Power Outlets: Other Chevrolet Silverado 2500 HD

Body Electrical 1 illustration ~110 words

Auxiliary Power Outlet - Center Seat (AZ3)

Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series, Flexlock (BK)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Auxiliary Power Outlet - Center Seat (AZ3) Connector Parts Information

PinWire ColorCircuit No.Function
A0.8 RD/WH6040Battery Positive Voltage
BNot Used
C0.8 BK1250Ground

Auxiliary Power Outlet - Center Seat (AZ3) Connector Terminal Identification

Auxiliary Power Outlet - Console (D07)

Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series, Flexlock (BK)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Auxiliary Power Outlet - Console (D07) Connector Parts Information

PinWire ColorCircuit No.Function
A0.8 RD/WH1040Battery Positive Voltage
BNot Used
C0.8 BK1050Ground

Auxiliary Power Outlet - Console (D07) Connector Terminal Identification

Scheme 46

Scheme 46: Auxiliary Power Outlet - Front 1
Scheme 46: Auxiliary Power Outlet - Front 1
Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Auxiliary Power Outlet - Front 1 Connector Parts Information

PinWire ColorCircuit No.Function
A0.8 RD/WH640Battery Positive Voltage
BNot Used
C0.8 BK1050Ground

Auxiliary Power Outlet - Front 1 Connector Terminal Identification

Auxiliary Power Outlet - Front 2

Connector Part Information OEM: 12176446 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series, Flexlock (BK)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Auxiliary Power Outlet - Front 2 Connector Parts Information

PinWire ColorCircuit No.Function
A0.8 RD/WH1040Battery Positive Voltage
BNot Used
C0.8 BK1050Ground

Auxiliary Power Outlet - Front 2 Connector Terminal Identification

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .
