Sunroof System: Specifications Chevrolet SSR I

Sun Roof/t-Top/convertible Top 8 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Body Rear Compartment Fasteners10 N.m88 lb in
DRL Resistor Fastener5 N.m44 lb in
Folding Top Center Header Latch Linkage Jam Nut10 N.m88 lb in
Folding Top Latch Fasteners - Center10 N.m88 lb in
Folding Top Latch Fasteners - Rear12 N.m106 lb in
Folding Top Latch Fasteners - Rear Upper12 N.m106 lb in
Folding Top Latch Fasteners - Side10 N.m88 lb in
Folding Top Lock Pillar Fasteners45 N.m33 lb ft
Folding Top Lower Bulkhead Floor Bracket25 N.m18 lb ft
Folding Top Panel Fasteners - Front25 N.m18 lb ft
Folding Top Panel Fasteners - Rear25 N.m18 lb ft
Folding Top Rear Latch Cable Jam Nut5 N.m44 lb in
Folding Top Rear Window Fasteners7 N.m61 lb in
Folding Top Stowage Compartment Lid Fasteners25 N.m18 lb ft
Folding Top Striker Fasteners - Rear Upper10 N.m88 lb in
Folding Top Weatherstrip Retainer Fasteners - Side Front2.5 N.m22 lb in
Hydraulic Pump Manifold Plate Fasteners10 N.m88 lb in
Stowage Compartment Lid Extension Panel Fasteners10 N.m88 lb in
Stowage Compartment Lid Hinge Fasteners25 N.m18 lb ft
Stowage Compartment Lid Latch Fasteners10 N.m88 lb in
Stowage Compartment Lid Striker Fasteners10 N.m88 lb in

Fastener Tightening Specifications

Folding Top Clearance Gap Specifications

DescriptionGapParallelFlush
Folding Top Front Panel to Windshield Header7.0/9.0 mm0.05/0.05 mm1/1 mm
Folding Top Front Panel to Rear Panel7.0/9.0 mm0.05/0.05 mm1/1 mm
Folding Top Rear Panel to Rear WindowOffset 9.8 mm
Folding Top Rear Stowage Compartment Lid to Rear Window7.0/13.0 mm0.05/0.05 mm
Folding Top Rear Stowage Compartment Lid to Roof at Door6.7/8.7 mm0.05/0.05 mm1/1 mm
Folding Top Rear Stowage Compartment Lid to Door4.0/6.0 mm0.05/0.05 mm1/1 mm
Folding Top Rear Stowage Compartment Lid to Extension Panel7.0/9.0 mm1.0/1.0 mm2/2 mm
Folding Top Rear Stowage Compartment Lid to Quarter Panel4.0/6.0 mm0.05/0.05 mm1/1 mm
Folding Top Rear Stowage Compartment Lid to Rear Compartment Lid4.0/6.0 mm0.05/0.05 mm1/1 mm
Folding Top Rear Stowage Compartment Lid to Quarter Panel (Vertical Joint)4.0/6.0 mm0.05/0.05 mm1/1 mm

Folding Top Clearance Gap Specifications

Scheme 1

Scheme 1: Power Folding Top Schematics
Scheme 1: Power Folding Top Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Power Roof Systems Component Views
Scheme 5: Power Roof Systems Component Views
CalloutComponent Name
1Passenger Window Switch
2Door Lock/Unlock Switch
3Folding Top Switch
4Center Console Switch Assembly
5Traction ON/OFF Switch
6Driver Window Switch

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Roof/Door Module Connector
2Roof/Door Module Connector
3Roof/Door Module Connector
4Roof/Door Module Connector
5Relay Block - Rear
6Daytime Running Lamp (DRL) Diode
7Roof/Door Module
8Body Harness

Scheme 7

Scheme 7
Scheme 7
CalloutComponent Name
1Folding Top Stowage Compartment Lid Latch Switch/Sensor - Right
2Folding Top Stowage Compartment Latch Cylinder Position Sensor - Right
3Folding Top Motor Left Relay
4Folding Top Pump Motor Assembly
5Folding Top Valve 1
6Folding Top Valve 2
7Folding Top Valve 3
8Folding Top Valve 4
9Folding Top Motor Right Relay
10Folding Top Stowage Compartment Latch Cylinder Position Sensor - Left
11Folding Top Stowage Compartment Lid Latch Switch/Sensor - Left

Scheme 8

Scheme 8
Scheme 8
CalloutComponent Name
1Folding Top Pump Motor Assembly Connector C5
2Folding Top Stowage Compartment Lid Latch Switch/Sensor Connector - Right
3Folding Top Cylinder Position Sensor Connector
4Folding Top Stowage Compartment Lid Extension Panel Cylinder Position Sensor
5Folding Top Stowage Compartment Lid Cylinder Position Sensor
6Folding Top Outer Latch Striker Position Switch
7Folding Top Outer Latch Actuator
8Folding Top Outer Latch Position Switch
