Adjustable Pedal System: Specifications Chevrolet Silverado 2500 HD

Accessories Control Systems 7 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Accelerator Actuator Screws2.5 N.m22 lb in
Accelerator Pedal Bracket Nuts9 N.m80 lb in
Brake Pedal Pushrod Retaining Clip Bolt10 N.m89 lb in
Electronic Adjustable Pedal (EAP) Bracket Nuts25 N.m18 lb ft
Electronic Adjustable Pedal (EAP) Bracket Bolt25 N.m18 lb ft
Master Cylinder Nuts33 N.m24 lb ft
Transmission Range Selector Cable Support Bolt10 N.m89 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Adjustable Pedal Schematics

Scheme 2

Scheme 2

Scheme 3

Scheme 3: Adjustable Pedal Component Views
CalloutComponent Name
1Electronic Adjustable Pedal Assembly (JF4)
2Stop Lamp Switch
3Accelerator Pedal Position (APP) Sensor

Scheme 4

Scheme 4
CalloutComponent Name
1Driver Information (DIC) Switch
2Instrument Panel Cluster (IPC)
3Radio
4Ambient Light/Sunload Sensor Assembly (CJ2) / Ambient Light Sensor (C67/C42)
5HVAC Control Module
6Inflatable Restraint I/P Module Disable Switch (C99)
7Power Take-Off (PTO) Switch
8Auxiliary Power Outlet - Front 2
9I/P Multifunction Switch Assembly
10Auxiliary Power Outlet - Front 1
11Transfer Case Shift Control Switch (NQF/NQH)
12Trailer Brake Control Panel Switch (JL1)
13Headlamp and Panel Dimmer Switch

Scheme 5

Scheme 5
CalloutComponent Name
1Instrument Panel Cluster (IPC)
2Inflatable Restraint Steering Wheel Module
3Shift Control Lever
4Ambient Light/Sunload Sensor Assembly (CJ2)/Ambient Light Sensor (C67/C42)
5Speaker - Center (UQA +Y91)
6Radio
7Inflatable Restraint I/P Module
8I/P Compartment Lamp
9HVAC Control Module
10Auxiliary Power Outlet - Front 2
11I/P Multifunction Switch Assembly
12Auxiliary Power Outlet - Front 1
13Driver Information Center (DIC) Switch
14Steering Wheel Control Switch Assembly - Right (UK3)
15Steering Wheel Control Switch Assembly - Left (K34/KA9)
16Trailer Brake Control Panel Switch (JL1)
17Headlamp and Panel Dimmer Switch
18Dimmer Control
19Transfer Case Shift Control Switch (NQF/NQH)
20Turn Signal Multifunction Switch

Scheme 6

Scheme 6: Electronic Adjustable Pedal Assembly
Connector Part Information OEM: 15477860 Service: See Catalog Description: 6-Way F BFC 180 Series (BK)
Terminal Part Information Pins: 1-3 Terminal/Tray: 173630-7/7 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-33 (YE) Pins: 4-5 Terminal/Tray: 173630-7/7 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-33 (YE)

Electronic Adjustable Pedal Assembly Connector Parts Information

PinWire ColorCircuit No.Function
10.5 TN62075-Volt Reference (AN3)
20.5 PK5289Adjustable Pedal Sensor Signal (AN3)
30.5 GY6206Low Reference (AN3)
41 YE5129Adjustable Pedals Relay Rearward Control
51 PU5130Adjustable Pedals Relay Forward Control
6Not Used

Electronic Adjustable Pedal Assembly Connector Terminal Identification

Scheme 7

Scheme 7: I/P Multifunction Switch Assembly
Connector Part Information OEM: 13551678 Service: See Catalog Description: 12-Way F Receptacle 0.64 Series (BK)
Terminal Part Information Pins: 1-8, 10-12 Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU)

I/P Multifunction Switch Assembly Connector Parts Information

PinWire ColorCircuit No.Function
10.35 L-BU1788Traction Control Switch Signal (JL4)
20.35 GY2555Rear Park Assist Disable Signal (UD7)
30.35 BK1850Ground
40.35 YE6817LED Backlight Dimming Control
50.35 BN5852Rear Park Assist LED Disable Signal (UD7)
60.35 PU/WH6816Indicator Dimming Control (UD7/XA7)
70.35 L-GN6096Washer Fluid Heated Control Switch Signal (AX7)
80.35 D-BU/WH5970Washer Fluid Heated Control Switch LED Supply Voltage (XA7)
9Not Used
100.5 OG/BK5285Adjustable Pedals Relay Rearward Control (JF4)
110.5 YE/BK581312-Volt Supply (JF4)
120.5 PU5286Adjustable Pedals Relay Forward Control (JF4)

I/P Multifunction Switch Assembly Connector Terminal Identification
