Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Air Inlet Grille Panel Screws | 2 N.m | 18 lb in |
| Battery Tray Bolts | 9 N.m | 80 lb in |
| Cab Mount Bolts | 75 N.m | 55 lb ft |
| Cable Handle Nut | 11 N.m | 97 lb in |
| Condenser Mounting Bolts | 9 N.m | 80 lb in |
| Diagonal Brace Bolts | 25 N.m | 18 lb ft |
| Fender Bolts | 25 N.m | 18 lb ft |
| Fender to Cowl Support Brace Bolts | 9 N.m | 80 lb in |
| Fender to Door Hinge Bolts | 25 N.m | 18 lb ft |
| Fender to Radiator Support Bolts | 25 N.m | 18 lb ft |
| Fender to Upper Cowl Bracket Bolts | 25 N.m | 18 lb ft |
| Ground Strap Nut | 9 N.m | 80 lb in |
| Headlamp Housing Screws | 9 N.m | 80 lb in |
| Hinge to Fender Bracket Bolt | 25 N.m | 18 lb ft |
| Hood Hinge Bolts | 25 N.m | 18 lb ft |
| Hood Latch Bolts | 9 N.m | 80 lb in |
| Hood Spring Bolts | 25 N.m | 18 lb ft |
| Link Assembly Bolts | 25 N.m | 18 lb ft |
| Lower Fender Bolts | 25 N.m | 18 lb ft |
| Pickup Box to Frame Rail Bolts | 70 N.m | 52 lb ft |
| Pivot Bolt | 25 N.m | 18 lb ft |
| Radiator Support to Frame Mounting Nut | 70 N.m | 52 lb ft |
| Upper Radiator Support Bolts | 9 N.m | 80 lb in |
| Washer Reservoir Bolt | 9 N.m | 80 lb in |
| Wheelhouse Panel Bracket Bolts | 9 N.m | 80 lb in |
| Wheelhouse Panel Bracket Nuts | 25 N.m | 18 lb ft |
| Wheelhouse Panel to Dash Panel Bolt | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 10
- Remove the front hood bumper by turning the front hood bumper (1) out counterclockwise.
- Remove the side hood bumper by sliding the side hood bumper (2) rearward and pulling up.
