caused this temporary data loss.
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| Schematic Reference: OnStar Schematics Connector End View Reference: Cellular Communication Connector End Views | ||||
| 1 | Did you perform the Cellular Communication Diagnostic System Check? | Go to Step 2 | Go to Diagnostic System Check - Cellular Communication | |
| 2 | IMPORTANT: It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and global positioning system (GPS) data can be received from satellites. It is also necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. With a scan tool, observe the GPS signal status indicator in the GPS Data Display menu, for at least 10 seconds.Does the indicator display "Yes"? | Go to Step 3 | Go to Step 6 | |
| 3 | Press the OnStar® Call Center button. Ask the OnStar® Call Center advisor if they have received GPS data. Has the advisor received GPS data? | Go to Step 4 | Go to Step 5 | |
| 4 | Ask the OnStar® Call Center advisor to verify your position. Is the location provided by the OnStar® Call Center advisor within a reasonable distance from the actual location of the vehicle? | Go to Diagnostic Aids | Go to Step 10 | |
| 5 | Ask the OnStar® Call Center advisor if this call was a fail to voice. Was the call a fail to voice? | Contact the General Motors Technical Assistance Center | Go to Step 6 | |
| 6 | Disconnect the navigation antenna coax from the navigation antenna within the wiring harness. Disconnect the navigation antenna from the vehicle interface unit (VIU). Measure the resistance from the center conductor of the coax to the metal outer shield. Does the meter read out of limits? | Go to Step 7 | Go to Step 8 | |
| 7 | Measure the resistance of the navigation antenna coax center conductor from end to end. Does the resistance measure greater than the specified value? | 1.0 ohms | Go to Step 8 | Go to Step 9 |
| 8 | Replace the navigation antenna coax. Did you complete the replacement? | Go to Step 11 | ||
| 9 | Replace the navigation antenna assembly. Refer to Navigation Antenna Replacement . Did you complete the replacement? | Go to Step 11 | ||
| 10 | Replace the Vehicle Interface Unit. Refer to OnStar Vehicle Interface Unit (VIU) Replacement . Did you complete the replacement? | Go to Step 11 | ||
| 110 | Operate the system in order to verify the repair. Did you correct the condition? | Go to Step 2 | System OK | |
| IMPORTANT |
|---|
| It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and global positioning system (GPS) data can be received from satellites. It is also necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. |
Global Positioning System (GPS) Data Not Current or Inaccurate
OnStar Battery Consumption Test
In order to allow the OnStar® system to receive cellular calls and perform remote functions (such as door unlock) while the ignition is in the OFF position, and maintain an acceptable level of battery drain, the Vehicle Interface Unit uses a unique sleep cycle. In the event the OnStar® system is not cycling properly, excessive current draw from the battery may result. This procedure is designed to determine which one of the two OnStar® control modules is the source of a battery drain once the battery electrical drain test has been performed and it is has been concluded that the OnStar® subsystem is the source of the parasitic load.
The OnStar® system uses three states of readiness
- High Power
- Low Power
- Sleep
The High power state is in effect whenever the ignition is in the "ON" or "RUN" position, and enables the OnStar® system to send and receive cellular calls and perform all remote functions.
The Low power state is entered once the vehicle ignition is placed in the "OFF" position and the Retained Accessory Power (RAP) function has been turned off, or times out. This state will last for one minute after the ignition state reaches the "OFF" position and allows incoming cellular calls to be received. The Low power state will pull approximately 250mA from the battery.
After the one minute "window", the OnStar® system moves to the Sleep state, where the lowest current draw is maintained at approximately .5mA. This state will not recognize or receive incoming cellular calls and will last for nine minutes.
After this nine-minute interval, the system will wake up to the Low state of power and listen for any incoming calls that the OnStar® Call Center may be sending. In the event a call is being sent, the OnStar® system will receive the call and immediately go into the High power mode to perform any requested functions. If no call is received during the one-minute interval, the system will go back into the sleep mode for another nine minutes. This process will continue for up to 48 hours, after which, the OnStar® system will permanently enter the Sleep state until the ignition is once again turned to the "ON" or "RUN" position.
The OnStar® Call Center is able to maintain a record of exactly what time each vehicle will enter the one-minute Low power state by synchronizing their clocks with those of the vehicle, based on GPS signals.
Scheme 42
| Callout | Component Name |
|---|---|
| 1 | Key OFF After Initial Low Power Timeout |
| 2 | Sleep State |
| 3 | Low Power Window |
- If the vehicle has not been reconfigured correctly or configured at all, the system may not enter and cycle through each of the power states correctly.
- In the event the OnStar® system loses, or is temporarily removed from battery power, the sleep cycle will not begin until the vehicle passes into an open outside area where a GPS signal can be acquired, providing a reference for time.
