Scheme 215
Circuit/System Description
The vehicle is fitted with a 12 V accessory power receptacle. The accessory power outlets are controlled by an ignition operated relay. The accessory power receptacle is operational when the ignition is turned to either the On or the Accessories positions.
System Description
The vehicle is fitted with either a cigarette lighter or with 12 V accessory power outlets. The power outlet is operational when the ignition is turned to either the On or the Accessories positions. The cigarette lighter is operational whenever the ignition is in the On position. To operate the cigarette lighter, press in the lighter knob. When the element is hot, the lighter automatically pops out and is ready for use.
