Wiring diagram: Computer data lines — Computer data lines circuit, except hybrid Chevrolet Silverado 1500
All systems
- Air conditioning 12
- Anti-lock brakes 17
- Anti-theft 3
- Body computer
- Body control modules
- Computer data lines 6
- Cooling fan 3
- Cooling fan 4.3l vin x
- Cooling fan 4.8l vin a
- Cooling fan 4.8l vin c
- Cooling fan 5.3l vin 0
- Cooling fan 5.3l vin 3
- Cooling fan 5.3l vin 7
- Cooling fan 5.3l vin j
- Cooling fan 5.3l vin m
- Cooling fan 6.0l vin 5 2
- Cooling fan 6.0l vin j 2
- Cooling fan 6.0l vin y
- Cooling fan 6.2l vin 2
- Cruise control 4.3l 3
- Cruise control 4.3l vin x
- Cruise control 4.8l 3
- Cruise control 4.8l vin a
- Cruise control 4.8l vin c 2
- Cruise control 4.8l vin v
- Cruise control 5.3l 3
- Cruise control 5.3l vin 0 3
- Cruise control 5.3l vin 3 2
- Cruise control 5.3l vin 7
- Cruise control 5.3l vin b
- Cruise control 5.3l vin j 3
- Cruise control 5.3l vin m 2
- Cruise control 5.3l vin t
- Cruise control 5.3l vin z
- Cruise control 6.0l vin 5
- Cruise control 6.0l vin j
- Cruise control 6.0l vin n
- Cruise control 6.0l vin u
- Cruise control 6.0l vin y 2
- Cruise control 6.2l vin 2 2
- Defoggers 11
- Electronic power steering 4
- Electronic suspension
- Engine performance 4.3l 2
- Engine performance 4.3l vin x
- Engine performance 4.8l 12
- Engine performance 4.8l vin a
- Engine performance 4.8l vin c
- Engine performance 4.8l vin v 2
- Engine performance 5.3l 12
- Engine performance 5.3l vin 0
- Engine performance 5.3l vin 3
- Engine performance 5.3l vin 7
- Engine performance 5.3l vin b
- Engine performance 5.3l vin j
- Engine performance 5.3l vin m
- Engine performance 5.3l vin t 3
- Engine performance 5.3l vin z 2
- Engine performance 6.0l vin 5 2
- Engine performance 6.0l vin j 2
- Engine performance 6.0l vin n 2
- Engine performance 6.0l vin u
- Engine performance 6.0l vin y
- Engine performance 6.2l vin 2
- Exterior lights 5
- Ground distribution 3
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 8
- Memory systems 5
- Navigation 15
- Power distribution
- Power distribution 4.3l vin x 2
- Power distribution 4.8l vin c
- Power distribution 4.8l vin v 2
- Power distribution 5.3l vin 0
- Power distribution 5.3l vin 3
- Power distribution 5.3l vin b
- Power distribution 5.3l vin j
- Power distribution 5.3l vin m
- Power distribution 5.3l vin t 3
- Power distribution 5.3l vin z 2
- Power distribution 6.0l vin n 2
- Power distribution 6.0l vin u
- Power distribution 6.0l vin y
- Power door locks 9
- Power mirrors 9
- Power seats 20
- Power top/sunroof
- Power windows 9
- Radio 23
- Shift interlock
- Shift interlocks
- Starting/charging 8
- Starting/charging 4.3l vin x 2
- Starting/charging 4.8l vin a 2
- Starting/charging 4.8l vin c 2
- Starting/charging 4.8l vin v 2
- Starting/charging 5.3l vin 0 2
- Starting/charging 5.3l vin 3 2
- Starting/charging 5.3l vin 7 2
- Starting/charging 5.3l vin j 2
- Starting/charging 5.3l vin m 2
- Starting/charging 5.3l vin t 2
- Starting/charging 5.3l vin z 2
- Starting/charging 6.0l vin n 2
- Starting/charging 6.0l vin y 2
- Starting/charging 6.2l vin 2 2
- Supplemental restraints 2
- Transmission 6
- Transmission 4.3l 6
- Transmission 4.3l vin x 5
- Transmission 4.8l 5
- Transmission 4.8l vin a 3
- Transmission 4.8l vin c 4
- Transmission 4.8l vin v 2
- Transmission 5.3l 5
- Transmission 5.3l vin 0 5
- Transmission 5.3l vin 3 5
- Transmission 5.3l vin 7 3
- Transmission 5.3l vin b
- Transmission 5.3l vin j 4
- Transmission 5.3l vin m 4
- Transmission 5.3l vin t 3
- Transmission 5.3l vin z 2
- Transmission 6.0l vin j 3
- Transmission 6.0l vin n 2
- Transmission 6.0l vin u
- Transmission 6.0l vin y 4
- Transmission 6.2l vin 2 3
- Warning systems 10
- Wiper/washer 5
Computer data lines circuit, except hybrid (1 of 2) Chevrolet Silverado 1500
Components on the diagram
Computer data lines circuit, except hybrid (1 of 3) Chevrolet Silverado 1500
Components on the diagram
Computer data lines circuit, except hybrid (2 of 2) Chevrolet Silverado 1500
Components on the diagram
Computer data lines circuit, except hybrid (2 of 3) Chevrolet Silverado 1500
Components on the diagram
Computer data lines circuit, except hybrid (3 of 3) Chevrolet Silverado 1500
