Test Description
The number(s) below refer to the step number(s) on the diagnostic table.
- 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
- 3: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Install a scan tool. Does the scan tool power up? | Go to Step 2 | Go to Scan Tool Does Not Power Up in Data Link Communications |
| 2 | Turn ON the ignition, with the engine OFF. Attempt to establish communication with the powertrain control module. Does the scan tool communicate with the powertrain control module? | Go to Step 3 | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications |
| 3 | Select the powertrain control module display DTCs function on the scan tool. Does the scan tool display any DTCs which begin with a "U"? | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications | Go to Symptoms - Transfer Case |
Diagnostic System Check - Transfer Case
Symptoms - Transfer Case
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Transfer Case Description and Operation . |
The numbers below refer to the step numbers on the diagnostic table.
- 2: Tests for proper ignition 3 voltage to the front axle actuator.
- 3: Tests for proper ground at the front axle actuator.
- 4: Tests the axle actuator control circuit and transfer case switch for a short to ground.
- 5: Tests the axle actuator control circuit for a short to ground.
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Transfer Case Control Schematics | ||||
| 1 | Did you perform a Diagnostic System Check-Transfer Case? | Go to Step 2 | Go to Diagnostic System Check - Transfer Case | |
| 2 | Turn OFF the ignition. Disconnect the front axle actuator. Ensure the 4-wheel drive (4WD) control lever is in the 2-wheel drive (2WD) position. Turn ON the ignition, with the engine OFF. Test the ignition 3 voltage circuit for proper voltage. Does the voltage measure within the specified value? | 9-14 V | Go to Step 3 | Go to Step 6 |
| 3 | Disconnect the front axle actuator. Turn ON the ignition, with the engine OFF. Measure the voltage between the ignition 3 voltage circuit and the ground circuit at the front axle actuator. Does the voltage measure within the specified value? | 9-14 V | Go to Step 4 | Go to Step 7 |
| 4 | Turn ON the ignition, with the engine OFF. Shift the transfer case into 2HI. Connect a test lamp between the ignition 3 voltage circuit and the axle actuator control circuit, at the front axle actuator. Does the test lamp illuminate? | Go to Step 5 | Go to Step 9 | |
| 5 | Disconnect the transfer case switch. Connect a test lamp between the ignition 3 voltage circuit and the axle actuator control circuit at the front axle actuator. Does the test lamp illuminate? | Go to Step 8 | Go to Step 10 | |
| 6 | Repair the open in the ignition 3 voltage circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 11 | ||
| 7 | Repair the open in the ground circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 11 | ||
| 8 | Repair the short to ground in the axle actuator control circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 11 | ||
| 9 | Replace the front axle actuator. Refer to Electric Motor Actuator Replacement in Front Drive Axle. Did you complete the replacement? | Go to Step 11 | ||
| 10 | Replace the transfer case switch. Refer to Transfer Case Gear Indicator Switch Replacement . Does the scan tool display the status Front Axle Switch Locked? | Go to Step 11 | ||
| 11 | Operate the vehicle in order to determine if the symptom has been corrected. Is the symptom still present? | Go to Step 2 | System OK | |
Four-Wheel Drive Does Not Disengage
The numbers below refer to the step numbers on the diagnostic table.
- 2: Tests for proper ignition 3 voltage to the front axle actuator.
- 3: Tests for proper ground at the front axle actuator.
- 4: Tests for proper ground at the axle actuator control circuit through the transfer case switch.
- 5: Tests the transfer case switch ground circuit for an open.
- 6: Tests the transfer case switch for proper operation.
