Entertainment System: Specifications Chevrolet Suburban X

Entertainment Systems 70 illustrations ~150 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Amplifier Retaining Screws3.4 N.m30 lb in
Antenna Cable Mounting Screw5 N.m44 lb in
Antenna Mast6 N.m53 lb in
Antenna Mounting Nut5 N.m44 lb in
Console Side Panel Screws2 N.m18 lb in
Digital Radio Antenna Retaining Bolt6 N.m53 lb in
Digital Radio Antenna Retaining Nut3.5 N.m30 lb in
DVD Player Retaining Bolts9 N.m80 lb in
Mounting Bracket Bolts6 N.m18 lb in
Radio Antenna Module Retaining Bolt9 N.m80 lb in
Radio Control Module Retaining Bolt9 N.m80 lb in
Radio Retaining Screws1.6 N.m14 lb in
Speaker to Mounting Screws - Rear Door6 N.m53 lb in
Subwoofer Assembly Retaining Screws6 N.m53 lb in
Trim Bezel Screws2 N.m18 lb in

Identifying Fastener Tightening Specifications

Scheme 1

Scheme 1: Entertainment Schematic Icons
Scheme 1: Entertainment Schematic Icons

Scheme 2

Scheme 2: Radio/Audio System Schematics (Base/Uplevel Radio - UQ3/UQ5)
Scheme 2: Radio/Audio System Schematics (Base/Uplevel Radio - UQ3/UQ5)

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Radio/Audio System Schematics (Premium Radio - UQ7 w/o Y91)
Scheme 5: Radio/Audio System Schematics (Premium Radio - UQ7 w/o Y91)

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12: Radio/Audio System Schematics (Luxury Radio - UQ7 w/ Y91)
Scheme 12: Radio/Audio System Schematics (Luxury Radio - UQ7 w/ Y91)

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21: Steering Wheel Controls Schematics
Scheme 21: Steering Wheel Controls Schematics

Scheme 22

Scheme 22: Video System Schematics
Scheme 22: Video System Schematics

Scheme 23

Scheme 23: Entertainment Component Views
Scheme 23: Entertainment Component Views

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36: Entertainment Connector End Views
Scheme 36: Entertainment Connector End Views

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70
