Object Sensor - Left Rear Middle
| Connector Part Information OEM: 13521095 Service: 88988337 Description: 3-Way F Sealed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU) |
Object Sensor - Left Rear Middle Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | 0.5 L-BU | 2374 | Object Sensor Supply Voltage |
| 2 | 0.5 GY | 2379 | Low Reference |
| 3 | 0.5 OG | 2376 | LR Middle Object Sensor Signal |
Object Sensor - Left Rear Middle Connector Terminal Identification
Object Sensor - Right Rear Corner
| Connector Part Information OEM: 13521095 Service: 88988337 Description: 3-Way F Sealed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU) |
Object Sensor - Right Rear Corner Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | 0.5 L-BU | 2374 | Object Sensor Supply Voltage |
| 2 | 0.5 GY | 2379 | Low Reference |
| 3 | 0.5 PU | 2378 | RR Corner Object Sensor Signal |
Object Sensor - Right Rear Corner Connector Terminal Identification
Object Sensor - Right Rear Middle
| Connector Part Information OEM: 13521095 Service: 88988337 Description: 3-Way F Sealed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU) |
Object Sensor - Right Rear Middle Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | 0.5 L-BU | 2374 | Object Sensor Supply Voltage |
| 2 | 0.5 GY | 2379 | Low Reference |
| 3 | 0.5 D-GN | 2377 | RR Middle Object Sensor Signal |
Object Sensor - Right Rear Middle Connector Terminal Identification
Scheme 9
| Connector Part Information OEM: 13551679 Service: 19115653 Description: 8-Way F Kaizen 0.64 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU) |
Rear Object Sensor Control Module X1 Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | 0.5 PU | 2378 | RR Corner Object Sensor Signal |
| 2 | 0.5 D-GN | 2377 | RR Middle Object Sensor Signal |
| 3 | 0.5 OG | 2376 | LR Middle Object Sensor Signal |
| 4 | 0.5 D-BU | 2374 | Object Sensor Supply Voltage |
| 5 | 0.5 YE | 2375 | LR Corner Object Sensor Signal |
| 6-7 | Not Used | ||
| 8 | 0.5 GY | 2379 | Low Reference |
Rear Object Sensor Control Module X1 Connector Terminal Identification
Scheme 10
| Connector Part Information OEM: 13551678 Service: See Catalog Description: 12-Way F Receptacle 0.64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU) |
Rear Object Sensor Control Module X2 Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | 0.35 RD/WH | 840 | Battery Positive Voltage |
| 2 | 0.35 WH | 2370 | Telltale Assembly Supply Voltage |
| 3 | 0.35 BN | 5852 | Rear Park Assist LED Disable Signal |
| 4 | 0.35 OG | 2371 | Left Amber Indicator Control |
| 5 | Not Used | ||
| 6 | 0.35 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 7 | 0.35 BK/WH | 2751 | Ground |
| 8 | 0.35 GY | 2555 | Rear Park Assist Disable Signal |
| 9 | 0.35 D-BU | 2372 | Center Amber Indicator Control |
| 10 | 0.35 GY | 2373 | Red Indicator Control |
| 11-12 | Not Used |
Rear Object Sensor Control Module X2 Connector Terminal Identification
Repair Procedures
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Rear Object Sensor Replacement»(ref-278044-S04626148972008012100000) for rear object sensor replacement
- «Control Module References»(ref-278020-S09054666032008012100000) for object alarm module replacement, setup, and programming
Reference Information
Schematic Reference
Object Detection Schematics
Connector End View Reference
Object Detection Connector End Views
Description and Operation
Object Detection Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-278019-S01379251932008012100000)
- «Connector Repairs»(ref-278019-S06982211772008012100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-278019-S21810776732008012100000)
- «Wiring Repairs»(ref-278019-S25320832652008012100000)
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Control Module References»(ref-278020-S09054666032008012100000) for object alarm module replacement, setup, and programming
- «Accessory Switch Replacement (without RPO SLT)»(ref-277996-S19954074462008012100000) or «Accessory Switch Replacement (with RPO SLT)»(ref-277996-S29115188042008012100000)
Schematic Reference
Object Detection Schematics
Connector End View Reference
Object Detection Connector End Views
Description and Operation
Object Detection Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-278019-S01379251932008012100000)
- «Connector Repairs»(ref-278019-S06982211772008012100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-278019-S21810776732008012100000)
- «Wiring Repairs»(ref-278019-S25320832652008012100000)
Circuit/System Verification
The red indicator displays continuously in the rear or front telltale assembly information center. If red indicator is not flashing, check if DTC is history.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Control Module References for object alarm module replacement, setup, and programming
