Object Detection System: Overview Chevrolet Silverado 2500 HD

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Information Center Telltale Assembly Connector Parts Information

Information Center Telltale Assembly Connector Terminal Identification

Scheme 8

Object Sensor - Left Rear Corner Connector Parts Information

Object Sensor - Left Rear Corner Connector Terminal Identification

Circuit/System Description

The object alarm detection system senses how close the vehicle is to an object. The distance is determined by the 4 ultrasonic sensors located in the rear bumper. The object detection system will notify the driver when backing up at speeds less than 8 km/h (5 mph), which make parking easier and helps you avoid colliding with objects such as parked vehicles. Each object sensor is a 3-wire sensor that is both a transmitter and a receiver that comprises a signal circuit, a low reference circuit, and an 8-volt supply voltage circuit. The rear object control module supplies 8 volts to the object sensors via the object sensor supply voltage circuit and provides ground via the low reference circuit. The rear object control module triggers the sensors in a sequential loop and after each sensor transmits, the rear object control module uses the echo or signal return to calculate the distance and position of an object from the rear bumper. The rear object control module directly controls the rear parking assist (RPA) display. The RPA consists of 2 amber and one red LED that indicate the range of an object from the rear bumper. The rear object control module will also use an audible warning by sending a low speed GMLAN message to the radio.

The object alarm detection system senses how close the vehicle is to an object. The distance is determined by the 4 ultrasonic sensors located in the rear bumper. The object detection system will notify the driver when backing up or moving forward while parking at speeds less than 8 km/h (5 mph). The object detection system will use rear display indicators and the radio speakers for notification. The system can be disabled by pressing the ON/OFF button. The ON/OFF indicator will be ON when the system is OFF. The driver information center (DIC) will also display PARK ASSIST OFF.

The object alarm detection system senses how close the vehicle is to an object. The distance is determined by the 4 ultrasonic sensors located in the rear bumper. The object detection system will notify the driver when backing up at speeds less than 8 km/h (5 mph), which make parking easier and helps you avoid colliding with objects such as parked vehicles.

Each object sensor is a 3-wire sensor that is both a transmitter and a receiver that comprises a signal circuit, a low reference circuit, and an 8-volt supply voltage circuit. The rear object control module supplies 8 volts to the object sensors via the object sensor supply voltage circuit and provides ground via the low reference circuit. The rear object control module triggers the sensors in a sequential loop and after each sensor transmits, the rear object control module uses the echo or signal return to calculate the distance and position of an object from the rear bumper. The rear object control module directly controls the rear parking assist (RPA) display. The RPA consists of 2 amber and one red LED that indicate the range of an object from the rear bumper. The rear object control module will also use an audible warning by sending a low speed GMLAN message to the radio.

When the ignition is turned ON, the object alarm module performs a self test to verify if any critical malfunction exists within the system. When the object alarm system has completed the power-up mode, the object alarm module establishes communication with the body control module (BCM). During the power-up mode the object detection module checks for a valid calibration data set, if no valid calibration set is found, the object alarm module disables the system and commands the red indicator ON.

When the ignition is turned ON, the object alarm module receives and stores the vehicle identification number (VIN) from the body control module (BCM). The BCM sends serial data messages to the object alarm module with the VIN information. The object alarm module will compare the VIN received to the VIN stored in memory. If the VIN stored in memory does not match the VIN transmitted by the BCM, the object alarm module sets a DTC and commands the red indicator ON indicating a system malfunction.

The object alarm detection system senses how close the vehicle is to an object. The distance is determined by the 4 ultrasonic sensors located in the rear bumper. The object detection system will notify the driver when backing up while parking at speeds less than 8 km/h (5 mph), which makes parking easier and helps you avoid colliding with objects such as parked vehicles. The object detection system will use the rear display indicators and the radio speakers for notification.

The object alarm detection system senses how close the vehicle is to an object. The distance is determined by the 4 ultrasonic sensors located in the rear bumper. The object detection system will notify the driver when backing up at speeds less than 8 km/h (5 mph), which make parking easier and helps you avoid colliding with objects such as parked vehicles. The object detection system will use the rear display indicators and the radio speakers for notification.

Ultrasonic Rear Park Assist Operation

The ultrasonic rear park assist system senses how close the vehicle is to an object. The distance is determined by the 4 object sensors located in the rear bumper. The object detection system will notify the driver when backing up at speeds less than 8 km/h (5 mph). The object detection system will use the rear parking assist (RPA) display and the radio speakers for notification.

When the ignition is ON and the vehicle is placed into reverse, the object detection system performs a bulb check. During the bulb check, the 3 indicators on the RPA will illuminate for approximately 2 seconds to indicate that the system is working. The object detection system performs a bulb check and operates when the following conditions are present

1. The ignition is ON.
2. The vehicle is placed in REVERSE (R) for rear parking aid.
3. The vehicle speed is less than 5 km/h (3 mph). At speeds greater than 5 km/h (3 mph), the object detection system is disabled. The red indicator flashes to warn the driver that the object detection system is disabled.

The object detection system senses how close the vehicle is to an object. The distance is determined by the 4 object sensors located on the rear bumper. When the system detects an object, one of the following will occur

1. If the object is less than 0.3 m (11 in) away from the vehicle, the amber outside, amber middle, and the red outside indicators flash and the chime sounds continuously.
2. If the object is less than 0.3-0.5 m (11-20 in) away from the vehicle, the amber outside, amber middle, and the red outside indicators are ON.
3. If the object is 0.5-1.0 m (20-40 in) away from the vehicle, the amber outside, and the amber middle indicators are ON.
4. If the object is 1-2.3 m (40-91 in) away from the vehicle, the amber outside indicator is ON.

Object detection system can detect objects 7.6 cm (3 in) wide and at least 25.4 cm (10 in) tall. It cannot detect objects above the level of the roof.

If the object detection system detects a malfunction, a diagnostic trouble code (DTC) will be stored and the object detection system will send a serial data communication message to the instrument panel (I/P) to SERVICE PARK ASSIST message on the driver information center (DIC). Then the chime will sound and the red indicator on the information telltale center will be lit continuously. The red LED in the rear display will be lit, notifying the driver that a malfunction exists. Message will clear once the driver acknowledges it.

Each object sensor is a three wire sensor that is both a transmitter and a receiver that comprises a signal circuit, a low reference circuit, and an 8-volt supply voltage circuit. The rear object control module supplies 8 volts to the object sensors via the object sensor supply voltage circuit and provides ground via the low reference circuit. The rear object control module triggers the sensors in a sequential loop and after each sensor transmits, the rear object control module uses the echo or signal return to calculate the distance and position of an object from the rear bumper. The rear object control module directly controls the RPA display.

Rear Vision Camera System Operation

The rear vision system can help a driver determine how close an object is to the rear bumper within a predefined rearward field of view. The system is composed of a video camera located on the rear liftgate, rear view camera image display module, electrical harness and the image display located on the radio.

The rear view camera image display module receives an active high (12-volt) signal from the body control module (BCM) when the vehicle is shifted into reverse. With the transmission is in the reverse, the rear view camera image display module will supply the camera with a regulated 6-volt power source. The rear view camera image display module also serves to process the video information from the camera and deliver it to the radio. The image from the rear view camera will only be displayed in the radio when the vehicle is in reverse.

The radio can display the following rear vision error messages

1. Rear Vision Camera System Unavailable-This message may display when the system is not receiving information it requires from other vehicle systems.
2. Service Rear Vision Camera System-This message may display when the system is not receiving video from the camera.