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| Schematic Reference: OnStar Schematics | ||||
| 1 | Did you perform the Battery Electrical Drain/Parasitic Load Test? | Go to Step 2 | Go to BATTERY ELECTRICAL DRAIN/PARASITIC LOAD TEST | |
| 2 | IMPORTANT: It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and GPS data can be received from satellites. It is also necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. Press the OnStar® Call Center button Ask the OnStar® Call Center advisor if the vehicle has been configured. Has the vehicle been configured? | Go to Step 4 | Go to Step 3 | |
| 3 | Ask the OnStar® Call Center advisor to perform a Reconfiguration on the vehicle. Was the Reconfiguration successful? | Perform the Battery Electrical Drain/Parasitic Load test to verify whether the condition has been corrected by the Reconfiguration | Ask the OnStar® Call Center Advisor why the Reconfiguration was not successful and contact the General Motors Technical Assistance Center | |
| 4 | Ask the OnStar® Call Center advisor if they have received GPS data. Has the OnStar® Call Center advisor received GPS data? | Go to Step 5 | Go to Global Positioning System (GPS) Data Not Current or Inaccurate | |
| 5 | Turn the ignition OFF Disconnect the VIU, connector C1 Remove the Battery Positive Voltage circuit from the connector at the Vehicle Interface Unit (VIU). Insert a fused jumper wire into the Battery Positive Voltage circuit cavity at the VIU connector Connect a DMM between the fused jumper from the VIU and the Battery Positive Voltage circuit. Set the DMM to the milli-amp scale. Reconnect VIU connector C1. Start the vehicle and move it to an open area where a GPS signal can be received. Allow the vehicle to run for 10 minutes. Observe the current draw reading of the DMM. Does the current draw measure greater than the specified value? | 350mA | Go to Step 8 | Go to Step 6 |
| 6 | Turn the ignition OFF. Disable the Retained Accessory Power (RAP) function by opening and closing the driver door. Enable the MIN/MAX feature of the DMM. Allow the vehicle to remain parked with the ignition OFF for at least 30 minutes. Record the minimum and maximum values displayed on the DMM. Is the maximum current draw greater than the specified value? | 300mA | Go to Step 8 | Go to Step 7 |
| 7 | Is the minimum current draw greater that the specified value? | .7mA | Go to Step 8 | Go to Step 9 |
| 8 | IMPORTANT: Perform the OnStar® setup procedure. Replace the VCU. Refer to OnStar Vehicle Communication Unit (VCU) Replacement . Did you complete the replacement? | Go to Step 10 | ||
| 9 | IMPORTANT: Perform the OnStar® setup procedure. Replace the VIU. Refer to OnStar Vehicle Interface Unit (VIU) Replacement . Did you complete the replacement? | Go to Step 10 | ||
| 10 | Perform the Battery Electrical Drain/Parasitic Load test in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 | |
| IMPORTANT |
|---|
| It is important to have the vehicle in an open outside area where a cellular call can be successfully placed and GPS data can be received from satellites. It is also necessary to inform the OnStar® Call Center advisor that this call is for vehicle diagnostic purposes. |
| IMPORTANT |
|---|
| Perform the OnStar® setup procedure. Replace the VCU. Refer to OnStar Vehicle Communication Unit (VCU) Replacement . |
| IMPORTANT |
|---|
| Perform the OnStar® setup procedure. Replace the VIU. Refer to OnStar Vehicle Interface Unit (VIU) Replacement . |
OnStar Battery Consumption Test
OnStar® Cellular, GPS, and Diagnostic Limitations
The proper operation of the OnStar® System is dependent on several elements outside the components integrated into the vehicle. These include the National Cellular Network Infrastructure, the cellular telephone carriers within the network, and the Global Positioning Satellite system.
The cellular operation of the OnStar® system may be inhibited by factors such as the user's range from an analog cellular tower, the state of the cellular carriers' equipment, and the location where the call is placed. Making an OnStar® keypress in areas that lack sufficient cellular coverage or have a temporary equipment failure will result in either the inability of a call to complete with a data transfer or the complete inability to connect to the OnStar® Call Center. The OnStar® system may also experience connection issues if the identification numbers for the modules (STID and ESN numbers) are not recognized by the cellular carriers local signal receiving towers. OnStar® cellular connection issues such as these require the assistance of the General Motors Technical Assistance Center OnStar® Group, which coordinate with cellular carriers to resolve connection issues.
The satellites that orbit earth providing the OnStar® system with GPS data have nearly no failures associated with them. In the event of a no GPS concern, the failure will likely lie with the inability of the system to gain GPS signals because of its location (i.e. in a parking structure), hardware failure, or being mistaken with an OnStar® call which has reached the Call Center without vehicle data.
During diagnostic testing of the OnStar® system, the technician should ensure the vehicle is located in an area that has a clear unobstructed view of the open sky, and preferably, an area where analog, cellular calls have been successfully placed. These areas can be found by successfully making an OnStar® keypress in a known good OnStar® equipped vehicle and confirming success with the OnStar® Call Center advisor. Such places can be used as a permanent reference for future OnStar® testing.
