Interior Trim: Other Chevrolet Silverado 2500

Eliminating Unwanted Odors in Vehicles

GM vehicle Care Odor Eliminator, GM P/N 12378554, US AC Delco 88900909, Canadian P/N 88901678, may control or eliminate odors in the interior and luggage compartment areas of GM vehicles. This non-toxic, biodegradable, odorless product has been shown to greatly reduce or remove the following types of odor

1. Objectionable smells of mold and mildew resulting from vehicle water leaks
2. Customer created odors, such as smoke

You may safely use GM vehicle Care Odor Eliminator on fabrics, vinyl, leather, carpet, and sound deadening materials. You may also induce this product into HVAC modules and instrument panel ducts for the control of non-bacterial related odors.

Important: This product leaves no residual scent and should not be used as an air freshener.

This product may result in the permanent elimination of an odor and may be preferable to customers whose allergies make them sensitive to perfumes. This product may effectively remove odors when directly contacting the odor source. In cases such as water leaks, use this product with diagnostic procedures to first eliminate the primary cause of the odor. Then use further applications on the residual odor. Then use further applications on the residual odor to permanently correct the vehicle conditions.

How To Use This Product

1. Spray GM vehicle Care Odor Eliminator directly or as an additive with carpet shampoo in steam cleaners.
2. Do not use on any interior surface that plain water would deteriorate because this product will have the same effect. Also avoid letting this product come into contact with vinegar or any acidic substance. Acid-based Products will hamper the effectiveness of GM Vehicle Care Odor Eliminator.
3. Instructions and cautions are printed on the bottle, but additional help is available. If you encounter a persist or recurring odor, you may call to obtain additional information and usage suggestions. In the USA Call 1-800-955-8591. In Canada, Call 1-800-977-4145.

Scheme 45

1. Remove the sill plate. Firmly pull the sill plate up and out from the retainers.
2. Remove the sill plate from the vehicle. Start from the front of the door sill. Use a flat-bladed tool in order to pry the door sill plate.

Floor Carpet Drying

If the carpet or the pad or insulator is wet, use the following criteria for drying or for replacing the components

1. For a 1-piece carpet assembly bonded to a cotton or a fiber padding, replace the entire assembly.
2. For a 2-piece carpet assembly with a cotton or a fiber padding, replace the padding only. While the carpet is out of the vehicle, dry the carpet using the method described below.
3. For a 1-piece carpet assembly bonded to a form padding or attached to a synthetic padding, dry the carpet using the method described below.
4. For a 2-piece carpet assembly with a synthetic padding, dry the assembly using the method described below.

Drying Method

1. If you observe puddles of liquid on the carpet face, use a wet vacuum to remove the excess moisture.
2. Blot the face of the carpet with a towel in order to absorb as much moisture as possible.
3. Point a fan at the affected area and air dry the carpet.

Scheme 46

1. Remove the hinge pillar trim panel. Refer to «Trim Panel Replacement - Hinge Pillar»(ref-176717-S03410443752005051800000) .
2. Remove the door sill plates. Refer to «Door Sill Plate Replacement - Front»(ref-176717-S29168192672005051800000) or «Door Sill Plate Replacement - Rear»(ref-176717-S03977996252005051800000) .
3. Remove the front seats. Refer to «SEAT REPLACEMENT - FRONT BUCKET»(ref-176716-S19498008392005051200000) .
4. Remove the floor storage console. Refer to «CONSOLE REPLACEMENT (LUXURY CONSOLE)»(ref-176702-S09497647752005051000000) , «CONSOLE REPLACEMENT (BASE CONSOLE)»(ref-176702-S24203128782005051000000) or «CONSOLE REPLACEMENT (PRO)»(ref-176702-S35568641132005051000000) .
5. Remove the center seat, if equipped Refer to «SEAT REPLACEMENT - CENTER»(ref-176716-S28423525282005051200000) .
6. Remove the control lever and boot, if equipped.
7. Remove the rear seat if equipped. Refer to «SEAT REPLACEMENT - REAR (EXTENDED CAB W/4TH DOOR)»(ref-176716-S39076088932005051200000) , «SEAT REPLACEMENT - REAR (EXTENDED CAB)»(ref-176716-S38439242742005051200000) or «SEAT REPLACEMENT - REAR (60/40 SPLIT)»(ref-176716-S29472392212005051200000) .
8. Remove the jack assembly.
9. Remove the quarter trim panel. Refer to «Trim Panel Replacement - Rear Quarter (Regular Cab)»(ref-176717-S26188285132005051800000) or «Trim Panel Replacement - Rear Quarter (Extended Cab)»(ref-176717-S04790890062005051800000) .
10. Remove the lower bolt from the instrument panel (I/P) support post. Refer to «INSTRUMENT PANEL (I/P) CARRIER REPLACEMENT»(ref-176702-S32310960782005051000000) .
11. Remove the carpet from the vehicle.
