Scheme 40
Scheme 40: Cigar Lighter/Power Outlet Schematics
Scheme 41
Scheme 41: Power Outlet Component Views
| Callout | Component Name |
|---|
| 1 | Driver Information (DIC) Switch |
| 2 | Instrument Panel Cluster (IPC) |
| 3 | Radio |
| 4 | Ambient Light/Sunload Sensor Assembly (CJ2) / Ambient Light Sensor (C67/C42) |
| 5 | HVAC Control Module |
| 6 | Inflatable Restraint I/P Module Disable Switch (C99) |
| 7 | Power Take-Off (PTO) Switch |
| 8 | Auxiliary Power Outlet - Front 2 |
| 9 | I/P Multifunction Switch Assembly |
| 10 | Auxiliary Power Outlet - Front 1 |
| 11 | Transfer Case Shift Control Switch (NQF/NQH) |
| 12 | Trailer Brake Control Panel Switch (JL1) |
| 13 | Headlamp and Panel Dimmer Switch |
Scheme 42
| Callout | Component Name |
|---|
| 1 | Instrument Panel Cluster (IPC) |
| 2 | Inflatable Restraint Steering Wheel Module |
| 3 | Shift Control Lever |
| 4 | Ambient Light/Sunload Sensor Assembly (CJ2)/Ambient Light Sensor (C67/C42) |
| 5 | Speaker - Center (UQA +Y91) |
| 6 | Radio |
| 7 | Inflatable Restraint I/P Module |
| 8 | I/P Compartment Lamp |
| 9 | HVAC Control Module |
| 10 | Auxiliary Power Outlet - Front 2 |
| 11 | I/P Multifunction Switch Assembly |
| 12 | Auxiliary Power Outlet - Front 1 |
| 13 | Driver Information Center (DIC) Switch |
| 14 | Steering Wheel Control Switch Assembly - Right (UK3) |
| 15 | Steering Wheel Control Switch Assembly - Left (K34/KA9) |
| 16 | Trailer Brake Control Panel Switch (JL1) |
| 17 | Headlamp and Panel Dimmer Switch |
| 18 | Dimmer Control |
| 19 | Transfer Case Shift Control Switch (NQF/NQH) |
| 20 | Turn Signal Multifunction Switch |
Scheme 43
| Callout | Component Name |
|---|
| 1 | Auxilary Power Outlet - Center Seat (AZ3) |
Scheme 44
| Callout | Component Name |
|---|
| 1 | Rear Seat Audio (RSA) Controller (UK6) |
| 2 | Auxiliary Power Outlet - Console (D07) |
| 3 | Audio Amplifier (UQA) |
| 4 | Auxiliary Power Outlet - Bin (D07) |
| 5 | Noise Compensation Microphone (Y91) |
| 6 | Audio/Video Adapter (U42) |
Scheme 45
Scheme 45: Auxiliary Power Outlet - Bin (D07)
| Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series, Flexlock (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet - Bin (D07) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.8 RD/WH | 1040 | Battery Positive Voltage |
| B | | | Not Used |
| C | 0.8 BK | 1050 | Ground |
Auxiliary Power Outlet - Bin (D07) Connector Terminal Identification
