Removal Procedure
- Remove the instrument panel (IP) top cover. Refer to «TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER»(ref-176702-S10596506242005051000000) .
- Remove the module. Unsnap the 2 lock arms.
- Disconnect the electrical connector.
Installation Procedure
- Connect the electrical connector.
- Install the module starting with the large tang-tilt. Snap the 2 lock arms into the square holes.
- Install the instrument panel (IP) top cover. Refer to «TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER»(ref-176702-S10596506242005051000000) .
- Program the transmitter. Refer to «Transmitter Programming»(ref-176703-S06073184962005051200000) .
Under normal use, the battery in the transmitter will last about 2 years. For battery replacement, use a Panasonic® 3 volt, type CR2032, or equivalent.
Scheme 9
Scheme 10
- Open the transmitter case and perform the following steps: 1.1. Insert a dime between the 2 halves of the transmitter near the key ring hole. 1.2. Twist the dime.
- Remove the battery.
- Install the battery with the (+) positive side down.
- Close the transmitter case and perform the following steps: 2.1. Align the top and bottom covers. 2.2. Press together the top and the bottom covers. 2.3. Inspect the operation of the transmitter.
- Synchronize the transmitter. Refer to «Transmitter Synchronization»(ref-176703-S41511490422005051200000) .
