Intermittent
Electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections
Reference Information
Schematic Reference
Cigar Lighter/Power Outlet Schematics
Connector End View Reference
Component Connector End Views
Description and Operation
Power Outlets Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-544474-S28522670622013042400000)
- «Connector Repairs»(ref-544474-S01694319662013042400000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-544474-S10250380742013042400000)
- «Wiring Repairs»(ref-544474-S21510154002013042400000)
Circuit/System Verification
- Ignition ON, connect an appropriate device to the E32 Cigarette Lighter Receptacle.
- Verify the device is powered by the E32 Cigarette Lighter Receptacle. If the device is not powered Refer to Circuit/System Testing below If the device is powered
- All OK.
Repair Instructions
Perform the Diagnostic Repair Verification after completing the repair.
Accessory Power Receptacle Replacement .
Scheme 216
| Callout | Component Name |
|---|---|
| WARNING: Refer to Battery Disconnect Warning . Preliminary Procedure Disconnect battery negative cable. Refer to Battery Negative Cable Disconnection and Connection . Remove accessory power/cigar lighter receptacle. Refer to Accessory Power Receptacle Replacement . | |
| 1 | Accessory Power/Cigarette Lighter Receptacle Retainer |
| WARNING |
|---|
| Refer to Battery Disconnect Warning . |
Accessory Power Receptacle Retainer Replacement
Scheme 217
| Callout | Component Name |
|---|---|
| Preliminary Procedure Disconnect battery negative cable. Refer to Battery Negative Cable Disconnection and Connection . | |
| 1 | Accessory Power/Cigarette Lighter Receptacle Procedure Disconnect electrical connectors. Special Tools BO-48871 Cigar Lighter Socket Remover For equivalent regional tools, refer to Special Tools . |
Accessory Power Receptacle Replacement