| Step | Action | Values | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Transfer Case Control Schematics | ||||
| 1 | Did you perform a Diagnostic System Check-Transfer Case? | Go to Step 2 | Go to Diagnostic System Check - Transfer Case | |
| 2 | Turn OFF the ignition. Disconnect the front axle actuator. Ensure the 4-wheel drive (4WD) control lever is in the 4WD position. Turn ON the ignition with the engine OFF. Test the ignition 3 voltage circuit for proper voltage. Does the voltage measure within the specified value? | 9-14 V | Go to Step 3 | Go to Step 7 |
| 3 | Disconnect the front axle actuator. Turn ON the ignition, with the engine OFF. Measure the voltage between the ignition 3 voltage circuit and the ground circuit at the front axle actuator. Does the voltage measure within the specified value? | 9-14 V | Go to Step 4 | Go to Step 8 |
| 4 | Turn ON the ignition, with the engine OFF. Shift the transfer case into 4HI. Connect a test lamp between the ignition 3 voltage circuit and the axle actuator control circuit, at the front axle actuator. Does the test lamp illuminate? | Go to Step 11 | Go to Step 5 | |
| 5 | Disconnect the transfer case switch. Connect a test lamp from the ignition 3 voltage circuit to the transfer case switch ground circuit Does the test lamp illuminate? | Go to Step 6 | Go to Step 9 | |
| 6 | With the control lever in the 4WD position, test for continuity across the transfer case switch. Is continuity present across the switch? | Go to Step 10 | Go to Step 12 | |
| 7 | Repair the open in the ignition 3 voltage circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 13 | ||
| 8 | Repair the open in the ground circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 13 | ||
| 9 | Repair the open in the transfer case switch ground circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 13 | ||
| 10 | Repair the open in the axle actuator control circuit. Refer to Circuit Testing , and to Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 13 | ||
| 11 | Replace the front axle actuator. Refer to Electric Motor Actuator Replacement in Front Drive Axle. Did you complete the replacement? | Go to Step 13 | ||
| 12 | Replace the transfer case switch. Refer to Transfer Case Gear Indicator Switch Replacement . Did you complete the repair? | Go to Step 13 | ||
| 13 | Operate the vehicle in order to determine if the symptom has been corrected. Is the symptom still present? | Go to Step 2 | System OK | |
Four-Wheel Drive Does Not Engage
The numbers below refer to the step numbers on the diagnostic table.
- 2: Tests for an intermittent condition.
- 3: Determines whether the failure is the result of a faulty 4WD system.
- 4: Determines if the failure is the result of a faulty instrument cluster.
- 5: Determines if the failure is the result of a faulty PCM.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Transfer Case Control Schematics | ||||
| 1 | Did you perform A Diagnostic System Check - Transfer Case? | Go to Step 2 | Go to Diagnostic System Check - Transfer Case | |
| 2 | Verify the fault is present. Does the system operate normally? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 | |
| 3 | Does the front axle disengage when the four wheel drive (4WD) control lever is in the two wheel drive (2WD) position? | Go to Step 4 | Go to Four-Wheel Drive Does Not Disengage | |
| 4 | Turn ON the ignition, with the engine OFF. Install a scan tool. Use the scan tool to command the 4WD indicator OFF. Does the 4WD indicator turn OFF? | Go to Step 5 | Go to Step 8 | |
| 5 | Test the axle switch signal circuit for voltage at the PCM. Does the voltage measure within the specified value? | 9-14V | Go to Step 6 | Go to Step 7 |
| 6 | Inspect the axle switch signal circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. If OK, replace the front axle actuator. Refer to Electric Motor Actuator Replacement in Front Drive Axle. Did you complete the replacement? | Go to Step 9 | ||
| 7 | Replace the PCM. Refer to Powertrain Control Module (PCM) Replacement in Engine Controls - 4.3 L, Powertrain Control Module (PCM) Replacement in Engine Controls - 4.8 L, 5.3 L, and 6.0 L, or Powertrain Control Module (PCM) Replacement in Engine Controls - 8.1 L. Did you complete the replacement? | Go to Step 9 | ||
| 8 | Replace the instrument panel cluster. Refer to Instrument Panel Cluster (IPC) Replacement in Instrument Panel, Gauges, and Console. Did you complete the replacement? | Go to Step 9 | ||
| 9 | Operate the vehicle in order to determine if the symptom has been corrected. Is the symptom still present? | System OK | Go to Step 2 | |
4WD Indicator Always On
The numbers below refer to the step numbers on the diagnostic table.
- 2: Tests for an intermittent condition.
- 3: Determines whether the failure is the result of a faulty front axle circuit or the instrument cluster.
- 4: Tests for proper signal voltage to the PCM.
