Steering Wheel & Steering Column: Specifications Chevrolet Suburban X

Ignition Switch/steering Lock 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Column Support Bracket Nuts30 N.m22 lb ft
Horn Contact Plate Screws5.5 N.m50 lb in
Ignition Lock Cylinder Case Screws7 N.m62 lb in
Intermediate Shaft to the Steering Column Pinch Bolt47 N.m35 lb in
Intermediate Shaft to the Steering Gear Pinch Bolt47 N.m35 lb ft
Knee Bolster Deflector Screw9 N.m80 lb in
Linear Shift Assembly to Steering Column Mounting Screws10 N.m89 lb in
Turn Signal Multifunction Switch Screws Side7 N.m62 lb in
Turn Signal Multifunction Switch Screws Top3 N.m30 lb in
Shift Lever Screw1.5 N.m13 lb in
Steering Column Bulkhead Connector Screw6 N.m53 lb in
Steering Column Seal Nuts3 N.m25 lb ft
Steering Column Support Screws17 N.m13 lb ft
Steering Column Trim Cover Screws Lower2 N.m18 lb in
Steering Column Trim Cover Screws Lower3.5 N.m31 lb in
Steering Column Trim Cover Screws Upper1.5 N.m13 lb in
Steering Wheel Nut40 N.m29 lb ft
Steering Wheel Shroud Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Steering Column Disassembled View (Column Shift Lean Shaft)
Scheme 1: Steering Column Disassembled View (Column Shift Lean Shaft)

Scheme 2

Scheme 2: Steering Column Disassembled View (Floor Shift Lean Shaft)
Scheme 2: Steering Column Disassembled View (Floor Shift Lean Shaft)

Scheme 3

Scheme 3: Steering Column Disassembled View (Column Shift Standard)
Scheme 3: Steering Column Disassembled View (Column Shift Standard)

Scheme 4

Scheme 4: Steering Column Disassembled View (Floor Shift Standard)
Scheme 4: Steering Column Disassembled View (Floor Shift Standard)

Symptoms - Steering Wheel and Column

Review the system description and operation in order to familiarize yourself with the system functions. Refer to STEERING WHEEL AND COLUMN DESCRIPTION AND OPERATION .
