Lighting Systems: Specifications Chevrolet Silverado 3500 HD

Exterior Lights 21 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Center High-Mounted Stop Cargo Lamp Mounting Screws2.5 N.m22 lb in
Headlamp Ballast Screws2 N.m18 lb in
Headlamp Mounting Screws6 N.m53 lb in
License Plate Lamp Screws2 N.m18 lb in
Power Vacuum Brake Booster Pushrod Retaining Bolt10 N.m89 lb in
Rear Tail/Turn Signal Lamp Assembly Screws2 N.m18 lb in
Rear Side Marker Lamp Screws2.5 N.m22 lb in
Roof Marker Lamp Screws - Center2 N.m18 lb in
Roof Marker Lamp Screws - Outer2 N.m18 lb in
Tail Lamp Screws2 N.m18 lb in

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: Fog Lights Schematics
Scheme 4: Fog Lights Schematics

Scheme 5

Scheme 5: Exterior Lights Schematics
Scheme 5: Exterior Lights Schematics

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: Interior Lights Schematics
Scheme 13: Interior Lights Schematics

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17: Interior Lights Dimming Schematics
Scheme 17: Interior Lights Dimming Schematics

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