- 5: Tests for proper ignition 1 voltage to the instrument cluster.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Transfer Case Control Schematics | ||||
| 1 | Did you perform A Diagnostic System Check - Transfer Case? | Go to Step 2 | Go to Diagnostic System Check - Transfer Case | |
| 2 | Verify the fault is present. Does the system operate normally? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 | |
| 3 | Turn ON the ignition, with the engine OFF. Install a scan tool. Use the scan tool to command the 4WD indicator ON. Does the 4WD indicator turn ON? | Go to Step 4 | Go to Step 5 | |
| 4 | Ensure the 4WD control lever is in the 4WD position. Test the axle switch signal circuit for proper voltage at the PCM. Does the voltage measure within the specified value? | 9-14 V | Go to Step 8 | Go to Step 9 |
| 5 | Test the ignition 1 voltage circuit for a proper voltage at the instrument cluster. Does the voltage measure within the specified value? | 9-14 V | Go to Step 6 | Go to Step 7 |
| 6 | Replace the instrument panel cluster. Refer to Instrument Panel Cluster (IPC) Replacement in Instrument Panel, Gauges, and Console. Did you complete the replacement? | Go to Step 10 | ||
| 7 | Repair an open or high resistance in the ignition 1 voltage circuit. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you complete the repair? | Go to Step 10 | ||
| 8 | Replace the PCM. Refer to Powertrain Control Module (PCM) Replacement in Engine Controls - 4.3 L, Powertrain Control Module (PCM) Replacement in Engine Controls - 4.8 L, 5.3 L, and 6.0 L, or Powertrain Control Module (PCM) Replacement in Engine Controls - 8.1 L. Did you complete the replacement? | Go to Step 10 | ||
| 9 | Inspect the axle switch signal circuit for an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. If OK, replace the front axle actuator. Refer to Electric Motor Actuator Replacement in Front Drive Axle. Did you complete the replacement? | Go to Step 10 | ||
| 10 | Operate the vehicle in order to determine if the symptom has been corrected. Is the symptom still present? | System OK | Go to Step 2 | |
4WD Indicator Inoperative
Transfer Case Description and Operation
The New Venture Gear (NVG) 261, RPO NP2 transfer case is a two-speed, part-time with "mode shift-on-the-fly" capability. It has a chain driven front output shaft and an epicyclical low range planetary arrangement. The NVG 261 transfer case features a four position shift lever control located in the vehicle floor plan. As required, the operator can select 4HI position from 2HI "on-the-fly," as described in the owners manual. A dash 4WD lamp continues flashing during shifting, until all criteria have been met and the new mode/range position has been reached. Once the new mode/range position is fully engaged and the front axle disconnect locks in, the dash light 4WD indicator lamp remains ON constantly. Range shifting functions similarly, although it should be limited to speeds 5 km/h (3 mph) or less.
The four manual mode, or range gear positions, of the NVG 261 transfer case are
- 2HI - 2 wheel drive high range
- 4HI - 4 wheel drive high range, part-time
- 4LO - 4 wheel drive low range, 2.72:1 gear ratio reduction
- N - Neutral, 4 wheel
When the ignition switch is placed in the run position and the 4WD shift lever is in the 4WD position, the transfer case switch closes, supplying a ground to the axle actuator control circuit. With the ground applied, the logic of the front axle actuator actuates a DC motor to engage the front axle and supply voltage to the axle switch signal circuit. The axle switch signal circuit notifies the powertrain control module (PCM) and the Anti-Lock Brake System that the vehicle is in the 4WD mode. The 4WD indicator is commanded on via a Class 2 serial data signal from the PCM. When the 4WD shift lever is in the 4WD low range position, the transfer case switch closes and supplies a ground on the 4WD low signal circuit. This informs the PCM that the vehicle transfer case is in low range. When the vehicle is in low range, the PCM changes the shift pattern of the automatic transmission.
During normal driving situations, the transfer case can operate in the 2WD mode. The driver may choose to select any of the mode/range gear positions while driving the vehicle. However, the transfer case should not be shifted into or out of 4LO unless the following criteria have been met
- The automatic transmission is in neutral or the clutch pedal is depressed.
- The vehicle speed is less than 5 km/h (3 mph).
This transfer case also has a neutral position. A shift to the neutral position allows the vehicle to be towed without rotating the transmission output shaft. In the neutral position, the rear propeller shaft rotates the transfer case rear output shaft, in turn rotating the oil pump, providing constant lubrication during towing. Note, this neutral position is a 4WD neutral, meaning the front and rear outputs of the transfer case are engaged as though in 4HI. With a disconnecting front axle, there is no power flow to the front wheels, allowing towing with the front wheels off the ground or flat towing without driveline binding. Again, the transfer case should not be shifted into or out of neutral unless the following criteria have been met
- The automatic transmission is in neutral or the clutch pedal is depressed.
- The vehicle speed is less than 5 km/h (3 mph).
