Wiper System & Washer System: Specifications Chevrolet Silverado 2500 HD

Wiper/washer Systems 13 illustrations ~128 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Inlet Grille Panel Screws1.3 N.m12 lb in
Plenum Reinforcement Panel Bolts9 N.m80 lb in
Windshield Washer Solvent Container Bolts9 N.m80 lb in
Windshield Washer Solvent Heater Nuts9 N.m80 lb in
Windshield Wiper Arm Pivot Shaft Nuts30 N.m22 lb ft
Windshield Wiper System Module Bolts to Plenum9 N.m80 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Wiper/Washer Schematics
Scheme 1: Wiper/Washer Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Wiper/Washer Component Views
Scheme 5: Wiper/Washer Component Views
CalloutComponent Name
1Battery - Right
2Windshield Wiper Motor
3Windshield Washer Solvent Heater (XA7)
4Fuse Block - Underhood
5Battery - Left (Diesel/6A6/T92)
6Washer Fluid Level Switch
7Windshield Washer Fluid Pump
8Air Cleaner Box

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Sunroof
2Sunshade - Right
3Outside Moisture Sensor (CE1)
4Inside Rearview Mirror (ISRVM) Window Anchor

Scheme 7

Scheme 7
Scheme 7
CalloutComponent Name
1Turn Signal Multifunction Switch
2Ignition Lock Cylinder
3Tow/Haul Switch
4Steering Angle Sensor
5A/T Shift Lock Control Solenoid
6Theft Deterrent Control Module
7Ignition Switch
8Inflatable Restraint Steering Wheel Module Coil

Scheme 8

Scheme 8: Outside Moisture Sensor (CE1)
Scheme 8: Outside Moisture Sensor (CE1)
Connector Part Information OEM: 15324252 Service: 15306387 Description: 4-Way F Micro-Fit (BK)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Outside Moisture Sensor (CE1) Connector Parts Information

PinWireCircuit No.Function
10.35 L-GN482Outside Moisture Sensor Signal 2
20.35 TN481Outside Moisture Sensor Signal 1
30.35 BK1050Ground
40.35 WH2283Ignition Voltage

Outside Moisture Sensor (CE1) Connector Terminal Identification

Scheme 9

Scheme 9: Washer Fluid Level Switch
Scheme 9: Washer Fluid Level Switch
Connector Part Information OEM: 15449028 Service: 88987993 Description: 2-Way F 150 GT Series Sealed (BK)
Terminal Part Information Pin: A Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-2A (GY) Pin: B Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Washer Fluid Level Switch Connector Parts Information

PinWireCircuit No.Function
A0.5 TN185Low Washer Fluid Indicator Control
B0.8 BK150Ground

Washer Fluid Level Switch Connector Terminal Identification

Scheme 10

Scheme 10: Windshield Washer Fluid Pump
Scheme 10: Windshield Washer Fluid Pump
Connector Part Information OEM: 12052641 Service: 12102747 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Windshield Washer Fluid Pump Connector Parts Information

PinWireCircuit No.Function
A0.5 OG228Windshield Washer Pump Control
B0.8 BK150Ground

Windshield Washer Fluid Pump Connector Terminal Identification

Scheme 11

Scheme 11: Windshield Washer Solvent Heater X1 (XA7)
Scheme 11: Windshield Washer Solvent Heater X1 (XA7)
Connector Part Information OEM: 15489811 Service: 19115654 Description: 2-Way M Y-Type 9.5 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 7114-3250/14 Core/Insulation Crimp: G/3 Release Tool/Test Probe: 12094430/J-35616-21 (RD)

Windshield Washer Solvent Heater X1 (XA7) Connector Parts Information

PinWireCircuit No.Function
15 RD/BK1642Battery Positive Voltage
20.5 BK1350Ground

Windshield Washer Solvent Heater X1 (XA7) Connector Terminal Identification

Scheme 12

Scheme 12: Windshield Washer Solvent Heater X2 (XA7)
Scheme 12: Windshield Washer Solvent Heater X2 (XA7)
Connector Part Information OEM: 15423411 Service: 19115669 Description: 6-Way F 1.5 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 33012-1003/23 Core/Insulation Crimp: 2/E/2 Release Tool/Test Probe: J-38125-217/J-35616-2A (GY)

Windshield Washer Solvent Heater X2 (XA7) Connector Parts Information

PinWireCircuit No.Function
10.35 L-GN6096Washer Fluid Heated Control Switch Signal
20.35 D-BU/WH5970Washer Fluid Heated Control Switch LED Supply Voltage
3Not Used
40.35 BK/WH1851Ground
50.35 PK94Windshield Washer Switch Signal
60.35 OG300Ignition 3 Voltage

Windshield Washer Solvent Heater X2 (XA7) Connector Terminal Identification

Scheme 13

Scheme 13: Windshield Wiper Motor
Scheme 13: Windshield Wiper Motor
Connector Part Information OEM: 15316488 Service: 19149298 Description: 5-Way F 090 Series Sealed (GY)
Terminal Part Information Pins: 1, 4, 5 Terminal/Tray: 8100-0461/6 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY) Pins: 2, 3 Terminal/Tray: 8100-0460/6 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Windshield Wiper Motor Connector Parts Information

PinWireCircuit No.Function
11 D-GN95Windshield Wiper Motor Low Speed
20.8 BK/WH1851Ground
30.35 YE196Windshield Wiper Motor Park Switch Signal
41 PU92Windshield Wiper Motor High Speed
51 BK550Ground

Windshield Wiper Motor Connector Terminal Identification
