Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Accelerator Pedal Assembly Nuts | 9 N.m | 80 lb in |
| Brake Pedal Pivot Nut | 30 N.m | 22 lb ft |
| Brake Pedal Position Sensor Bolt | 9 N.m | 80 lb in |
| EAP Bracket to Booster Nuts | 25 N.m | 18 lb ft |
| EAP Bracket Top Bolt | 25 N.m | 18 lb ft |
| I/P Carrier to l/P Reinforcement Brace Upper Nut | 22 N.m | 16 lb ft |
| I/P Reinforcement Brace to EAP Bracket Lower Bolt | 25 N.m | 18 lb ft |
| Transmission Range Selector Cable Support Bolt | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Begin adjustable pedal system diagnosis with the DIAGNOSTIC SYSTEM CHECK - ADJUSTABLE PEDALS . The Diagnostic System Check will provide the following information
- The identification of the control modules which command the system.
- The ability of the control modules to communicate through the serial data circuit.
- The identification of any stored diagnostic trouble codes and their status.
The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