The NVG 261 transfer case is available in 5 variations, depending on the engine and transmission configurations. The variations allow the transfer case to handle different torque loads. When servicing the transfer case it is important to understand which variation is being serviced because of the difference in parts.
| Model | Transmission | Input Gear | Output Shaft | Chain Size | Hi/Low Planetary | Application |
|---|---|---|---|---|---|---|
| Light Duty (LD) | M30 - 4L60E | 27T Spline | 32T Spline | 3/8 X 1.25 in | 3 Pinion | K1 |
| Light Duty (LD) | MG5 - NV 3500 | 32T Spline | 32T Spline | 3/8 X 1.25 in | 3 Pinion | K1 |
| Heavy Duty 1 (HD1) | MT1 - 4L80E MW3 - NV 4500 | 32T Spline | 32T Spline | 3/8 X 1.5 in | 6 Pinion | K2 Non Heavy Duty |
| Heavy Duty 2 (HD2) | MT1 - 4L80E MW3 - NV 4500 | 32T Spline | 32T Spline | 7/16 X 1.5 in | 6 Pinion | K2 Heavy Duty |
| Super Heavy Duty (SHD) | ML6 - ZF S6-650 M74 - Allison | 29T Spline | 31T Spline | 7/16 X 1.5 in | 6 Pinion | K3 |
NVG 261 Variations
The SHD model shares many of the same components, but the increased torque capacity of the SHD requires a double row input bearing and larger diameter rear output shaft, rear output shaft bearing higher capacity, larger rear seal and case halves machined differently.
The following changes were made to the NVG 261 for this model year
- The case half bolts now use a cup style aluminum washer, which allow using the bolts again.
- On the light duty version, the planetary carrier has been changed from a 4 pinion gear to a 3 pinion gear design.
- The bearing is changed to a bushing in the shift control lever shaft support.
- The rear output shaft is machined differently at the retaining ring groove for the synchronizer retaining ring and the retaining ring is now a smaller diameter.
Scheme 56
The transfer case is shifted by a remote mounted shift lever, which is connected by linkage to the shift lever (9) on the shift detent lever shaft. The shift detent lever shaft rotates the cam shaped shift detent lever (10) and moves the high/low range shift fork (11) or the 2/4 wheel drive mode shift fork (8). Depending on the selected mode or range, the shift forks move either the high/low range sleeve (4) for the high/low range planetary assembly (3) or the synchronizer sleeve (6) for the 2/4 wheel drive mode. In the 2WD mode, the engine power from the transmission (1) is delivered to the input shaft (2). The engagement teeth on the inside of the input shaft (2) are engaged to the outer teeth on the high/low range sleeve (4). The high/low range sleeve (4) is slipped splined to the rear output shaft (5). The engine power flows from the high/low range sleeve (4) to the rear output shaft (5) and is delivered to the rear propeller shaft (7).
Scheme 57
In the 4HI mode, the engine power from the transmission (1) is delivered to the input shaft (2). The engagement teeth on the inside of the input shaft (2) are engaged to the outer teeth on the high/low range sleeve (3). The high/low range sleeve (3) is slipped splined to the rear output shaft (4). During a shift mode from 2HI to 4HI the cam profile on the shift detent lever (14) pushes the 2/4 wheel drive mode shift fork (9) and the synchronizer sleeve. The sleeve, engaging the synchronizer (5) equalizes the front propeller shaft (12) and rear propeller shaft (7) speeds. Then the sleeve engages to the 2/4 wheel drive synchronizer gear (8), which is splined to the drive sprocket (6). The engine power flow for driving the front propeller shaft (12), now travels from the rear output shaft (4) to the synchronizer hub, which is splined to the rear output shaft (4). The power flows from the synchronizer hub to the sleeve and then to 2/4 wheel drive synchronizer gear (8). The power flow is transmitted by a chain (10) to the driven sprocket on the front output shaft (11) and to the front propeller shaft (12). The front and rear propeller shafts are being driven at equal RPMs, therefore giving a four wheel drive mode. This mode should only be used for extra traction. Using this mode on dry pavement causes tire scuffing when turning.
Scheme 58
During range shift request to 4LO, a separate cam profile on the same shift detent lever (12) moves the high/low shift fork (13). The high/low shift fork (13) moves the high/low range sleeve (6) rearward. The high/low range sleeve (6) outer teeth disengage from the input shaft (2) high-speed teeth. The high/low range sleeve (6) outer teeth then engage in the high/low planetary carrier teeth (5). The power flow is now from the transmission (1), to the planetary teeth on the input shaft (2), to the planetary gears (3) in the carrier. Rotating the planetary gears (3), which are engaged in the annulus gear (4), rotates the planetary carrier. The planetary carrier delivers the power to the high/low range sleeve (6). The high/low range sleeve (6) then drives the rear output shaft (7), providing a 2.72:1 gear ratio reduction to the rear output shaft (7). The 2/4 wheel drive synchronizer (8) is still engaged to drive the drive sprocket (9), as in the 4HI position, providing the engine power to the rear propeller shaft (10) and to the front propeller shaft (11).