Schematic Reference
Object Detection Schematics
Connector End View Reference
Object Detection Connector End Views
Electrical Information Reference
- «Circuit Testing»(ref-278019-S01379251932008012100000)
- «Connector Repairs»(ref-278019-S06982211772008012100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-278019-S21810776732008012100000)
- «Wiring Repairs»(ref-278019-S25320832652008012100000)
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Control Module References for object alarm module replacement, setup, and programming
Schematic Reference
Object Detection Schematics
Connector End View Reference
Object Detection Connector End Views
Electrical Information Reference
- «Circuit Testing»(ref-278019-S01379251932008012100000)
- «Connector Repairs»(ref-278019-S06982211772008012100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-278019-S21810776732008012100000)
- «Wiring Repairs»(ref-278019-S25320832652008012100000)
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Control Module References for the BCM and object alarm module replacement, setup, and programming
B1E3A 03
The object alarm module has detected the object alarm sensor supplied voltage circuit is below 7.2 volts.
B1E3A 07
The object alarm module has detected the object alarm sensor supplied voltage circuit is above 9.2 volts.
Schematic Reference
Object Detection Schematics
Connector End View Reference
Object Detection Connector End Views
Description and Operation
Object Detection Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-278019-S01379251932008012100000)
- «Connector Repairs»(ref-278019-S06982211772008012100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-278019-S21810776732008012100000)
- «Wiring Repairs»(ref-278019-S25320832652008012100000)
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Control Module References»(ref-278020-S09054666032008012100000) for object alarm module replacement, setup, and programming
- «Rear Object Sensor Replacement»(ref-278044-S04626148972008012100000)
Symptoms - Object Detection
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Object Detection Description and Operation . |
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Schematic Reference
Object Detection Schematics
Connector End View Reference
Object Detection Connector End Views
Description and Operation
Object Detection Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-278019-S01379251932008012100000)
- «Connector Repairs»(ref-278019-S06982211772008012100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-278019-S21810776732008012100000)
- «Wiring Repairs»(ref-278019-S25320832652008012100000)
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Control Module References for object alarm module replacement, setup, and programming
Scheme 11
| Callout | Component Name |
|---|---|
| Preliminary Procedure: Remove the front passenger bucket seat. Refer to Front Seat Replacement - Bucket . | |
| 1 | Rear Object Alarm Module Nut (Qty: 3) NOTE: Refer to Fastener Notice . Tighten: 9 N.m (80 lb in) |
| 2 | Rear Object Alarm Module Assembly Procedure Position carpet in order to access module. Disconnect electrical connector. |
| NOTE |
|---|
| Refer to Fastener Notice . |
Object Alarm Module Replacement
SERVICE PARK ASSIST
The driver information center (DIC) displays SERVICE PARK ASSIST when the object alarm module detects a malfunction in the object detection system and sends a request to the DIC for display of the message. The DIC also displays SERVICE PARK ASSIST when there is a loss of communication with the object alarm module.
PARK ASSIST OFF
The PARK ASSIST OFF message is displayed in the DIC when the object alarm system is disabled due to conditions that disable or inhibit the system. The red LED in the rear display, as well as, the telltale in the switch will be lit, notifying the driver the PARK ASSIST system is disabled. The object alarm module requests the DIC via the serial data circuit to display PARK ASSIST OFF when it detects that one of the following conditions is true
- Object alarm system disabled through DIC vehicle customization feature. Refer to the Owners Manual for more information.
- Automatic Object induced disable feature such as towing a trailer, bicycle rack, hitch receiver still attached to the vehicle.
- The park brake is not fully released.
- An object is hanging out of the endgate.
- The system receives vibrations from a large nearby vehicle or from a heavy equipment such as a jackhammer.
In the case of towing a trailer, the PARK ASSIST OFF message will continue to be displayed until the trailer hitch receiver is removed and the vehicle is driven forward above 24 km/h (15 mph).
